Operation With A Pc - Oxford Instruments X-MET8000 Series Operator's Manual

X-MET8000 Series Operator's Manual
8

Operation With A PC

It is possible to operate the X-MET8000 series with a PC to do the following:
• Create a report for a series of results.
• Do a test measurement.
• Access the X-MET8000 Series User Manual.
Both supervisors and operators can operate the X-MET8000 series with a PC. Each uses their own
login code. There is not a separate login code for PC operation.
Operations with the PC use an Internet browser. While using an USB connection the standard URL to
connect to the X-MET8000 series is http://10.0.0.1/. Please contact the local Oxford Instruments
representative if it is necessary to change the URL. When connecting to the X-MET8000 series over
Wi-Fi the URL depends on the IP address assigned to the X-MET8000 series by the network.
Connect To A PC And Login
Follow these steps to login on the X-MET8000 series from a PC over WLAN.
1. Follow the steps to connect the X-MET8000 series to a Wi-Fi network. Please note that the PC must
be connected to the same WLAN network for the connection to work.
2. Open the Wi-Fi Settings screen on the X-MET8000 series and note the IP address found under
NETWORK INFORMATION.
86
