- Page 1 Central Office HP 9000 Series 800t Addendum to D Class Enterprise Servers System Installation Guide...
- Page 3 The information contained in this document is subject to change without notice. HEWLETT-PACKARD MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THE MATE- RIAL, INCLUDING, BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABIL- ITY AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
- Page 4 Printing History Printing History The Printing History below identifies the edition of this manual and any up- dates that are included. Periodically, update packages are distributed which contain replacement pages to be merged into the manual, including an updat- ed copy of this printing history page. Also, the update may contain write-in instructions.
- Page 5 Preface Preface The HP 9000 family of products embraces the D Class Enterprise Server line which includes Series 800t, a NEBS-compatible version. This document ex- plains how to install the seismic rack and DC power supply which provide NEBS compatibility for the system.
- Page 6 Preface...
- Page 7 Contents Addendum to D Class Enterprise Servers System Installation Guide Contents ..........1-2 Purpose of this Addendum .
- Page 8 Contents...
- Page 9 Addendum to D Class Enterprise Servers System Installation Guide...
-
Page 10: Contents
Addendum to D Class Enterprise Servers System Installation Guide Contents Contents • Purpose of this Addendum • Seismic Rack Kit for Series 800t • DC Power to a Series 800t... -
Page 11: Purpose Of This Addendum
Addendum to D Class Enterprise Servers System Installation Guide Purpose of this Addendum Purpose of this Addendum This addendum provides information and procedures for installation of a Hewlett-Packard 9000 Series 800t D Class Server in a Central Office. It provides information about differences between this computer and the Hewlett-Packard D Class Enterprise Server, and contains the following procedures not found in the D ClassEnterprise Servers System Installation Guide:... -
Page 12: Seismic Rack Kit
Seismic Rack Kit Seismic Rack Kit The HP 9000 Series 800t D Class Server can be fitted with a seismic rack mount kit for installation in a 19-inch open relay rack. This earthquake rack fulfills Bellcore requirements for Telecommunication equipment installed in a NEBS-compatible central office. -
Page 13: Site Hazard Considerations
Addendum to D Class Enterprise Servers System Installation Guide Seismic Rack Kit Table 1. Earthquake Rack-Mount Components Item Description Quantity Part Number Number Split Lock Washer, #12 2190-0631 Flat Washer, #12 3050-0103 Screw 10-32 x, 38” Torx Pan 2680-0281 Flat Washer, #10 3050-0226 Nut w/lock, 10-32 2740-0003... - Page 14 Addendum to D Class Enterprise Servers System Installation Guide Seismic Rack Kit 5.) Circuit Overloading - Please refer to the NOTE on page 16. 6.) Reliable Earthing - Please refer to the topic see Safety Grounding Procedures on page 16.
-
Page 15: Installation
Addendum to D Class Enterprise Servers System Installation Guide Installation Installation Install the seismic rack kit and the HP 9000 D Class Server into Series 800t an open relay rack using the following steps. References to item numbers in these steps pertain to the item numbers listed in Table 1. - Page 16 Addendum to D Class Enterprise Servers System Installation Guide Installation Figure 1. Seismic Rack Installation items 2, 3 in Figure 2 5 Attach the right and left main bracket panels ( ) to the ver- tical mounting rails of the relay rack, using hardware item 24, Table 1. The brack- et panel is oriented top to bottom as shown in Figure 2 on the next page.
- Page 17 Addendum to D Class Enterprise Servers System Installation Guide Installation Figure 2. Seismic Rack Installation...
- Page 18 Addendum to D Class Enterprise Servers System Installation Guide Installation 8 Using item 16 screws (only) attach the bezel mount brackets (items 5, 6 in Figure 3) to the vertical rails as shown. Attach the two clip-on receptacles (item 30) at the bottom of the brackets as shown.
- Page 19 Addendum to D Class Enterprise Servers System Installation Guide Installation 12 Attach cable retractor ( item 26, Figure 3) to right main bracket as shown. 13 Attach the slide assemblies to the main brackets using the top row of holes (above the base pan).
- Page 20 Addendum to D Class Enterprise Servers System Installation Guide Installation CAUTION: Two people are highly recommended for this next task. 16 With tray extended hoist computer into position, aligning base with locator pins in tray. Slide tray and computer into rack and secure at three places with thread- forming screws (hardware item 22) at rear of tray.
- Page 21 Addendum to D Class Enterprise Servers System Installation Guide Installation 20 Install the emblem insert and door removed from the standard bezel (ref. Step 3) onto the wide bezel (item 14) shown below. 21 Remove handles from the wide bezel and position it onto the bezel mounts at- tached to the rack.
-
Page 22: Dc Power Supply
Series 800t current (DC) power supply, rather than the alternating current (AC) power supply furnished with the standard HP 9000 D Class computer. This switching power supply is designed to work on DC by replacing the AC input module with a DC-to-DC converter module. - Page 23 Addendum to D Class Enterprise Servers System Installation Guide DC Power Supply CAUTION: The power wire assembly has been evaluated for use as internal wire only and therefore needs to be installed in a cabinet for the system to retain its safety regulatory markings.
-
Page 24: Safety Grounding Procedures
Addendum to D Class Enterprise Servers System Installation Guide DC Power Supply NOTE: To protect the equipment from overload or short circuits that may cause equipment damage or fire, the power supply is fused internally. For added safety and integrity in the Central Office, the circuit which connects to power supply should be protected with a 30 Amp over-current fuse. -
Page 25: Specifications
Addendum to D Class Enterprise Servers System Installation Guide DC Power Supply Specifications Chuck...fill in the correct numbers please Table 3. DC Power Specifications Specification Data Input -48V, 20A max under full load -60V Shutdown Thresholds -72V (input over-voltage) -40V (input under-voltage) Power 650W Outputs (* = remote sense provided) - Page 26 Addendum to D Class Enterprise Servers System Installation Guide DC Power Supply...
- Page 27 Regulatory/Safety Statements...
-
Page 28: Fcc Statement (Usa Only)
Regulatory/Safety Statements FCC Statement (USA Only) FCC Statement (USA Only) The Federal Communications Commission (in 47 CFR 15.105) has specified that the following notice be brought to the attention of the users of this product. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 29: International
Regulatory/Safety Statements International International VCCI Class A Statement (Japan Only) Spécification ATI Classe A (France seulement) DECLARATION D'INSTALLATION ET DE MISE EN EXPLOITATION d'un matériel de traitement de l'information (ATI), classé A en fonction des niveaux de perturbations radioélectriques émis, définis dans la norme européenne EN 55022 concernant la Compatibilité... -
Page 30: Product Noise Declaration (Germany Only
Regulatory/Safety Statements International Le non respect de cette obligation peut être sanctionné par les peines prévues au code des Postes et Télécommunications et celles indiquées dans la loi du 31 mai 1993 susvisée. Arrêté du 27 Mars 1993, publié au J.O. du 28 Mars - ATI Product Noise Declaration (Germany Only) Acoustic Noise Emissions LpA: 57 dB... -
Page 31: Emc Regulatory
Regulatory/Safety Statements EMC Regulatory EMC Regulatory EMC Certification 〈 prEN 55024-2 〈 prEN 55024-3 〈 prEN 55024-4 〈 For USA, FCC Class A, part 15 〈 For Europe, CISPR-22 Level A 〈 For Japan, VCCI Class A EMC Labels 〈 CE Mark 〈... -
Page 32: Declaration Of Conformity
Product Name: PA-RISC Computer System Model Numbers: HP 9000, Models Dxyz (x, y, z is any number 0-9) and Z76xy (x, y is any number from 0 to 9) Product Options: conforms to the following Product Specifications:... - Page 33 Manual Part No. Z7634-96001 Printed in U.S.A. May 1998...
