Model No. PETL79817.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
390042
USER'S MANUAL
www.iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power 545i and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form Power 545i

Summary of Contents for Pro-Form Power 545i

  • Page 1 Model No. PETL79817.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE 390042 UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 21. The treadmill is capable of high speeds. frame securely in the storage position. Do Adjust the speed in small increments to not operate the treadmill while it is folded. avoid sudden jumps in speed. 26. Do not change the incline of the treadmill by 22.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM POWER manual. To help us assist you, note the product model ® 545 I treadmill. The POWER 545 I treadmill provides number and serial number before contacting us. The an impressive selection of features designed to make model number and the location of the serial number your workouts at home more effective and enjoyable.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 6. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you finish all assembly steps.
  • Page 8 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (81) to the front of the Base (6). Next, identify the Right Upright (90). Have a second person hold the Right Upright near the Base (6).
  • Page 9 4. Hold the Right Upright (90) against the Base (6). Make sure not to pinch the Upright Wire (81). Attach the Right Upright (90) with two 3/8" x 2 3/8" Screws (7), a 3/8" x 1 1/4" Screw (63), a 3/8" x 1 3/4" Screw (62), and four 3/8" Star Washers (13) as shown;...

  • Page 10: Surface To Avoid Scratching The Console Base

    6. If there are two screws (E) preattached inside each Handrail (84), remove and discard the screws. Attach a Handrail (84) to the Right Upright (90) with two 5/16" x 3" Screws (28) and two 5/16" Star Washers (11); start both Screws, and then tighten them.
  • Page 11 8. IMPORTANT: To avoid damaging the Pulse Crossbar (31), do not use power tools and do not overtighten the #10 x 1 1/4" Screws (9). Orient the Pulse Crossbar (31) as shown. Attach the Pulse Crossbar to the Handrails (84) with four #10 x 1 1/4"...
  • Page 12 10. Set the console assembly (G) on the Handrails (84). Make sure that no wires are pinched. Insert the excess Upright Wire (81) into the Right Upright (90). Attach the console assembly (G) to the brack- ets on the Handrails (84) with four 1/4" x 1/2" Screws (4);...
  • Page 13 12. Carefully slide the Upright Crossbar (18) between the Left and Right Uprights (89, 90). Attach the Upright Crossbar with the four 5/16" x 3/4" Screws (8) that you removed in step 5 and four 5/16" Star Washers (11); start all four Screws, and then tighten them.
  • Page 14 14. Remove the 5/16" Nut (34) and the 5/16" x 1 3/4" Bolt (23) from the bracket on the Base (6). Next, orient the Storage Latch (26) as shown. Attach the lower end of the Storage Latch (26) to the bracket on the Base (6) with the 5/16" x 1 3/4"...
  • Page 15 16. Firmly tighten the four 3/8" x 2 3/8" Screws (7), the two 3/8" x 1 3/4" Screws (62), and the two 3/8" x 1 1/4" Screws (63). Next, set the Left Inner Base Cover (50) onto the lower end of the Left Upright (89). Slide the Left Base Cover (82) downward and press it onto the Left Inner Base Cover.

  • Page 16: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
  • Page 17 CONSOLE DIAGRAM FEATURES OF THE CONSOLE To turn on the power, see page 18. To use the man- ual mode, see page 18. To use an onboard workout, The treadmill console offers a selection of features see page 20. To use a custom-focus weight loss workout, see page 21.

  • Page 18: To Turn On The Power

    HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 19 5. Change the incline of the treadmill as desired. To reset the displays, press the Stop button repeat- edly, or remove the key and then reinsert the key. To change the incline of the treadmill, press the 7. Measure your heart rate if desired. Incline increase and decrease buttons or one of the Quick incline buttons.

  • Page 20: To Use An Onboard Workout

    8. When you are finished exercising, remove the 4. Start the workout. key from the console. Press the Start button. A moment after you press Step onto the foot rails, press the Stop button, and the button, the treadmill will automatically adjust to adjust the incline of the treadmill to zero.
  • Page 21 HOW TO USE A CUSTOM-FOCUS WEIGHT LOSS 6. Measure your heart rate if desired. WORKOUT See step 7 on page 19. 1. Insert the key into the console. 7. When you are finished exercising, remove the See HOW TO TURN ON THE POWER on page 18. key from the console.
  • Page 22 3. Connect your tablet to the console. Note: If there is more than one compatible heart rate monitor near the console, the console will connect to Press the iFit Sync button on the console; the the heart rate monitor with the strongest signal. console pairing number will appear in the display.
  • Page 23 HOW TO USE THE SOUND SYSTEM HOW TO USE THE TABLET HOLDER To play music or audio books through the console IMPORTANT: The tablet holder is designed for use with most full-size tablets. Do not place any other sound system while you exercise, plug a 3.5 mm male electronic device or object in the tablet holder.

  • Page 24: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 25: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal per- as shown, the switch has tripped. To reset the formance and to reduce wear. Inspect and properly power switch, wait for five minutes and then press tighten all parts each time the treadmill is used.
  • Page 26 SYMPTOM: The walking belt slows when walked on Locate the Reed Switch (101) and the Magnet (103) on the left side of the Pulley (49). Turn the Pulley until the Magnet is aligned with the Reed a. If an extension cord is needed, use only a 3-con- Switch.
  • Page 27 SYMPTOM: The walking belt is off-center SYMPTOM: The tablet holder does not stay in place The edges of the walking belt should be aligned with a. Rotate the tablet holder backwards. Then, tighten the belt alignment marks (see the drawing below) on the indicated screw slightly until the tablet holder the foot rails.

  • Page 28: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 29 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 30: Part List

    PART LIST Model No. PETL79817.0 R1216A Key No. Qty. Description Key No. Qty. Description #8 x 5/8" Screw Right Inner Base Cover #8 x 3/4" Screw 3/8" Plastic Bushing Base Pad 1/4" x 1 1/4" Screw 1/4" x 1/2" Screw Drive Motor #10 Star Washer Motor Belt...
  • Page 31 Key No. Qty. Description Key No. Qty. Description Reed Switch Filter Clamp Motor Isolator Magnet – User’s Manual Motor Bushing Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual. *These parts are not illustrated.

  • Page 32: Exploded Drawing

    EXPLODED DRAWING A Model No. PETL79817.0 R1216A...
  • Page 33 EXPLODED DRAWING B Model No. PETL79817.0 R1216A...
  • Page 34 EXPLODED DRAWING C Model No. PETL79817.0 R1216A...
  • Page 35 EXPLODED DRAWING D Model No. PETL79817.0 R1216A 66 2...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
