- Page 1 Audio player SA3104 SA3105 SA3114 SA3115 SA3124 SA3125...
-
Page 2: Need Help
Need help? Please visit www.philips.com/welcome where you can access to a full set of supporting materials such as user manual, the latest software updates and answers to frequently asked questions. -
Page 3: Table Of Contents
Contents Important safety information Your new player What’s in the box Register your product Getting started Overview of controls and connections Main menu Install Connect and charge 3.4.1 Use the supplied USB cable Transfer 3.5.1 Disconnect your player safely Enjoy 3.6.1 Power on and off 3.6.2... - Page 4 Contents Update your player Manually verify whether your firmware is up to date 23 Technical data Frequently asked questions...
-
Page 5: Important Safety Information
• Active mobile phones in the vicinity may cause interference. • Backup your files. Please ensure that you retain the original files you have downloaded to your device. Philips is not responsible for any loss of data if the product becomes damaged or not readable / legible. -
Page 6: Copyright Information
In case this one needs replacement, we recommend that you contact your retailer to order a model identical to that of the original, provided by Philips. Copyright information All other brands and product names are trademarks of their respective companies or organizations. -
Page 7: Data Logging
The data stored on the device are retrieved and used ONLY if the user returns the device to the Philips service centre and ONLY to simplify error detection and prevention. The data stored shall be made available to user on user’s first request. -
Page 8: Notice For Usa
• This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation. Notice for the European Union This product complies with the radio interference requirements of the European Union. Philips SA3104 SA3105 SA3114 SA3115 SA3124 SA3125... -
Page 9: Your New Player
2.1 What’s in the box The following accessories are included with your player: Player CD-ROM containing Philips Device Manager, Philips Media Converter, User Manual and Frequently Asked Questions 2.2 Register your product We strongly recommend that you register your product in order to gain access to free upgrades. -
Page 10: Getting Started
3 Getting started 3.1 Overview of controls and connections Microphone slider Lock all keys except volume keys C MENU Press to access the menu / Return to previous menu D y / 2; Short press to play/pause songs/videos, long press to power on/off Headphones jack Reset... -
Page 11: Main Menu
1 Insert the CD supplied with your product into the CD ROM drive of your PC. 2 Follow the on-screen instructions to complete the installation of Philips Device Manager and Philips Media Converter (to convert video clips into readable file format for the player, it can also convert a JPEG photo into the player for quality display.). -
Page 12: Connect And Charge
3.4 Connect and charge Your player will be charged when connected to the PC. 3.4.1 Use the supplied USB cable 1 Connect the supplied USB cable to the mini USB port at the bottom of the player, the other end to your PC. 2 The player will start to charge as soon as it is connected to your PC. -
Page 13: Transfer
3.5 Transfer Your player appears as a USB mass storage in Windows Explorer. You can organize files, transfer music and picture to your player during USB connection. Use Philips Media Converter to transfer video file. See Media Converter for details. -
Page 14: Detail Operation
4 Detail operation 4.1 Music mode Your player supports MP3 and WMA formats. 4.1.1 Control You can do the following action during music playback: Play / Pause music Skip to next song Return to previous song Fast forward Fast rewind Return to browsing menu Long/short press Increase volume Decrease volume... -
Page 15: Find Your Music
4.1.2 Find your music 1 From the main menu, select You can search from the following music options: All songs Alphabetically listed tracks Artists Alphabetically listed artists Albums Alphabetically listed albums Genres Alphabetically listed genres Playlists Playlists collections 2 Press to scroll through the list. -
Page 16: Clear Playlist On The Go
1 Connect the player to your computer. 2 Drag and drop your photos to the PHOTO folder of your player. Tip To have excellent viewing quality, please use Philips Media Converter to convert the JPEG photo files. 4.2.2 View pictures The player supports JPEG graphics and provides a slide show function. -
Page 17: Video
Converter provided in the suplied CD to transfer to your player. 4.3.2 Media Converter Philips Media Converter is a program that will allow you to change the video format of a video file to one that is supported by the player, it can also convert a JPEG photo into the player for quality display. -
Page 18: Video Playback
6 When error occurs for the particular file, move the mouse pointer to the error report for this file. Tip You can click Support file format from the help menu to check the list of video format the converter supports. Note In case you convert the files into your PC. -
Page 19: Recordings
4.4 Recordings You can make voice recordings using your player. See Overview of controls and connections sections for the location of recording microphone. 1 From the main menu, select 2 Select Start recording to start recording a voice. > Your player will display the voice recording screen and voice recording starts automatically. 3 Press to pause. -
Page 20: Upload Your Recordings To The Computer
4.4.3 Upload your recordings to the computer 1 Connect your player to your computer. 2 Select your player in Windows Explorer. > You will find a Voice folder. This folder contains the recordings. 3 Copy and paste the recordings to any desired location on the computer. 4.5 Radio From the main menu, select Connect the headphones... -
Page 21: Play A Preset Radio Station And Tune The Station
4.5.3 Play a preset radio station and tune the station 1 From the Radio menu 2 Press to browse and select the preset stations. 3 After you select a preset station, short press 4 You can also tune the frequency of selected preset station by long pressing 5 Short press to move one tuning step, long press strongest signal. -
Page 22: Use Your Player To Store And Carry Data Files
In the Settings menu, the following options are available: Settings Language Playmode Equalizer Slideshow setting Backlight Radio settings Information Factory settings 4.7 Use your player to store and carry data files You can use your player to store and carry data files by copying data files into your player with Windows Explorer. -
Page 23: Update Your Player
3 Make sure you are connected to the internet. 4 Click Update. > Philips SA31XX Device Manager will check whether a new firmware is available on the Internet and install it on your player. 5 When Update completed appears on the screen, click OK and disconnect the player. -
Page 24: Technical Data
Connectivity • Headphone 3.5mm, USB 2.0 (full speed)++ Music and photo transfer • Drag and drop in Windows Explorer Video transfer • Via Philips Media Converter Data transfer • Via Windows Explorer System requirements • Windows® ME, 2000 or XP •... - Page 25 * Rechargeable batteries have a limited number of charge cycles and may eventually need to be replaced. Battery life and number of charge cycles vary by use and settings. + 1MB = 1 million bytes; available storage capacity will be less. 1GB = 1 billion bytes;...
-
Page 26: Frequently Asked Questions
If none of the above works, then you may have to use the Device Manager to recover your player: 1 Launch the Philips Device Manager at Start > Programs > Philips Digital Audio Player > SA31XX > Philips SA31XX Device Manager on your PC. - Page 27 Note The existing contents on your player will not be erased. 2 If nothing happens, recharge the battery for at least 4 hours and try to power on or reset again. If this does not work, you might have to repair your player with Philips Device Manager.
- Page 28 PHILIPS reserves the right to make design and specification changes for product improvement without prior notice.
- Page 29 Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners © 2007 Koninklijke Philips Electronics N.V. All rights reserved. Printed in China www.philips.com wk7295...
