Summary of Contents for Philips EXP 101/01
- Page 1 EXP 101 Portable MP3-CD player EXP 103...
- Page 2 EXP 101/01/16 EXP 103/01/16 Alimentación: 110–127/220–240 V; ~50–60 Hz Consumo: Importador: Philips Mexicana, S.A. de C.V. Domicilio: Norte 45, # 669, Col. Industrial Vallejo Localidad y Telefono: C.P. 02300 México D.F., Tel. 728 42 00 Exportador: Philips Electronics Hong Kong, Ltd.
- Page 3 ∑ Guarantee and service for Use of controls or adjustments or performance of Guarantees New Zealand ........96 procedures other than herein may result in hazardous Certificado de Garantia Philips product warranty for Brasil..........97 radiation exposure. Australia........94–95 Ploiza de Garantía México.........98–99...
- Page 4 CONTROLS QUICK START , refer to the illustration on page 3 1 ......display OPEN 2 9.......stops CD play, erases a program and switches the set off ......switches the set on, starts and interrupts CD play ....CD Audio : skips or fast search tracks forwards MP3 : skips or search a previous track or album (AL) 5 PROGRAM ..programs tracks and reviews the program ....CD Audio : skips or fast search tracks backwards...
-
Page 5: Power Supply
POWER SUPPLY POWER SUPPLY/LINE OUT Batteries Mains adapter (not included) (supplied or optionally available) Only use the AY 3170 mains adapter With this set you can use : (4.5 V/300mA direct current, positive pole to the • alkaline batteries (type LR6, UM3 or AA) centre pin). -
Page 6: General Information
HEADPHONES GENERAL INFORMATION Headphones (AY3677) CD player and CD handling • Do not touch the lens A of the CD player. Connecting the headphones • Connect the supplied headphones to p. • Do not expose the set, batteries or CDs to humidity, rain, sand or excessive heat (caused by heating equipment or direct sunlight). - Page 7 IN-CAR CONNECTION CD PLAY In-car use Playing a CD (connections supplied or optionally available) Only use the AY 3545 car This CD player can play all kinds of Audio Discs and voltage converter (4.5 V, DC, MP3 CD-ROM such as CD Recordables and CD positive pole to the centre pin) Rewritables.
- Page 8 CD PLAY FEATURES Playback information Selecting a track and searching • If a CD Rewritable (CD Recordable) is not recorded properly, nF dISC is Selecting a track during playback displayed. • Briefly press 5 or 6 once or several times to skip For CD Audio, use FINALIZE on your CD recorder to complete the to the current, previous or subsequent track start.
- Page 9 FEATURES FEATURES Programming track numbers Storing the last position played – RESUME You can select up to 30 tracks and store them in the You can store the last position played. When restarting, memory in a desired sequence. You can store any track playback continues from where you have stopped, more than once.
- Page 10 FEATURES FEATURES Selecting different playing options – MODE It is possible to play tracks in random order, to repeat a track or the CD and to play the With a conventional portable CD player, you might have first few seconds of each track. experienced that the music stopped e.g.
- Page 11 MP3-CD PLAYBACK MP3-CD PLAYBACK To play MP3-CDs Selecting and searching a track/album IMPORTANT INFORMATION The following table shows the different functions available for the controls • Use .mp3 as the extension to save audio files onto CD-R(W) or CD ROM, e.g. when playing CD Audio or MP3 CDs.
- Page 12 MP3-CD PLAYBACK MP3-CD PLAYBACK Fast track select Single session In the stop position, you can select tracks from your album (AL 00). The display will show the total number The following chart is an example of a Windows Explorer display for a single of tracks, and AL 00.
- Page 13 MP3-CD PLAYBACK MP3-CD PLAYBACK Multi-session Notes: This chart is an example of a Windows Explorer display for a multi-session MP3 CD Arrow pathway shows the sequence of MP3 ROM with albums. Multi-session playback differs from single session in that each album and track playback.
-
Page 14: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Symptom Check point Treatment WARNING Playback does Is the RESUME or PROGRAM Switch off the RESUME Under no circumstances should you try to repair the set yourself as this not start from function activated? function or clear the will invalidate the guarantee.
