  • Page 1 230T GRAPHITE SERIES 230T MID-TOWER PC CASE ® INSTALLATION GUIDE...
  • Page 2 Installation Guide Accessory Kit Rubber fan mounts Fan screws (short) Fan screws (long) At Corsair, we believe that no matter GRAPHITE SERIES ® 230T your budget, building your own PC should be easy, and have great looking results. You've made a good choice with the Graphite Series 230T.
  • Page 3 GRAPHITE SERIES 230T MID-TOWER PC CASE GRAPHITE SERIES 230T MID-TOWER PC CASE ® ® Dual 120mm/140mm fan mounts compatible with 240mm/280mm radiators Built-in cable routing cutouts (x2) USB 3.0, Headphone/Mic, Power/Reset Dual 120mm fan mounts CPU backplate cutout Removable dust filters (x3) Tool-free optical drive bays Tool-free 3.5"...

  • Page 4: Removing The Side Panels

    > Align the motherboard with the stando s in the case. > Secure with the included screws (MBD/HDD screws). Note: Corsair recommends that both side panels are completely removed and set aside when building your system to avoid accidental damages.

  • Page 5: Installing The Pci-E/Pci Cards

    Installing the power supply (PSU) Installing the PCI-E/PCI cards > Remove thumbscrews and corresponding slot cover(s). > Unscrew and remove the PSU mounting bracket. > Install the add-on card and secure with thumbscrews. > Place the PSU on the bottom of the case with the fan side facing outwards. >...
  • Page 6 Installing a 5.25" drive/devices (ODD) Installing a 3.5" HDD/ 2.5" SSD > Place the drive into the tool-free cage until you feel it secure. > Remove the front panel 5.25" drive bay cover. > To remove the drive, pull the tabs to release. >...

  • Page 7: Installing The Front I/O Connectors

    Attach case fan cables to motherboard headers Installing the front I/O connectors > See your motherboard manual for front panel header locations and pin-outs. > See your motherboard manual for fan header locations. USB 3.0 HDD LED POWER SW POWER LED – HD AUDIO RESET SW POWER LED +...
