Summary of Contents for Easy Vac PM60
- Page 1 U S E R M A N U A L Model No. PM60 SAVE THESE INSTRUCTIONS Federal (USA) law restricts this device to sale CAUTION by or on the order of a physician. 300 Held Drive Tel: (+001) 610-262-6090 Northampton, PA 18067 USA...
-
Page 2: Explanation Of Abbreviations
This manual instructs a Professional to install and operate the Easy Vac Aspirator. This is provided for your safety and to prevent damage to the Easy Vac Aspirator. If you do not understand this manual, DO NOT USE the Easy Vac Aspirator and contact your Provider. - Page 3 • Caution must be exercised when using this Aspirator where oxygen is being administered. • The Easy Vac Aspirator is not suitable for use in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide. WARNING To reduce risk of burns, electrocution, fire, or injury to persons: • The Easy Vac Aspirator should never be left unattended when running.
-
Page 4: Specifications
SPECIFICATIONS Operating Vacuum Range: 0-25 inHg (0-635 mmHg) dimensions: Length: 13.25 in (33.7 cm) Width: 8.00 in (20.3 cm) Height: 9.75 in (24.8 cm) Weight: 11.4 lbs (5.2 kg) Shipping Weight: 13.7 lbs (6.2 kg) Electrical: 108 -132 VAC, 60 Hz, 5 Amps Operating Temperature Range: 50°F to 104°F (10°C to 40°C) Storage Temperature Range: -4°F to 104°F (-20°C to 40°C) -
Page 5: Component Description
COMPONENT dESCRIPTION CAUTION If for any reason any label becomes illegible or lost, contact Precision Medical, Inc. Patient Vacuum Tubing Gauge Connection Control Knob On/Off Switch Suction Feet Inline Hydrophobic Filter Standard 800cc Suction Canister with Float Shutoff Power Cord Keeper Power Cord... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS CAUTION Inspect the Easy Vac Aspirator for visual damage, DO NOT USE if damaged. 1. Place Easy Vac Aspirator near electrical receptacle on a table, floor or other horizontal, smooth, hard surface. Allow a minimum of 4 in. (10 cm) clearance on all sides to ensure adequate air flow for cooling of Aspirator. - Page 7 8. Connect one end of the Patient Suction Tubing to the port on the Canister marked Patient Tubing. 9. Connect the other end of the Patient Suction Tubing to the suction catheter and begin procedure as instructed by Provider. 10. When procedure is completed, press the On/Off Switch to the “OFF”...
-
Page 8: Cleaning & Maintenance
CLEANING / MAINTENANCE WARNING Turn the Easy Vac Aspirator off and disconnect from any external power source before cleaning. Inline Hydrophobic Filter: This filter cannot be cleaned. If it becomes contaminated or clogged, it must be replaced. To replace Inline Hydrophobic Filter: 1. -
Page 9: Disposal Instructions
dISPOSAL INSTRUCTIONS Dispose of Bio-waste products as described by your Healthcare Professional or Healthcare Facility protocol. Please Recycle WARNING If Aspirator is used for treatment of infectious disease, consult your Physician or Healthcare Professional for recommended procedures for proper disposal. REPLACEMENT PARTS description Part #... -
Page 10: Troubleshooting
TROUBLESHOOTING If the Easy Vac Aspirator fails to function, consult the Troubleshooting Guide below. If the problem cannot be corrected, consult your Provider. Problem Probable Cause Remedy Aspirator will not 1. On/Off switch in 1. Push On/Off switch operate “OFF” position to “ON”... -
Page 11: Limited Warranty
LIMITEd WARRANTY LIMITATION OF LIABILITY Precision Medical, Inc. warrants that EASY VAC Aspirator (the Product) will be free of defects in workmanship and/or material for the following period: Five (5) years from shipment Should any failure to conform to this warranty appear within the applicable period, Precision Medical, Inc. - Page 12 Precision Medical, Inc. 300 Held Drive Northampton, PA 18067 USA Toll Free Tel: 800-272-7285 Toll Free Fax: 800-353-1240 Tel:(+001) 610-262-6090 Fax:(+001) 610-262-6080 1907 Rev10 08/30/12 (?M) P rinted in...
