User manual Manuel d’utilisation | Benutzerhandbuch Gebruikershandleiding | Manuale per l'utente Användar-handbok Micro jukebox | Manual del usuario | Manual do usuário HDD085...
Playing recordings ... 12 Customizing settings ... 13 Using your player to store and carry data files About Philips Device Manager and Windows Media Player About Philips Device Manager...15 About Windows Media Player ...15 Install Windows Media Player and Device Manager ...15 Windows Media Player 10 Search and add tracks to the Library...17...
Page 3
Update and repair with Philips Device Manager Upgrade ...24 Firmware Update ...24 Device Repair ...25 Troubleshooting ...26 Safety and Maintenance General maintenance ... 27 About operating and storage temperatures Take care when using headphones Copyright information ... 27 Data logging ... 28 Environmental information ...
Register your product Since it is possible for you to upgrade your product, we recommend that you register your product on www.philips.com/register so we can inform you as soon as new free upgrades become available. More information Please visit www.philips.com/support...
Enjoy Powering on / off Power on: Press and hold PHILIPS splash screen appears briefly Power off: Press and hold Your device automatically powers down if there is no operation and no music played for 10 minutes. Last playback status / screen will be resumed at next powering on.
Overview of controls and connections USB cable connector 5V DC HOLD slider LCD display VIEW J( / § y 2; Neckstrap eyelet Volume + / - PLAYLIST Type number Serial number Headphones jack Charging socket To disable key press Dynamically displays menu, options and track information To switch between root menu, library and now playing screens Scroll;...
Root menu When your device powers up, you will see the ROOT MENU. Music select to play your digital music tracks Radio*** select to listen to your radio presets Settings select to customize settings for your device Recordings select to play recordings ***FM radio is available only to some regional versions.
Searching for your desired music From the root menu, select MUSIC to enter the music mode. As you enter the music mode, you can search from the following display options: Playlists Playlists collections All songs Alphabetically listed tracks Artists Alphabetically listed artists Genres Alphabetically...
Insert the supplied CD into your computer's CD-ROM drive. Follow screen instructions to complete installation of Philips Device Manager and Windows Media Player. HDD085 user: Install the Easy start CD first, followed by the “ GoGear Software and user manuals” CD. Connect your device to the computer Connect your device to your computer using the supplied USB cable.
Playback (also applicable to playback of recordings) The 2;, 3, 4, J(, § keys are multi-functional. They work according to how you press them: press or press and hold. During music playback, you can do the following: Operation Pause music Go to next track Go to previous track Forward search...
Playback features PLAY MODES You can set your device to play music tracks randomly (Shuffle ) and / or repeatedly (repeat ). Changing play modes From the root menu, select Settings. Use scroll controls to select the following options. Press §...
Page 12
Playback features EQUALIZERS You can set your device to play music tracks with different EQ (equalizers). Changing equalizers From the root menu, select Settings > Equalizers. Use scroll controls to select Rock, RnB, Electronica, HipHop, Classical, Jazz or Off. You can also adjust Equalizer settings by pressing the 4 key during music playback. Introscan You can preview the first 10 seconds of each track in your selection using introscan Press...
Radio mode*** Select your FM region*** Connect your headphones to your device. From the root menu, select SETTINGS to enter the settings mode. Select Radio > Radio settings. Use scroll controls to select your option. § Press to confirm your selection. Press ***FM radio is available only to some regional versions.
Making voice recordings Preparing to make recordings From the root menu, select SETTINGS to enter the settings mode. Select SETTINGS > Advanced to make settings before recording. Press your selection. Making voice recording Make sure you are not in the radio mode. Press and hold for 3 seconds to start voice recording.
Playing recordings You can find your recordings in the RECORDINGS library. Searching for your desired recording From the root menu, select RECORDING to enter the recordings library. As you enter the recording library, you can search from the following options: Recordings Press to scroll up or...
Customizing settings From the root menu, select SETTINGS to enter the settings mode. Use scroll controls to select your option. Press § your selection. Press to deslect a checked option. You can adjust the following settings. Press and hold to exit the menu display. - Options for each setting are shown on the device display.
Using your player to store and carry data files You can use your player to store and carry data files by copying data files to your player via Window Explorer. Make sure to copy the data files into the data folder of your player.
About Philips Device Manager With Philips Device Manager, you can update and repair your device with a few simple clicks. About Windows Media Player With Windows Media Player you can easily manage your digital music collection and transfer music to your device.
Launch Windows Media Player 10 Connect your device to your computer using the supplied USB cable. The USB connection screen will automatically appear. Please refer to your computer’s manual for the exact position of your USB port. Look for the USB symbol on the processing unit of your computer. Launch Windows Media Player.
Search and add tracks to the Library Go to File menu. Click Add to Library > By Searching Computer. Click Browse in the dialog box to point to the folder you want to add to. Complete the information in the dialog box, and then click Search. Files will be added to the Library.
Transfer tracks to your device Simply connect your device to your computer, choose the synchronization method you want, and you're ready to synchronize your library to your device. Choose a synchronization method: Automatic. With this option, the Player synchronizes content to the device when you connect it to your computer or when you change synchronization settings.The Player synchronizes your entire library if it can fit, or the Player synchronizes your favorite content first.
Page 22
In the Items on Device pane, show the device that you want to copy files to, i.e. Philips. Clear the check boxes next to any files you do not want to copy. . Click the Start Sync button For further details of music transfer on WMP 10, go to the help section of Windows Media...
Add Tracks to a Playlist on your PC using WMP Click to highlight an item. Right click on the item and select Add to > Additional Playlist. From the Add to Playlist pop-up window, select an existing playlist or add new one. The selection is added to playlist.
Delete Tracks and Playlists Click to highlight an item. Right click and select Delete to delete. Press and hold <Ctrl> on your keyboard and click to select more than one item. To select consecutive items, click the first item, press and hold <Shift> on your keyboard, and then click the last item.
Edit Track Information Click on a track. Right click and select Edit. Click on the text boxes to edit relevant information. *Actual display varies with use.
Search for Tracks Type a search string in the Search field. Click on Search to start searching. You will see tracks that contain the search string. You can play, transfer, delete or add these tracks. *Actual display varies with use.
Your device is controlled by an internal program called firmware. You can install the latest firmware from the bypacked CD and download it from www.philips.com/support to keep your device updated. Please charge your device fully before firmware update. This will ensure steady power supply for completing the whole process.
Launch Device Manager User Interface by right-clicking on this taskbar and selecting "Launch Device Manager" or by going to Start Programs Philips Device Manager In the main window, go to the repair tab and click Repair. You will be prompted before repair begins. ATTENTION! All media contents will be erased! Click OK to continue.
If a fault occurs, first check the points listed in the following pages. For further help and other troubleshooting tips, please also check out FAQs at www.philips.com/support. If you are unable to find a solution by following these hints, consult your dealer or service center.
– Active mobile phones in the vicinity may cause interference. – Backup your files. Please ensure that you retain the original files that you have downloaded to your device. Philips is not responsible for any loss of content if the product becomes damaged or not readable / legible.
ONLY if the user returns the device to the Philips service centre and ONLY to simplify error detection and prevention.The data stored shall be made available to user on users' first request.
Philips HDD082 HDD084 HDD085 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses, and can radiate radio frequency...
Music transfer Data transfer System Requirements PHILIPS reserves the right to make design and specification changes for product improvement without prior notice. *Note that some operating systems display capacity in units of “GB” where 1.0 GB = 2 30 = 1,073,741,834 bytes.The resulting “GB”...
