Page 1: Quick Installation Guide
DAU eA680 Quick Installation Guide HUAWEI TECHNOLOGIES CO., LTD. - Page 2 Install the DAU eA680（Mounting on a Utility Pole） Insert the hose clamp to the mounting frame Insert the SIM card Install the hose clamp on the utility (Optional) Install the angle pole and adjust the length of the adjusting component on the...
- Page 3 Install the DAU eA680（Mounting on the Wall） Insert the SIM card Marking the fixing points Installing the expansion bolt Fix the DAU on the wall-mounting Fix the wall-mounting frame. frame to the wall.
- Page 4 Huawei Technologies Co., Ltd. Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Website: http://www.huawei.com Email: support@huawei.com Customer Service Tel: 4008302118 Issue: 01 Part number: 31010WRH...
- Page 5 Install the Cables of DAU eA680 Installing the PGND Cable Install the POE Network Cable Make the POE Network Cable Cut the unnecessary rip- Strip the PET Strip the cable cord Insert the netw ork cable into the crystal connector.
-
Page 6: Safety Information
Huawei. The safety precautions in the document are related to only Huawei products. Huawei is not liable for any consequence that results from the violation of universal regulations for safety operations and safety codes on design, production, and equipment use.
