Packing List
The FWT package box contains the following items. Check the items according to the
following table. If any of the items is missing or damaged, contact your local dealer.
Item
Main unit, handset, and
1
coiled cord
Power adapter
1
FWT User Guide
1
Front View of the FWT
No.
Item
1
Display screen
2
SET/OK key
3
RECEIVED/▲
key
4
▼
DIALED/
key
5
CANCEL key
6
End key
7
HAND-FREE key
8
Call/Redial key
Quantity
Item
Battery
Antenna (optional)
Certificate of Quality
1
2
3
4
5
6
7
8
Function
Displays the current operation of the FWT
Set and save various functions
Access Call In in standby mode
Access Call Out in standby mode
Delete queried information
End or reject a call
End the current operation when setting parameters
Press and hold it to switch on/off the FWT
Make a call or receive an incoming call without lifting the
handset
Dial the telephone number on the screen
Answer the call when there is an incoming call
Quantity
1
1
1

Advertisement

Table of Contents
loading

Related Manuals for Huawei QISETS2205

Summary of Contents for Huawei QISETS2205

  • Page 1 Packing List The FWT package box contains the following items. Check the items according to the following table. If any of the items is missing or damaged, contact your local dealer. Item Quantity Item Quantity Main unit, handset, and Battery coiled cord Power adapter Antenna (optional)

  • Page 2: Back View And Side View

    Back View and Side View Item Item Antenna jack Power jack Data port Battery cord jack Battery container cover Coiled cord jack on main unit Battery case UIM card slot Hook Screen Icons Item Description Indicates the signal strength. The more the bars are, the stronger the signal is.

  • Page 3: Installing The Battery

    Installing UIM Card (Optional) Caution: Whether an UIM card is needed, consult your service provider for details. The UIM card and its golden contact can be easily damaged by scratch or bending. Thus, be careful when installing or removing the UIM card. After power off the FWT and disconnect the power, install or remove the UIM card.

  • Page 4: Making A Call

    Vertically Pull out the handset retaining clip from the slot turn it around and then push it back so that the handset will not fall down when the FWT is placed vertically. According to the distance between the two hooks (7.7 cm), hammer two nails into the wall with a 3 mm end left outside.

  • Page 5: Answering A Call

    Answering a Call In standby mode, you can lift the handset, press or press to answer a call. Note: In standby mode, press to reject the incoming call. Caller ID display function is network dependent. Consult your service provider. Options During a Call To switch a call from the handset to the hands-free mode, press , and then put back the handset when the icon...

  • Page 6: Setting Ring Volume

    Make a Call When the Long Distance Lock Is Enabled When the long distance lock is enabled, adopt method 2 of Making a Call. Follow these steps: Enter the long distance number you want to dial. Press to display code. Enter the password.

  • Page 7: Maintenance

    Maintenance The FWT should be deployed in a clean and dry environment. A temperature higher than 55°C or lower than –10°C may damage the FWT. If the FWT is covered with dust, clean it with a clean fine cloth. Do not clean the FWT with cleanser or other chemical solvents.

  • Page 8: Warnings And Precautions

    Warnings and Precautions To use HUAWEI Fixed Wireless Terminal (FWT) correctly, efficiently and safely, you should notice following cautions. Basic Cautions Check fittings based on the packing list to make sure they are complete and undamaged. Read this manual carefully before installing and using FWT.

  • Page 9: Fcc Statement

    The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons. Please observe the national local regulations in the location where product is to be used. This product may be restricted for use in some or all countries of European Union.
  • Page 10 HUAWEI are trademarks of Huawei Technologies Co., Ltd. All other trademarks mentioned in this manual are the property of their respective holders Please refer color and shape to product. Huawei reserves the right to make changes or improvements to any of the products without prior notice.
