DVD/CD RECEIVER
XV-DV360
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
XV-DV360
KUCXJ
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
Power Requirement
AC 120 V
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
XV-DV360
Regional restriction
codes (Region No.)
1
T-ZZK MAY 2006 printed in Japan
ORDER NO.
RRV3411
Remarks

Advertisement

Table of Contents
loading

Related Manuals for Pioneer XV-DV360

Summary of Contents for Pioneer XV-DV360

  • Page 1 PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936...

  • Page 2: Safety Information

    PIONEER Service Manual. A subscription to, or additional copies Also test with plug reversed of, PIONEER Ser vice Manual may be obtained at a (Using AC adapter Earth nominal charge from PIONEER. plug as required)
  • Page 3 To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be installed before shipment. Please be sure to follow this method especially if it is specified in this manual. XV-DV360...

  • Page 4: Table Of Contents

    7.1.10 CIRCUIT DESCRIPTION OF DIGITAL AMP. SECTION ..............77 7.1.11 SPECIFICATIONS FOR THE PROTECTION CIRCUITS FOR THE DIGITAL AMPLIFIER ..... 78 7.1.12 PASS/FAIL TEST PROCEDURE OF HDMI TRANSMITTER IC ............79 7.1.13 DISASSEMBLY..........................80 7.2 PARTS..............................87 7.2.1 IC ............................... 87 8. PANEL FACILITIES ............................102 XV-DV360...

  • Page 5: Specifications

    • AM Loop Antenna • AA size IEC R6 TOP MENU TUNE MENU (ATB7013) dry cell batteries ENTER HOME (to confirm MENU RETURN TUNE system operation) SETUP TEST TONE SURROUND SOUND TV CONTROL SLEEP INPUT CHANNEL VOLUME MUTE VOLUME XV-DV360...

  • Page 6: Exploded Views And Parts List

    For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions, apply as you think it appropriate.) 2.1 PACKING 7, 8 Front side Joint of Packing XV-DV360...
  • Page 7 • • • • • • • • • • • • Remote Control AXD7440 Battery Cover AZN8018 • • • • • • NSP 19 Polyethylene Bag AHG7117 Packing Sheet AHG7053 Pad L AHA7454 Pad R AHA7455 Packing Case AHG8457 XV-DV360...

  • Page 8: Exterior Section

    2.2 EXTERIOR SECTION Refer to "2.3 06 LOADER ASSY". XV-DV360...
  • Page 9 Front Panel Assy AXG7295 NSP 22 Button AAD7753 NSP 23 Display Window AAK8327 NSP 24 Front Panel AMB7911 Pioneer Name Plate VAM1129 Rubber Foot VEB1325 Tray Panel AAK8329 Bonnet AZN8017 NSP 29 Name Label AAL7424 • • • • • •...

  • Page 10: Loader Assy

    JGZ17P028FTC Flexible Cable (24P) ADD7545 Screw VBA1094 Connector Assy 2P VKP2253 Tray VNL1920 Floating Rubber VEB1351 Clamp Magnet VMG1029 Belt VEB1358 Stabilizer VNE2253 Loading Base VNL1917 Float Base 04 VNL1968 Drive Cam VNL1919 Gear Pulley VNL1921 Loading Gear VNL1922 XV-DV360...
  • Page 11 Rear View Daifree Daifree No. 23 No. 23 GEM1036 GEM1036 Tray Tray Concave of unevenness Concave of unevenness Inner side of a ditch Daifree GEM1036 Top View Bottom View Side of the rib Concave of unevenness Daifree Daifree GEM1036 GEM1036 XV-DV360...

  • Page 12: Traverse Mechanism Assy-S

    Note : Spindle screw (DBA1252) of No.13 is the screw which applied special bond. Therefore the adhesion becomes inteffective when takes it off once. Spindle screw is the part which cannot recycle. When part #2 is replaced, part #13 also need to be replaced at the same time. XV-DV360...
  • Page 13 Joint Spring VK1 DBK1235 Stepping Motor VK1 DXM1201 NSP 8 Mechanism Frame VK1 DNK4160 Precision Screw VK1 DBA1209 Skew Screw VK1 DBA1211 Skew Spring VK1 DBH1516 NSP 12 Stepping Screw DBA1205 Spindle Screw VK1(for Service) DBA1252 NSP 14 Hold Spring DBK1297 XV-DV360...

  • Page 14: Block Diagram And Schematic Diagram

    MECHA -Preset EQ EEPROM etc. Y , Cb , Cr FM/AM TUNER TUNER ADBCK IC3003 UNIT ADLRCK AK5358ET ADDATA LINE/TV 12.288M ADMCK0 ADMCK1 TC7WU04FU IC3004 LINE DVD MAIN ASSY SW+10.5V DVD POWER V+5V SW5.0V SW3.3V(A) 1.8V V+1R8 PWRCONT EV+5V XV-DV360...
  • Page 15 Y, Cb, Cr Y, Cb, Cr Video Composite Y, C Y, C S-Video IC931 HDMI HDMI OUT Transmitter MT1392E/C-L GND +B FLDC +- -25.5V EV5.0V SW3.3V (A) SW 3.3V (B) SW 10.5V AC IN SW 6.8V POWER SUPPLY UNIT SW 5.0V XV-DV360...

  • Page 16: Loab Assy And Overall Wiring Connection Diagram

    CN602 LOAB ASSY MOTOR ASSY CN601 CN104 VWG2346- TRKG RTN TRKG RTN : VXX2912 S5B-PH-K-S B5B-PH-K-S FOCS DRV FOCS DRV LOAD- LOAD- FOCS RTN FOCS RTN LOAD+ LOAD+ LOAB ASSY PICK UP ASSY GNDD GNDD OWY8087- (VWG2346) PF05PP-B40 ADX7480- XV-DV360...
  • Page 17 SDATA1 SDATA1 SDATA2 SDATA2 CN3211 SDATA3 SDATA3 AKE7121 MCLK MCLK SCLK SCLK LRCLK LRCLK LIN1_L LIN1_L LIN1_R LIN1_R CN3102 2P AWK7931 6ch SP OUT AWK7932 S_TVOUT_L S_TVOUT_L AWK7933 AWK7934 FAN CONT S_TVOUT_R S_TVOUT_R RECMUTE RECMUTE FANCONT FAN CONT/GND * XV-DV360...

  • Page 18: Dvd Main Assy (1/5)

    V+3D XFLAG USB POWER CONTROL 3-C2 USBPOWER V+5USB 3-B4 V+6R8 IC781 NJM2845DL-05 D782 D781 STBY STBY L772 R772 GNDD 100k ATL7002-A-T XFLAG R771 FLASH AYW7096 IC771 AAT4618IGV-0.5-1-TLB V+5USB V+3D C773 C771 STBY 0.1/16 1/16 C772 R284 GNDD R285 GNDD XV-DV360...
  • Page 19 R257 (R/Cr) R269 : VIDEO SIGNAL ROUTE (R/Cr) R240 (G/Y) : VIDEO SIGNAL ROUTE (G/Y) R247 (B/Cb) R243 : VIDEO SIGNAL ROUTE (B/Cb) R248 (AD) R262 : AUDIO DATA SIGNAL ROUTE R263 (HDMI) R222 : VIDEO/AUDIO SIGNAL ROUTE (HDMI) XV-DV360...

  • Page 20: Dvd Main Assy (2/5)

    HDMI Transmitter AVDD C942 DVSS TCK+ TCK- AVSS AVSS AVDD AVDD PLLC1 PLLC0 AVSS GNDD GNDD R901 STBY R902 STBY PRDN R903 STBY R904 STBY INT0# R905 STBY HDMISCL XDVDRST HDMISDA PUSEL GNDD C940 STBY IC932 STBY EEPROM GNDD XV-DV360...
  • Page 21 R958 CLOCK- STBY STBY V+5HD STBY R974 STBY HDMISCL HDMISDA R975 DDC/CEC GND STBY R973 GNDD HOT PLUG DETECT V+5HD V+5HD Q934 UMB1N GNDD Q934 UMB1N Q936 STBY Q935 STBY Q935 STBY Q933 R970 RT1N144M (DTC114YUA) D933 UDZS5R1(B) GNDD XV-DV360...

  • Page 22: Dvd Main Assy (3/5)

    STBY CKS3378- C5604 R5544 GNDD STBY KEY2 R5598 STBY KEY1 R5543 C5605 GNDD STBY C5603 GNDD 1000p FLDC+ FLDC- C5602 VFDP 1000p VE+5 REMOCON REMOUT 3-A5 FLCS FLCK FLDATA C5601 1000p FLDC- FLDC+ GNDD KN5601 STBY VFDP CHASSIS GND XV-DV360...
  • Page 23 4.7k GNDD 2SC4154(BFG) (2SC4081(QR)) SW3.3V(B) DATA SELECTOR BACK END IC IC1101 SW3.3V(A) R1101 NJM2846DL3-18 V+1R8 HDMI Pwr-ctr GNDD V+1R8 FL DC- FL DC+ -25.5V GNDD 2/5,4/5 BEAT_CUT DVDPOWER FLDC- FLDC+ VFDP R1001 CHASSIS GND STBY KN1001 STBY GNDM GNDD XV-DV360...

  • Page 24: Dvd Main Assy (4/5)

    CKSR**~ (C/V) : VIDEO SIGNAL ROUTE(C/V) (S_Y) : VIDEO SIGNAL ROUTE (S_Y) (S_C) : VIDEO SIGNAL ROUTE (S_C) : VIDEO SIGNAL ROUTE (R) : VIDEO SIGNAL ROUTE (G) : VIDEO SIGNAL ROUTE (B) (AD) : AUDIO DATA SIGNAL ROUTE XV-DV360...
  • Page 25 S VIDEO OUTPUT C428 STBY R423 C423 1000/6.3 STBY JA402 XKB3061 (VKB1153) L422 CTF1389- R426 C426 C431 STBY 470/6.3 L421 COMPONENT CTF1389- R425 VIDEO C430 75 (F) C425 OUTPUT 470/6.3 STBY R9402 R424 C424 C429 STBY 1000/6.3 EU,GA GNDD XV-DV360...

  • Page 26: Dvd Main Assy (5/5)

    STBY VREF GNDD VREF C3019 STBY 10/50 J,KUC R3019 C3020 R3020 GNDD J,KUC 10/50 R5712 R5713 V+10 MICOUT CN5701 R5714 CKS3376 STBY (1/2) Q5703 R5715 RT3CLLM(EF) STBY R5716 (HN1C01FU) STBY R5717 (2/2) Q5703 STBY RT3CLLM(EF) R5718 STBY (HN1C01FU) GNDD XV-DV360...
  • Page 27 R3065 ADDATA BCKO ASDAT0 ADMCK1 R3063 DATA0 ACLK R3066 (AD) MCKO (AD) GNDD VREF Chip Size RESISTOR : 2125 Size RS1/10S~ :1608 Size RS1/16S~ CAPACITOR : 2125 Size CKSQ**~ :1608 Size CCSR**~ CKSR**~ (AD) : AUDIO DATA SIGNAL ROUTE XV-DV360...

  • Page 28: Damp Assy (1/2)

    VBGAP GNDD GNDA /RESET GNDD XHPSEL /HP_SEL XPDN /PDN XMUTE /MUTE STBY R3104 V+3R3 V+3R3 DVDD DVSS R3105 23 24 26 27 IC3181 SN74AHC1G04DBV-TLB STBY XRST X3101 GNDD ASS7062 IC3182 T-TPS3825-33DBVR R3106 R3181 4.7K GNDD RESET CONTROL CIRCUIT TAS5508 XV-DV360...
  • Page 29 PWM_P_1 PWM_M_1 (AD) PWM_M_1 VALID VALID CN3201 D3101 IC3191 DVSS R3110 MC2846-11 BA10358F B2P-VH GNDD /BKND_ERR (DAP202U) POWER CONFIG STBY DVDD V+3R3 DVSS DVSS R3109 VR_DIG STBY 29 30 31 32 GNDD GNDD (AD) : AUDIO DATA SIGNAL ROUTE XV-DV360...

  • Page 30: Damp Assy (2/2)

    PWM_P_2 330p/50 OUT_C R3304 R3343 VALID /RESET_CD R3341 ATH7019 OUT_D C3341 R3303 STBY /SD_AB OUT_D 330p/50 C3311 R3311 R3302 STBY /SD_CD PVDD_D R3301 STBY XOTW 0.1/50 /OTW PVDD_D R3315 GREG BST_D GVDD V+BSW GNDD NOTICE R3211~R3214,R3311~R3314,R3411~R3414 : ACN7148 (2.7Ω)) XV-DV360...
  • Page 31 L3401 PWM_M_7 C3443 OUT_C 0.1/50 PWM_P_7 330p/50 OUT_C R3404 R3443 VALID /RESET_CD R3441 ATH7019 OUT_D C3441 R3403 STBY 330p/50 /SD_AB OUT_D C3411 R3411 R3402 STBY /SD_CD PVDD_D R3401 STBY XOTW /OTW PVDD_D 0.1/50 R3415 GREG BST_D GVDD V+BSW GNDD XV-DV360...

  • Page 32: Display And Usb Assys

    RS1/10S***J CN5902 GNDD CKS3376 HPMUTE ALL INDUCTORS ARE IN µH V5USB HP_L JA602 XKP3086 GNDD LAU***J-TA HP_R HP_DET L601 STBY GNDUSB V5USB L603 STBY V5USB USB_DP2 L602 STBY USB_DM2 SHLD GNDUSB C603 STBY R602 STBY R603 STBY GNDUSB GNDD XV-DV360...
  • Page 33 XV-DV360...

  • Page 34: Power Supply Unit

    3.11 POWER SUPPLY UNIT XV-DV360...
  • Page 35 POWER SUPPLY UNIT (AWR7046) CN3201 XV-DV360...

  • Page 36: Waveforms

    CN102-pin 11, 10, 9 (IC101-pin 30, 33, 36) [SPINDLE (WVU)] V: 2V/div. H: 2msec/div. IC401-pin23 [CompositeVideo Out] IC401-pin21 [S VIDEO OUT - Y] V: 1V/div. H: 10µsec/div. V: 1V/div. H: 10µsec/div. IC401-pin26 [S VIDEO OUT - C] V: 1V/div. H: 10µsec/div. XV-DV360...
  • Page 37 V: 1V/div. H: 20nsec/div. V: 2V/div. H: 500nsec/div. IC201-pin210 [ABCK] V: 2V/div. H: 500nsec/div. IC201-pin197 [ASDATA0] V: 2V/div. H: 500sec/div. DAMP ASSY IC3201, IC3301, IC3401 [PWM_M, PWM_P] IC3201, IC3301, IC3401 [OUT_A, B, C, D] V: 1V/div. H: 2µsec/div. V: 5V/div. H: 2µsec/div. XV-DV360...
  • Page 38 XV-DV360...

  • Page 39: Pcb Connection Diagram

    Resistor array 3-terminal regulator 4.1 LOAB ASSY SIDE A SIDE B LOAB ASSY LOAB ASSY VNP1836-C LOAB PNE-1B1 S101 LOAD+ VWG2279- CN602 C102 LOAD- CN602 VWG2346- C101 CN601 (VNP1836-C) (VNP1836-C) CN601 CN602 CN601 CN601 CN602 CN104 LOADING MOTOR ASSY XV-DV360...

  • Page 40: Dvd Main Assy

    R271 R265 D1415 R5582 CN5501 R281 KN5501 Q1413 R5558 R5581 C282 R267 R1403 R1401 C281 R1404 C5557 IC202 C286 C287 C288 C283 R1402 0 1 2 3 0 1 2 3 4 5 6 7 8 9 CN5602 CN5901 XV-DV360...
  • Page 41 C414 R903 R962 L3901 R257 R269 R914 C455 C238 C270 C283 R433 C945 R966 R970 VA902 R975 C415 Q934 C261 R964 C451 IC932 D933 R968 VA901 R974 C457 R959 R960 C222 R967 R963 Q935 C416 Q936 R965 R969 (ANP7566-C) XV-DV360...
  • Page 42 SIDE B DVD MAIN ASSY CN401 CN3002 CN3001 CN5701 XV-DV360...
  • Page 43 SIDE B CN1001 CN103 CN102 (ANP7566-C) XV-DV360...

  • Page 44: Damp Assy

    C3923 AWK7932 DAMP ASSY AWK7933 C3613 C3614 R3151 R3152 R3611 R3612 R3607 R3608 R3606 AWK7935 C3624 C3623 C3602 C3608 R3605 C3152 CN3101 CN3102 C3604 C3601 C3607 C3603 R3601 D3603 R3624 C3622 C3621 R3623 R3621 (ANP7531-D) CN3101 CN3102 CN3001 CN3002 XV-DV360...
  • Page 45 SIDE B SIDE B DAMP ASSY CN3201 C3448 C3447 C3445 C3446 C3348 C3345 C3347 C3346 C3248 C3245 C3247 C3246 CN3102 CN3101 (ANP7531-D) XV-DV360...

  • Page 46: Display And Usb Assys

    4.4 DISPLAY and USB ASSYS SIDE A SIDE A DISPLAY ASSY CN5602 CN5901 (ANP7568-A) USB ASSY CN5601 CN5902 CONTACT SIDE W5904 C602 PNE-1B1 Production Code KN5902 USB ASSY W5902 GNDUSB AWU8290 W5913 W5901 JA5901 JA602 GNDUSB (ANP7568-A) XV-DV360...
  • Page 47 SIDE B SIDE B DISPLAY ASSY CN5901 (ANP7568-A) USB ASSY CN5902 CN5902 USB ASSY PNE-1B1 GNDUSB GNDUSB JA5901 JA602 (ANP7568-A) XV-DV360...

  • Page 48: Power Supply Unit

    4.5 POWER SUPPLY UNIT SIDE A SIDE A POWER SUPPLY UNIT To AC POWER CORD XV-DV360...
  • Page 49 SIDE B SIDE B POWER SUPPLY UNIT XV-DV360...

  • Page 50: Pcb Parts List

    L 937 (A,100,169) CHIP BEADS ATL7010 Q 307 (A,11,61) CHIP TRANSISTOR HN1A01F L 1305(A,20,108) INDUCTOR CTF1395 L 1501(A,58,44) AXIAL INDUCTOR LAU220J Q 308 (A,16,61) CHIP TRANSISTOR HN1A01F L 3951(A,40,65) INDUCTOR CTF1346 Q 933 (A,114,212) TRANSISTOR RT1N144M L 3952(A,38,65) INDUCTOR CTF1346 XV-DV360...
  • Page 51 R 233 (A,68,92) RS1/16S0R0J R 426 (A,29,210) RS1/10S75R0F R 234 (A,79,86) RS1/16S330J R 767 (A,51,104) RS1/16S153J R 235 (A,77,86) RS1/16S472J R 768 (A,52,101) RS1/16S153J R 237 (A,77,89) RS1/16S330J R 769 (A,51,103) RS1/16S330J R 240 (A,88,147) RS1/16S0R0J R 770 (A,52,100) RS1/16S330J XV-DV360...
  • Page 52 R 3054(A,31,128) RS1/16S101J CAPACITORS R 3055(A,27,129) RS1/16S105J C 101 (A,40,18) CEAT101M10 R 3056(A,23,129) RS1/16S101J C 102 (A,40,22) CKSRYB105K10 R 3057(A,27,150) RS1/16S0R0J C 103 (A,48,29) CKSRYB105K10 R 3060(A,29,143) RS1/16S0R0J C 104 (A,49,34) CKSRYB105K10 C 121 (A,48,32) CKSRYB105K6R3 R 3061(A,37,130) RS1/16S221J XV-DV360...
  • Page 53 CCSRCH9R0D50 C 931 (A,96,186) CKSRYB104K16 C 252 (A,74,135) CCSRCH120J50 C 932 (A,97,180) ELECT. CAPACITOR CEAT470M35 C 254 (A,67,135) CKSRYB102K50 C 933 (A,94,185) CKSRYB104K16 C 255 (A,60,137) CKSRYB474K10 C 934 (A,94,187) CKSRYB102K50 C 256 (A,64,140) CEAT100M50 C 935 (A,96,166) CKSRYB104K16 XV-DV360...
  • Page 54 C 5517(A,68,41) CKSRYB103K50 R 3112(A,18,97) RS1/16S470J C 5518(A,66,38) CKSRYB104K16 R 3113(A,15,96) RS1/16S3R3J C 5519(A,62,33) CKSRYB103K50 R 3114(A,28,54) RS1/16S103J C 5521(A,63,28) CKSRYB104K16 R 3131(A,41,140) RS1/16S473J C 5522(A,64,33) CKSRYB103K50 R 3132(A,39,136) RS1/10S123J C 5524(A,62,65) CEAT100M50 R 3133(A,39,133) RS1/16S102J C 5539(A,84,25) CKSRYB104K16 XV-DV360...
  • Page 55 R 3911(A,13,32) RS1/16S183J R 3316(A,64,87) CHIP RESISTOR RS1/8S1R5J R 3912(A,9,32) RS1/16S183J R 3317(A,64,82) CHIP RESISTOR RS1/8S1R5J R 3913(A,11,43) RS1/16S472J R 3318(A,64,96) CHIP RESISTOR RS1/8S1R5J R 3914(A,7,42) RS1/16S472J R 3323(A,39,73) RS1/10S821J R 3915(A,12,41) RS1/16S472J R 3324(A,39,96) RS1/10S821J R 3916(A,8,43) RS1/16S472J XV-DV360...
  • Page 56 C 3428(A,49,124) CKSRYB104K25 C 3237(A,104,66) CKSRYB103K50 C 3431(A,85,111) CFTLA474J50 C 3238(A,107,66) CKSRYB103K50 C 3432(A,85,128) CFTLA474J50 C 3239(A,101,66) CKSRYB103K50 C 3433(A,102,113) CKSRYB104K25 C 3240(A,110,66) CKSRYB103K50 C 3434(A,107,107) CKSRYB104K25 C 3241(A,56,44) CKSRYB331K50 C 3435(A,102,111) CKSRYB104K25 C 3242(A,56,58) CKSRYB331K50 C 3436(A,107,110) CKSRYB104K25 XV-DV360...
  • Page 57 This assembly has no service parts. CAPACITORS C 5907(A,67,59) ELECT. CAPACITOR CEJQ470M35 FM/AM TUNER UNIT C 5911(B,165,42) CKSRYB223K50 C 5912(B,159,45) CKSRYB223K50 This assembly has no service parts. C 5913(A,162,46) CEAL470M6R3 C 5915(B,134,36) CKSRYB103K50 C 5916(B,114,50) CKSRYB223K50 C 5917(B,127,47) CKSRYB223K50 C 5918(A,123,46) ELECTR. CAPACITOR CEAL470M35 XV-DV360...

  • Page 58: Adjustment

    [Electrical Part] screw screw Electrical adjustments are not required. 6.2 JIGS AND MEASURING INSTRUMENTS Test mode remote control Screwdriver (large) Screwdriver (medium) TV monitor unit (GGF1381) Screw tight (GYL1001) DVD test disc Precise screwdriver Soldering iron (GGV1025) XV-DV360...

  • Page 59: Necessary Adjustment Points

    Exchange the Traverse Mechanism point Assy-S Electric point ∗ After adjustment, screw locks Mechanical Ÿ Exchange the Spindle Motor point with the Screw tight. Electric point Exchange PCB Assy Mechanical Exchange PC Board point LOAB and DVD MAIN ASSYS Electric point XV-DV360...

  • Page 60: Test Mode

    • After going into test mode, if you play back the disc, "DISC-NON" is displayed. • The video signal and the audio signal are outputted during the test mode. • The SKIP key and the SCAN key are effective during the test mode. TEST MODE: OFF POWER GGF1381 Test mode remote control unit XV-DV360...

  • Page 61: Mechanism Adjustment

    (Refer to "6.1 ADJUSTMENT ITEMS AND LOCATION".) Joint 7.5mm Mechanism base • Attach the Traverse Mechanism Assy-S to the 06 LOADER Assy. • Turn it over and attach the joint and the joint spring. • Arrange the flexible cables. (Refer to "7.1.13 DISASSEMBLY".) XV-DV360...
  • Page 62 90 degrees step till ERROR RATE block error rate becomes around "1E-3" again . CHP/TIM • Record the number of rotation (N1). • Fasten the tangential adjustment screw till the number of rotation becomes Service mode end harf of N1. Best tangential point XV-DV360...

  • Page 63: General Information

    : Press the [TEST] (A8-5E) and [4] (A8-04) keys in order, and turn on the laser diode (780n). 3 Release the Test mode • Turn off the power. • Press the [ESC] (A8-5F) key of the remote control unit and reset it. XV-DV360...

  • Page 64: Display Specification Of The Test Mode

    : [NTSC] PAL system : [PAL] Automatic setting : [AUTO] Scart terminal output [SK – ∗ ∗] (Display only the WY model which can do the output setting of scart terminal.) VIDEO : [00] S-VIDEO : [01] : [02] XV-DV360...

  • Page 65: Functional Specification Of The Shortcut Key

    • Region confirmation mode (ESC + A.MON [Test mode remote control unit] + "1"-"8" [Test mode remote control unit] keys) After you press the AUDIO key while holding the ESC key pressed and then input the region number, if the number is different from that set in the unit, an error message is displayed, and the tray opens. XV-DV360...

  • Page 66: Specification Of Model Information Display

    Display it according to model information set from the FL controller. 2 Region No. 3 Part number 4 ROM version 5 Flash size 6 FL controller version 7 CHIP VERSION 9 Remote control code 0 Key code of Main unit XV-DV360...

  • Page 67: Functional Specification Of The Service Mode

    %%e -2 : NG 7.0e -4 : NG 3 EDC/ID error history (ID Address, EDC/ID errors, last eight errors) Note: ∗ Error of AV1 is not supported in this player. Indication plan contents Character in bold : Item name : Information display XV-DV360...

  • Page 68: Service Test Mode

    TUNER S E R headphone operation with 5-channel STEREO is not LINE S E R guaranteed. If you wish to check the sound through the headphones, use a function other than LINE. XV-DV360...
  • Page 69 • The accumulated power-on time basically cannot be cleared. Service Test Mode connecting point R5531 R5532 R5533 R5534 DVD MAIN ASSY C5605 R5535 SIDE A C5604 R5536 R5537 R5544 R5538 Q5533 R5545 R5543 R5566 R5570 Connecting point D1417 R5548 R5557 D1416 V+3R3 R1415 XV-DV360...

  • Page 70: Method For Diagnosing Degradation Of The Lds On The Pickup Assy

    PICKUP ASSY DVD MAIN ASSY CN101 Q307 R322 Q308 C309 R321 R325 R318 L308 Q305 C310 R326 Q304 R313 L309 R3952 R3954 Front side L3952 SIDE A L3951 R3953 R772 C773 R3951 C144 C131 C146 C145 IC771 R771 L772 XV-DV360...

  • Page 71: Dvd Trouble Shooting

    An opening screen is not DVDMAIN Assy displayed on the monitor Check the video signal path between DVD IC (DVDMAIN Assy IC201) Video circuit after DVD IC (The FL display lights. The and video-out terminal (see the block diagram) (IC201) mechanism works.) XV-DV360...
  • Page 72 Video IC (IC401, IC451) RGB video signal (IC401-pin 16, pin 18, pin 20) Check the waveform (ALCK : IC201-pin 212), (ALRCK : IC201-pin No sound DVDMAIN Assy 209), (ABCK : IC201-pin 210), (ASDATA0 : IC201-pin 197). (Picture is normal) DVD IC (IC201) XV-DV360...
  • Page 73 Any kind of symptoms (no power, a failure in any of the servo, video and audio systems, etc.) may be (DVDMAIN Assy : IC201) generated, because the DVD processing is performed by a single chip. 64M SDRAM No power. (DVDMAIN Assy : IC202) Block noise is generated during playback. XV-DV360...

  • Page 74: Id Number And Id Data Setting

    ID number. 0 0 0 0 0 0 0 0 1 Note: If you press the PLAY button before inputting a 9-digit ID <PLAY> Enter number, the unit returns to Step 2 without doing anything else. Input ID Number ! XV-DV360...
  • Page 75 (The STOP key is not accepted after all 9 digits have been entered.) [Player's ID Number Setting] ID Number ? 0 0 0 0 0 0 0 0 1 Compare 0 0 0 0 0 0 0 0 1 <PLAY> Enter <STOP> Memory Clear Input ID Number ! XV-DV360...
  • Page 76 Insert The ID Data Disc ! If no ID data are set after the ID number is changed, the message "NO DATA" flashes on the screen and FL display for a few seconds after the power is turned on or during Stop mode. XV-DV360...

  • Page 77: Circuit Description Of Digital Amp. Section

    As a signal to drive the BTL is output from the negative speaker terminal, DO NOT short-circuit between the negative speaker terminal and ground, such as the chassis. COMPONENT FRONT CENTER VIDEO LINE AC IN SURROUND WOOFER VIDEO OUT AUDIO IN SPEAKERS Negative Speaker Terminal Do not short-circuit Ground (Chassis) XV-DV360...

  • Page 78: Specifications For The Protection Circuits For The Digital Amplifier

    Conditions: The above prerequisite is upheld, and the conditions for an overcurrent detection are met. 5. Process when the protection circuits are activated The unit is shut down within 30 ms after abnormality detection then the volume level is set to 0. The unit can be turned on immediately after the shutdown. XV-DV360...

  • Page 79: Pass/Fail Test Procedure Of Hdmi Transmitter Ic

    PC monitor equipped with a Check if the initialization process for HDCP, etc. is OK by DVI input. connecting this unit with a Pioneer Plasma Display equipped Purpose: To check if the HDMI output line, including the with an HDMI input.

  • Page 80: Disassembly

    Press the 0 OPEN/CLOSE button to close the tray. (Test disc is clamped.) Press the STANDBY/ON button to turn off the power. Pull out the Power cord. Test disc Tray open Slit Tray Tray panel Screwdriver (small) Screwdriver (small) Projection Drive cam 06 LOADER Assy Bottom view XV-DV360...
  • Page 81 (open). Disconnect the four connectors. Remove the two screws. Remove the 06 LOADER Assy. Note: Do not touch the bottom side of the 06SD Pickup Assy. If touched, the optical axis may be shifted. 06 LOADER Assy XV-DV360...
  • Page 82 Bridge 04 Tray Note when reinserting the tray When reinserting the tray, first align the triangle Drive cam printed on the loading base and the pin of the drive cam, then insert the tray. Front side Loading base Triangle XV-DV360...
  • Page 83 Note: Do not touch the IC for the optical axis. If touched, the optical axis may be shifted. Flexible cable for the pickup Bottom view Unhook the four hooks. Traverse Mechanism Assy-S × 2 Remove the Traverse Mechanism Assy-S. × 2 XV-DV360...
  • Page 84 Remove the two adjustment screws. (skew screw VK1) Adjustment screw Remove the 06SD Pickup Assy. (skew screw VK1) 06SD Pickup Assy Note: Be careful not to lose the adjustment spring (skew spring VK1). Adjustment screw (skew screw VK1) Adjustment spring (skew spring VK1) XV-DV360...
  • Page 85 Silicone Adhesive GEM1037 Arrangement of the flexible cable for the spindle motor : Conductive surface Hook Front Side [Caution] DO NOT touch the OE IC. It occurs out of the optical axis due to the shock. Hook Bottom view XV-DV360...
  • Page 86 Pass the flexible cable through the hook. Attach the flexible cable for the pickup to the connector. Reference line Hook Hook Front Side Bottom View Fold the flexible cable along the hook. Pass the flexible cable through the hook. Hook Hold Spring Backing Hook XV-DV360...

  • Page 87: Parts

    Control of DSPMUTE combining DIRERR., "L" at digital mode, "H" at analog mode. ADMD XADPDN POWER DOWN for A/D DSPMUTE MUTE requeat to DSP MODULE Control of LED XDEC MUTE Detection of 1stDSP boot success from DSP MODULE DSPHREQ Error detection from DSP (MOTOROLA) − VSS4 VSS4 − VDD4 VDD4 XV-DV360...
  • Page 88 DIGITAL INPUT SELECT P32/UTX1 SR+TX UART Tx of SR+ function P33/URX1 SR+RX UART Rx of SR+ function P34/UTX2 SHUTDWN D-AMP SHUTDOWN detection P35/URX2 XREADY XREADY for DVD module XOTW D-AMP Over Temperature Warning PB7/D7 XDVDRST RESET to DVD MODULE XV-DV360...
  • Page 89 • PortE and PortF can be selected for input or output by each 2 bits. • In case of without RDS, it is best that RDSDATA and RDSCLK are assigned as I/O port which can be set output and output low level. XV-DV360...
  • Page 90 VPLLVDD3 USB_VSS RCLK USBP USBM DVDD3 USB_VDD3 FG/V_ADIN8 TDI / V_ADIN4 DVDD18 TMS / V_ADIN5 TCK / V_ADIN6 TDO / V_ADIN7 RA10 DVDD18 IOA2 IOA3 RCS# IOA4 RAS# IOA5 CAS# IOA6 RWE# IOA7 DQM1 HIGHA0 DVDD3 IOA18 IO_18 IOA19 XV-DV360...
  • Page 91 Servo I/O Servo Motor Video Processor Drive Digital Video Deinterlacer Processor Spindle Control MPEG-1/2 Flash ROM JPEG Audio Video Decoder Memory Controller Audio 5.1ch Audio DRAM External System Audio DAC Parser Audio Output CPPM/CPRM SPDIF System GPIO 32-bit RISC IR/VFD XV-DV360...
  • Page 92 VPLL External Capacitance connection 45 VPLLVDD3 Power Analog 3.3V Power for VPLL Reference Voltage (3) Name Alt. Function 28 V2REFO Analog output Reference voltage 2.8V 29 V20 Analog output Reference voltage 2.0V 30 VREFO Analog output Reference voltage 1.4V XV-DV360...
  • Page 93 Analog output Focus servo output. PDM output of focus servo compensator LVTTL 3.3V Input, Schmitt Input, 50 FG (Digital pin) V_ADIN8 pull up , with Motor Hall sensor input, or Version AD input 8 analog input path for V_ADIN8 XV-DV360...
  • Page 94 78 IOOE# Inout, 2-16MA, SR, SMT Flash output enable, active low / IO 66 IOWR# Inout, 2-16MA, SR, SMT Flash write enable, active low / IO Inout, 2-16MA, SR 76 IOCS# Flash chip select, active low / IO PU,SMT XV-DV360...
  • Page 95 I2C clock pin Microcontroller port 3-5 Hardwired RD232 TXD 106 UP3_5 Inout, 4MA, SR, PU, SMT C data pin 109 IR Input, SMT IR control signal input Inout, 2-16MA, 110 INT0# Microcontroller external interrupt 0, active low SR, PU, SMT XV-DV360...
  • Page 96 While not support Microphone: 215 MC_DATA INT2# PD SMT Microcontroller external interrupt 2 GPIO Output, 2-16MA, SR : ON/OFF 216 SPDIF SPDIF output Non-pull 217 APLLVDD3 Power 3.3V Power pin for audio clock circuitry 218 APLLCAP Analog Inout APLL External Capacitance connection XV-DV360...
  • Page 97 Blue or CB Output Video data output bit 6 182 YUV6 R/Cr/Pr 4MA, SR Red or CR Vertical sync input/output Inout While no External TV-encoder: 4MA,SR 181 YSYN V_ADIN1 Vertical sync for video-input Version AD input port 1 Non-pull GPIO XV-DV360...
  • Page 98 Digital Video output C bit 5 169 C_5 (RD21) Non-pull GPIO IO_6 Inout Digital Video output C bit 6 168 C_6 (RD22) Non-pull GPIO IO_7 Inout Digital Video output C bit 7 167 C_7 (RD23) Non-pull GPIO Inout GPIO 177 IO_17 (DQM2) Pull-Up XV-DV360...
  • Page 99 DRAM data 10 126 RD11 Inout DRAM data 11 125 RD12 Inout DRAM data 12 124 RD13 Inout DRAM data 13 123 RD14 Inout DRAM data 14 122 RD15 Inout DRAM data 15 121 RD0 Inout DRAM data 0 XV-DV360...
  • Page 100 Version AD input port 5 Non-Pull GPIO Serial interface port 3 clock pin Inout 53 TCK V_ADIN6 Version AD input port 6 Non-Pull GPIO Serial interface port 3 chip-select Inout 54 TDO V_ADIN7 Version AD input port 7 Non-Pull XV-DV360...
  • Page 101 I/O Audio serial data clock "L" output in master mode at power-down mode. 13 PDN Power down mode "H": Power up, "L": Power down 14 DIF Audio interface format "H": 24bit I S compatible, "L": 24bit MSB justified 15 CKS2 Mode select 2 16 CKS0 Mode select 0 XV-DV360...

  • Page 102: Panel Facilities

    CD , TUNER , USB , LINE ). USB interface Number buttons / CLEAR / DISPLAY Connect a USB device for playback (see USB CLEAR playback ). Clears an entry. PHONES jack DISPLAY Connect headphones. Displays/changes disc information shown Display on-screen. See Display below. XV-DV360...
  • Page 103 USB playback for an explanation pressing MENU. of these controls. TV CONTROL buttons Cursor buttons, ENTER and tuning These control Pioneer plasma displays. buttons 10 MUTE Cursor buttons Use the cursor buttons ( / / Mutes the sound (press again to cancel).

  • Page 104: Jigs List

    "6.5 MECHANISM ADJUSTMENT" CLEANING Before shipping out the product, be sure to clean the following positions by using the prescribed cleaning tools: Position to be cleaned Cleaning tools Pickup leneses Cleaning liquid : GEM1004 Cleaning paper : GED-008 XV-DV360...
