1-1 Introduction.
Thank you for your purchase of USB2BT. You can connect your favorite USB HID device such
as keyboard, mouse or gamepad to smartphone or PC with USB2BT, USB HUB and Bluetooth
dongle (version 2.1 or later). Before using USB2BT, please read this user's manual carefully,
and keep this manual at hand.
1-2 Package contents.
-
USB2BT unit
-
User's manual
-
Hole positioning sticker
-
USB HUB
(not attached to the kit version).
2-1 Product specification.
Supported operating
system
(Bluetooth is necessary)
Connector
Wireless format
Wireless specification
Pairing system
Power
Android 4.0 and later
iOS(except for iphone3G, first/second generation iPod touch)
Windows 7 and later / MAC OSX/ PS4
USB TypeA connecter (USB1.1 full speed)
Bluetooth2.1EDR and later, HID profile
dependent on Bluetooth Dongle
SecureSimplePairing, always waiting for pairing.
5V (supplied via USB miniB connector)
Advertisement
Summary of Contents for Bit Trade One USB2BT
-
Page 1: Package Contents
1-1 Introduction. Thank you for your purchase of USB2BT. You can connect your favorite USB HID device such as keyboard, mouse or gamepad to smartphone or PC with USB2BT, USB HUB and Bluetooth dongle (version 2.1 or later). Before using USB2BT, please read this user’s manual carefully, and keep this manual at hand. - Page 2 Working temperature 0 - 40℃（No condensation) Country of origin Made in Japan Size W74×D28×H10mm(not include a pointed projection) Weight Package contents body/hole positioning sticker/manual/USB Hub(outside goods) 2-2 Necessary equipment To use this product, you will need USB HID device and the following devices: USB-Bluetooth Dongle (version 2.1 or later).
- Page 3 Prepare the USB HID device, Bluetooth Dongle, USB HUB, USB AC Adaptor, and USB MiniB Cable, then connect them as following picture 4-1 Check the connection. Please check that the POWER LED is ON and STATUS LED is OFF in following state. When POWER LED does not turns on, check the connection of USB Adaptor and USB MiniB Cable.
- Page 4 About a risk in the use of this product Because this product is always waiting for pairing, there are risks of such USB2BT would be connected from the other device, such as smartphone. So when you enter the password via keyboard, check that USB2BT succeeded in recognize the target system and whether it is possible to input operation correctly.
