Please read these instructions before installation or using your appliance! Dear Customer, By purchasing this product you have chosen an appliance of advanced technology and high quality. The appliance was produced in modern facilities which meet all environmental standards. The instructions will help you to operate the appliance quickly and safely.
Table of Contents Before installation ........9 GENERAL INFORMATION ..4 Installation and connection.....10 Overview ...........4 PREPARATION ......13 Technical Data ..........5 Accessories supplied with the unit ...5 Tips for saving energy......13 Initial operation ........13 SAFETY INSTRUCTIONS .... 6 First cleaning of the appliance....13 Explanation of safety instructions.....6 HOW TO USE THE HOB ....14 Basic safety instructions......6...
GENERAL INFORMATION Overview Pan support Assembly clamp Spark plug Burners' plate Normal burner Gas burner's knob Rapid burner Auxiliary burner Base cover Auxiliary burner Front right Normal burner Rear left Rapid burner Front left Normal burner Rear right 4 | EN...
Technical Data Voltage/frequency 220-240 V ~ 50 Hz Cable type / cross section H05RR-FG 3 x 0,75 mm Cable length max. 2 m Gas device category 2H 3B/P Gas type/pressure LPG G 30/30 mbar Total gas consumption 7.9 kW § Conversion to gas type/pressure NG G 20/20 mbar Outer dimensions (height/width/depth)
SAFETY INSTRUCTIONS appliance are obtained under Explanation of safety laboratory conditions as per relevant instructions standards. These values may vary according to the usage of the appliance and ambient conditions. The following types of safety instructions and information are used in this manual. •...
surface of appliance. These kind of • The use of a gas-cooking appliance dishes should not be used to keep produces heat and humidity in the food either. space where it is located. You should assure a good ventilation of the •...
4. Warn the neighbours. This appliance bears the selective sorting symbol for waste electrical and electronic 5. Call the fire-brigade. Use a telephone equipment (WEEE). This means that this outside the house. appliance must be handled pursuant to European Directive 2002/96/EC in order to 6.
INSTALLATION • Surfaces, synthetic laminates and Before installation adhesives used must be heat resistant The hob is designed for installation in a (100 °C minimum). commercial worktop. A safety distance • The worktop must be aligned and fixed must be left between the appliance and the horizontally.
• The appliance mains cable must Installation and connection correspond to the specifications and the power consumption; see Technical • For installation the appliance must be Data, page 5. connected in accordance with all local gas and/or electrical regulations. Important The plug should be easily Connection to the mains supply accessible after installation (but not...
Page 11
Connecting the gas hose If there is a built-in oven installed under the hob; • Have your appliance connected in a way that it will be close to the gas • Gas hose must be routed in a way not connection and avoid gas leakage.
Page 12
2. In order to avoid the foreign substances Bottom view (clamp holes) and liquids penetrating between the hob and the worktop, please apply the putty supplied in the package to the contour of the housing in the worktop before installation but make sure that the putty does not overlap.
PREPARATION Tips for saving energy Initial operation The following tips will help you to use your First cleaning of the appliance appliance in an ecological way and to save NOTICE energy: The surface might get damaged by • Use pots/pans with lids for cooking. some detergents or cleaning Without a lid, the current consumption materials.
HOW TO USE THE HOB General information on cooking How to use hobs DANGER Risk of fire by overheated oil! When you heat oil, do not leave it unattended. Never try to extinguish the fire with water! When oil has caught fire, immediately cover the pot or pan with a lid.
Page 15
• Keep the knob at pressed position for Switch off the gas burners 3-5 seconds after you see the flame Turn burner control knob to off position around the burner. (top). • Repeat the sequence of operations if the flame does not continues. After Flame failure device (model dependant) you release the knob, if the ignition In case of any...
MAINTENANCE AND CARE avoiding these from burning the next time General information the appliance is used. DANGER No special cleaning agents are required for Risk of electric shock! cleaning the appliance. It is recommended to use warm water with washing liquid, a Switch off the electricity before soft cloth or sponge and use a dry cloth for cleaning appliance to avoid an...
TROUBLESHOOTING DANGER Normal operating conditions Risk of explosion or poisoning • Smoke and smell may emit for a by unprofessional repair. couple of hours during the first Repairs on the appliance must be operation. carried out by an approved service •...
