Summary of Contents for DV Mark DV MICRO 50 II
- Page 1 v.29.march.2017...
-
Page 2: Safety Instructions
MORE INFORMATION For warranty and service information, please contact your local DV Mark distributor (contact information available at www.dvmark.it). For more technical information, please visit us at www.dvmark.it and ll out the form on the Support page. We hope you enjoy your power amp and use it to make great music! “The Lightning Flash with arrowhead symbol... - Page 3 At DV Mark, we invested a lot of resouces in R&D to develope a proprietary power amp, designed to respect and glorify the tone of your instrument. So enjoy my amps, and I invite you to contact us any time with your comments and questions, at info@ dvmark.it.
- Page 4 OVERVIEW DV MICRO 50 II We made a few to our DV Micro 50 . The features the and a upgrades best seller head DV Micro 50 II FX Loop new designed Lead , together with connections. Channel Aux In...
-
Page 5: Front Panel
FRONT PANEL - DV MICRO 50 II - DV MICRO 50 M - DV MICRO 50 CMT 1) INPUT Connect your guitar to this input using a standard ¼” shielded instrument cable. It’s also designed to perfectly interface with all the effects most used by guitarists. -
Page 6: Rear Panel
Reverb Overdrive REAR PANEL - DV MICRO 50 II - DV MICRO 50 M - DV MICRO 50 CMT Clean ― 15) AC POWER SOCKET Make sure the unit is grounded; all three terminals of the AC power plug must be connected to avoid any injury to the user... -
Page 7: Technical Specs
TECHNICAL SPECS - DV MICRO 50 II - DV MICRO 50 M - DV MICRO 50 CMT Channels: BLOCK DIAGRAM Two (clean / lead) Controls: Level (clean ch) Drive / Level (lead ch) EQ Controls: Bass - Mid - High (clean ch) - Page 8 Clean ― FRONT PANEL Overdrive - DV MICRO 50 JAZZ 1) INPUT Connect your guitar to this input using a standard ¼” shielded instrument cable. DV Micro Input Clean Phones Level Bass 50 CMT 2) LEVEL Start with the Master Level control OFF (all the way counter-clockwise) and turn it up gradually until you reach your deidered volume. 3) BASS This knob controls the amount of low frequencies in your sound.
-
Page 9: Speaker Out
JAZZ JAZZ DV MICRO 50 REAR PANEL - DV MICRO 50 JAZZ 10) AC POWER SOCKET Make sure the unit is grounded; all three terminals of the AC power plug must be connected to avoid any injury to the user or damage to the unit 11) VOLTAGE SELECTOR The DV MICRO heads feature a 120V/240V Voltage Selector to use the amp in countries with different voltages, so make sure the switch on the rear panel is on the correct voltage before connecting it to the AC power, and the fuse is the right value for that... - Page 10 TECHNICAL SPECS - DV MICRO 50 JAZZ Channels: BLOCK DIAGRAM One (clean) Controls: Level EQ Controls: Bass - Mid - High Speaker Outputs: Two ¼” Jacks mono out 8 ohm Power Output: 60W @ 4ohm / 50W @ 8ohm Send Other Features: Footswitch input for reverb on/off Input...
- Page 11 Product specifications are subject to change without notice www.markbass.it www.markaudio.it www.momark.it Italy - 66020 San Giovanni Teatino CH - Via Po, 52 Tel: +39 0854407764 / 0854465705 - Fax: +39 0854407764 / 0854407399 - www.dvmark.it - info@dvmark.it...
