Canopy
150/300 Mbps
Backhaul

User Guide

BH150/300-UG-en
Issue 1.1
April 2006

Advertisement

Table of Contents
loading

Related Manuals for Motorola Canopy 300 Mbps Backhaul

Summary of Contents for Motorola Canopy 300 Mbps Backhaul

  • Page 1: User Guide

    ™ Canopy 150/300 Mbps Backhaul User Guide BH150/300-UG-en Issue 1.1 April 2006...
  • Page 2 Page 17. Preventing Overexposure to RF Energy Motorola shall not be liable for technical or editorial errors or omissions contained herein. The contents of this User Guide are subject to change without notice. Trademarks, Product Names, and Service Names MOTOROLA, the stylized M Logo and all other trademarks indicated as such herein are trademarks ®...
  • Page 3 The system has basically been shown to comply with the limits for emitted spurious radiation for a Class B digital device pursuant to Part 15 of the FCC Rules in the USA as well as comparable regulations in other countries. These limits have been designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4 Examples of Regulatory Limits Power/Radiated Power/Region Setting USA / Canada / Taiwan / Brazil Equipment can be operated in any mode, best results will be obtained using Region 1 settings Under UK Regulations, operation of this product is only allowed with a License Key for Region 4 (1W EIRP with Radar Detection) Eire Under Eire Regulations, operation of this product is only allowed...
  • Page 5 The company reserves the right to make alterations or amendments to the detail specification at its discretion. The publication of information in this document does not imply freedom from patent or other rights of Motorola or others. Issue 1.1 April 2006...

  • Page 6: Table Of Contents

    Contents ABOUT THIS USER GUIDE....................14 Interpreting Typeface and Other Conventions ..............14 Getting Additional Help ......................16 Sending Feedback ........................ 16 AVOIDING HAZARDS......................17 Preventing Overexposure to RF Energy ................17 2.1.1 Calculations for Separation Distances and Power Compliance Margins......17 Getting Started ........................
  • Page 7 Tools Required ........................36 Installation Support........................ 36 Legal Disclaimer........................36 Mounting the ODUs....................... 37 Connecting Up........................38 7.7.1 Preparing The 150/300 PIDU TO ODU Cable ..............38 7.7.2 Making the Connections at the ODU..................40 7.7.3 Making the 150/300 PIDU Connection At The ODU ............. 41 7.7.4 Routing the Cable........................
  • Page 8 8.3.16 Reboot..........................108 Recovery Mode........................109 Upgrade Software Image ....................110 Reset IP & Ethernet Configuration ..................113 Erase Configuration......................114 Reboot..........................116 Fault Finding........................117 10.1 Hardware..........................117 10.1.1 Power ..........................117 10.1.2 Ethernet..........................118 10.2 Radio ........................... 120 10.2.1 No Activity ...........................
  • Page 9 14.3 Software/Features ....................... 139 14.3.1 Status Page......................... 139 14.3.2 Configuration Pages......................139 14.3.3 Installation Pages ........................ 140 14.4 Deployment Considerations ....................142 14.5 Link Budget ......................... 142 14.6 Regulatory Issues........................ 142 14.6.1 Antenna Choice........................144 14.6.2 Cable Losses........................144 14.7 Antennas for USA / Canada....................
  • Page 10 18.1 Important Note on Modifications ..................167 18.2 National and Regional Regulatory Notices ................. 167 18.2.1 U.S. Federal Communication Commission (FCC) and Industry Canada (IC) Notification.. 167 18.2.2 European Union Notification ....................168 18.2.3 UK Notification........................168 18.3 Exposure ..........................168 18.4 Legal Notices........................
  • Page 11 Figure 19: 150/300 Mb BH Home Page Figure 20: Alarm Warning Triangle Figure 21: Status Page Figure 22: System Administration Login Page Figure 23: System Configuration Page Figure 24: LAN Configuration Page Figure 25: Configuration Reboot Page Figure 26: Configuration Reboot Page - Ethernet Auto Negotiation Disabled Figure 27: VLAN Configuration Fields Figure 28: LAN Configuration Page - Manual Ethernet Configuration Figure 29: Save and Restore Configuration Page...
  • Page 12 Figure 55: Example Spectrum Management Graphic Figure 56: Active Channel History Screen Figure 57: Spectrum Management Time Series Plot Figure 58: Spectrum Management Fixed Frequency Screen Figure 59: Spectrum Management Help Page Figure 60: Spectrum Management Help Page (Fixed Frequency) Figure 61: Spectrum Management (UK) Master Screen Figure 62: Spectrum Management (UK) Slave Screen Figure 63: Remote Management...
  • Page 13 Figure 91: Upper Grounding Configuration Figure 92: Lower Grounding Configuration Figure 93: Surge Arrestor ALPU-ORT Connection Illustration Figure 94: Canopy 150/300 Mb BH-C Outdoor Unit Figure 95: Canopy 150/300 Mb BH-C Status Page Figure 96: Canopy 150/300 Mb BH-C ‘System Configuration’ Page Figure 97: Canopy 150/300 Mb BH-C ‘Installation Wizard’...
  • Page 14 List of Tables Table 1: Font types Table 2: Admonition types Table 3: Exposure separation distances Table 4: Power Compliance Margins Table 5: 300 Mb BH - Aggregate Ethernet throughput rate v maximum link loss Table 6: Audio indications from the ODU Table 7: 150/300 Mbps Backhaul Factory Configuration Values Table 8: Spectrum Management change state key Table 9: Spectrum Management Time Series Key...

  • Page 15: About This User Guide

    ABOUT THIS USER GUIDE This guide covers the installation, commissioning, operation and fault finding of the Canopy 150/300 Mbps Backhaul. Interpreting Typeface and Other Conventions This document employs distinctive font to indicate the type of information, as described in Table 1. Table 1: Font types Font Type of Information...

  • Page 16: Table 2: Admonition Types

    Table 2: Admonition types Admonition General Message Label NOTE: informative content that may ◦ defy common or cursory logic. ◦ describe a peculiarity of the Canopy implementation. ◦ add a conditional caveat. ◦ provide a reference. ◦ explain the reason for a preceding statement or provide background for what immediately follows.

  • Page 17: Getting Additional Help

    ® b. in the Adobe Reader search capability for keywords that apply. 2) Visit the Canopy systems website at http://www.motorola.com/canopy. 3) Ask your Canopy products supplier to help. 4) Gather information such as a. the IP addresses and MAC addresses of any affected Canopy modules.

  • Page 18: Avoiding Hazards

    AVOIDING HAZARDS Preventing Overexposure to RF Energy Caution! To protect from overexposure to RF energy, install Canopy radios so as to provide and maintain the minimum separation distances from all persons shown in Table When the system is operational, avoid standing directly in front of the antenna. Strong RF fields are present when the transmitter is on.

  • Page 19: Table 4: Power Compliance Margins

    2.1.1.1 Calculated Distances and Power Compliance Margins Table 4 shows calculated minimum separation distances d, recommended distances and resulting power compliance margins for each frequency band and antenna combination. Table 4: Power Compliance Margins Variable Recom- Power Frequency Antenna mended Compliance Band Distance...

  • Page 20: Getting Started

    CAUTION SAFETY will be compromised if external quality cables are not used for connections that will be exposed to the weather. CAUTION Safety will be compromised if a different power supply is used than the one supplied by Motorola as part of the system. Issue 1.1 April 2006 Page 19...

  • Page 21: Product Description

    Product Description This User Manual is specifically written for the Canopy 150/300 Mbps Backhaul platform and the 58200 software load. The Canopy 150/300 Mbps Backhaul is a Point-to-Point wireless Ethernet bridge operating at broadband data rates in the 5.8GHz license exempt band. The Canopy 150/300 Mbps Backhaul is aimed at enterprises that have a requirement to connect together the Local Area Network (LAN) of two or more buildings.
  • Page 22 Each end of the link consists of: • An integrated outdoor transceiver unit containing all the radio and networking electronics hereafter referred to as the Outdoor Unit (ODU). • An indoor connection box containing a mains power supply, status indicators and network connection port.

  • Page 23: The Outdoor Unit (Odu)

    3.2.1 The Outdoor Unit (ODU) The ODU (Figure 2) is a self-contained unit. It houses both radio and networking electronics. The Canopy 150/300 Mb BH ODU should only be deployed using the supplied Canopy 150/300 Mb BH PIDU. Figure 2: Canopy 150/300 Mb BH Integrated (ODU) 3.2.2 The Canopy 150/300 PIDU The 150/300 PIDU is used to generate the ODU supply voltage from the mains supply and...

  • Page 24: Figure 4: Canopy 150/300 Pidu - Recovery Switch Location

    The power indicator is illuminated when the Canopy 150/300 Mb BH PIDU is receiving mains power. The Ethernet indicator normally illuminates when the Ethernet link is working; Flashing when there is Ethernet activity; the fact that it lights also indicates that the ODU is powered. At power up the LED will flash 10 times to indicate that a correct start up sequence has occurred.

  • Page 25: Figure 5: Canopy 150/300 Pidu - Power Input

    Figure 5: Canopy 150/300 PIDU - Power Input Issue 1.1 April 2006 Page 24...

  • Page 26: Redundancy And Alternate Powering Configurations

    3.2.3 Redundancy and Alternate Powering Configurations Note: The use of DC supplies of less than 55v will reduce the usable distance between Canopy 150/300 PIDU and Canopy 150/300 Mb BH ODU see Figure 6 . SPIDU to ODU Cable Length DC Supply Voltage (V) Figure 6: Canopy 150/300 PIDU to ODU Cable Length Graph WARNING The maximum distance from the ODU to the connected network equipment is...

  • Page 27: Remote Leds And Recovery Switch

    DC Out Power Ethernet AC Mains DC In Supply To Network To ODU Equipment Figure 8: 150/300 PIDU - External DC Supply and AC Supply 3.2.3.3 External DC Supply and Redundant AC Supply To guard against mains failure, DC supply failure of the Canopy 150/300 PIDU failure. DC Out Ethernet Power...

  • Page 28: Cables And Connectors

    Cables and Connectors The cable used to connect the 150/300 PIDU to the ODU can be any standard CAT5e type provided that it is suitable for outdoor deployment. Motorola recommends that cables to the specification below be used: NEC/CEC: CMR (ETL) C (ETL) 75C SUN RES OIL RES II Failure to use the recommended (or equivalent) standard of cable may invalidate the system’s safety certification.

  • Page 29: Mounting Brackets

    3.2.7 Mounting Brackets The Canopy 150/300 Mb BH is supplied with a mounting bracket suitable for mounting the ODU to a pole of 25mm (1”) to 75mm (3”) in diameter. For more details on mounting, see section 7 “ Installation ”. The bracket allows for adjustment in both azimuth and elevation. The bracket may be split allowing the pole mount section of the bracket to be mounted to the pole first.

  • Page 30: Product Architecture

    Product Architecture The Canopy 150/300 Mb BH consists of an identical pair of unit’s deployed one at each end of the link. The radio link operates on a single frequency channel in each direction using Time Division Duplex (TDD). One unit is deployed as a master and the other as a slave. The master unit takes responsibility for controlling the link in both directions.
  • Page 31 HTTP, SNMP, etc. The unit can be configured to use VLAN tags on the management interfaces. The Canopy 150/300 Mb BH is fully software upgradeable. New software images are first download from the Motorola website http://www.motorola.com/canopy to a convenient computer.

  • Page 32: General Considerations

    These standard features may require some additional equipment to be configured as part of the system installation to be fully effective. Motorola recommends the use of screened cable and a surge arrestor to protect connected equipment from nearby strikes.

  • Page 33: Electrical Requirements

    Transtector ALPU-OR Transtector ALPU-ORT Transtector ALPU-ORT Installed by Radio Installed by Grounding Stake Internal View Note: The 150/300 Mbps Backhaul is not designed to survive direct lightning strikes. For this reason the unit should not be installed as the highest point in a localized area, unless specific precautions are taken.

  • Page 34: Site Planning

    Site Planning Site Selection Criteria The following are guidelines for selecting the installation location of the Canopy 150/300 Mb BH ODU and 150/300 PIDU. 6.1.1 ODU Site Selection When selecting a site for the ODU the following should be taken into consideration: •...

  • Page 35: Equation 1: Path Loss

    Free Space Path Loss (dB) free space Excess Path Loss (dB) excess Fade Margin Required (dB) fade Seasonal Fading (dB) seasonal Equipment Capability (dB) capability Equation 1: Path Loss Issue 1.1 April 2006 Page 34...

  • Page 36: Aggregate Ethernet Throughput Rate V Maximum Link Loss

    Divide the above Aggregate Ethernet rates in half to compute 150 Mb BH rates. The full calculation is relatively complicated and thus Motorola have supplied a link estimator that calculates the radio propagation and reliability of NLoS links using the Canopy 150/300 Mbps Backhaul equipment.

  • Page 37: Installation

    A Frequently Asked Questions (FAQ) section can be found in section 14.8. Legal Disclaimer IN NO EVENT SHALL MOTOROLA BE LIABLE FOR ANY INJURY TO ANY PERSONS OR ANY DAMAGE CAUSED DURING THE INSTALLATION OF THE MOTOROLA Canopy 150/300 Mbps Backhaul PRODUCT.

  • Page 38: Mounting The Odus

    Mounting the ODU The ODU mounting bracket is designed to ease installation by fixing the bracket to a pole and then bringing the ODU into position using a single bolt fixing. The ODU should be mounted using the following steps ensuring that the cable entry is at the bottom. The ODU mounting bracket is design to work with poles with diameters in the range 50mm (2”) to 75mm (3”).

  • Page 39: Connecting Up

    Integral Safety loop - detail arrowed Figure 12: Integral Safety Loop The length of the safety lanyard must not exceed 1m (approx 3 ft) in length. The lanyard should be made from a material that does not degrade in an outdoor environment. The safety lanyard must be fixed to a separate fixing point that is not part of the direct mounting system for the ODU.

  • Page 40: Figure 13: Completed Odu Connector

    The cable should be assembled to the following instructions: Step 1: Assemble gland on cable as shown Step 2: Strip the outer insulation Step 3: Arrange conductors as shown in Step 4: Insert conductors and crimp Figure 14 and cut to length Figure 13: Completed ODU connector Both ends of the ODU cable are terminated in the same way.

  • Page 41: Making The Connections At The Odu

    Figure 14: RJ45 Pin Connection (T568B Color Coding) 7.7.2 Making the Connections at the ODU Looking at the back of the unit with the cable entry at the bottom. The Canopy 150/300 PIDU connection is the first hole on the right (Figure 15: 150/300 PIDU Connection) and is labelled PIDU.

  • Page 42: Making The 150/300 Pidu Connection At The Odu

    7.7.3 Making the 150/300 PIDU Connection At The ODU The following procedure describes how connection is made at the ODU. It is often easier to carry out this procedure on the ground or a suitable surface prior to mounting the ODU. Ensure no power is connected to the Canopy 150/300 PIDU or present on the cable before connecting the ODU.

  • Page 43: Routing The Cable

    Should it be necessary to disconnect the 150/300 PIDU to ODU cable at the ODU this can be achieved by removing the weather proofing gland and depressing the RJ45 locking tab with a small screwdriver as shown below: Figure 16: Disconnecting the ODU Warning: Ensure that power is removed from the system at the 150/300 PIDU to prevent damage to the ODU whilst making or breaking the connection.

  • Page 44: Making The Network Connection At The Canopy 150/300 Pidu

    connection between the 150/300 PIDU and ODU. Plugging the ODU into other equipment may damage the ODU and/or the other equipment. Step 1: Undo the retaining screw and hinge Step 2: Plug in the ODU to 150/300 PIDU back the cover. Cable ensuring that it snaps home Step 3: Replace the cover and secure with the retaining screw 7.7.8...

  • Page 45: Mounting The Canopy 150/300 Pidu

    7.7.9 Mounting The Canopy 150/300 PIDU This step is optional. Motorola recommends that you mount the 150/300 PIDU on a wall or other suitable mounting surface. This prevents the unit from being knocked or kicked and can help maintain link availability. Ensure that the reset switch can be accessed when mounting the unit.

  • Page 46: Figure 18: 150/300 Pidu Drip Loop Configuration

    To ODU Power Ethernet AC Mains Mount PIDU+ at a height that protects it from flooding or rising damp Drip Loop Optional Drain Hole Figure 18: 150/300 PIDU Drip Loop Configuration WARNING It is possible for moisture to enter the cable due to damage to the outer protective layer.

  • Page 47: Powering Up

    7.7.10 Powering Up The Canopy 150/300 Mb BH system is supplied as a pair of matched Master/Slave units. The Master unit can now be powered up and accessed using the default URL http://169.254.1.2 ; the Slave unit can be accessed using http://169.254.1.1 Prior to powering up the Canopy 150/300 Mb BH, a computer with web browsing capabilities should be configured with an IP address of 169.254.1.n and subnet mask of 255.255.0.0...

  • Page 48: Aligning The Odus

    7.7.11 Aligning the ODUs The following is a description of the steps taken to establish a radio link between the two units forming the bridge and align the units for the best signal strength. The Canopy 150/300 Mb BH uses audible tones during installation to assist the installer with alignment.
  • Page 49 The following behaviour should be noted: • When first started up and from time to time the Master unit will carry out a band scan to determine which channels are not in use. During this time, between 10 and 15 seconds, the Master unit will not transmit and as a consequence of this neither will the Slave unit.

  • Page 50: Web

    Web Page Reference The web user interface has three main sections. The home page presents to the operator a high level summary of the Canopy 150/300 Mb BH wireless link. The status page presents a more detailed set of system parameters describing the performance of the wireless link together with other key system performance metrics.

  • Page 51: Home Page Alarm Display

    Figure 19: 150/300 Mb BH Home Page Elapsed Time Indicator The elapsed time indicator attribute presents the total time in days, hours, minutes and seconds since the last system restart. The system can restart for several reasons, e.g. commanded reboot from the system reboot webpage, or a power cycle of the equipment.

  • Page 52: Figure 20: Alarm Warning Triangle

    Canopy 150/300 Mb BH can’t find a channel to operate Hardware Authentication Alarm If the Hardware Authentication Alarm is displayed on the front page please contact Motorola Customer support for further assistance. Ethernet Link Disable Warning This warning is displayed if the Ethernet link has been administratively disabled via the SNMP Interface.

  • Page 53: Systems Status Page

    Telecoms Channel B Status Indicates that there is a problem with the telecoms channel B. Possible problems are "No Signal (local)", "No Signal (Remote)", and "No Signal (Local and Remote)". Telecoms Interface A Loopback The telecoms loopback features are intended for installation testing only and should be set to 'None' for normal operation.

  • Page 54: Figure 21: Status

    5.8 GHz regulatory regime of the particular country. The region code is encoded in the product license key. If the operator wishes to change region code, a new license key must be obtained from Motorola or the local distributor / system integrator.
  • Page 55 Ethernet Speed and Duplex The negotiated speed and duplex setting of the Ethernet interface. The speed setting is specified in Mbps. Full Duplex data transmission means that data can be transmitted in both directions on a signal carrier at the same time. For example, on a local area network with a technology that has full duplex transmission;...

  • Page 56: Equation 2: Link Loss

    The data used to compute the histogram statistics can be downloaded in an ASCII comma separated variable (CSV) format via the download diagnostics page, see section 8.3.12. The link loss calculation presented below: − Where Link Loss (dB) Transmit power remote wireless unit (dBm) Received signal power at the local...
  • Page 57 of the wireless link not the maximum potential capacity of the link as displayed by link capacity. Transmit Modulation Mode The modulation mode currently being used on the transmit channel. Details on the modulation modes can be found in section 11.1 “System Specifications ”.

  • Page 58: System Administration

    System Administration Pages The following menu options are available for the system administrator and can be password protected Figure 22 shows the system administration login page. By default a system admin password is not set. Simply click the login button to access the system administration features.

  • Page 59: Figure 23: System Configuration

    The save and restore submenu allows the system administrator to backup and restore 150/300 Mbps Backhaul configuration. It is recommended after a unit has been successfully installed that a copy of the active configuration is taken and archived by the system administrator.
  • Page 60 Maximum Transmit Power This specifies the maximum transmit power in dBm of the system, it is country dependent and although the user can change this in 1dB steps, it will be limited to that country’s regulations Why Reduce Transmit Power? If the link losses are low and the link data rate and availability targets are being easily achieved, the transmitted power level may be reduced with a consequent benefit to other users of the band, e.g.

  • Page 61: Figure 24: Lan Configuration

    8.3.1.2 LAN Configuration Page The LAN configuration page (Figure 24) is used by the system administrator to configure the Canopy 150/300 Mb BH LAN interface. Figure 24: LAN Configuration Page IP Address Internet protocol (IP) address. This address is used by the family of Internet protocols to uniquely identify this unit on a network.

  • Page 62: Figure 25: Configuration Reboot

    connected equipment, its automatic configuration mechanisms will normally cause a duplex mismatch, and you will receive greatly reduced throughput! When Ethernet Auto Negotiation is Disabled the format of the LAN configuration page will change see Section 8.3.1.4 “ LAN Configuration Page – Manual Ethernet Configuration ”. Auto Neg Advertisement This controls the rates that the auto negotiation mechanism will advertise as available.

  • Page 63: Figure 26: Configuration Reboot Page - Ethernet Auto Negotiation Disabled

    Figure 26: Configuration Reboot Page - Ethernet Auto Negotiation Disabled This will be followed by a pop-up dialogue box asking to confirm the action. Note: At this point you will lose connection to the unit. If you have just changed the IP Address you now have to reconnect to the unit using the address just set.

  • Page 64: Figure 27: Vlan Configuration Fields

    8.3.1.3 LAN Configuration Page – Use VLAN For management Interfaces The layout of the LAN Configuration page changes if this attribute is enabled in order to allow the VLAN VID and VLAN Priority to be set, see Figure 27 . The VLAN settings are applied only after the unit is rebooted.

  • Page 65: Figure 28: Lan Configuration Page - Manual Ethernet Configuration

    8.3.1.4 LAN Configuration Page – Manual Ethernet Configuration Figure 28: LAN Configuration Page - Manual Ethernet Configuration Force Configuration This option allows the user to force the speed and duplex setting of the Ethernet interface. See warning above! Warning: Over the air throughput will be capped to the rate of the Ethernet interface at the receiving end of the link 8.3.1.5 Save and Restore The save and restore feature of Canopy 150/300 Mb BH allows the system administrator to...

  • Page 66: Figure 29: Save And Restore Configuration

    Figure 29: Save and Restore Configuration Page Figure 30: Save File Pop-up Issue 1.1 April 2006 Page 65...

  • Page 67: Figure 31: Example Configuration File

    The configuration file is encoded using an ASCII encoding scheme. An example is show in Figure 31. # Canopy 150/300 Mbps Backhaul Configuration file # MAC Address :- 00:04:56:80:00:0c # IP Address :- 169.254.1.2 # License Key :- DCBD-A7AA-6851-4679 # Software Version :- 58200-01-00 # Creation Date :- 01-Sep-05 20:03:23...

  • Page 68: Figure 33: Telecoms Interface

    After the unit has restarted the entire configuration from the configuration file will now be active. Note: The IP address of the unit may have also been changed the user can check the new IP address by reading the header of the configuration file Figure 31 . 8.3.1.6 Telecoms Configuration Page The Telecoms page is only available when the Telecoms Interface has been set to either E1 or T1 in the Installation Wizard.
  • Page 69 A "Wireless" loopback sends the telecoms data received across the wireless link back across the link on the same channel. The link may be checked using, for example a Bit Error Rate Tester. A typical E1 or T1 installation might include a "Copper" loopback on the local unit followed by a "Wireless"...

  • Page 70: Statistics Page

    8.3.2 Statistics Page The 150/300 Mbps Backhaul statistics page is designed to display some key statistics of the Ethernet Bridge and the underlying wireless performance. Figure 34: System Statistics Wireless Tx Packets This displays the total number of good packets the bridge has sent for transmission by the wireless interface.
  • Page 71 Packets To Internal Stack This displays the total number of good packets the bridge has transmitted to the internal stack (e.g. ARP requests, PING requests, HTTP requests). The number in (+nn) displays the number of packets transmitted since the last page refresh. Packets From Internal Stack .This displays the total number of good packets the bridge has received from the internal stack (e.g.
  • Page 72 Receive Modulation Mode Detail This supplies the user with information regarding the receive modulation mode in use. Possible values are: • Running at maximum receive mode • Running at user-configured Target Modulation Mode • Restricted because Installation is armed • Restricted because of byte errors on the wireless link •...

  • Page 73: Detailed Counters Page

    8.3.3 Detailed Counters Page Figure 35: Detailed Counters Page The detailed counters page is subdivided into two columns. Column one presents the detailed statistics for the Canopy 150/300 Mb Backhauls Ethernet interface. Column two relates to the wireless interface. The Counters have the following definitions: Tx &...
  • Page 74 Rx Broadcasts Total number of good broadcast packets. Rx Multicasts Total number of good multicast packets. Rx CRC and Align Total number of packets with CRC or frame alignment errors. Rx Undersize Total number of packets received that are less than 64 bytes and have a valid CRC.

  • Page 75: Install

    Statistics Page Refresh Period The statistics page refreshes automatically according to the setting entered here (in seconds). 8.3.4 Install Pages These pages are used during system installation. There follows a description of the install pages along with their use during the installation configuration process. The actual installation process is described in section 7.7.11 “Aligning the ODUs”.

  • Page 76: Table 7: 150/300 Mbps Backhaul Factory Configuration Values

    (EIRP) to less than 25 dBm you should obtain a new license key containing the correct region code from your local distributor or direct from Motorola. Alternatively in the short term, you should reduce the maximum transmit power by following the procedures in ‘...

  • Page 77: Figure 36: License Key Data Entry

    Figure 36: License Key Data Entry A license key is programmed into each unit during production and can be found written on the Configuration Data Summary Label which is attached to the Quick Install Guide. If subsequently the license key has been mislaid, replacement keys can be applied for online or via your distributor.

  • Page 78: Figure 38: Vlan Warning

    Subnet Mask A subnet allows the flow of network traffic between hosts to be segregated based on a network configuration. By organizing hosts into logical groups, subnetting can improve network security and performance. Gateway IP Address The IP address of a computer / router on the current network that acts as a gateway.

  • Page 79: Figure 39: Telecoms Data Entry

    Figure 39: Telecoms Data Entry Telecoms Channel Selection This controls the selection of the telecoms interface standard supported options or E1 and T1. Channel A Line Code The line code setting of the telecoms interface. This must match the setting of the device connected to this interface. Channel B Line Code The line code setting of the telecoms interface.

  • Page 80: Figure 40: Installation Wizard Wireless Configuration

    Figure 40: Installation Wizard Wireless Configuration Target MAC Address The MAC Address of the peer unit that will be at the other end of the wireless link. This is used by the system to ensure the unit establishes a wireless link to the correct peer.
  • Page 81 Target Range Installers that know the range between the two wireless units to within ± 1 km can use the target range mode. The main advantage of the target range mode is that it reduces the time taken by the units to range. To use the target range mode the installer MUST select Target Range as the ranging mode and enter the approximate range in km in the Target range data entry field at both ends of the link.

  • Page 82: Figure 41: Fixed Frequency Operation

    Figure 41: Fixed Frequency Operation Figure 42: WiMAX operation Once the installer is satisfied with the wireless configuration options then the “Submit Wireless Configuration” button or the “Next” link should be clicked. Installation Tones Where the use of audio installation tones is not required this control allows the installer to optionally disable the tone generator during the installation process.

  • Page 83: Figure 43: Installation Wizard Confirm Configuration

    Figure 43: Installation Wizard Confirm Configuration If all the settings are correct and appropriate click the “Confirm Configuration, Arm Installation and Reboot” button. The user will now be prompted to confirm the action (Figure 44). Figure 44: Reboot Confirmation Pop Up All the attributes are committed to non-volatile memory.

  • Page 84: Figure 45: Disarm Installation

    8.3.4.5 Disarm Step 5 of the installation wizard is the disarm phase. Figure 45: Disarm Installation Once section 7.7.11 “Aligning the ODUs” is complete pressing the “Disarm Installation Agent” button completes the installation process and the audible installation tone will be switched FP T off.

  • Page 85: Graphical Install

    Figure 46: Optional Post Disarm Configuration 1 After installation the system administrator may wish to modify the wireless unit’s descriptive configuration (link name and link location). In addition the system administrator may wish to change the spectrum management configuration of the wireless unit, or look at the analysis of the 5.8 GHz spectrum to see if the automatic channel selection is appropriate for the system administrator’s network.

  • Page 86: Software Upgrade

    . The software image is delivered by Motorola as a compressed zip file. Once the zip file has been downloaded the user should extract the Canopy 150/300 Mb BH Software image, identifiable by its ‘.dld’ file extension.

  • Page 87: Figure 49: Software Upgrade Image Check

    The software image will now be uploaded to the unit where it will be stored in SDRAM until it is committed to the unit’s non-volatile memory. This upload should only take a few seconds. Once complete the image is verified and validated to ensure that no errors occurred during transfer and that the image is valid to run on the current platform.

  • Page 88: Figure 50: Software Download Progress Indicator

    Figure 50: Software Download Progress Indicator Figure 51: Software Upgrade Complete When the software image has been written to non-volatile memory (Figure 51) will be displayed showing the status of the software upload. Reboot the unit by clicking the “Reboot Wireless Unit” button. You will be asked to confirm this action as shown in Figure 52.

  • Page 89: Spectrum Management

    Figure 52: Reboot Confirmation Pop Up This will reboot the unit, taking up to 120 seconds, during this time you will not be able to communicate with the unit. If you cannot communicate with the unit after 120 seconds this could indicate a problem with the memory update process.
  • Page 90 is not altered by the channel barring process. Measurements are still collected for all channels irrespective of the number of barred channels. 8.3.7.3 Measurement Analysis Spectrum Management uses statistical analysis to process the received peak and mean measurement. The statistical analysis is based on a fixed, one minute, measurement quantization period.

  • Page 91: Figure 53: Spectrum Management As Seen From The Master

    to keep identical copies of Spectrum Management configuration data in their non-volatile memories. It is therefore possible to swap master and slave roles on an active Point-to-Point link without modifying Spectrum Management configuration. Figure 53: Spectrum Management as seen from the Master Figure 54: Spectrum Management as seen from the Slave Issue 1.1 April 2006 Page 90...
  • Page 92 If the user believes that the performance of the Spectrum Management algorithm requires some modifications this should only be done after consulting your distributor or one of the Motorola field support engineers. Refresh Page Period The page refreshes automatically according to the setting entered here (in seconds).

  • Page 93: Figure 55: Example Spectrum Management Graphic

    Figure 55: Example Spectrum Management Graphic The X-axis shows a stylized view of the 9 or 10 selectable wireless channels. It is important to note that adjacent channels on the display have a 10 MHz overlap. The display separates the display of channels to help the clarity of the resultant display. The axis is labelled using the channel center frequencies in MHz.

  • Page 94: Table 8: Spectrum Management Change State Key

    The colored bar represents the following channel state: The channel is currently in use hosting the Point-to-Point Green Active wireless link Orange Interference The channel has interference above the interference threshold The channel has an interference level below the interference Blue Available threshold and is considered by the Spectrum Management...

  • Page 95: Spectrum Management (Fixed Frequency And Wimax)

    Figure 57: Spectrum Management Time Series Plot Figure 57 shows an example time series plot. A time series plot displays the previous 145 measurement quantization periods. If the Canopy 150/300 Mb BH unit has not been running for 145 quantization periods then only the number of measurement quantization periods that are available are displayed.

  • Page 96: Spectrum Management Online Help

    Figure 58: Spectrum Management Fixed Frequency Screen Channel barring is disabled in fixed frequency mode; it is not required as dynamic channel hopping is prohibited in this mode. The only controls available to the master are the Statistics Window and Interference Threshold attributes.

  • Page 97: Figure 59: Spectrum Management Help

    Figure 59: Spectrum Management Help Page Issue 1.1 April 2006 Page 96...

  • Page 98: Figure 60: Spectrum Management Help Page (Fixed Frequency)

    Figure 60: Spectrum Management Help Page (Fixed Frequency) Spectrum Management Control (UK) 8.3.9.1 It should be noted that close range installations in the UK that result in a receive power of greater that –48 dBm should have their transmit power turn down to minimize the risk of false radar detections.

  • Page 99: Figure 61: Spectrum Management (Uk) Master Screen

    The only controls available to the master is the Interference Threshold attribute. This has no effect on the operation of the wireless link and will only affect the generation of the channel spectrum graphics. A channel marked with a ‘no entry’ symbol with their associated statistics colored black are the RTT prohibited channels.

  • Page 100: Table 10: Spectrum Management (Uk) Change State Key

    Figure 62: Spectrum Management (UK) Slave Screen The colored bar represents the following channel state: The channel is currently in use hosting the Point-to-Point Green Active wireless link Orange Interference The channel has interference above the interference threshold The channel has an interference level below the interference Blue Available threshold and is considered by the Spectrum Management...

  • Page 101: Remote Management Page

    • RFC-2233 (High capacity counter) MIB • WiMAX MIB SNMP TRAPs supported: • Cold Start • Link Up • Link Down • DFS Channel Change • DFS Impulsive Interference Motorola MIB, Proprietary MIB definition Issue 1.1 April 2006 Page 100...
  • Page 102 For a copy of the Motorola proprietary MIB RFC please visit http://www.motorola.com/canopy 8.3.10.3 SNMP Configuration SNMP State The SNMP state attribute controls the creation of the SNMP features. Changing the SNMP state attribute requires a mandatory reboot of the unit. Only when the SNMP state is enabled at system start-up will the SNMP processor task be created.

  • Page 103: Diagnostics

    8.3.10.5 SNTP (Simple Network Time Protocol) The SNTP client allows the Canopy 150/300 Mb BH to obtain accurate date and time updates from a networked timeserver. The system time is used for SNMP and event logging. SNTP State When enabled, the Remote Management web page permits the following attributes to be set: SNTP IP Address The IP address of the networked SNTP server.

  • Page 104: Figure 64: Diagnostic Plotter

    • Histogram 2: 24 hours at a resolution of 1 minute • Histogram 3: 30 Days at a resolution of 1 hour For example when histogram 1 fills up and starts to overflow the first minute of overflow is analysed and the maximum, minimum and mean over that minute is computed and inserted into histogram 2.

  • Page 105: Diagnostics Download

    The diagnostic plotter itself uses a bespoke x-axis which compresses the timeline of the plot without sacrificing resolution. The Trace selection allows the user to control which traces are plotted. As with other management pages the page refresh period can be used to interactively monitor the wireless link.

  • Page 106: Change System Administration Password

    8.3.12.1 Download Diagnostics All diagnostics are extracted from the associated status and statistics webpage histograms. They are translated in a CSV file containing at most 5784 entries which equates to one hour’s worth of diagnostics. Each entry is a one second average of the number of samples the 150/300 Mbps Backhaul makes in a one second period.

  • Page 107: Properties

    Figure 67: Software License Key Data Entry The user must enter the license key and click the ‘Validate License Key’ button to check that the key is valid and program it to non-volatile memory. If a valid license key is detected then the user will be presented by a system reboot screen, The user will then be asked to confirm the reboot (Figure 69).

  • Page 108: Figure 70: Properties

    Figure 70: Properties WEB Properties: Disable Front Page Login Allow access to homepage and status page web pages without forcing a login as the system administrator. WEB Properties: Disable HTTP NO-CACHE META data Removes the HTTP NO-CACHE META clause from all dynamically created web pages. Auto Logout Timer Configures the time in minutes when the system administrator is automatically logged out if no webpage activity is detected.

  • Page 109: Reboot

    8.3.16 Reboot The reboot page allows the system administrator to perform commanded reboots of the wireless unit. The reboot page also allows the system administrator to view a list of past reboot reasons. The “Previous Reasons For Reset/Reboot” field has been implemented as a drop down selection box, where the latest reason for reboot is located at the top of the list.

  • Page 110: Recovery Mode

    Recovery Mode The Canopy 150/300 Mb BH has a special mode of operation that allows the user to recover a unit from configuration errors or software image corruption. Recovery mode is entered by depressing the Recovery Switch located on the underside of the Canopy 150/300 PIDU while applying mains power, as shown in section 3.2.2.

  • Page 111: Upgrade Software Image

    Figure 74: Recovery Options Page The recovery options available are: Upgrade Software Image This allows the user to reload a software image. This may be the original image if software corruption is suspected or a step back to an old image if an incorrect image has just been loaded.

  • Page 112: Figure 75: Software Download Progress Indicator

    During software download, progress is indicated by a pair of progress bars (Figure 76). Figure 75: Software Download Progress Indicator Page When the download is complete a page is displayed indicating the status of the software download (Figure 77). Figure 76: Software Download Complete Page After carefully checking that correct image has been downloaded the user should reboot the unit by pressing the “Reboot Wireless Unit”...

  • Page 113: Figure 77: Reboot Confirmation Pop Up

    Figure 77: Reboot Confirmation Pop Up The unit will now reboot. Providing the unit configuration is still intact the unit should restart in normal operational mode and the link recovers. Should the unit or link fail to recover the user should refer to section 10 “...

  • Page 114: Reset Ip & Ethernet Configuration

    Reset IP & Ethernet Configuration To reset IP & Ethernet configuration back to factory defaults the user should press the “Reset IP & Ethernet Configuration back to factory defaults” button on the “Recovery Options” page (Figure 74). The user will now be presented with a pop up box asking them to confirm the action (Figure 78).

  • Page 115: Erase Configuration

    Figure 80: Reboot Confirmation Pop Up The unit will now reboot. The unit should now start up in normal mode but with the IP address set to 169.254.1.1/2 and the Ethernet interface set to auto-negotiate and auto-MDI/MDIX. Should the unit fail to start up the user should refer to section 10 “Fault Finding ”. Erase Configuration To erase the unit’s configuration the user should press the “Erase Configuration”...

  • Page 116: Figure 82: Erase Configuration Successful

    Figure 82: Erase Configuration Successful Page The user will now be presented with a pop up box asking them to confirm the action (Figure 83). Figure 83: Reboot Confirmation Pop Up The unit will now reboot. The unit should now start up in normal mode but with all configurations erased.

  • Page 117: Reboot

    Reboot To erase the units configuration the user should press the “Reboot” button on the “Recovery Options” page (Figure 74). The user will now be presented with a pop up box asking them to confirm the action (Figure 84). Figure 84: Reboot Confirmation Pop Up The unit will now reboot.

  • Page 118: Fault Finding

    Fault Finding If communication has been lost with the unit at the near end of the link then there may be a hardware fault with the wiring, network or hardware. Go to the hardware section below. If communication with the far end of the link is lost then go to the radio section below. 10.1 Hardware If there are problems suspected with the link hardware the following procedure is recommended.

  • Page 119: Ethernet

    If neither is illuminated then there is no voltage on the power wires to the ODU. • Check that the mains power is connected and switched on. • Check that the lamp illuminates if the ODU connector is disconnected at the Canopy 150/300 PIDU (Remove the 150/300 PIDU cover).
  • Page 120 Power Indoor Unit LED check chart: Yellow LED Ethernet Cable Yellow LED No Ethernet Connected between Mode Green LED Cable Connected Canopy 150/300 PIDU and NIC/Switch/Hub No Power Applied Will flash once per second regularly Will flash once per second approximately 30 regularly approximately 30 seconds after power...

  • Page 121: Radio

    10.2 Radio 10.2.1 No Activity If communication over the radio link has been lost and the unit at the other end of the link can be managed on its local network then the following procedure should be adopted: If there is no wireless activity then the configuration should be checked. It is essential that the following items are correct: •...

  • Page 122: Specifications

    Specifications 11.1 System Specifications Radio Technology Specification 5.725-5.850GHz RF Band 5830BH / 5830BH15: BH 300 Mbps / BH 150 Mbps integrated antenna Model #: 5830BHC / 5830BHC15: BH 300 Mbps / BH 150 Mbps connectorized antenna By dynamic frequency control and manual intervention Channel Selection Automatic detection on start-up and continual adaptation to avoid interference.

  • Page 123: Table 11: Receive Sensitivity And System Gains

    The receive sensitivities and system gains for each mode are as follows: Mode Receive Sensitivity (dBm) Transmit Power (dBm) Link Budget (dB) BPSK 0.63 -88.1 160.1 single payload QPSK 0.63 -84.6 155.6 single payload QPSK 0.87 -81.6 151.6 single payload 16QAM 0.63 -79.3 148.3...
  • Page 124 Antenna Antenna Type Integrated flat plate antenna Antenna Gain 23.5 dBi typical Antenna Beam width 8 Degrees Wireless PHY Max Path Loss 161 dB Duplex Scheme TDD, Symmetric (1:1) 125 miles (200km) optical Line-of-Sight Range 6 miles (10km) non-Line-of-Sight Over-the-Air Encryption Proprietary scrambling mechanism.
  • Page 125 Ethernet Bridging Protocol IEEE802.1; IEEE802.1p; IEEE802.3 compatible 10/100/1000BaseT (RJ-45), Supports MDI/MDIX Interface Auto Crossover BPSK 0.67 (Single) 6.45 Mbps QPSK 0.67 (Single) 12.90 Mbps 16 QAM 0.67 (Single) 25.79 Mbps Data Rate 0 – 5 km Mode 16 QAM 0.67 (Dual) 51.59 Mbps 64 QAM 0.78 (Dual) 93.07 Mbps...

  • Page 126: Safety Compliance

    Telecoms 2 E1 balanced 120R or 2 T1 balanced 100R over a CAT5 screened Interfaces twisted pair cable Jitter and Wander Compliant with G.823/ G.824. Surge Protection Compliant with GR1089, EN60950, K20, K21). and Power Cross Telecoms Connector Pinout Signal Name Pin 1 E1T1A_TX- Pin 2...

  • Page 127: Emc Emissions Compliance

    11.3 EMC Emissions Compliance Region Specification FCC Part 15 Class B Canada CSA Std C108.8, 1993 Class B Europe Designed to comply with EN55022 CISPR 22 11.4 EMC Immunity Compliance Top-level Specification ETSI 301-489 Designed to comply with: Specification Comment EN 55082-1 Generic EMC and EMI requirements for Europe EN 61000-4-2: 1995 Electro Static...

  • Page 128: Environmental Specifications

    11.6 Environmental Specifications Category Specification ODU: -40°F (-40°C) to 140°F (+60°C) 150/300 Mbps Backhaul PIDU (SPIDU): 32°F (0°C) to Temperature 104PoPF(+40°C) 150/300 Mbps Backhaul PIDU: -40°F (-40°C) to 140°F (+60°C) 151mph Max (242kph). See section 13 “Wind Loading” for a Wind Loading full description.

  • Page 129: System Connections

    11.7 System Connections 11.7.1 Canopy 150/300 PIDU to ODU and ODU to Network Equipment Connections PIDU ODU Power Connector Data pair 1 & 0V (White and Orange) PIN 1 PIN 1 PIN 2 PIN 2 Data pair 1 & 0V (Orange) PIN 3 PIN 3 Data pair 2 &...

  • Page 130: Lightning Protection

    Lightning Protection (Lightning) damage is not covered under warranty The recommendations in this user manual when installed correctly give the user the best protection from the harmful effects of However 100% protection is not implied or possible 12.1 Overview The idea of lightning protection is to protect structures, equipment and people against lightning by conducting the lightning current to ground via a separate preferential solid path and by reducing the electromagnetic field.

  • Page 131: Detailed Installation

    12.2 Detailed Installation The recommended components for an installation protected for nearby strikes are: • Grounding Kits — Andrew Type 223158 ( w ww.andrew.com H T U • Screened (Shielded) Cat 5e Cable • Surge Arrestor Units — Surge Arrestor ALPU-ORT ( w ww.transtector.com H T U •...

  • Page 132: Table 12: Protection Requirements

    the ODU to be mounted inside Zone B Zone A Zone B Ground (Earth) ODU Mandatory Mandatory Screen Cable Mandatory Mandatory Surge Arrestor Unit at ODU – ALPU- Mandatory Mandatory Ground (Earth) Cable at Building Mandatory Mandatory Entry Surge Arrestor Unit at Building Entry Mandatory Mandatory –...

  • Page 133: Figure 90: Diagram Of A Typical Wall Installation

    Surge Arrestor to 150/300 ODU Ground Mbps BH Connection Power/Ethernet Connection Surge Arrestor Surge Arrestor Grounding Cable 150/300 BH PIDU Plus fitted inside building Copper Connection to Network Ground Stake Figure 90: Diagram of a Typical Wall Installation A typical installation is shown in Figure 89 and Figure 90. Note: Grounding Points are shown unprotected for clarity.

  • Page 134: Figure 92: Lower Grounding Configuration

    Figure 92: Lower Grounding Configuration The Andrew Grounding Kit at the ODU is optional providing a Surge Arrestor Unit is located at the ODU and is reliably grounded. However, it may be a regulatory requirement to cross- bond the screened CAT-5 at regular intervals up the mast. Refer to local regulatory requirements for further details.

  • Page 135: Table 13: Surge Arrestor Alpu-Ort Cable 1 Termination

    Terminal Identification Conductor RJ45 Pin CON3 Pin 1 Orange/White CON3 Pin 2 Orange CON3 Pin 3 Green/White CON3 Pin 6 Green CON1 Pin 4 Blue CON1 Pin 5 Blue/White CON1 Pin 7 Brown/White CON1 Pin 8 Brown Table 13: Surge Arrestor ALPU-ORT Cable 1 Termination Terminal Identification Conductor RJ45 Pin...

  • Page 136: Figure 93: Surge Arrestor Alpu-Ort Connection Illustration

    Figure 93: Surge Arrestor ALPU-ORT Connection Illustration Note: Cable screens have been sleeved Issue 1.1 April 2006 Page 135...

  • Page 137: Wind Loading

    Wind Loading 13.1 General Antennas and electronic equipment mounted on towers or pole mounted on buildings will subject the mounting structure to lateral forces when there is appreciable wind. Antennas are normally specified by the amount of force (in pounds) for specific wind strengths. The magnitude of the force depends on both the wind strength and size of the antenna.

  • Page 138: Canopy 150/300 Mb Bh Capabilities

    13.3 Canopy 150/300 Mb BH Capabilities The structure and mounting brackets of the Canopy 150/300 Mb BH product range is capable of withstanding wind speeds up to 151mph (242kph). The installer should ensure that the structure the Canopy 150/300 Mb BH is fixed to is also capable of withstanding the prevalent wind speeds and loads.

  • Page 139: Canopy 150/300 Mbps Backhaul-C

    Canopy 150/300 Mbps Backhaul-C 14.1 Scope This Chapter details the changes and additional features relevant to the connectorized variant of the Canopy 150/300 Mb BH-C product. 14.2 Product Description 14.2.1 Hardware The Canopy 150/300 Mb BH-C is a variant designed to provide the system integrator and installer with the ability to provide extra capability to cope with very difficult radio links compared to the Canopy 150/300 Mb BH Integrated product.

  • Page 140: Software/Features

    14.3 Software/Features The variant operates in the same way as the basic Canopy 150/300 Mb BH product and is released initially with the feature set of the Canopy 150/300 Mb BH-C product. The areas where the functionality is modified are: 14.3.1 Status Page The link loss calculation presented on the Status Page on the management interface has to be modified to allow for the increased antenna gains at each end of the link.

  • Page 141: Installation

    Figure 96: Canopy 150/300 Mb BH-C ‘System Configuration’ Page 14.3.3 Installation Pages The installer is prompted to enter the Antenna Gain and Cable Loss (150/300 Mb BH-C to antenna) at each end of the link. The Installation Page(s) is shown as Figure 97- Figure 99. Figure 97: Canopy 150/300 Mb BH-C ‘Installation Wizard’...

  • Page 142: Figure 98: Canopy 150/300 Mb Bh-C 'Confirm Installation

    Cable Loss Loss in the cable between the ODU and the antenna. Note: In the event that there is a significant difference in length of the antenna cables for the two antenna ports, then the average value should be entered. Spectrum Management Control Is used to configure the Canopy 150/300 Mb BH Spectrum Management features, see section 8.3.6 for more details.

  • Page 143: Deployment Considerations

    Dual polarization antennas (with a gain greater than the integrated antenna) are currently only available in parabolic dish form. 14.5 Link Budget An estimate of the link budget for a specific application can be obtained by using the Motorola link estimation tools. For more information see the Motorola website. 14.6 Regulatory Issues In countries where FCC regulations are not relevant, installations should conform to any applicable local regulations for the Equivalent Isotropic Radiated Power (EIRP).
  • Page 144 Ensuring compliance becomes more complex when the connectorized unit is used with external antennas which may be locally sourced. With higher gain external antennas fitted, the Maximum Transmit power may need to be reduced for operation in specific countries. The following table indicates the default setting of the Maximum Transmit Power by region and this can be used with the specification for the intended antenna and the loss of the antenna feeder to determine the correct setting of the maximum Transmit Power.

  • Page 145: Antenna Choice

    Region Maximum Transmit Power (default) 25dBm 10dBm 13dBm 7dBm -3dBm 7dBm 25dBm Products deployed in North America or where FCC Part 15 regulations are applicable for unlicensed radio equipments, the sections 14.6.1 and 14.6.2 apply. Brazil Notification – Important Note: This equipment operates as a secondary application, so it has no rights against harmful interference, even if generated by similar equipment, and can not cause harmful interference on systems operating as primary applications.

  • Page 146: Antennas For Usa / Canada

    14.7 Antennas for USA / Canada M anufacturer A ntenna Type Flat Plate Parabolic D ish G ain (dBi) Andrew Andrew 1-foot Flat Panel, FPA5250D 12-N (23.6dBi) 23.6 Andrew Andrew 2-foot Flat Panel, FPA5250D 24-N (28dBi) G abriel G abriel 1-foot Flat Panel, D FPD 1-52 (23.5dBi) 23.5 G abriel G abriel 2-foot Flat Panel, D FPD 2-52 (28dBi)

  • Page 147: Installation

    LMR400 is a lot more difficult to handle and route than a cable of a type similar to LMR100. Motorola recommends the use of weatherproof connectors. Preferably, ones that come supplied with adhesive lined heat shrink sleeve that is fitted over the cable/connector interface.

  • Page 148: Mounting The Antennas

    When using dual polar antennas the Canopy 150/300 Mb BH-C unit should be mounted in such a position as to minimize the cable length, keeping losses to a minimum (taking into account the minimum cable lengths required by the FCC regulations, see section 14.7 ”...

  • Page 149: Completing The Installation

    Step 10: Align the second antenna using the tones as described in section 7.7.11 “ Aligning the ODUs ”. Step 11: Re-connect the second antenna to the Canopy 150/300 Mb BH-C (Note: you will notice the tone pitch increase as you re-connect the second antenna due to the additional received signal).

  • Page 150: Figure 101: Weatherproofing The Antenna Connections

    Ensure that contact is made between the sealing tape and the barrel of the connector Weatherproof N Connector Self-Amalgamating Tape PVC Tape Tape beyond the end of the connector and any heat shrink material employed terminating the cable Figure 101: Weatherproofing the Antenna Connections Issue 1.1 April 2006 Page 149...

  • Page 151: Faqs

    Can I source and use my own PoE adaptor with the Canopy 150/300 Mb Backhaul? No. The Canopy 150/300 Mb Backhaul uses a non-standard PoE configuration. Failure to use the Motorola supplied 150/300 Power Indoor Unit (PIDU) could result in equipment damage and will invalidate the safety certification and may cause a safety hazard.
  • Page 152 the other part of the network and filters packets it does not need to forward. The system is transparent to higher-level management systems such as VLANs and Spanning Tree. How does the Canopy 150/300 Mbps Backhaul provide security for data traffic? The Canopy 150/300 Mbps Backhaul has a range of security features.

  • Page 153: E1/T1 Installation Guide

    E1/T1 Installation Guide 16.1 Preparing the Canopy 150/300 Mb BH E1/T1 Cable Note: The maximum cable length between the ODU and the customers terminating equipment is 200m for T1. The E1/T1 cable should be assembled to the following instructions: Step 2: Strip the outer insulation Step 1: Assemble gland on cable as shown Step 4: Insert conductors and crimp Step 3: Arrange conductors as shown in...

  • Page 154: Making The Connection At The Odu

    Pin 1 E1/T1 A Tx- (White and Orange) Pin 2 E1/T1 A Tx+ (Orange) Pin 3 E1/T1 A Rx- (Green and White) Pin 4 E1/T1 B Tx- (Blue) Pin 5 E1/T1 B Tx+ (Blue and White) E1/T1 A Rx+ (Green) Pin 6 E1/T1 B Rx- (Brown and White)
  • Page 155 Step 1: Assemble the cable as described in Step 2: Insert the RJ45 connector making above sure that the locking tab snaps home Step 4: Screw on the clamping nut and Step 3: Screw in the body of the weather tighten proofing gland and tighten Should it be necessary to disconnect the...

  • Page 156: Routing The Cable

    Figure A4: Disconnecting the ODU 16.3 Routing the Cable After connecting the cable to the ODU it can be routed and secured using standard cable routing and securing techniques. When the cable is in place it can then be cut to the desired length.
  • Page 157 E1/T1 A Tx- (White and Orange) PIN 1 PIN 2 E1/T1 A Tx+ (Orange) 150/300 Mbps PIN 3 E1/T1 A Rx- (Green and White) PIN 4 E1/T1 B Tx- (Blue) E1/T1 B Tx+ (Blue and White) PIN 5 E1/T1 A Rx+ (Green) PIN 6 E1/T1 B Rx-...

  • Page 158: Lightning Protection

    16.6 Lightning Protection 16.7 Overview Chapter 12 in the main body of this manual contains the requirements for the 150/300 Mbps Backhaul deployment. This section details the additional requirements for the deployment of E1/T1. 16.8 Recommended Additional Components for E1/T1 Installation The recommended components below are in addition to those listed in section 10, the extra components required for the E1/T1 installation are: •...
  • Page 159 Surge Arrestors ALPU-ORT mounted the same Andrew height as the ODU Spectra Grounding Assembly to Tower Surge Arrestor to ODU Ground Connection Ethernet Connection Ground Connections should be less than 2ft long. All upper tower grounds should E1/T1 Connection be within 1ft of the ODU bracket and on the same Optional Ethernet metal...

  • Page 160: Surge Arrestor Wiring

    Optional Ethernet Fibre connection to ODU Spectra Surge Arrestors ALPU-ORT Surge Arrestor to ODU Ground Connection Power/Ethernet Connection E1/T1 Connection Surge Arrestors Spectra PIDU fitted inside building Copper Connection to Network Grounding Cable E1/T1 Connection Optional Fibre Connection to Network Ground Stake Typical Wall Installation Figure A7: Diagrammatically Showing Typical Wall Installation with the addition of...
  • Page 161 Terminal Identification Conductor RJ45 Pin CON3 Pin 1 Orange/White CON3 Pin 2 Orange CON3 Pin 3 Green/White CON3 Pin 6 Green CON1 Pin 4 Blue CON1 Pin 5 Blue/White CON1 Pin 7 Brown/White CON1 Pin 8 Brown Table A2: Surge Arrestor ALPU-ORT Cable 1 Termination Terminal Identification Conductor RJ45 Pin...
  • Page 162 Figure A8: Surge Arrestor ALPU-ORT Connection Illustration Issue 1.1 April 2006 Page 161...

  • Page 163: Data Rate Calculations

    Data Rate Calculations To aid the calculation of data rate throughput the following plots of data rate throughput verses link range have been produced for all the Canopy 150/300 Mb BH modulation modes assuming the units are connected using Gigabit Ethernet. To aggregate data rate capacity can be calculated using four key system parameters: •...

  • Page 164: Figure 104: Qpsk 0.87 Single Payload

    Figure 104: QPSK 0.87 Single Payload Figure 105: 16 QAM 0.63 Single Payload Figure 106: 16 QAM 0.87 Single Payload Issue 1.1 April 2006 Page 163...

  • Page 165: Figure 107: 64 Qam 0.75 Single Payload

    Figure 107: 64 QAM 0.75 Single Payload Figure 108: 64 QAM 0.92 Single Payload Figure 109: 256 QAM 0.81 Single Payload Issue 1.1 April 2006 Page 164...

  • Page 166: Figure 110: 16 Qam 0.63 Dual Payload

    Figure 110: 16 QAM 0.63 Dual Payload Figure 111: 16 QAM 0.87 Dual Payload Figure 112: 64 QAM 0.75 Dual Payload Issue 1.1 April 2006 Page 165...

  • Page 167: Figure 113: 64 Qam 0.92 Dual Payload

    Figure 113: 64 QAM 0.92 Dual Payload Figure 114: 256 QAM 0.81 Dual Payload Issue 1.1 April 2006 Page 166...

  • Page 168: Legal And Regulatory Notices

    Legal and Regulatory Notices 18.1 Important Note on Modifications Intentional or unintentional changes or modifications to the equipment must not be made unless under the express consent of the party responsible for compliance. Any such modifications could void the user’s authority to operate the equipment and will void the manufacturer’s warranty. 18.2 National and Regional Regulatory Notices 18.2.1 U.S.

  • Page 169: European Union Notification

    18.2.2 European Union Notification The 5.7 GHz connectorized product is a two-way radio transceiver suitable for use in Broadband Wireless Access System (WAS), Radio Local Area Network (RLAN), or Fixed Wireless Access (FWA) systems. It is a Class 2 device and uses operating frequencies that are not harmonized throughout the EU member states.

  • Page 170: Legal Notices

    Termination. This License is effective until terminated. This License will terminate immediately without notice from Motorola or judicial resolution if you fail to comply with any provision of this License. Upon such termination you must destroy the Software, all accompanying written materials and all copies thereof, and the sections entitled Limited Warranty, Limitation of Remedies and Damages, and General will survive any termination.
  • Page 171 Software as a licensed duly paid for upgrade, update, patch, new release, enhancement or replacement of a prior version of the Software. If you are a Motorola licensed distributor, when you are transferring the Software as permitted herein, you agree to transfer the Software with a license agreement having terms and conditions no less restrictive than those contained herein.

  • Page 172: Hardware Warranty In U.s

    18.4.2 Hardware Warranty in U.S. Motorola U.S. offers a warranty covering a period of one year from the date of purchase by the customer. If a product is found defective during the warranty period, Motorola will repair or replace the product with the same or a similar model, which may be a reconditioned unit, without charge for parts or labor.

  • Page 173: Additional Resources

    Additional Resources Canopy provides two additional resources where you can raise questions and find answers: Canopy User Community at http://motorola.canopywireless.com/support/community/ This resource facilitates communication with other users and with authorized Canopy experts. Available forums include General Discussion, Network Monitoring Tools, and Suggestions.

  • Page 174: Glossary

    Glossary Address Resolution Protocol NLoS non-Line-of-Sight Automatic Repeat reQuest Canopy 150/300 Mbps Backhaul Outdoor Unit Binary Phase Shift Keying Orthogonal Frequency Division BPSK OFDM Multiplex Direct Current PIDU Canopy 150/300 Power Supply Dynamic Frequency Selection IBM Compatible Personal Computer European Telecommunications Screened is also known as Shielded ETSI Screened...
