4.10.10

Transmission Power Class

NOTICE: This feature is a paid feature.
Transmission Power feature enables your radio to choose whether to transmit with Class 3L or Class
4. The RF Power icon indicates when the radio uses this feature.
4.10.10.1
Selecting RF Power
Use this procedure when you are entering the area that requires higher signal strength.
Procedure:
1 From the home screen, press the Menu key.
2 Select Setup → RF Power.
3 Select one of the following:
• Hi RF Power — Activates this feature.
• Normal RF Pwr — Deactivates this feature.
NOTICE:
• Changing RF Power Class to Normal RF Pwr during calls may result in dropping the
call. The power level may be not sufficient to sustain the transmission.
• Battery consumption is higher when Hi RF Power is selected.
4.10.11
Accessory Setup
You can connect IMPRES, CORE, Other, or Secondary accessories to the radio side connector.
If you connect an IMPRES accessory, the radio detects and recognizes the accessory automatically. If
you connect a CORE, Other (for example, a third-party accessory), or Secondary accessory (for
example, an earpiece connected to an RSM), the radio may detect the connection but manual
selection is required at the Accry Setup menu.
The Accry Setup menu contains the supported accessories, represented by their Model Number as
defined by the related Audio Device Descriptor (ADD). ADD is a set of parameters in the radio that
defines the audio settings, such as gains and filters settings, for each accessory.
IMPORTANT: Do not connect RSMs to both connectors at the same time. To ensure correct
connection, do not press any RSM buttons when connecting the RSM to the radio.
4.10.11.1
Selecting CORE/Other/Secondary Accessories
Procedure:
1 From the home screen, press the Menu key.
2 Select Setup → Accry Setup.
3 Select one of the following:
• CORE RSM/PHF — select an accessory from the list of the CORE accessories.
• CORE Earpiece — select an earpiece from the list of the CORE accessories.
