Summary of Contents for Vango 1080p DLP LED
- Page 1 1080p DLP LED Front Projector User's Manual 1080p DLP LED Front Projector from http://www.suovango.com...
-
Page 2: Preface
ENGLISH ABOUT THIS MANUAL This manual is designed for use with the 1080p DLP LED Front Projector. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. -
Page 3: Notices
Notices WARNING! To meet FCC requirements, a shielded power cord is recommended in order to prevent interference. It is essential that only the supplied power cord is to be used. Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not approved by the party responsible for compliance could void your authority to operate the equipment. - Page 4 SYMBOL EXPLANATIONS DISPOSAL: Do not use household or municipal waste collection services for disposal of electri- cal and electronic equipment. EU countries require the use of separate recycling collection services. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com...
-
Page 5: Table Of Contents
Contents Preface ................1 Notices ................2 Introduction Package Contents ............. 7 Features ................7 Components ..............8 Projector (Front, Top, and Side View) ....8 Projector (Rear and Side View)......9 Remote Control ........... 10 Using the Remote Control ..........11 Available Range of the Remote Control .... - Page 6 EE Color ................46 Connecting Pin Assignments .......... 47 Computer Compatibility Chart ......... 48 Video Compatibility Chart ..........49 Troubleshooting............... 50 Product Specifications ............. 51 Short Throw Lens Dimension .......... 52 Long Throw Lens Dimension........... 53 to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com...
-
Page 7: Introduction
Introduction... -
Page 8: Package Contents
• Use of an HDMI/HDCP terminal enables all processes from input to signal processing and projection to be performed digitally, resulting in the realization of all-digital projection without any data loss due to analog conversion. This also supports the building of home theaters using HTPC. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 9: Components
Components Projector (Front, Top, and Side View) LENS SHIFT (H) Lens shift dial Lens shift dial (Horizontal) (Vertical) LENS SHIFT (V) Intake vent Power indicator Temperature indicator This indicator glows red, Pr /C r when the temperature of the Pb /C b HD M I HD M I S- VI DE... -
Page 10: Projector (Rear And Side View)
RS-232 Input 3: Remote control Video/S-Video sensor Terminals for connecting Video/S-Video REPEATER 12V-TRIGGER IR Repeater Terminal for wired remote control 12V Trigger Terminals for screen controlling AC socket 100~240V AC 50-60Hz Exhaust vent to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 11: Remote Control
Remote Control Power (ON/OFF) button Press to turn the power on and off. MENU button Press to enter the OSD menus. Adjustment buttons ( , , , ) ENTER button Displays adjustment and Sets the selected items or setting screens. adjustments from the menu. -
Page 12: Using The Remote Control
Insert the batteries making sure the polarities correctly match the marks inside the battery compartment. Insert the lower tab of the cover into the opening, and press down the cover until it clicks in place. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 13: Connections And Setup
Connections and Setup... -
Page 14: Connecting The Projector To Other Devices
HD 15-pin VGA to VGA cable (optional item, sold separately). Connecting the Power Cord Supplied Power cord accessory Plug in the supplied power cord into the AC socket on the rear of the projector. IGG ER 12V -TR ATE R RE PE to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 15: Connecting To Video Equipment
Connecting to Video Equipment Connecting to Video VCR or other video equipment Equipment Using an S-Video or a Composite Video To S-Video output terminal Cable Using an S-Video or a Composite video cable, To Video output terminal a VCR, laser disc player or other video equipment can be connected to INPUT 3 input terminals. -
Page 16: Connecting To Component Video Equipment
Connect an HDMI to HDMI cable To HDMI output terminal to the projector. Connect the above cable to the video equipment. Note • Select the input signal type of the video equipment. HDMI to HDMI cable to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 17: Connecting To An Ee Color Processor
Connecting to an EE Color DVD player or DTV* decoder Processor To HDMI output terminal Use two HDMI to HDMI cables when connecting an HDMI video equipment to the projector with an EE color processor. Note • For users using DVD player, DTV decoder or other devices without HDMI outputs, it is EE Color processor... -
Page 18: Connecting The Thumbscrew Cables
Before using the “Plug and Play” function, be sure to turn on the projector first and the connected computer last. Note • The DDC “Plug and Play” function of this projector operates only when used in conjunction with a VESA DDC compatible computer. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 19: Using The Adjustment Feet
Using the Adjustment Feet • The height of the projector can be adjusted using the adjustment feet when the projector is placed on the uneven surface or when the screen is slanted. • The projection of the image can be made higher by adjusting the projector when it is in a location lower than the screen. -
Page 20: Setting Up The Screen
1/2 of screen height: Left 15%, Right 15% • It is recommended that images be projected onto the dashed line octagonal area for fine image quality. • There is a tolerance of ±5% in the formula above. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 21: Screen Size And Projection Distance
Screen Size and Projection Distance (Short throw lens) When using a wide Wide Screen 16:9 screen (16:9) Distance from lens center to Screen Size Throw Distance image bottom after lens shift In case of displaying the Diagonal size Width Height Maximum Minimum Shift up (max) Shift down (max) -
Page 22: Screen Size And Projection Distance
Z2 (Down max) = -0.45x bottom (in) Note • There is a tolerance of ±3% in the formula above. • Values with a minus (-) sign indicate the lens center is above the image bottom. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 23: Projection From Behind The Screen
Projection from behind the screen Projecting a Reversed/Inverted Image Place a translucent screen between the projector and the When using the default setting. audience. On-screen Display Reverse the image by setting “Rear” for “PRJ Mode” in the “Options” menu. The image is reversed. Projection using a mirror Place a mirror (normal flat type) in front of the lens. -
Page 24: Basic Operation
Basic Operation to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 25: Image Projection
Image Projection Basic Procedure Connect the required external equipment to the projector before operating the following procedures. Info • The language preset at the factory is English. If you want to change the on-screen display to another language, reset the language according to the procedure on page 25. -
Page 26: Selecting The On-Screen Display Language
語 , 한국어 , Press “MENU”. • The menu will be displayed. Press to select “Language”. Press to select desired language, and then press The desired language will be set as the on-screen display. Press “EXIT”. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 27: Using The Menu Screen
Using the Menu Screen This projector has one set of menu screens that allow you to adjust the image and various projector settings. You can operate the menus from the remote control using the following procedure. Menu Selections (Adjustments) Press on the remote control. -
Page 28: Adjusting The Picture
Use this option to adjust the contrast of the image. Use this control in conjunction with brightness to fine-tune the display. The scale is from -50 to 50. Color Use this option to adjust the color intensity of the image. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... - Page 29 Tint Use this option to adjust the tint of your image. Press to make the image more green. Press to make the image more purple. Sharpness Use this option to adjust the clarity and focus of the image. Gamma Use this option to adjust the gamma correction of the image. Default setting is 2.2. Gamma correction provides eight sets of gamma corrections 1.0, 1.5, 1.8, 2.0, 2.2, 2.35, 2.5, and 2.8.
- Page 30 • When Editing Saved Contents: Edit the contents of the “Picture” menu after selecting the Memory number for which adjustment values are to be edited. • The default three modes Normal/Bright/Movie cannot be saved in the memory. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com...
- Page 31 Save Picture Settings Use this option to save changes you made in “Picture setting” to Memory 1, Memory 2, or Memory 3. Advanced Select this menu to access Dynamic Black and Detail Enhancement functions. Dynamic Black: This function utilizes the contrast of colors to enable black colors to appear blacker on screen while significantly enhancing the performance of black scenes.
-
Page 32: Adjusting Computer Images
Auto Tune a computer image. (PC only) Select “Execute Auto Tune”. Note • Auto Tune may take some time to complete, depending on the image stored in the computer connected to the projector. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 33: Easy To Use Functions
Easy to Use Functions... -
Page 34: Selecting The Picture Display Mode
• With 4:3 input, the central ratio remains true to scale, but the image is stretched to fit display width. • 16:9 input image is identical to the one displayed in Anamorphic mode. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... - Page 35 VIDEO Anamorphic Standard LetterBox Panoramic 480i 480p 576i For 4:3 576p 1920x1080 1440x1080 1920x1080 1920x1080 aspect ratio NTSC SECAM 480p 1920x1080 1440x1080 1920x1080 1920x1080 576p For 16:9 aspect ratio 720p 1920x1080 1440x1080 1920x1080 1920x1080 1080i/p 1920x1080 1440x1080 1920x1080 1920x1080 Output screen image Input Signal Anamorphic Standard...
- Page 36 N.A. For 4:3 aspect ratio (640x480) SVGA N.A. For 4:3 aspect ratio (800x600) N.A. For 4:3 aspect ratio (1024x768) SXGA N.A. For 5:4 aspect ratio (1280x1024) UXGA N.A. For 4:3 aspect ratio (1600x1200) to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com...
-
Page 37: Overscan Type
Overscan Type This function enables you to remove some edges of the image. The following options are available: Selected item Description Scales or zooms the Zoom image. Cuts a portion of the Crop image. Overscan Adjust This function enables you to adjust the image display on screen. -
Page 38: H-V Keystone Function
• Straight lines or the edges of images may appear jagged while adjusting the image. Vertical Keystone Correction to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 39: Options Menu
Options menu You can adjust the projector's settings to your preferences with the Options menu. Sync Threshold This function is only available on Component input. The projector is compatible with EDTV(480p and 576p) and HDTV(720p,1080i and 1080p) video signals. If a hardware device, such as a DVD player, is not syncing properly with the projector, adjust this option to help it to sync when connected to the projector. -
Page 40: Source Select
(PAL 50Hz and SECAM) enhancement to progressive mode images. Note • In PAL50Hz or SECAM, the 2:2 pull down enhancement will be enabled only in film mode, after the film source has been entered. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 41: Sti
This function allows you to set the LTI and CTI level. Selected Item Description Adjusts the LTI level to (Luminance enhance luminance, filter fuzzy Transient edges and remove smear. Improvement) Adjusts the CTI level to (Color Transient enhance color, filter fuzzy Improvement) edges, and remove smear. -
Page 42: Prj Mode
When the mode is enabled, all the fan in the projector will be running in high speed mode. Status The Status screen displays information about the current Input Source, Resolution, Horz Freq, Vert Freq, Power On Timer, and Firmware Information. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 43: Input Source
Input Source In the Main menu, press the button to select Input Source, and press the Enter button to confirm. Note • If you select “Auto” as the Input source, then the correct input source is automatically selected. Factory Reset This process will set all the items to Factory default settings except PRJ Mode. -
Page 44: Appendix
Appendix to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 45: Maintenance
Maintenance Cleaning the projector Unplug the power cord before cleaning the projector. Avoid using benzene or thinner, as these can damage the finish on the cabinet and operation panel. Do not use volatile agents such as insecticides on the projector. Do not leave rubber or plastic objects in contact with the projector for long periods as they may damage the finish of the projector. -
Page 46: Temperature Led (Over Temperature)
15 seconds. You should ensure that the airflow around the projector is sufficient, and ensure that the projector has proper ventilation. When the over temperature LED lights up, a warning also appears on the screen. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 47: Ee Color
EE Color EE Color is a revolutionary, patent pending three-dimensional color processing that uses visual models to map input color standards to the much larger color gamut of the EE LED Projector while preserving flesh tones, blue skies and other memory colors. This color processing is performed in the EE Color Processor or integrated with the EE LED Projector. -
Page 48: Connecting Pin Assignments
Reserved (N.C. on device) T.M.D.S data 1 shield DDC clock T.M.D.S data 1- DDC data T.M.D.S data 0+ DDC ground T.M.D.S data 0 shield +5V power T.M.D.S data 0- Hot plug detection T.M.D.S clock+ to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 49: Computer Compatibility Chart
Computer Compatibility Chart Computer • Multiple signal support • Horizontal Frequency: 25-91 kHz, Vertical Frequency: 24-85 Hz, Pixel Clock: 25-162 MHz • XGA, SXGA, UXGA compatible with advanced intelligent compression • The following is a list of modes that conform to VESA. However, this projector supports other signals that are not VESA standards. -
Page 50: Video Compatibility Chart
Horizontal Frequency (kHz) Vertical Frequency (Hz) HDMI Support 480i 15.7 480p 31.5 576i 15.6 576p 31.3 720p 45.0 720p 37.5 1080i 33.8 1080i 28.1 1080p 1080p 28.1 1080p 33.8 1080p 56.3 1080p 67.5 to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 51: Troubleshooting
Troubleshooting Problem Check Projector power cord is not plugged into the wall outlet. Remote control batteries have run out. Projector does not start. The selected input mode is wrong. Cables may be incorrectly connected to the rear panel of the projector. Power to the external connected device is off. -
Page 52: Product Specifications
Power Supply 100 ~ 240 V AC, 50-60 Hz Power Consumption Maximum: 370W Normal: less than 300W Standby: less than 1W Operating Temperature 5°C to 35°C Specifications are subjected to change without notice. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... -
Page 53: Short Throw Lens Dimension
Short Throw Lens Dimension Units: mm (inch) Rear View 12V-TRIGGER REPEATER Side View Side View 200mm 165mm [7.9in] [6.5in] 365mm [14.4in] Front View 285mm [11.2in] 75mm [3.0in] Bottom View... -
Page 54: Long Throw Lens Dimension
For ceiling/wall installation, by means of suspension bracket, carefully follow the instructions and safety instructions recommended by the manufacturer in the bracket's literature. to purchase VANGO : http://www.plasmapan.org | http://www.suovango.com... - Page 55 VANGO : http://www.plasmapan.org | http://www.suovango.com Release Version A...
