Etisalat iModem Manual

Hide thumbs Also See for iModem:
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for purchasing the Etisalat iModem. This
iModem brings you a high speed wireless network
connection.
This document will help you understand your iModem so you can start using it right away.
Please read this document carefully before using your iModem.
For detailed information about the functions and configurations of the iModem, refer to the
online help on the web management page that comes with the iModem.
For detailed instructions for logging in to the web management page, refer to "Logging In to
the Web Management Page".
To connect a Wi-Fi device to your iModem, see "SSID and Wireless Network Key" on page 10.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iModem and is the answer not in the manual?

Questions and answers

Related Manuals for Etisalat iModem

Summary of Contents for Etisalat iModem

  • Page 1 For detailed instructions for logging in to the web management page, refer to "Logging In to the Web Management Page". To connect a Wi-Fi device to your iModem, see “SSID and Wireless Network Key” on page 10.

  • Page 2: Application Scenarios

    Getting to Know Your Etisalat iModem Note: The iModem function descriptions and illustrations in this document are for your reference only. The product you have purchased may vary. Application Scenarios Wi-Fi devices (such as smartphones, tablet computers, and game consoles) or computers can all access the Internet through iModem.
  • Page 3 Scenario 1: Accessing the Internet Using a 3G or 2G Network The iModem uses your operator's 3G or 2G network to access the Internet. 3G/2G...
  • Page 4 Scenario 2: Accessing the Internet Using a Wi-Fi Network When you use the iModem in Wi-Fi coverage areas, for example, an airport, cafe, hotel, or your home, the iModem can access the Internet via Wi-Fi networks, helping to save your 3G or 2G network usage.
  • Page 5 Appearance  Power button  Screen  Micro USB port  MENU button  Lanyard hole...
  • Page 6 Screen Home screen  Roaming R: Data roaming turned on.  Signal strength : Signal strength from weak to strong.  Network type 3G/2G: Connected to a 3G/2G network.  0 B/2GB : Connected to WLAN.   Network connection status ...
  • Page 7  Wi-Fi Wi-Fi turned on.  Number of connected Wi-Fi devices.   Traffic statistics Data usage this month.  Monthly data usage limit.  Note: To set the start date of the monthly data usage statistics and data usage limit, go to ...
  • Page 8 Menu screen Press the button to display the menu. Back  Back Device Info Return to the previous screen. QR code  Options  Operation tips Press the button to scroll down.  Next Press the button to confirm your selection. ...
  • Page 9 Update screen When updates are available, you will be prompted to update the iModem.  Update New software Press the button to start the update.  Cancel Update Press the button to ignore the update. Cancel...
  • Page 10 SSID and Wireless Network Encryption Key When a Wi-Fi device establishes a connection to the iModem for the first time, you may need to enter the default Service Set Identifier (SSID) and wireless network encryption key. The default SSID and encryption key are printed on the iModem label.
  • Page 11 To view the current SSID and wireless network encryption key on the screen: Press the button to display the menu. Back Device Info QR code Next Press the button to scroll to Device Info. Back Device Info QR code Next Press the button to enter Device Info.

  • Page 12: Getting Started

    Getting Started Installing Install the SIM card, microSD card, and battery according to the illustration. Note: The microSD card is an optional accessory. If no microSD card is included in the package, please purchase one separately.

  • Page 13: Charging The Battery

    Charging the Battery If the iModem has not been used for a long time or if the battery is fully depleted, the iModem may not power on immediately after the charger is plugged in. Please charge the battery for a while before attempting to power on the iModem.
  • Page 14 For details about the specific charger model, contact an authorized dealer. Method 2: Charge the device through a computer connection Use the data cable provided with your device to connect the iModem to the computer.
  • Page 15 Verifying the PIN If the iModem's network parameters have been correctly configured but you cannot access the internet after powering it on, PIN verification may be enabled. Log in to the web management page and enter the PIN when prompted. To avoid entering the PIN every time you power on the iModem, disable PIN verification from the web management page.

  • Page 16: Connecting To The Internet

    The iModem will be connected to the Internet after its startup. If data is transmitted, the iModem will automatically connect to the Internet. If data is not transmitted for a period of time, the iModem will automatically disconnect from the network connection.

  • Page 17: Using A Wi-Fi Network

    Using a Wi-Fi Network Ensure that the Wi-Fi extender function is enabled. The iModem automatically connects to a Wi-Fi hotspot set by your service provider or yourself. When the iModem is connected to a Wi-Fi network, and the Wi-Fi hotspot SSID are displayed on the screen.

  • Page 18: Logging In To The Web Management Page

    Logging In to the Web Management Page Make sure the connection between the iModem and the Wi-Fi device or computer is working normally. Open the browser, and enter http://192.168.8.1 in the address box. Note: If the IP address conflicts with other IP addresses on the network, the IP address of the iModem automatically changes.

  • Page 19: Battery Saving Mode

    When the iModem is being powered only by the battery, you can choose to enable or disable the automatic Wi-Fi turnoff function. If this function is enabled and if no Wi-Fi devices access the iModem for a period of time, the Wi-Fi turns off automatically. You can press any button to turn the Wi-Fi on again.
  • Page 20 Wi-Fi extender on or off. Wi-Fi extender Note: Fast boot Alternatively, you can log in to the iModem's web management  Next page to enable or disable Wi-Fi extender. After the Wi-Fi extender function is enabled, up to nine Wi-Fi devices can be ...
  • Page 21 Press the button to display the Mobile app screen. Back On your Android and iOS devices: Wi-Fi key Scan the QR code on the iModem to download the HUAWEI Mobile Mobile app WiFi App. Note: Next To download the HUAWEI Mobile WiFi App to your device: For an iPhone or iPad, search for HUAWEI Mobile WiFi in App Store.
  • Page 22 Wi-Fi key screen. Back On your Android device: Wi-Fi key Mobile app Scan the QR code on the iModem using the HUAWEI Mobile WiFi App. Your Android device will then connect to the iModem. Next Note:...

  • Page 23: Establishing A Wps Connection

    Establishing a WPS Connection If the Wi-Fi device to be connected to the iModem supports WPS, the Back wireless network encryption key is generated automatically and there is Device Info no need to enter it manually. QR code The steps for WPS connection are as follows: Turn on the iModem.

  • Page 24: Restoring To Factory Settings

    If you forget the user name, password, or SSID you have set, you can restore the settings on the web management page to their factory values. To do so, simply press and hold the RESET button until the iModem restarts.
  • Page 25 If the computer indicates a wireless network connection, the wireless network adapter can be used. Otherwise, verify that your wireless network adapter is working properly. Select the wireless network connection with the iModem's SSID and click Connect.
  • Page 26 Note: If the wireless network connection is encrypted, enter the correct wireless network  encryption key. To view the current SSID and wireless network encryption key, see the operations in the  “SSID and Wireless Network Encryption Key” section. Wait a moment for the wireless network connection icon to appear in the system tray in the lower right corner of the computer screen.
  • Page 27 Select Scan to search for wireless networks. A list of access points will be displayed on the screen. Select the access point with the iModem's SSID, and press the ► button on the PSP. Confirm the SSID, and enter the correct wireless network encryption key.
  • Page 28 Press the ► button to proceed to the next step, and then press the X button to save settings. Select Test Connection to test whether the network connection is successful. You can now open the browser and access the network.
  • Page 29 (The lock icon indicates that the encryption key is required to connect to this wireless network.) Note: Wi-Fi devices, such as an iPhone, iPod touch, PS3 and NDSi, can all access the Internet through the iModem. For specific operations, refer to the Wi-Fi device's user manual.
  • Page 30 Tips When the iModem is in use for an extended period of time, it will become warm and may overheat. Should this happen, the iModem will automatically close the network connection and turn off to protect itself from damage. If this occurs, place the iModem in a well ventilated space to allow the heat to dissipate, then turn it on and continue to use it as normally.
