SpiroTiger STGO Quick User Manual

User's Quick Guide
GO
ST
EN
1. Starting
Assembly
Place the pieces, as shown below, on the table.
1. Place the valve piston
and secure it into place using the screw fastening
(small opening).
2. Place the V-tube into the handheld device
2
3. Place the mouth tube
it using the second screw fastening
4. Place the respiration bag
V-tube and the mouthpiece
2
the mouth tube .
5
Turning on
Press the Enter key for at least two seconds.
Turning off
Press the Enter key for at least three seconds. If not
used the device automatically shuts off after five minutes.
Valve piston
Screw fastening
3
with small opening
Individual
7
respiration bag
This document does not replace any other provided measures necessary for the operation/usage of this device. Read before
using the SpiroTiger
www.idiag.ch - Application, Downloads, SpiroTiger Sport, Handbücher
into the V-Tube as shown
1 2
.
4
into the V-tube and fasten
5 2
(large opening).
6
on the open end of the
7
on the opening end of
8
1 2
V-tube
Handheld device
device the detailed instructions of the user manual! The complete manual can be downloaded from:
®
2. Set-up
Entering training duration, respiration rate, and bag size
After the device has been turned on press the
desired symbol starts to blink.
3
WATCH for training duration
FREQUENCY for respiration rate
BAG for respiration bag size
Select with the
it using the Enter key
Setting ranges
• Training duration: 0 - 99 minutes
0 (zero) equals no fixed training duration.
• Respiration rate:
15 - 60 breaths per minute
0 (zero) respiration rate means no given breathing pace.
• Respiration bag size: 0,5 to 5,0 litre
Respiration bags are labelled with their size.
The respiration bag size has to be individually
determined for every user.
Screw fastening
6
with large opening
Mouthpiece
Mouth tube 5
4
Battery compartment
and keys the desired value and confirm
.
8
idiag AG, Mülistrasse 18
CH-8320 Fehraltorf
Tel. +41 (0)44 908 58 58
Fax +41 (0)44 908 58 59
info@idiag.ch
www.idiag.ch
