Related Manuals for Electronics International UBG-16

Summary of Contents for Electronics International UBG-16

  • Page 1 You must read this manual before installing or operating the instrument. This manual contains warranty and other information that may affect your decision to install this product and/or the safety of your aircraft. Electronics International Inc. Electronics International Inc. Electronics International Inc.
  • Page 2 If you do not accept the terms of the Warranty / Agreement, do not install this product this product this product. This product may be returned for a refund. Contact Electronics International inc. for details. this product this product The pilot must...

  • Page 3: Table Of Contents

    Contents Warranty --------------------------------------------------------------------------------------------------- ntroduction ----------------------------------------------------------------------------------------------- Mode Selector Switch ----------------------------------------------------------------------------------- Normal Operating Mode ------------------------------------------------------------------------------- Step Switch ------------------------------------------------------------------------------------------------ 1. Displaying the EGTs and CHT’s: --------------------------------------------------------------- 2. Displaying a Temperature on the 7th Column of Bars: --------------------------------------- 3. Displaying Other Temperatures and/or Functions Digitally: --------------------------------- 4.
  • Page 4 3. Takeoff: -------------------------------------------------------------------------------------------- 22 4. Climb: ---------------------------------------------------------------------------------------------- 22 5. Cruise: ---------------------------------------------------------------------------------------------- 22 6. Descent: -------------------------------------------------------------------------------------------- 23 Work Sheet for Setting Limits ------------------------------------------------------------------------- 24 "UBG-16" Configuration Form ------------------------------------------------------------------------ 25 Fuel/Air Profile ------------------------------------------------------------------------------------------- 26 Specifications and Operating Features -------------------------------------------------------------- 28 Page 2 of 2...

  • Page 5: Warranty

    Electronics International Inc. 4. Electronics International Inc. is not liable for expenses incurred by the customer or installer due to factory updates, modifications, improvements, upgrades, changes, or any other alterations to the product that may affect the form, fit, function or operation of the product.

  • Page 6: Introduction

    Introduction Introduction Introduction Introduction Introduction Congratulations on purchasing the Ultimate Bar Graph Engine Analyzer (UBG), one of the most sophisticated diagnostic tools available in general aviation. You can learn the basic operation of the UBG in the first few minutes of hands-on operation. Although the UBG is simple to operate, its capabilities are numerous. The UBG is shipped from the factory with all of the programmed limits turned off.

  • Page 7: Step Switch

    The Bar Graph Display allows visual comparison of EGTs and CHTs at a glance. It also allows you to see where the EGTs and CHTs are operating in their normal operating range (i.e., high EGTs will be displayed with many bars lit in a column and low EGTs will be displayed with few bars lit in a column).

  • Page 8: Displaying Other Temperatures And/Or Functions Digitally

    Note: An aircraft engine can not be shock cooled when cylinder head temperatures are below 300'F. For this reason, the UBG-16 will display "-00" when the CHT drops below 300'F. A Shock Cooling Limit and the cylinder to be monitored for shock cooling are programmable (see “Programming the Shock Cooling Limit and Cylinder”).

  • Page 9: Displaying The Egt Difference

    6. Displaying the EGT Difference: 6. Displaying the EGT Difference: 6. Displaying the EGT Difference: 6. Displaying the EGT Difference: 6. Displaying the EGT Difference: While the Peak EGT is being displayed, push the Step Switch once to the right to display the difference between the hottest and coldest EGT.

  • Page 10: Lean Operating Mode

    It is recommended that the EGT columns be normalized while operating your aircraft in normal cruise flight, with the engine leaned. When operating in the Normalized Mode only Normalized Mode only Normalized Mode only Normalized Mode only Normalized Mode only, the EGT bars may be normalized on the UBG display by performing the following steps: 1.

  • Page 11: False Peaks

    Next, slowly lean your engine by pulling the mixture out a very small amount. When the increase in temperature slows to less than one degree per second, once again lean the engine a very small amount. The slower you lean, the more accurate the results will be. When any cylinder reaches its peak (hottest) EGT and starts to decrease in temperature, the digital display will blink the word “PEAK”...

  • Page 12: Alternate Method For Leaning On The Rich Side Of Peak

    3. Alternate Method for Leaning on the Rich Side of Peak: 3. Alternate Method for Leaning on the Rich Side of Peak: 3. Alternate Method for Leaning on the Rich Side of Peak: 3. Alternate Method for Leaning on the Rich Side of Peak: 3.

  • Page 13: Alarms

    C. C. C. C. C. Push the Mode Switch twice to the left to acknowledge the peak and to cause the display to show the Temperature Below Peak. D. D. D. D. D. Lean the mixture to a desired Temperature Below Peak for the richest cylinder. Alarms: Alarms: Alarms:...

  • Page 14: Canceling All Active Alarms For 10 Minutes

    5. Canceling all Active Alarms for 10 Minutes: 5. Canceling all Active Alarms for 10 Minutes: 5. Canceling all Active Alarms for 10 Minutes: 5. Canceling all Active Alarms for 10 Minutes: 5. Canceling all Active Alarms for 10 Minutes: To cancel all active alarms for 10 minutes, push and hold the Step Switch to the left until the word “CANCEL”...

  • Page 15: Selecting The Low Egt Limits

    recommended limit. As you get to know your engine’s normal operating temperatures, you may want to adjust these limits accordingly. 2. Selecting the Lower EGT Limits: 2. Selecting the Lower EGT Limits: 2. Selecting the Lower EGT Limits: 2. Selecting the Lower EGT Limits: 2.
  • Page 16 High and low EGT and CHT limits may be set for each cylinder displayed on the UBG. When operating in the Normal Mode only Normal Mode only Normal Mode only Normal Mode only, the EGT and CHT limits may be set by performing the following steps: Normal Mode only A.

  • Page 17: Programming The Range Of The Egt Columns Of Bars

    Programming the Range of the EGT Columns of Bars: Programming the Range of the EGT Columns of Bars: Programming the Range of the EGT Columns of Bars: Programming the Range of the EGT Columns of Bars: Programming the Range of the EGT Columns of Bars: The range of the EGT columns of bars may be customized to accommodate any engine or pilot preference.

  • Page 18: Programming The High And Low Limits And Range Of The 7Th Column Of Bars

    7. 7. 7. 7. 7. To exit this programming mode, push and hold the Mode Switch to the left until the word “END” appears in the digital display. Programming the High and Low Limits and Range of the 7th Col- Programming the High and Low Limits and Range of the 7th Col- Programming the High and Low Limits and Range of the 7th Col- Programming the High and Low Limits and Range of the 7th Col-...

  • Page 19: Programming The High And Low Limits For Other Temperatures Or Functions

    Note: Note: Note: Note: Note: Setting a limit to “000” will disable the limit and any alarms. 6. 6. 6. 6. 6. To exit this programming mode, push and hold the Mode Switch to the left until the word “END” appears in the digital display.
  • Page 20 " " " " " " " " " "...

  • Page 21: Programming The Shock Cooling Limit And Cylinder

    Programming the Shock Cooling Limit and Cylinder: Programming the Shock Cooling Limit and Cylinder: Programming the Shock Cooling Limit and Cylinder: Programming the Shock Cooling Limit and Cylinder: Programming the Shock Cooling Limit and Cylinder: Sudden cooling of the CHT (known as shock cooling) is a common problem in some engines. In others, it is rare. Shock cooling an engine can result in bent pushrods due to exhaust valves sticking, burned valves, spark plug fouling, broken piston rings, cracked cylinders at the spark plug and valve ports and warped exhaust valves.

  • Page 22: Power-Up Programming

    Your engine’s EGTs will vary at different power, altitude and mixture settings. To further enhance the UBG’s ability to detect a problem, select the EGT Difference (“DIFF”) on the UBG’s digital display and note the EGT Difference during climb, cruise and descent. Set the EGT Differential Limit for 30’F higher than the observed maximum difference.

  • Page 23: Enter The Power-Up Programming Mode

    Enter the Power-up Programming Mode: Enter the Power-up Programming Mode: Enter the Power-up Programming Mode: Enter the Power-up Programming Mode: Enter the Power-up Programming Mode: With the power to the UBG off, press and hold the Mode Switch to the left. Continue to hold the Mode Switch to the left and turn the power to the UBG on.

  • Page 24: Configuring The Remaining Left And Right Channels

    4. Configuring the Remaining Left and Right Channels: 4. Configuring the Remaining Left and Right Channels: 4. Configuring the Remaining Left and Right Channels: 4. Configuring the Remaining Left and Right Channels: 4. Configuring the Remaining Left and Right Channels: Push the Mode Switch to the right.

  • Page 25: Takeoff

    3. Takeoff: 3. Takeoff: 3. Takeoff: 3. Takeoff: 3. Takeoff: During takeoff, check the Bar Graph Display for proper EGTs. It is also vital to pay close attention to the Oil Pressure. If you have activated all canceled alarms and the High and Low Limits have been set properly, the UBG will automatically diagnose your engine during takeoff.

  • Page 26: Descent

    Descent: Descent: Descent: Descent: Descent: During descent, the air gets heavier and the engine will run leaner. The manifold pressure will increase one inch for each thousand feet of descent. During descent, enrichen the mixture to maintain proper EGTs and gradually decrease the throttle to maintain proper Manifold Pressure.

  • Page 27: Work Sheet For Setting Limits

    Work Sheet for Setting Limits Work Sheet for Setting Limits Work Sheet for Setting Limits Work Sheet for Setting Limits Work Sheet for Setting Limits 1. During High P 1. During High Power Climb to 5,000 ft. +: 1. During High P ower Climb to 5,000 ft.

  • Page 28: Ubg-16" Configuration Form

    __________ Channel 8 is the last available channel on the Right. Note: Note: Note: Note: Note: The UBG-16 digital display steps through the channels starting with number one on the LEFT and ending with number 8 on the RIGHT.

  • Page 29: Fuel/Air Profile

    Fuel/Air Profile Fuel/Air Profile Fuel/Air Profile Fuel/Air Profile Fuel/Air Profile When viewing "Profile" the bar graph display shows the fuel/air distribution for your engine. This display is intended as a technical view of how your engine is operating. Once you know the fuel/air distribution for your engine, its easier to make logical decisions on how to run your engine (rich of peak, at peak, lean of peak, lean on climb, etc.).
  • Page 30 To produce a Fuel/Air Profile for your engine, perform the following: 1. 1. 1. 1. 1. Climb to cruise altitude and set your manifold pressure and RPM for cruise flight. 2. 2. 2. 2. 2. Enter the Lean Operating Mode and lean your engine slowly until all the cylinders' EGTs have passed peak (all the cylinder numbers located at the top of the EGT columns are blinking).

  • Page 31: Specifications And Operating Features

    SPECIFICA TIONS and OPERA TING FEA TURES S1111981 11/11/98 Model: Model: UBG-16 and UBG-16T Model: Model: Model: Weight: Weight: Weight: Unit only: 22 oz., One probe and 6 foot cable: 3.5 oz., One Probe and 20 foot cable: 7 oz.
