Magnavox MTFT750 Owner's Manual

7 inch tft screen portable dvd/cd player
Hide thumbs Also See for MTFT750:

Advertisement

Table of Contents

7 INCH TFT SCREEN
7 INCH TFT SCREEN
PORTABLE DVD/CD PLAYER
PORTABLE DVD/CD PLAYER
PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
Model: MTFT750
Owner's Manual
Size: 148.5(W) x 210(H)mm (A5)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTFT750 and is the answer not in the manual?

Questions and answers

Janet L Mills
February 6, 2025

How do i get a new remote? Mine has been misplaced

User image 67a4af7f0aa73
0

Related Manuals for Magnavox MTFT750

Summary of Contents for Magnavox MTFT750

  • Page 1 7 INCH TFT SCREEN 7 INCH TFT SCREEN PORTABLE DVD/CD PLAYER PORTABLE DVD/CD PLAYER Owner's Manual PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model: MTFT750 Size: 148.5(W) x 210(H)mm (A5)

  • Page 2: Important Safety Instruction

    IMPORTANT SAFETY INSTRUCTION The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product`s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT The exclamation point within an equilateral REMOVE COVER (OR BACK).
  • Page 4 IMPORTANT SAFETY INSTRUCTION 17) Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 18) Object and liquid entry Never push objects of any kind into the product through openings as they may touch dangerous voltage points or short out parts that could result in fire or electric shock.

  • Page 5: Notes On Handling

    IMPORTANT SAFETY INSTRUCTION NOTES ON MOISTURE CONDENSA TION: NOTES ON HANDLING: Moisture condensation damages the DVD player When shipping the unit, always use the Please read the following carefully original shipping carton and packing materials. Moisture condensation occurs, for example, when you For maximum protection, repack the unit as it pour a cold drink into a glass on a warm day.

  • Page 6: Disk Compatibility

    DISK COMPATIBILITY To see if a specific function is compatible that accompanies s that may not be compatible In North America, including use the setting in North America, occurs...

  • Page 7: Location Of Controls

    LOCATION OF CONTROLS 14 15 Press to start playback or pause. Press to switch the aspect retio to 4:3 or 16:9. 2. MODE In playback mode, press to stop. Press to enter to disc selection menu.(Function depends on the disc recording). MENU Press to decrease volume level.

  • Page 8: Remote Control

    LOCATION OF CONTROLS REMOTE CONTROL 1. POWER Button POWER 2. VOLUME +/– Buttons MUTE Button 4. GOTO Button 5. Direction Buttons ( Skip Forward Button ( Fast Searching Forward Button ( Play/Pause Button TITLE Button MENU Button AUDIO Button PBC Button REPEAT Button 15.
  • Page 9 CONTROLS TITLE LCD ON/OFF Press to return to disc's title page ( where applicable). Press to turn on or off the LCD display. POWER MENU Press to return to disc's menu page (where applicable). Press to turn to standby mode. Press again to turn on .(For saving battery power, always turn off the unit AUDIO by slide the Power ON/OFF switch to OFF position.)

  • Page 10: Remote Control Battery Installation

    REMOTE CONTROL BATTERY INSTALLATION Battery installation: 1. Press the tab on the battery door and lift off. 2. Install two(2) x "AAA" size batteries into the battery compartment as illustrated following the polarity markings inside battery compartment. 3. Replace the battery door. Safety precautions: Follow these steps when installing a battery in this device: 1.Use only the size and type of battery specified.

  • Page 11: Power Source

    POWER SOURCE Recharge it as follows: The unit has a built- in Lithium-ion rechargeable battery. Charging by supplied AC/DC Adaptor: Charging by supplied AC/DC Adaptor: 1. Connect the small plug from the AC/DC Adaptor to the DC IN Jack on the right of unit. 2.
  • Page 12 CONNECTIONS 1. Connecting to a TV with AV connection cable Connected to the TV Video input jack ( Yellow ) Audio left channel input jack ( White ) Audio right channel input jack ( Red )

  • Page 13: Operation

    OPERATION DVD Playback: the Power Switch to the "ON" position to power on the unit, the Green Indicator 1. Lift up the panel. Slide on the right corner of the front panel will turn on. 2. Press the "OPEN" Button to open the disc tray. Place the disc on the center spindle with the label side facing up.

  • Page 14: Important Notes

    OPERATION Playback of a JPEG ( PICTURE ) MP3 disc: 1. Turn on the player and place the disc into the player as previously instructed. The folder/files list will appear on the screen. 2. Use the Direction Buttons to select and highlight the desired folder then press the OK Button on the Remote Control or ENTER Button on the unit, a file list will appear on the screen.
  • Page 15 CD OR DVD PROGRAMING illustrated press the ( Program ) During CD or DVD playback, Button. The Program menu will appear as below. TT: 02 CH: 01 START NEXT EXIT EXIT START NEXT Use the Arrows and Numeric Buttons to select and set the desired TT (Title), CH (Chapters), or tracks (for CD). Use the Arrows to select and highlight the "START"...

  • Page 16: System Setup

    SYSTEM SETUP Setting Menus: Press stop to get to the main menu, then press the SETUP Button. The setting menu will appear on the screen as ◄, ►, ▲, ▼ Buttons to select the option you would like to change. illustrated below.
  • Page 17 SYSTEM SETUP In Video Setup Page: 1. If Picture is selected, using the Direction and ENTER/OK Buttons to set the picture quality such like Sharpness; Brightness; Contrast; Hue or Saturation as desired. 2. If Panel Display is selected, using the Direction and ENTER/OK Buttons to set the aspect ratio of the panel to 16:9 or 4:3 to match the aspect ratio of the playing movie.

  • Page 18: Care And Maintenance

    CARE AND MAINTENANCE Caring for Discs Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to contact with the shiny, unprinted side of the disc. Do not attach adhesive tape, stickers, etc. to the disc label. Clean the disc periodically with a soft, lint-free,dry cloth, Never use detergents or abrasive cleaners to clean the disc.

  • Page 19: Specifications

    SPECIFICATIONS Power Source: Built-in DC 7.4V; 1200mAH (8.88WH) Lithium-ion rechargeable battery, recharge by DC 9-12V, through DC IN Jack Power Source of Remote Control: DC 3V, 2 x AAA Size Batteries (included) Disc Compatibility: DVD/ CD/CD-R/CD-RW/ DVD±R/DVD±RW/MP3/JPEG Play time after fully charge: Approximate 2.5 Hours Accessories 1 x User's Manual 1 x AC/DC Adaptor (Input: AC 100-240V~, 50/60Hz, 0.5A;...
  • Page 20 LIMITED WARRANTY Magnavox warrants this product to be free from manufacturing defects in material and workmanship under normal use for a period of 180 days from date of purchase. If service is required, please return the product to the store where it was purchased for exchange;...
