1. Check to make sure the fresh water tank drain valve, located on
roadside in the service center, is in the closed position.
2. Connect the hose labeled for potable water to the water source.
Install the provided pressure regulator on the fill valve. Arrow on
regulator must be pointed toward valve. On a hot day the hose
may expand and burst from water pressure within the water
hose.
3. Remove white plug in the end of the pressure regulator.
4. Connect the water hose to the pressure regulator inlet.
5. The fill valve should be in the Fresh Water Tank position.
6. Turn on the water at the water source. The water should be
audible as the fresh water tank fills.
When connecting the motorhome to fresh water, use a hose manufactured
and labeled for potable water to ensure that the hose will not flavor the water.
1. Install the provided pressure regulator on the fill valve. Arrow on
regulator must be pointed towards valve.
2. Remove white plug from the end of the pressure regulator.
3. Connect water hose to the city water inlet.
4. Valve handle should be in the local supply position.
5. Turn on water at water source.
6. The water pump can either be in the OFF position or in the ON
position. It will not affect the water pump to leave it on.
7. Open each faucet, one at a time, to rid any trapped air inside the
pipes.
CAUTION: Some water sources develop high water
pressure, particularly in mountainous regions. High water
pressure is anything over 55 psi (pounds per square inch).
Excessive water pressure may cause leaks in water lines
and/or damage the water heater.
WATER SYSTEMS
DIPLOMAT 2004
WATER TANK
- FRESH FILL
040460f
WATER CITY
HOOK-UP
040460f
6 • 247
