Summary of Contents for Stewart Golf X3R

Page 1 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Stewart Golf Limited could void the users authority to operate the equipment. Stewart Golf Limited...
Page 2 Owners Manual Contents Welcome The Anatomy Of Your X3R To Start Using Your New X3R Getting The Best From Your X3R To Help Conserve Battery Power X3R Handset Information Other X3R Information & Tips Trim Adjustment Cruise Control Quick Release Wheels...
Page 3 Please try to avoid the temptation of going straight out to the course to use your new X3R, and take a few minutes to read this manual so that you can get the best from your X3R. • The first thing that you need to do is remove the battery and charger from their respective boxes and put the battery on charge.
Page 4 • never let it run out of your sight. R 8-Oct-05 / P 27-Jul-06 - 3 -...
Page 5 The Anatomy Of Your X3R X3R is made from an innovative system of bonded composites and precision injection mouldings. The drawings below show the basic anatomy of the machine, with the major parts labeled. These parts will be referred to in this manual.
Page 6 These are the only places from which you should lift the X3R. 2. With the X3R placed on the floor, hold the Fig 1: Removing the front cover handle and pull it up and towards you until both top and bottom clips snap into place.
Page 7 (fig 3). • Your X3R is designed for use on the fairway. Do not attempt to drive the X3R through bunkers or deep puddles. Do not attempt to drive your X3R down steps or off high kerbs.
Page 8 Press and release to bring the X3R to an immediate stop. Do not use this as a matter of course as it may cause the X3R to skid. This function can also be used as a parking brake when on slopes, however it is still recommended that the X3R be parked ‘across’...
Page 9 Remove the old battery, and then press every button before connecting the new battery. Now carefully replace the two halves, ensuring that the battery lead is not obstructing location, and replace the screws, making sure they are not over- tightened. R 8-Oct-05 / P 27-Jul-06 - 8 -...
Page 10 You can then make the X3R drive to you. • If you are a right-handed player, park the X3R to the right of the ball so that it does not interfere with your shot.
Page 11: Cruise Control
This can be done from the handset by following these easy steps: 1. Ensure that your X3R is on a flat level surface. It is useful to align the caddy with a curb or object in the distance so that you know when the X3R is moving in a straight line.
Page 12: Quick Release Rear Wheels
Now just lift the side of the X3R and pull off the wheel. The X3R has a built in freewheel setting so that you can always finish your round even in the unlikely event of a fault.
Page 13 • To attach your sunglasses or spectacles, slide one arm through the loop until they rest on the hinge. Be aware that if the X3R is operating on rough terrain, e.g. a bumpy path, then it is possible for your glasses to 'bounce' out of the loop. This problem is much less of an issue on a smooth fairway.
Page 14 2. Remove the front cover, disconnect and remove the battery, then replace the cover as described earlier. It is possible to leave the battery in place when transporting the X3R. This is not recommended, as lifting the combined weight of the X3R and battery can cause injury.
Page 15 Power On. This light will remain on all of the time that the battery is connected. Means that the battery is flat. In this situation, you can make use of the ‘freewheel’ position on the rear wheels and use the X3R like a regular trolley. Yellow Transmitter sending and receiving.
Page 16 Breaking this seal increases the risk of moisture entering the case, and reduces the reliability of your X3R. No attempt should be made to open the case and doing so may invalidate the warranty.
Page 17: Battery Charger
Battery Your X3R has been supplied with a superior Gel technology battery. Correct treatment of the battery will result in increased life and better performance. Observing the following tips below will help achieve this. • Treat the battery with care, as any damage can result in a dramatic reduction in the life of the battery.
Page 18: Battery Charging Safety
• Once the power is connected correctly, the charger will automatically diagnose which type of charge the battery needs - you don’t have to do anything! • A full charge of the battery will take up to 8 hours. • If the battery is connected to reverse polarity, no charging will take place. •...
Page 19: After Sales Service And Warranty
(1) year after delivery. If you have any problems with your X3R, all you have to do is contact Stewart Golf. We will do everything we can to make good any problems and get you back on the course as quickly as possible.
Page 20 high-pressure jet washers as this increases the possibility of moisture entering the motors, gearboxes and electronics. R 8-Oct-05 / P 27-Jul-06 - 19 -...
Page 21: Troubleshooting Guide
The main battery is flat Allow the charger to complete an entire cycle (page 13/14) You may be out or The X3R has a range of 50m, but the range range can also be affected by numerous other factors. I can hear the motors...
