Operating Your Chromatic Dispersion Analyzer

Selecting the Source Type

Selecting the Source Type
Different sources can be used for testing with your Chromatic Dispersion
Analyzer. The different sources allow you work on either the C-band, the
L-band or the C+L-bands.
FLS-5834, FLS-5804, FLS-5803
FLS-5834A
Note: If you change the source type, you must perform a new reference
measurement. For details, see Performing Reference Measurements on
page 28.
To select the source type:
On the Parameters tab, select the desired source in the corresponding list.
26
Source Type Available Bands
C, L, C+L
C+L
FTB-5800
