Summary of Contents for BodyTrain T103
- Page 1 MOTORIZED TREADMILL BodyTrain Walking Elite INSTRUCTION Thank you very much for purchasing our product. Please read this instruction carefully before use it and keep the instruction at proper place.
- Page 2 1. CAUTION To avoid any hurts, please read this manual carefully before using. For safety purpose do not stand on running belt while start. Please stop immediately for any feeling of vomit、jerky during using. Please speed up slowly if needed. ...
- Page 3 Please do not stand directly on the belt while starting the machine. Do not disassemble the machine without conduct of professional person. Please make sure the running belt is fastened before using. 4. TECHNICAL SPECIFICATION BodyTrain Walking Elite Product Name 500W Power...
- Page 4 5. ASSEMBLY PARTS Name Specification Main Frame Handrail Control Panel Wheel Fix Knob M12*45 Hex Wrench Screw M8*50 Arc Washer Φ8 Silicone Oil Handrail cap Safety Key...
- Page 5 6. Assemble Instruction 1. Put the machine on flat ground. 2. Open the frame. 3. Assemble the handrail,the fast connect plug wire 4. The second by handrail put the frame, fix by screws on handrail. 5. Install the two wheels into the frame and fix by screws. 6.
- Page 6 7.Control Panel 1. Plug in the power, open the power switch（display“ERR”） ，put on safety key （display“OFF”） 2. Screen display“OFF”，Press“ON/OFF”key, the machine will start by 1km/h after 3 seconds。And then press“ON/OFF”key，the machine will stop。 3. Press “+”key for speed up and “-” for slow down， the lowest speed is 1.0KM/H， the fastest is 6.0KM/H。...
- Page 7 Fold：After use, please fold the machine and insert the fix knob. If the long time does not use the machine can be pushed to the idle position space saving. Unfold：Put the machine on the ground smoothly, open the fix knob. 9.
- Page 8 (1) Running belt deviate to left Start the machine by speed at 2-3Km/h without loading, use die nut to make the screw go 1/4 circle(see fig1). Then make the machine running without loading 1-2 minutes. Please adjust like this to make the belt till to mid place. (2) Running belt deviate to right Start the machine by speed at 2-3Km/h without loading, use die nut to make the screw go 1/4 circle(see fig2).
