  • Page 1 User Manual...
  • Page 2 OTES The Ovation H-605FC User Manual includes a description, safety precautions, installation, programming, operation and maintenance instructions for the Ovation H-605FC as of the release of this edition. Trademarks CHAUVET, the Chauvet logo and Ovation H-605FC are registered trademarks or trademarks of Chauvet &...

  • Page 3: Table Of Contents

    15 Ch..........................13 Ch..........................12 Ch..........................10 Ch..........................7 Ch..........................5 Ch..........................3 Ch..........................HSV..........................Configuration (Standalone) ................18 Auto Programs ....................... Master/Slave ........................White Balance ........................ Virtual Color Wheel ......................Ovation H-605FC User Manual Rev. 1 TOC 1 of 2...
  • Page 4 6. Te c hnic al S pe c ific atio ns ............Photometrics Chart ..................24 Photometrics Chart ..................25 Photometrics Chart ..................26 7. Re turns ..................8. Co ntac t Us .................. TOC 2 of 2 Ovation H-605FC User Manual Rev. 1...

  • Page 5: What Is Included

    Any reference to data or power connections in this manual assumes the use of Seetronic IP rated cables. The term “DMX” used throughout this manual refers to the USITT DMX512-A digital data transmission protocol. Ovation H-605FC User Manual Rev. 1 Page 3 of 28...

  • Page 6: Before You Begin

    40,000 to 50,000 hours. If extending this lifespan is vital, lower the operating temperature by improving the ventilation around the product, thus reducing the ambient temperature. In addition, limiting the overall projection intensity may extend the LEDs’ lifespan. Page 4 of 28 Ovation H-605FC User Manual Rev. 1...

  • Page 7: Introduction

    NTRODUCTION Description The Ovation H-605FC is a silent LED house light that features full spectrum of hues with RGBAL LEDs. It comes standard with interchangeable lenses for adjustments for differing heights, 5-pin DMX and install terminals for permanent and temporary installations. The product also features 16-bit dimming response, remote device management, and has adjustable PWM (pulse width modulation) to avoid flickering in filmed environments.

  • Page 8: Product Overview

    NTRODUCTION Product Overview Power Input Safety Loop/ Pendent Mounting Yoke Adjustment Alternate DMX Control Panel Data Connection DMX Data Fuse Connection Page 6 of 28 Ovation H-605FC User Manual Rev. 1...

  • Page 9: Product Dimensions

    NTRODUCTION Product Dimensions 9.41 in 6.69 in 239 mm 170 mm 16.57 in 421 mm 12.44 in 316 mm 5.20 in 132 mm 13.31 in 338 mm Ovation H-605FC User Manual Rev. 1 Page 7 of 28...

  • Page 10: Setup

    ETUP AC Power Each Ovation H-605FC has an auto-ranging power supply that works with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the power requirements for each Ovation H-605FC, refer to the label affixed to the product. You can also refer to the Technical Specifications chart in this manual.

  • Page 11: Dmx Linking

    ETUP DMX Linking You can link the Ovation H-605FC to a DMX controller using a 5-pin DMX connection or hard wiring using the Phoenix connector. If using other DMX-compatible products with this product, you can control each individually with a single DMX controller.

  • Page 12: Rdm (Remote Device Management)

    If the Ovation H-605FC has already been paired with the W-DMX transmitter, the Signal Strength Indicator in the middle of the LCD screen will show the strength of the signal. In this case, the Ovation H-605FC is ready to work in Wireless mode. Pairing the Ovation H-605FC and a new W-DMX transmitter From the Ovation H-605FC’s control panel, go to Wireless Setting.

  • Page 13: Mounting

    Procedure The Ovation H-605FC comes with a double-bracketed yoke to which you can either attach mounting clamps for hanging or simply use as a floor stand. You must supply the mounting clamps. Make sure the clamps are capable of supporting the weight of this product. Use at least one mounting point per product.

  • Page 14: Control Panel Operation

    <DOWN> function Control Options Set the Ovation H-605FC starting address in the 001-512 DMX range. This enables control of up to 34 products in the 15-channel 15CH personality. Programming Refer to the Menu Map to understand the menu options. The menu map shows the main level and a variable number of programming levels for each option.
  • Page 15 5000K Temperature Chart section for 5600K specific values. 6000K 6500K Combine red, green, blue, Green amber, and lime to make a (Manual Color Blue custom color Mixer) Amber (0–100%) Lime Ovation H-605FC User Manual Rev. 1 Page 13 of 28...
  • Page 16 Shows total product hours Information Version V_._-V_ _ Shows installed software version _ _ _ _ _ _ _ _ _ _ _ _ Shows product UID Factory Reset to factory defaults Setting Page 14 of 28 Ovation H-605FC User Manual Rev. 1...

  • Page 17: Configuration (Dmx)

    Virtual Color Refer to the Virtual Color Wheel Chart section for  Wheel 1 specific values Color Refer to the Preset Color Temperature Chart section for  Temperature specific values Ovation H-605FC User Manual Rev. 1 Page 15 of 28...
  • Page 18 Preset dimmer speed from display menu  Linear dimmer  Dimmer Nonlinear dimming curve 1 (fastest)  Speed Mode Nonlinear dimming curve 2  Nonlinear dimming curve 3 (slowest)  Page 16 of 28 Ovation H-605FC User Manual Rev. 1...

  • Page 19: Hsv

    Wheel 1 specific values Color Refer to the Preset Color Temperature Chart section for  Temperature specific values Channel Function Value Percent/Setting 0-100%  Saturation 0-100%  Value 0-100%  Ovation H-605FC User Manual Rev. 1 Page 17 of 28...

  • Page 20: Configuration (Standalone)

    The master should be the first product in the daisy chain. White Balance This setting allows for selection of the white balance shown by the Ovation H-605FC when the color setting is RGBAL and the DMX controller’s red, green, blue, amber, and lime faders are set to 255.

  • Page 21: Manual Color Mixer

    Select PWM Frequency (600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, or 25Khz). Back Light This setting allows for selection of the amount of time the back light on the Ovation H-605FC’s display stays on after the last button is pressed on the control panel.

  • Page 22: Emergency Mode

    PERATION Emergency Mode This feature can be set to turn on the Ovation H-605FC in the event DMX signal is lost. Go to the Emergency Mode main level. Select Device ID. Factory Reset This option restores the Ovation H-605FC to the original factory settings.

  • Page 23: Preset Color Temperature Chart

    Note: The color temperatures above are simulated renditions of the color output produced as compared to a tungsten lamp at the specified color temperature. Chauvet makes no guarantee of the color output accuracy. Ovation H-605FC User Manual Rev. 1 Page 21 of 28...

  • Page 24: Technical Information

    Softly drag any dirt or grime to the outside of the transparent surface. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Page 22 of 28 Ovation H-605FC User Manual Rev. 1...

  • Page 25: Technical Specifications

    3, 5, 7, 10, 12, 13 or 15 Ordering Product Name Item Code UPC Number Ovation H-605FC (White) 3031307 781462216559 Ovation H-605FC (Black) 3031315 781462216634 UL 1573 CSA C22.2 No. 166 E113093 Ovation H-605FC User Manual Rev. 1 Page 23 of 28...

  • Page 26: Photometrics Chart

    4.99 m 11.55 m 15 m 7.48 m 17.32 m 20 m 9.97 m 23.09 m 25 m 12.47 m 28.87 m 30 m 14.96 m 34.64 m Field Field Beam Page 24 of 28 Ovation H-605FC User Manual Rev. 1...

  • Page 27: Photometrics Chart

    3.35 m 6.69 m 15 m 5.02 m 10.04 m 20 m 6.69 m 13.38 m 25 m 8.37 m 16.73 m 30 m 10.04 m 20.08 m Field Field Beam Ovation H-605FC User Manual Rev. 1 Page 25 of 28...

  • Page 28: Photometrics Chart

    7.08 m 12.99 m 15 m 10.62 m 19.48 m 20 m 14.16 m 25.98 m 25 m 17.71 m 32.47 m 30 m 21.25 m 38.96 m Field Field Beam Page 26 of 28 Ovation H-605FC User Manual Rev. 1...

  • Page 29: Returns

    Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be your responsibility. FedEx packing or double-boxing are recommended. Chauvet reserves the right to use its own discretion to repair or replace returned product(s). Ovation H-605FC User Manual Rev. 1 Page 27 of 28...

  • Page 30: Contact Us

    Visit the applicable website above to verify our contact information and instructions to request support. Outside the U.S., United Kingdom, Ireland, Mexico or Benelux, contact the dealer of record. Page 28 of 28 Ovation H-605FC User Manual Rev. 1...
