- Page 1 SC-3008-DL SEQUENTIAL CIRCULATOR Operating Instructions U.S. BASED MANUFACTURER Quality Medical Products Since 1983...
-
Page 2: Table Of Contents
Table of Contents Introduction ......................3 Device Description and Operating Principle ............. 3 Package Contents ....................3 Intended Use ......................4 Contraindications ....................4 Important Safety Tips ................... 4 Description of International Symbols ..............5 General Equipment Specifications ..............6 Environmental Conditions ................... -
Page 3: Introduction
INTRODUCTION Congratulations on the purchase of your BIO COMPRESSION SYSTEMS MODEL SC-3008-DL Sequential Circulator Device system and garments. DEVICE DESCRIPTION AND OPERATING PRINCIPLE: The Model SC-3008-DL Sequential Circulator provides gradient pneumatic compression for the treatment of lymphedema and associated venous disorders. -
Page 4: Intended Use
INTENDED USE: The Model SC-3008-DL Sequential Circulator is a pneumatic compression device intended for either primary or adjunctive treatment of primary or secondary lymphedema. The device is also intended for additional or alternate treatment of venous insufficiency and chronic venous stasis ulcers associated with venous insufficiency as well as general treatment for swelling of the extremities. -
Page 5: Description Of International Symbols
Symbol Explanation Refer to Documentation before using and servicing CAUTION Type B - applied part. Electrical shock hazard. Disconnect LINE CORD before servicing; refer servicing to qualified service personnel. Federal (USA) law restricts this device to sale by or on the order of a physician. -
Page 6: General Equipment Specifications
GENERAL EQUIPMENT SPECIFICATIONS: DIMENSIONS: 4.5” H x 11.75 W x 7.75” D WEIGHT: 5.5 lbs INFLATION: 54 Seconds DEFLATION: 6 Seconds CYCLE TIME: 6.5 Seconds / Chambers ELECTRICAL: 120 VAC, 60 Hz, 0.5 A APPLIED PART: TYPE B PROTECTION AGAINST ELECTRICAL CLASS II SHOCK OPERATION MODE:... -
Page 7: Front Operating Panel
FRONT OPERATING PANEL: Figure 1, Front of Pump Key Function 1. POWER ON/OFF BUTTON 2. MODE BUTTON 3. INCREASE BUTTON 4. DECREASE BUTTON 5. LED DISPLAY 6. CHAMBER NUMBER LED 7. RECEPTOR PORTS FOR TUBING LATCH CONNECTORS PORTS #5-8 PORTS #1-4 Figure 2, Latch Connectors on the ends of the garment tubing 8. -
Page 8: 8-Chamber Garment
8 Chamber Garment: Garments are available in the size and configuration to ensure both an effective treatment and maximum comfort. Please refer to section (2.5 Putting the garment on) in the operating manual for instructions on how to apply your garment. LATCH CONNECTORS: Attach and detach the garment to the pump. - Page 9 3.4 As the pump starts to run through its cycle, the number that shows in the LED Display (5) is the countdown timer. The SC-3008-DL includes a automatic shutoff timer. To run the pump in continuous (untimed) mode, see Section 6.
-
Page 10: Guidelines For Treatment
END OF TREATMENT The pump powers down one of two ways: 1) After your 60 minute treatment is complete 2) You press the “Power On/Off” (1) button while the pump is running. 4.1 When your treatment is over, wait one minute before taking off the garment. 4.2 Squeeze the LATCH CONNECTOR and pull outward to remove garment from pump. - Page 11 PROGRAMMING YOUR PUMP TO OPERATE IN DIFFERENT MODES The SC-3008-DL can run in a number of different modes, all of which are set in the following manner: 6.1 With the Pump off, press the “Power” On/Off button.
-
Page 12: Important Usage Information
HOUR METER 7.1 The hour meter is displayed for 5 seconds each time you turn on your pump. The num- bers in the “LED Readout” show the 1-999 hours, the letter in the “Chamber Number LED” indicates the following: A. Less than 1000 hours B.= 1000 - 2000 hours C.= 2000 - 3000 hours D. - Page 13 3. Cleaning solution should consist of 1/3 cup of laundry detergent per 1 gallon of warm tap water. Use either a large sink or plastic tub able to hold enough solu- tion (depending on size and quantity of garments) to completely submerge the garment leaving the latch connector bars out of the water.
-
Page 14: Garment Specifications
8 CHAMBER GARMENT SPECIFICATIONS: PRODUCT APPLICATION SIZE SIDE G8-3035-S Small G8-3035-M Medium G8-3035-L Large G8-3035-SH/S Arm & Shoulder Small G8-3035-SH/M Arm & Shoulder Medium G8-3035-SH/L Arm & Shoulder Large GV-3010-S-R Arm Elite Bio Small Right GV-3010-S-L Arm Elite Bio Small Left GV-3010-M-R Arm Elite Bio... -
Page 15: Troubleshooting
TROUBLESHOOTING If the corrective action does not solve the problem, then call Bio Compression Systems, Inc., at 1-800-888-0908. Be sure to have serial number available when calling for service. Symptom Possible Cause Corrective Action No electricity Check the electrical wall outlet to be sure that the pump is plugged into the outlet correctly. -
Page 16: Warranty Information
WARRANTY INFORMATION: You can feel confident that your product is backed by the best warranty in the industry covering any and all malfunctions (including parts and labor) resulting from component and/or manufacturing defects. Compression Pump = 3 years from date of purchase / invoice Sleeves/Garments = 1 year from date of purchase / invoice Serial Number: ____________________________________ Date Purchased: ___________________________________... -
Page 17: Classification
EMC Manufacturer’s Declaration Model SC-3008-DL electromagnetic emissions—manufacturer’s declaration The model SC-3008-DL is intended for use in the electromagnetic environment specified below. The customer or the user of the model SC-3008-DL should assure that it is used in such an environment. - Page 18 Recommended separation distances between portable and mobile RF communications equipment and the model SC-3008-DL The model SC-3008-DL is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer of user of the model SC-3008-DL can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the model SC-3008-DL as recommended below, according to the maximum output power of the communications equipment.
