MDG ICE FOG Q User Manual

Low fog generator
Hide thumbs
Table of Contents

Advertisement

Quick Links

ICE FOG Q
TM
Low Fog Generator
U
G
SER
UIDE
Revision A/d, May 2017, © MDG Fog Generators Ltd
Les Générateurs de Brouillard MDG Ltée / MDG Fog Generators Ltd
10301 avenue Pelletier, Montréal, Québec, Canada H1H 3R2
Tel. 514-272-6040 / 800-663-3020 - Fax 514-722-3229
www.mdgfog.com
e-mail : info@mdgfog.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICE FOG Q and is the answer not in the manual?

Questions and answers

Related Manuals for MDG ICE FOG Q

Summary of Contents for MDG ICE FOG Q

  • Page 1 Low Fog Generator UIDE Revision A/d, May 2017, © MDG Fog Generators Ltd Les Générateurs de Brouillard MDG Ltée / MDG Fog Generators Ltd 10301 avenue Pelletier, Montréal, Québec, Canada H1H 3R2 Tel. 514-272-6040 / 800-663-3020 - Fax 514-722-3229 www.mdgfog.com...
  • Page 2 ICE FOG Intentionally left blank User Guide, Revision A/d, May 2017 2 / 16...
  • Page 3 ICE FOG INTRODUCTION MDG is a company globally recognized as the leader of the fog production industry. We design and manufacture the most reliable fog/haze generators since 1979 and, we continue to impress the entertainment and industrial market with unmatched innovations.

  • Page 4: Basic Description

    At the heart of the MDG Generators is an electronic assembly that keeps the heating module(s) at a very stable temperature, which integrates three types of fail-safe systems.
  • Page 5 ICE FOG Detachable standard remote control See next page Fog Output adjustment: Pressure regulator & Gauge Max. Operating pressure 4.1 bar (60 psi) Pressure Switch: Upward position will pressurize the Fluid Reservoir. Downward position will depressurize allowing to refill the Fluid reservoir. Main Power switch Operating Pressure:...
  • Page 6 Power switch with the Red LED Standard remote control MT35A-n Standard Accessories Fluid input: 2,5 Litres reservoir Use only MDG Low Fog Fluid Output Fog Hose: 2.5 m (8’) long / 23 cm (9”) diameter Different lengths available Low Fog Front...

  • Page 7: Optional Accessories

    ICE FOG Optional Accessories IF35-RCT DMX-M35AX Optional Remote Control Timer Optional 2 Channel DMX Interface Refrigerated Low pressure Liquid Carbone Dioxide (L-CO ) Container (Dewar 180 Litres 230 Litres 230 Litres 160 Litres User Guide, Revision A/d, May 2017 7 / 16...
  • Page 8 ICE FOG SETTING UP WARNING:  When not in use ALWAYS switch off the power switch located on the back panel, or unplug the generator.  Never install above people.  These Fog Generators must be installed in an upright position on a stable and level surface.
  • Page 9 DEPRESSURIZE THE FLUID RESERVOIR BY TURNING OFF THE PRESSURE SWITCH LOCATED ON THE BACK PANEL OF THE GENERATOR To fill the fluid reservoir, unscrew the brass closure and pour the MDG Low Fog Fluid until it reaches the inside bottom of the opening.

  • Page 10: Operating Instructions

    ICE FOG OPERATING INSTRUCTIONS The MDG Low Fog Generators are quite easy to operate and require no preventive maintenance. They are supplied with a removable remote control. A DMX Interface can be purchased as an option. When the MAIN POWER 230 or 208 VAC and the MAIN POWER SWITCH are applied, the generator is placed in stand-by mode.

  • Page 11: Shutdown Procedure

    ICE FOG SHUT DOWN PROCEDURE A generator must never be shut down while making Fog. To power off a generator the following sequence must be observed:  Always turn off the fog emission,  Wait for the purge cycle to complete. ...

  • Page 12: Technical Data

    ICE FOG TECHNICAL DATA Model ICE FOG Q Fluid consumption 0.09 L (3 oz) (per minute at full output) Liquid CO type Low pressure refrigerated Liquid CO consumption 3 L (6.8 lb) at 1500 kPa (225 psi) (per minute) Reservoir capacity 2.5 L (0.66 US gallon)

  • Page 13: Technical Dimensions

    ICE FOG TECHNICAL DIMENSIONS User Guide, Revision A/d, May 2017 13 / 16...

  • Page 14: Warranty

    MDG or one of is authorized service center, or if it is used under conditions for which it has not been designed, or if a none MDG Fog Fluid has been used. MDG Fog Generators Ltd is not responsible for any damages resulting from a faulty installation or from abusive use of the product.

  • Page 15: Declaration Of Conformity

    ICE FOG DECLARATION OF CONFORMITY User Guide, Revision A/d, May 2017 15 / 16...
  • Page 16 ICE FOG NOTE User Guide, Revision A/d, May 2017 16 / 16...
