Power-up Key Combinations

Resetting to Factory Defaults (2-button reset)

A special key combination restores to the drive the current product code default values and
Macro 1 parameter values. This feature is only available at power-up as a security measure.

Changing the Product Code (3-button reset)

On rare occasions it may be necessary to change the default settings by changing the Product
Code. The Product Code is referred to in Chapter 2.
A special key combination is required to change the product code. This feature is only available
at power-up as a security measure.
The 3-button reset will take you to the POWER BOARD menu in the expanded SYSTEM menu
(highlighted in the diagram below).
SYSTEM
IMPORTANT: We recommend the menus marked *above are only used by Parker SSD Drives or
suitably qualified personnel.
Refer to The SYSTEM Menu, page 5-16 for all non-highlighted menus.
690+ Series AC Drive
Hold down the keys opposite:
Power-up the drive, continue
to hold for at least 2 seconds
RESTORE DEFAULTS
"UP" TO CONFIRM
POWER BOARD
LANGUAGE
DEFAULT TO 60HZ
RESTART
EXIT TO BOOT
SAVE CONFIG
RESTORE CONFIG
DELETE CONFIG
www.comoso.com
HOLD
M
E
UPDATES IGNORES
Hold down the keys opposite:
Power-up the drive, continue
to hold for at least 2 seconds
*
POWER BOARD
5.5kW 400V
*
*
POWER BOARD
menu at level 2
5-21
The Keypad
HOLD
E
PROG
for example
M
E
diagram
below
Select from the
expanded SYSTEM menu
see
