Summary of Contents for KitchenAid KSVC 3610
- Page 1 Instructions for use...
-
Page 3: Table Of Contents
Control panel Preliminary instructions for use Preparing vacuum bags and containers Machine operation indications Routine maintenance reminders Messages and Reminders Troubleshooting guide After-sales Service General reminders Electrical connection KitchenAid front panel in stainless steel with anti-fingerprint surface finish Technical data... -
Page 4: Before Using The Appliance
Before using the appliance Your new appliance is designed exclusively for domestic use. To get the most out of your new appliance, read the user handbook carefully as it contains a description of the appliance and some useful tips. Keep this handbook for future consultation. 1. -
Page 5: Advice For Safeguarding The Environment
Advice for safeguarding the environment 1. Packing competent local office, the household waste The packing materials are 100% recyclable and are collection service or the shop where you marked with the recycling symbol . Disposal purchased it. must be carried out in accordance with local regulations. -
Page 6: Precautions And General Recommendations
Precautions and general recommendations • The appliance must be handled and installed by • Before carrying out any maintenance or cleaning two or more people. operation, unplug the appliance or disconnect • During these operations, always wear the electrical power supply. protective gloves. -
Page 7: Control Panel
KitchenAid bags are disposable: after use, discard them, complying with local regulations on the disposal of plastics. KitchenAid bags are not suitable for cooking in traditional ovens or on conventional hobs, as they are not designed to withstand high temperatures (above 100 °C - 212 °F). - Page 8 When using KitchenAid containers, use the specific cycle only (cycle for containers/jars): the higher vacuum level achieved with the cycle for bags could result in damage to the container.
-
Page 9: Preparing Vacuum Bags And Containers
2. Switch the machine on using the blue switch on the front right hand side. 3. Select the size of KitchenAid bag best suited to the dimensions of the food (15x25 or 20x20). 4. Open the lid, making sure the vacuum chamber is dry. - Page 10 Always check that the seal is on top of or parallel to the dotted line on the KitchenAid bag. Moreover, check the effectiveness of the seal: after sealing, it must not be possible to pull the edges of the bag apart.
-
Page 11: Machine Operation Indications
Wait for approximately 20 seconds and the acoustic signal before starting another cycle. Vacuum cycle for KitchenAid containers At the start of each cycle, a brief acoustic signal is emitted. -
Page 12: Routine Maintenance Reminders
Routine maintenance reminders WARNING It is forbidden to remove the safety covers and devices in order to carry out routine maintenance operations. Both routine and non-routine maintenance must be carried out by a qualified technician in compliance with the manufacturer's instructions and current regulations in the country of installation. -
Page 13: Messages And Reminders
Before using again, check the machine is in good working order and clean it thoroughly again. MALFUNCTION In the event of a malfunction, before calling your KitchenAid Retailer for After-sales Service, check that the power supply cable is properly inserted and that there is no power cut. - Page 14 If the problem is not resolved, the alarm condition as described will persist. Before calling your authorized KitchenAid Retailer or After-sales Service, check the lid is closed properly and that the seal is properly located in its seat.
-
Page 15: Troubleshooting Guide
Troubleshooting guide Problem solving table FAULT POSSIBLE CAUSES SOLUTION All the led indicators on the Overheating; damage to electronic Switch the machine off and wait for control panel flash. circuit. approximately 15 minutes to allow cooling and automatic reset of the thermal overload cutouts. -
Page 16: After-Sales Service
After-sales Service Before contacting KitchenAid After-sales If repair work has to be carried out, contact an Service: authorized After-sales Service (use of original 1. See if you can eliminate the problem on your spare parts and proper repair is guaranteed). -
Page 17: General Reminders
General reminders • This manual is an integral part of the appliance and provides all the necessary information for correct installation and maintenance of the appliance. • This manual must be kept in a safe, accessible place for convenient consultation by all authorized users (installer, user, maintenance technician). -
Page 18: Kitchenaid Front Panel In Stainless Steel With Anti-Fingerprint Surface Finish
(see installation diagrams) 595 mm x 455 mm The KitchenAid front panel, made of stainless steel with an anti-fingerprint surface finish, is also available as an accessory. To order it, contact your retailer, requesting the following item:... - Page 20 Printed in Italy 03/12 5019 744 02024/A...
