Summary of Contents for Swift Group Basecamp 2018

  • Page 1 CREATING SMILES FOR LIFE Swift Group Owner’s Handbook Basecamp Issued July 2017...
  • Page 2 you deserve Luxury W H E R E V E R Y O U A R E...
  • Page 3 Truma Aventa Upgrade to even more comfort on the move Experience the ultimate comfort of Automatic Climate Control (ACC) by upgrading your Swift caravan with the Truma Aventa Air Conditioner. Your vehicles heating system and the Truma Aventa work perfectly together to keep you cosy in the winter and cool in the summer.
  • Page 4 The only Swift Partner for Paint ® and Upholstery Protection Paint Protection Upholstery and Carpet Protection From the Makers of Diamondbrite Diamondbrite Leisure The ultimate Paint and Upholstery Protection for your Swift Basecamp Diamondbrite Leisure is a two-step protection system for your Swift Basecamp with a Lifetime Guarantee* 1.
  • Page 5 INT R ODU CT ION Dear owner Throughout the season, specifications and equipment details contained within this Thank you for deciding to buy one of our handbook may change. Please refer to our new caravans. online handbooks (www.swiftgroup.co.uk) We are sure you will enjoy many happy hours for the most up-to-date version of your in it and we hope the information and hints in handbook.
  • Page 6 The site is packed full of features that actively encouraged to sign up, create their own encourage members, not only to liaise with the content, and start talking! Swift Group via the forums, but also interact Just visit www.swift-talk.co.uk with each other through publishing their own...
  • Page 7 CONT E N T S Warranty ............................ 5 Towing code ..........................8 Safety & security ........................32 Services ..........................38 Electrics ........................... 58 Fitted equipment ........................90 Maintenance .......................... 112 Useful information ........................148 Index ............................155...

  • Page 8: Warranty

    Back to main menu WAR RA N T Y IN FOR MAT ION Supplier contacts ........................6 To view the warranty details for your vehicle please follow the link:...

  • Page 9: Supplier Contacts

    WA RRAN TY Supplier contacts A number of Swift Group suppliers manage their own Technical and Warranty related queries. Where a customer has a question relating to a product manufactured by a company listed below, we would advise that the first contact should be directly with them.

  • Page 10: Table Of Contents

    Back to main menu T OW ING CODE Caravan towing code ......................8 Caravan terms ........................8 Towing vehicle terms ......................10 Measurement of nose weight ....................10 Type of driving licence held ..................... 11 Glossary & checklist ....................... 11 Useful memory aid ........................

  • Page 11: Caravan Towing Code

    Back to section menu T O WI NG CO DE Caravan towing code The Mass in Running Order + Personal Effects + Optional Equipment = Maximum Technical This Code of Practice contains Permissible Mass or MRO + PE + OE = recommendations jointly reviewed and MTPLM agreed by the following organisations:...
  • Page 12 Back to section menu (ii) New NCC certificate (declaring the Note: If you travel with water in the fresh upgraded MTPLM) water tank, the payload will be reduced (iii) Manufacturers letter confirming the upgrade accordingly. for that Vehicle Identification Number. Note: Tyre pressures may increase when The leisure battery is considered to be upgrading the MTPLM.

  • Page 13: Towing Vehicle Terms

    Back to section menu TO WI NG VEHI CL E TERMS Towing vehicle terms Measurement of nose weight Kerb weight Nose weight may be measured using a (Mass of Vehicle in Running Order): propriety brand of nose weight indicator. Such equipment is obtainable at your The weight of the towing vehicle as defined by Caravan Dealer.

  • Page 14: Glossary & Checklist

    Back to section menu D R IV IN G L I CEN CE / G L O SS A RY A ND CH E CK LIS T Glossary & checklist Driving licence If you passed your car test before 1st January Awnings - Can consist of just a simple top 1997 you are generally entitled to drive a sheet but may extend to a five sided frame...
  • Page 15 Back to section menu G LOS S ARY AN D CHECK L IS T WARNING: Your caravan dealer should Towing Bracket - Never use cheap be consulted if additional equipment is to be alternatives, obtain one manufactured by fitted as strong points may or may not be a reputable company complying with the provided in the design.

  • Page 16: Useful Memory Aid

    Back to section menu U S E FU L IT E MS Useful memory aid Make up. etc. Matches Raincoats Measuring jug Toothbrush Milk jug Toothpaste Mixing bowl External mirrors Scissors Needles and thread Fire extinguisher Shampoo Oven gloves Jack Shaving kit Pegs Petrol can...

  • Page 17: Preparing For The Road

    Back to section menu P R EPAR I NG F O R THE ROAD Preparing for the road WARNING: Always disconnect the electrical connector between the towing Pre-load checklist vehicle and the caravan before connecting a LV supply to the caravan. WARNING: Never enter the caravan without first lowering the four corner steadies with the brace provided.
  • Page 18 Back to section menu How to apportion it Towing vehicle’s rear suspension 1. Load heavy items low down near the floor It is important that the towing vehicle’s rear and mainly over or just in front of the axle(s) suspension is not deflected excessively by the (Fig.
  • Page 19 Back to section menu S TABIL ITY Stability Snaking All our models are of a well balanced design This is a term used to denote an unstable car and should be exceptionally good towers. and caravan combination where the caravan The common causes of poor stability include: ‘weaves’...

  • Page 20: Tyre Maintenance

    Back to section menu Types of tyres fitted Tread The original tyres fitted by the manufacturer are Keep tyre treads clean of stones and other suitable for towing at a maximum speed of up foreign bodies, and check regularly for to 81 mph (130 kph).

  • Page 21: The Tyre Law

    Back to section menu T H E T YRE LAW Tyres that display signs of aging should be Wheels removed and not put to further use. Caravan wheel bolts supplied with your caravan should be tightened to a torque of The effects of aging can be brought about 88Nm (65lb/ft) on steel wheels or 130Nm prematurely in several conditions.
  • Page 22 Back to section menu H IT CH ING- U P AK160 Type Hitch head Fig. A Open the locking mechanism by pulling the coupling handle upward in the direction of the arrow (Fig.A item 1). The handle will remain in the open position until the hitch head is positioned onto the towball.

  • Page 23: Pre Tow Check List

    Back to section menu PR E-T O W CHEC K LI ST Pre-Tow Check List Fit extending mirrors Release caravan handbrake, adjust all mirrors Check gas locker, battery locker and cassette from driving seat and proceed. toilet doors are secure. •...

  • Page 24: 13 Pin Soc Ke T

    Back to section menu 13 PIN SOC KE T 13 Pin socket Please be aware that some car manufacturers and towbar manufacturers do not wire up all 13 pins as standard, unless requested.

  • Page 25: Towcar Electrics

    T OW CAR EL EC TRIC S Tow Car Electrics Note: This will change updates will be In all cases, The Swift Group assumes that the required. tow car harness and electrics have been fitted with the specific requirement of connection to...

  • Page 26: Breakaway Cables

    Correct procedure for use Regularly check the cable and clip for damage. If in doubt contact your Swift Group dealer. Make sure the cable runs as straight as possible and goes through the cable guide fitted underneath the caravan coupling head.
  • Page 27 Back to section menu B R EAK AWAY CAB L E Determine whether or not the towing vehicle towbar has a designated attachment point (i.e. a part specifically designated for a breakaway cable). Where a point is designated on the towbar: •...

  • Page 28: Mirrors

    Back to section menu MOV ING OF F Mirrors Reversing The driver of the towing vehicle must have an When the towing vehicle is reversing, the adequate view of the rear. overrun device shaft is pushing in, applying the brakes via the overrun lever, brake rod system, If there is no rear view through the caravan it is bowden cables and the expander mechanism.

  • Page 29: Caravan Handling

    Back to section menu C AR AVAN HAN DL I N G Caravan handling Spare wheel Allow for caravan being wider than car. The spare wheel is located in the gas locker at the front of the caravan. Do not bump kerb with caravan wheels. When passing other vehicles allow more than Note: The side-lift jack (when fitted) has a the normal clearance for driving solo.

  • Page 30: Changing A Wheel

    Back to section menu CH A N GIN G A W H E E L Changing a wheel The sequences necessary to correctly carry out this work on a 5 stud wheel is as follows: 1. Leave caravan hitched to towing vehicle and ensure that the caravan and towing vehicle handbrakes are applied.

  • Page 31: Stopping On A Hill

    Back to section menu S T OPP IN G ON A HIL L 1. Selecting a pitch Do not pitch in such a position that your outfit will obstruct others coming in. Try to choose an area which is dry, reason- ably level and preferably with a hard base.

  • Page 32: Exterior Door

    Back to section menu U N H IT CH ING Fig. C Levelling board Exterior door To prevent distortion of the body, the caravan must be always correctly sited and levelled. Failure to site the caravan correctly may prevent the exterior door from closing properly. 3.
  • Page 33 Back to main menu S A FE T Y A N D S E CU RIT Y Fire ............................32 SI 601 Smoke Alarm Operation ....................32 Fire extinguisher ........................32 Escape paths .......................... 32 Children ........................... 32 CO Alarm - Fireangel CO-9X Carbo Monoxide Alarm operation ..........

  • Page 34: Fire

    Back to section menu FIR E / S MO KE ALARM / CO A L A RM Fire Fire Extinguisher Important: Your attention is drawn to the It is recommended that a dry powder fire extinguisher be carried inside your caravan at notice affixed inside the caravan wardrobe all times.

  • Page 35: Ventilation

    Back to section menu V EN T IL AT ION / S E CU R IT Y Ventilation Security Caravan theft All caravans comply with BS EN 721. The ventilation points on your caravan are fixed The theft of a caravan can occur in the most points of ventilation which are required by the unlikely circumstances;...

  • Page 36: Swift Command Tracker

    Back to section menu S WI FT C OM MAN D TRACK ER Caravan insurance Event of a Theft It is recommended that the caravan and its If the vehicle is moved whilst the tracker is contents should be insured against theft. armed the geo-fence monitoring will trigger a theft event.

  • Page 37: Al-Ko Secure Immobiliser

    Back to section menu AL - KO SECU R E IMMOBILIS E R Precautions Part B Wheel specific insert assembly consisting of: The Swift Command Tracker monitors the leisure battery supply and if the voltage falls - Red coloured wheel insert lozenge below a set level or the battery is removed this assembled with the locking bar and clip.

  • Page 38: Mobile Alarm System

    Back to section menu AL-K O J ACK / MOB I LE AL AR M SY S T E M AL-KO operating instructions - Read the AL-KO operating instructions and act in accordance with them. - Follow all safety instructions as well as the warning information.
  • Page 39 Back to main menu S E RV ICE S Water System ........................38 Plumbing connections ......................40 Plumbing troubleshooting ...................... .41 Pressure switch adjustment ....................42 Sanitising water system ......................42 Water Fault Finding ........................ 44 Typical gas schematic drawing ....................

  • Page 40: Water System

    Back to section menu WAT ER SY STEM Water system- Introduction All Swift Group caravans water systems have been designed around a pump fitted within the caravan. This pump draws water from an external source, to provide water pressure within the caravan, whenever it is switched on and water is available.
  • Page 41 Back to section menu WAT E R S Y S T E M On Arrival at the campsite / Whale Water In Socket and Watermaster® Priming the system exterior water pump with Easi-Push Plug (when fitted) • Ensure that the external water container is full.

  • Page 42: Plumbing Connections

    Back to section menu P LU MB ING CON N EC TION S Plumbing Connections 5) Adjust dust cover over opening in water container as shown in image below. Please In most cases, speed fittings are used, note dust cover should not be secured to which allow easy and quick connection of water container, as air must be allowed to water pipes.
  • Page 43 Back to section menu WATER S YS TE M T ROU B LE S H OOT ING Troubleshooting Pump continues to run (for more than 5 seconds) after taps are closed or pump Pump will not start, when the tap is turns on for no reason: opened: •...

  • Page 44: Pressure Switch Adjustment

    Back to section menu WAT ER SY STEM Water pump pressure switch The purpose of a pressure switch is to monitor the pressure on the outlet side of the pump. When a tap is closed, and the pump continues to run, there is an increase of pressure in the system, and when that pressure reaches a Pressure switch pre-set limit, the pressure switch will turn the...

  • Page 45: Sanitising Water System

    Back to section menu SAN I T IS ING WAT E R S YS T E M 7. The container should be inverted whilst stored overnight (if possible). 8. The container must be filled with mains water only and mains water only should be used for the above cleaning procedure.
  • Page 46 Back to section menu WAT ER FAU LTS Water Fault Cause Remedy Water not Freshwater tank empty Check flowing from Pump wired in reverse Check wiring, refer to pump manufacturers any tap when instructions operated but Pipe inlet or outlet pipe Check connections pump runs disconnected...
  • Page 47 Back to section menu WAT E R FA U LT S Water Fault Cause Remedy Water flows Cold water pipe kinked Check and re-route if necessary from hot preventing flow tap but has Blockage in cold pipe line Disconnect pipes after 1st connector and reduced flow check up to tap from cold...
  • Page 48 Back to section menu G AS S C H EMATI C...

  • Page 49: Gas

    Back to section menu GA S WARNING: Inspect flexible gas hose(s) regularly for deterioration and renew as General information necessary with the approved type, in any Gas Cylinders case no later than 5 years after the date of Bottled Liquified Petroleum Gas (LPG) is the manufacture marked on the hose.

  • Page 50: Types Of Gas

    Back to section menu Types of gas WARNING: When leaving the caravan for any period of time or storage always turn Propane off the gas at the gas cylinder. Propane is supplied in red, or partly red bottles which have a female left hand threaded Note: Never allow modifications or repairs connector.

  • Page 51: Changing A Gas Cylinder

    Back to section menu GA S Awning Spaces LPG Appliance Exhaust WARNING: Always read individual There is no danger of pollution of an enclosed appliance instructions awning space by the LPG exhaust from a refrigerator venting into it, as awning spaces WARNING: IF IN DOUBT ASK are generally well ventilated.
  • Page 52 Back to section menu has individual isolation taps for each appliance Thermal insulation heating (Fig A), as follows: Your caravan has been designed and manufactured to a grade 3 thermal insulation and heating level for specific climatic conditions and tested according to the procedure in EN1645-1.
  • Page 53 Back to section menu GA S FA U LT S Fault Cause Remedy Hob does No gas Check level of gas in the cylinder not light Check gas cylinder valve is on Check gas taps are on Air in pipe Purge system Refer to hob manufacturers instructions Oven does...

  • Page 54: Electrical System

    Back to section menu ELECT R I CAL SYS TEM The electrical system Care point: It is good practice to test the RCD (Residual Current Device) in the PSU before General Information switching on. There is a test button on the RCD to test the lever, put the lever in the up It is strongly advised that the mains installation position (on) before testing.
  • Page 55 Back to section menu 13 P IN CON NE CT ION 13 pin connection degrees clockwise until a click is felt or heard, at this point the cover flap can be allowed to When using the 13 pin connector system for fall over the circular surface of the plug top the first time it is worth taking a few minutes (figs 6 &...

  • Page 56: Mains Electrical Equipment Power Consumption

    Back to section menu 1 3 P IN C ON N ECTI ON 230V mains electrical equipment power consumption Note: It is possible that the 230v mains electrical equipment may not all operate simultaneously. A typical UK site mains hook up point provides a maximum output of 10 amps and on some continental sites the available output may be as low as 5 amps.

  • Page 57: Wiring Of Connecting Cable And Caravan Mains Inlet

    Back to section menu WIR IN G OF CON N ECT IN G C A BL E S A ND C ARAVAN M A IN S IN LE T...

  • Page 58: Typical Appliance Consumption Figures

    Back to section menu TY P IC AL AP P L IAN C E C ON SU M P T ION F IGU RE S...
  • Page 59 Back to main menu E LE CT R ICS Swift Command Power Control System ................... 58 Control Panel Operation ......................60 Residual Current Device & Miniature circuit breakers ..............63 Battery charger ........................64 Leisure Battery ......................... 64 12 Volt DC Fuses ........................
  • Page 60 Back to section menu S WI FT C OM MAN D P OWER CO N TR OL S Y S T E M ELECTRI CS 1. Introduction • The C44 Road Light Fuse Box - This small unit is located in the front bed box. The unit This section of the handbook will guide you houses fuses for the road lighting circuits through the operation of the electrical system.

  • Page 61: Swift Command Power Control System

    Back to section menu S WI FT CO MMAN D P OW ER C ONT R OL S YS T E M 2.3 Connecting to the Mains 230V supply Locate the green ‘Charger’ switch on the PSU and Safety checks and turn to the on position (press button in).

  • Page 62: 2.5 Control Panel Operation

    Back to section menu S WI FT C OM MAN D P OWER CO N TR OL S Y S T E M ELECTRI CS 2.4 Control Panel - Component Layout (see image below) Your control panel will have an appearance as below, but depending on your vehicle specification the control panel features will vary.
  • Page 63 Back to section menu S WI FT CO MMAN D P OW ER C ONT R OL S YS T E M • Leisure battery, the leisure battery voltage and charging or discharging current is displayed. Use the select button to toggle the display, with voltage on the main display whilst current (in or out of the battery is shown on the bar-graph and vice versa, current on the main display and voltage on the bar-graph.
  • Page 64 Back to section menu S WI FT C OM MAN D P OWER CO N TR OL S Y S T E M ELECTRI CS Pump Button. With the power on, press the pump button to turn the water pump on. Press the button again to turn the pump off. The adjacent LED will illuminate when the pump is on and the level of the water tank will be shown on the screen.

  • Page 65: Residual Current Device & Miniature Circuit Breakers

    Back to section menu S WI FT CO MMAN D P OW ER C ONT R OL S YS T E M 3 System Technical Information 3.2 Generator Usage Caution should be used before connecting a The following section provides further technical generator to your caravan.

  • Page 66: 3.3 Battery Charger

    Back to section menu S WI FT C OM MAN D P OWER CO N TR OL S Y S T E M ELECTRI CS 3.3 Battery Charger 3.4 Leisure Battery During stage 1 the battery voltage is increased A) Type / Selection gradually while the current is limited to start the For optimum performance and safety it charging process and protect the battery.
  • Page 67 Back to section menu S WI FT CO MMAN D P OW ER C ONT R OL S YS T E M C) Operation / Servicing Under normal circumstances it should not be necessary to remove the battery other than for routine inspection of the terminals and “topping up”...

  • Page 68: 3.5 12 Volt Dc Fuses

    Back to section menu S WI FT C OM MAN D P OWER CO N TR OL S Y S T E M ELECTRI CS 3.5 12 Volt DC Fuses WARNING: When replacing fuses always replace a fuse with the correct value. NEVER replace with a higher value / rating as this could damage the wiring harness.
  • Page 69 Back to section menu S WI FT CO MMAN D P OW ER C ONT R OL S YS T E M The following table shows details of the fuse(s) located at the Road Light fuse box. Fuse Rating Fuse Colour Description 20 Amps Yellow...
  • Page 70 Back to section menu S WI FT C OM MAN D P OWER CO N TR OL S Y S T E M ELECTRI CS 3.08 AC Current Limiter Operation 3.09 Lighting & Dimming Operation The EC600 system features a 230V current The system contains up to two dimming monitoring system which allows the mains channels for groups of lights which can be...
  • Page 71 Back to section menu S WI FT CO MMAN D P OW ER C ONT R OL S YS T E M 3.10 Heating Controls There are a number of heating systems that can be controlled by the EC600. The system will be preconfigured by the manufacturer or supplying dealer.
  • Page 72 Back to section menu S WI FT C OM MAN D P OWER CO N TR OL S Y S T E M ELECTRI CS 3.11 Refrigerator Controls The main refrigerator settings can be set / controlled by the EC620 control panel or the Swift Command app.
  • Page 73 Back to section menu S WI FT CO MMAN D P OW ER C ONT R OL S YS T E M 3.12 Air-conditioning Heat from other items in the vehicle (in particular components from the heating If your vehicle has been fitted with a system itself) will have a bearing on the reading compatible air-conditioning unit then the displayed by the Swift Command system.

  • Page 74: System Warnings

    Back to section menu S Y S T EM WARN IN G S 3.17 System Warnings The system incorporates a number of warnings that are active at specific times. These are summarised below, and also covered by relevant sections of this manual. When a warning is active a triangle will be displayed in the control panel header area.
  • Page 75 Back to section menu SY S T E M WA RN INGS Fault Possible Cause Proposed Fix Heating When set to Message on screen and 30 second audible beep. system control the heating Additional descriptive information is available when using system, the the Swift Command App.
  • Page 76 Back to section menu S Y S T EM WARN IN G S 3.18 Common Fault Table No 230 volt Connecting lead Check and connect lead as per 2.3C output from between the site and Leisure Vehicle not connected RCD switched off Reset RCD as per 2.3D RCD not operating Check supply polarity;...
  • Page 77 Back to section menu SY S T E M WA RN INGS Fault Possible Cause Proposed Fix Control Panel Control Panel has Check batteries and fuses, turn PSU isolate switch and Problems no display charger switch on and ensure mains supply is connected. Check control panel connecting lead at PSU and behind Control Panel Contact your Dealer 12V Power turns...
  • Page 78 Back to section menu S Y S T EM WARN IN G S 3.19 Common Fault Table Fault Possible Cause Proposed Fix No 230 volt Connecting lead Check and connect lead as per 2.3C output from PSU between the site and Leisure Vehicle not connected RCD switched off...
  • Page 79 Back to section menu SY S T E M WA RN INGS Fault Possible Cause Proposed Fix Control Panel Control Panel has Check batteries and fuses, turn PSU isolate switch Problems no display and charger switch on and ensure mains supply is connected.
  • Page 80 Back to section menu S Y S T EM WARN IN G S Fault Possible Cause Proposed Fix Pump not Fuse blown Replace fuse with correct value as per fuse table. working Pump turned off Turn pump on by pressing the pump button at the control panel.
  • Page 81 Back to section menu REMO TE A CCE S S & CON T ROL 3.20 Contact details Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Netherlands, Malta, Norway, Sargent Electrical Services Limited provide a Poland, Portugal, Romania, Slovakia, Slovenia, technical help line during office hours. Please Spain, Sweden, United Kingdom.
  • Page 82 Back to section menu T EC HNIC AL DATA AN D APP R OVA LS 5 Technical Data & Approvals 5.1 Equipment – EC601, EC602, EC651, EC620, EC630 & PX300 Control Equipment Outline Specification INPUT 230V 230 Volts / 0 to 16 Amps + / - 10% OUTPUT 230V RCD protected, 2 x MCB outputs of 10A &...
  • Page 83 Back to section menu A P P ROVA LS 5.2 Approvals System: BSEN 1648-1, BSEN1648-2 compliant, BS7671: 2008 compliant Residual Current Device: RCD 40A 30mA trip to BS EN 61008 Miniature Circuit Breakers: MCB’s type C 6000A breaking capacity to BSEN 60898 Electro Magnetic Compatibility (EMC) directive 2004/108/EC Certificate CE20071224-1...

  • Page 84: Battery

    Back to section menu BAT T ERY Battery WARNING: When connecting the battery, ensure that the correct polarity WARNING: Use precaution when is observed (black is negative and red/ removing or replacing the battery, as brown is positive) and that the terminals are batteries contain acid liquids which can securely fastened.
  • Page 85 Back to section menu S OLA R PA NE L Cleaning and maintenance (Floor mounted battery compartment) • Use protective clothing and glasses when handling a leaking battery, and avoid direct contact to the skin, eyes and respiratory organ. • Should a battery leakage occur, please act according to the instructions supplied by the manufacturer of the battery.

  • Page 86: Generator Usage

    Back to section menu B AT TERY CHARG I N G / G EN ERATO R Regulator Battery charging Unlike typical regulators, the factory fitted solar If a leisure battery is fitted and requires panel regulator has been specially designed charging the Charge Status LED will illuminate.

  • Page 87: Habitation Relay

    Back to section menu H A B ITAT ION RE L AY / EXT ER IOR 230 V SOC KE T Exterior 230V Whale Mains Elec- Whilst some generators use invertor tech- nology, others use a more basic principle tric Out Socket (when fitted) to generate the 230v supply.
  • Page 88 Back to section menu ELEC T R ICS Please remember that the equipment plugged into the socket may not be weatherproof, check with the equipment manufacturer’s product information for to confirm. To disconnect equipment, raise socket cover and remove the plug, then slide the lid down to close it and ensure a weatherproof seal.
  • Page 89 Back to section menu U S B S OCKE T Internal USB Socket Provision In addition to the 230v sockets and 12v sock- ets present there is a USB socket at the end of the sink unit. This can be used with a variety of devices such as mobile phones, media players etc, as a power supply for continued running of the device or charging of the internal battery...
  • Page 90 Back to main menu FIT T E D E Q UIP ME N T Whale Water Heater ........................ 90 Whale Space Heater ....................... 91 Dometic absorption refrigerator ....................92 Thetford Hob .......................... 93 Thetford Grill .......................... 100 Thetford Oven ........................100 Thetford C402 cassette toilet ....................

  • Page 91: Whale Water Heater

    Back to section menu WHAL E WATER HEATER Whale Water Heater Electrical operation of Whale Water Heater Your caravan is equipped with a Whale eight litre gas / electric water heater. Quick reference Once the water system is primed, the 230v and detailed instructions are available for the isolation button on the Sargent Power Supply water heater, please read these before using...

  • Page 92: Whale Space Heater

    Back to section menu WH A LE S PA CE H E AT E R Whale Space Heater In addition, in the base of the wardrobe are two switched fused spurs which individually Your caravan is equipped with a Whale isolate the 230v supply to the Whale space underfloor gas / electric space heater.

  • Page 93: Dometic Absorption Refrigerator

    Back to section menu R EFR IG ER ATO R Warranty Dometic absorption refrigerator WHALE® is a registered trademark of Before you start using the refrigerator,please Munster Simms Engineering Ltd (also trading read the operating instructions carefully. as Whale®). These instructions provide you with the necessary guidance for the proper use of your The Whale®...
  • Page 94 Back to section menu H OB Our policy is one of continuous development WARNING: and improvement. Specifications and • Appliances and accessible parts become illustrations may change subsequent to hot during use. publication. • Avoid touching heating elements. Provision of ventilation •...
  • Page 95 Back to section menu knowledge only if they are supervised or The use of inappropriate hob guards can have been given instructions on the safe cause accidents. use of this application and understand the Do not store items on the cooking surface potential hazards.
  • Page 96 Back to section menu H OB Safe cooking ATTENTION: Only use LPG (Liquified • Do not allow cooking vessels to overlap the Petroleum Gas). The appliance operates on edges of the appliance- use the correct sizes propane or butane. Propane is preferred of pans and position them centrally over the over butane, because butane provides poor burners.

  • Page 97: Gas Leaks

    Back to section menu Maintenance and cleaning Gas leaks Thetford recommends an annual inspection As soon as you smell gas: service by an approved service centre. • Ensure that all burners are turned off. Between annual servicing, clean the appliance •...

  • Page 98: Trouble Shooting

    Back to section menu HOB T ROU B LE S H OOT ING Trouble shooting Problem Problem cause Solution Burners do not burn or Gas bottle is empty Fill bottle burn unevenly Gas tap is closed Open tap Burner caps are not correctly Allow caps to cool, then positioned reposition them...
  • Page 99 Back to section menu H O B T EC HN I CAL SP ECI F IC ATI ON Technical Specifications Disposal This application is suitable for use with LPG (liquefied Petroleum Gas) and should not be Your product has been designed and used with any other gas.
  • Page 100 Back to section menu H OB Questions If you have questions about your product, parts, accessories or authorised services: • Visit www.thetford-europe.com • If you cannot solve a problem, contact the authorised local Service Centre or Thetford Customer Service in your country. Warranty Thetford BV offers the end users of its products a three-year-warranty.
  • Page 101 Back to section menu G R ILL Thetford MK3 Mini Grill Note:  (when fitted) • The grill pan supplied is multi functional, for use in grill or oven. WARNING: • The handle design allows removal or • The grill area can get hot when the oven is insertion whilst the pan is in use.
  • Page 102 Back to section menu O V E N 5. Release the knob and turn to required heat WARNING: setting. • Ignition must be carried out with the door 6. If the burner has not lit within 15 seconds, open. release knob and wait at least 1 minute •...
  • Page 103 Back to section menu OV EN Oven Temperture Zones Gas Mark Dish ¼ - ½ 90°C 110°C 130°C Very Cool Meringues 110°C 130°C 150°C Cool Stewed fruit 120°C 140°C 160°C Cool Rich fruit cake, rice pudding 130°C 150°C 170°C Warm Baked custard, shortbread fingers 140°C 160°C...

  • Page 104: Thetford Toilet

    Back to section menu TOI LET & E X T E RN A L B BQ P OINT Thetford Toilet Your Basecamp caravan is fitted with a Thetford C402 toilet. Using this model number, Operation: please read the user instructions for the toilet, Opening the sliding lid which are available from the following location: https://www.dropbox.com/s/...
  • Page 105 Back to section menu EXT ER NA L B B Q P OI N T / EX TER N AL S HOWER P OI N T Whale Water Out Socket with To disconnect, first turn the valve handle back to the OFF position as shown above, then Whale Compact Shower (when slide back the collar to release the connector fitted)
  • Page 106 Back to section menu EXTE RN A L S H OW E R P OINT Push back collar and remove end stop as To remove shower, push back the collar on the shown in the image below. shower outlet fitting, then pull the shower hose connection away from the socket.

  • Page 107: Tv Antenna

    Back to section menu T V ANT EN N A Status directional 5. Tune your television to the strongest signal. You may need to adjust the direction of the TV and FM radio antenna mast to achieve the best quality picture. Your Basecamp caravan is fitted with a 6.

  • Page 108: Bedding

    Back to section menu B ED DI N G / DOOR SC RE E N Bedding Exterior Door Key WARNING: Care should be taken not to leave the exterior door key in the door when unlocking the door. The key may result in damage in the vehicle side if the door is released with the key still in the lock.

  • Page 109: Rooflights

    Back to section menu W IND O W S / ROOF L IG HT Windows Therefore for optimal window life it is recommended:- To open all window types push the central button with your thumbs and turn the internal • Blinds starting at the bottom of the window a handles through 90 degrees and push open gap should be provided for ventilation at the the window.

  • Page 110: Shower Use

    Back to section menu TABL E STORAG E / SHOW E R / AW NING Table storage Before driving IMPORTANT: All rooflights must be locked To avoid damage care must be taken when down before travelling and both roller blinds removing tables from their stored position.

  • Page 111: Tv Brackets

    Back to section menu C O L OU R REF EREN CE / TV B R A CK E T / B ONDE D R OOF / S TEP O N HI TCH C OVE R / MOT OR MOV E R Care points Colour reference Whilst all the seams on your awning are taped...
  • Page 112 Back to main menu MA INT E N A N CE Fenix work sufaces ......................112 ® Vehicle modification and non-standard parts ................ 114 Caravan movers ........................114 Caravan exterior ........................114 Condensation ........................115 Caravan interior maintenance ....................116 Winterisation/storage ......................
  • Page 113 Back to section menu FENIX W ORK S U RFACES FENIX Work surfaces Type of dirt Recommended cleaning products Ordinary maintenance and method FENIX NTM surface should be cleaned regularly but does not require any special Syrup, fruit juice, Water with a sponge maintenance, just a damp cloth with warm jam, spirits, milk, tea, water or mild detergents.
  • Page 114 Back to section menu General precautions Maintenance Instructions Iron For best results in cleaning FENIX NTM, it is important to remember certain precautions: - although very durable, the surface of FENIX NTM must still never be treated with products containing abrasive substances, abrasive sponges or unsuitable products, such as sandpaper or steel wool;...

  • Page 115: Caravan Movers

    The Swift Group WARNING: Do not wash your caravan Warranty. with a high pressure washer as these can...

  • Page 116: Condensation

    Back to section menu CON DE NS AT ION a pin or sharp object, and replaced when the In the enclosed space of a caravan, the moist panes are dry. Care should be taken when air from the kitchen or bathroom areas will doing this.
  • Page 117 Back to section menu C O ND ENSATI ON AN D I N TERI O R MA INT E NA N CE d. After showering, keep the bathroom window (where the vehicle is not in use), we or skylights open, and shut the bathroom recommend the use of well fitted breathable door long enough to dry off the room.
  • Page 118 Back to section menu S WI FT S H IE LD FA B RIC / I N TE RIOR MA INT E N A N CE Swift Shield Fabric Work Surfaces You should not stand very hot items on any (optional) of the work surfaces, especially models with The Swift Shield fabric fitted to some Swift...
  • Page 119 W INT ER I S ATI ON Winterisation Furniture A simple wipe over with a damp cloth should The Swift Group recommends the following be all that is required. Polishing with a winterisation points for customers: proprietary brand of wax polish enhances and maintains furniture in showroom condition.
  • Page 120 Back to section menu W IN T E RIS AT ION • The battery should not be adversely affected Exterior (Body / Chassis) by winter temperatures but the level of • Ensure that all windows, skylights and charge should be maintained to maximise access doors are closed and secured.
  • Page 121 Back to section menu WI NT ER IS ATI ON Water system After a short while the majority of water will have left the plumbing system. At this point Water expands as it is frozen, and so trapped however it is still important to ensure that the water, when it expands, can damage the tap pump itself is 'dry'.

  • Page 122: Al-Ko Chassis

    Back to section menu A L - KO CH A S SIS AL-KO chassis Galvanised Parts Wet storage stain (white rust) Manufactured from high quality steel, the Hot dip galvanising has been used for many chassis has extra deep sections to provide years throughout the automotive industry and strength at points of maximum stress.

  • Page 123: Al-Ko Atc Control System

    Back to section menu AL-K O AT C CON TROL SY STEM WHERE FI TTED Display Diagnosis What to do Outcome Status Colour Condition Green ATC Active Everything Green ATC Active Self test Drive forward Green Ready for journey Flashing incomplete to detect (Constant)
  • Page 124 Back to section menu AL -K O ATC CON T ROL S Y S T E M Damage to chassis members through impact ATC draws power from the towing vehicle etc, MUST NOT be straightened or welded. towbar and requires connection to either: Twin Damaged chassis members MUST be * ATC stores operating errors in a log file which replaced.
  • Page 125 Back to section menu AL- K O ATC CON TRO L SY STEM The AL-KO formula optimum safety The AL-KO formula for optimum safety is a combination of industry leading technology that ensures the safest possible driving conditions for caravan owners. The formula provides total confidence and control when towing a caravan.
  • Page 126 Back to section menu AL -K O ATC C ONT R OL S YS T E M 7-Pin Connection caravan lighting is fully operational and check the vehicle is loaded appropriately, the nose ATC can be connected via the auxiliary 12S weight and tyre pressures are correct, and (white/grey) plug and requires power on confirm that the caravan is coupled to the...
  • Page 127 • Order - CHA402248 • Qty – 1 of 2 • Date - 3 May 05 • Type - B850-10 Fig. 4 • Capacity - 1000E Please consult your Swift Group Dealer to confirm if this is possible.

  • Page 128: Axle Types

    Back to section menu A XLE Axle types Note: The hub bearing is not protected against water ingress. Check wheel brake Safety Precautions linings for wear every 10,000 kilometers No welding is permitted on AL-KO Axles (6200 miles) or every 12 months via the inspection hole It is important that the wheel and hub / brake drum are compatible.
  • Page 129 Back to section menu AXLE Figs. 7, 8 & 9 show the deformation of the No attempt should be made to remove rubber elements at the extremes of the bearing. In the event of damage to the suspension movement. bearing or drum, only the drum complete with bearing and circlip will be available as The axle is designed to ride with the a spare.
  • Page 130 Back to section menu AL - KO AT C BR A KING S YS T E M 5. ALWAYS rotating the road wheel in the 12. OVER ADJUSTMENT of either the wheel forward direction - NEVER backwards; brakes or linkages, will result in difficult adjust the starwheel with a suitable reversing causing the wheels to “lock-up”.
  • Page 131 Back to section menu AL-K O B R EAK I N G S YS TEM AD J U S T ME NT S Figure 10 Brake Linkage Figure 11 Adjusting the Starwheel Figure 12A Standard Brake Linkage Figure 12B Brake Linkage with ATC Fitted...

  • Page 132: Stabilisers And Coupling Devices

    Back to section menu A K160 COU P L IN G Stabilisers and coupling devices SAFETY PRECAUTIONS Always ensure that the coupling head is properly connected to the tow vehicle’s towball every time you couple up. If this procedure is not carried out correctly, the caravan/ trailer may become detached from the towing vehicle! Maximum possible articulation of the...
  • Page 133 Back to section menu AK 1 6 0 C OU P L IN G AK160 Coupling Uncoupling Operating Instructions Open the coupling handle and lift the coupling head from the towball by using the jockey Coupling Up wheel winding handle. Wear indicator A wear indicator on the coupling head (Fig 15) shows whether the wear limit of the towing...

  • Page 134: Overrun Device

    Back to section menu A K160 COU P L IN G Overrun Device Caution: The breakaway cable operates the handbrake (emergency brake), in the In the importance of safety, please familiarise event of the caravan becoming detached yourself with the operation of this overrun from the towing vehicle during towing.
  • Page 135 Back to section menu AK 1 6 0 C OU P LI N G SPARE PARTS COMPLEMENTARY PRODUCTS AL-KO Security Device Spare parts are safety critical parts! For this reason when fitting spare parts in our products AL-KO Security Devices provide a substantial we recommend the use of original AL-KO deterrent against the theft of the caravan or parts or those parts that we have explicitly...
  • Page 136 Back to section menu T R OU BLS H OOT IN G Trouble shooting & fault finding Table 1 Axles Fault Cause Remedy Poor Braking Linings worn or damaged. Replace Brake Linings. Brake Linings not bedded in. Will pass after braking a few times. Brake set up incorrect.
  • Page 137 Back to section menu T R OU BLESHO OTIN G Table 2 Coupling Heads Fault Cause Remedy Coupling does Ball diameter too large. Change ball to correct size. not engage onto Ball could be damaged or Fit new ball. ball deformed.
  • Page 138 Back to section menu A CCE S S ORIE S Accessories Corner Steadies Corner Steadies are as stated, for the purpose of steadying the caravan corners. They are NOT JACKS AND SHOULD NEVER BE USED AS SUCH. The screw and pivot pins should be lubricated periodically to ensure Side Lift Jack 2 Tonne Jack...
  • Page 139 Back to section menu B AS ECAMP TECHN I CAL IN F OR MAT ION Model Basecamp Basecamp Plus Berths Number of Axles Internal Length (At bed box height) 3.42m / 11'3" 3.42m / 11'3" 2.28m / 7'6" 2.28m / 7'6" Overall width** Overall height** (including TV Aeriel) 2.58m / 8'5"...

  • Page 140: Bulb Replacement

    Back to section menu B U LB R E P LA CE M EN T Bulb Replacement (Interior and Exterior lighting) All of the lighting inside and outside of the Basecamp, including road lighting, is 12v LED. The light fittings contain no user serviceable parts.
  • Page 141 Back to section menu W IR ING DIAG RAM - RO AD L I G H TI NG...
  • Page 142 Back to section menu WI RI N G DIAG RAM - C ON SU M ER CIRCU IT S...
  • Page 143 Back to section menu W IR I NG DIAG RAM - CON SU M ER C IR CU IT S R OOF...
  • Page 144 Back to section menu WI RI N G DIAG R A M - P OW E R CIRCU IT S...
  • Page 145 Back to section menu W IR ING DIAG RAM - 230V C I RCU IT S...
  • Page 146 Back to section menu WI RI N G DIAG RA M - 13 P IN S OCK E T...
  • Page 147 Back to section menu W IR I NG DIAG RAM - CAB LE C OL OU R C H A RT...
  • Page 148 Back to main menu US EF U L INFO RMAT ION Owners Club ......................... 148 Spares and after sales Supercare ..................148 Repair facilities ........................148 Caravan Clubs ........................149 Motoring Associations ......................149 Trade Association ........................149 Change of ownership ......................

  • Page 149: Owners Club

    Swift Group Dealer Network, from door catches through to spare wheels. Please note, all parts enquiries must be directed through your dealer, as the Swift Group does not operate a direct retail service. We endeavour to supply parts for vehicles up to 8 years old.

  • Page 150: Caravan Clubs

    Motoring Associations Automobile Association (AA) Fanum House, Basingstoke, Hants. RG1 2EA Tel: 08705 448866 www.theaa.co.uk e-mail: customer.services@theaa.com RAC Motoring Services 8 Surrey St. Norwich Norfolk NR1 3NG Tel: 01922 437 000 www.rac.co.uk © 2017 SWIFT GROUP LTD...

  • Page 151: Change Of Ownership

    Back to section menu Change of ownership Notification of change of ownership As the new second hand owner, please notify the Swift Group of the change of ownership by completing this page, detaching it and sending it to: Customer Services Department...
  • Page 152 Back to section menu CH A NGE OF OW N E RS H IP Details of Model: caravan: Chassis No: Name: owner: Address: Email: Telephone: Mobile: Date of purchase: Previous Name: owner: Address: Email: Telephone: Mobile: Date of purchase:...

  • Page 153: Index

    Back to section menu I ND EX Symbols Bedding ..........107 Bluetooth Pairing ........71 12 Volt DC Fuses ........66 Breakaway cables ........23 13 pin connection ........53 Bulb Replacement Interior and 13 pin socket ........... 21 Exterior lighting ........139 230V mains electrical equipment power consumption ...........

  • Page 154: Whale

    Back to section menu Electrical Operation of Whale Space Habitation relay ........85 Heater ............. 91 Heating Controls ........69 Electrical operation of Whale Water Heater 90 Hitching-Up ..........18 Electrical overseas connection ....52 Escape paths .......... 32 Jacking points ......... 27 Exterior 230V Whale Mains Electric Out Socket (when fitted) ......
  • Page 155 Back to section menu IN D EX Repair facilities ........148 Residual Current Device & Miniature Table storage ......... 109 Circuit Breakers ........63 Temperature Readings ......71 Reversing ..........25 The electrical system ....... 52 Roller blind advice ......... 108 Thetford hob 900 Series ......

  • Page 156: Whale

    Back to section menu Water faults ..........44 Water Out Socket with Whale Compact Shower ..........104 Water Pump Operation ......67 Water pump pressure switch adjustment . 42 Water system .......... 38 Water system trouble shooting ....41 Whale Space Heater ........ 91 Whale water heater ........
  • Page 157 Back to section menu U S EFUL IN F ORMATI ON All Swift Group models have been certified by CRiS is the Central Registration & Identification the National Caravan Council for compliance Scheme that issues touring caravan with stringent European Standards, British...
  • Page 158 Back to section menu U SE F U L INF ORMAT ION Your Touring Caravan Registration Document For help, support and advice Contact CRiS: will include a 17 character VIN (Vehicle NCC CRiS Ltd Identification Number), shown in the top PO Box 445 right hand corner.
  • Page 159 CREATING SMILES FOR LIFE SWIFT GROUP Dunswell Road Cottingham East Yorkshire HU16 4JX Tel: 01482 875740 Fax: 01482 840082 Email: enquiry@swiftgroup.co.uk FIND OUT MORE AT SWIFTGROUP.CO.UK Brochure Layouts Social Dealer Video...

Table of Contents
