M.2 PCIe SSD RAID

You can create M.2 PCIe SSD RAID volume with UEFI BIOS.
Creating a M.2 PCIe SSD RAID Volume
1. Access the BIOS setup
2. Switch to Advanced Mode by pressing F7 key.
3. Go to SETTINGS > Advanced > Windows OS Configuration.
4. Set Windows 8.1/10 WHQL Support to Enabled.
5. Go to SETTINGS > Advanced > Integrated Peripherals.
Setting\Advanced\Integrated Peripherals
SATA Configuration
SATA Mode
M2_1 Pcie Storage Remapping
M2_2 Pcie Storage Remapping
M2_3 Pcie Storage Remapping
6. Set SATA Mode to RAID Mode.
7. Set the M2_1/ M2_2/ M2_3 Pcie Storage Remapping items to Enabled.
8. Press F10 to save and exit and then press the Enter key to select Yes.
9. Reboot the system and access the BIOS setup again.
10. Switch to Advanced Mode by pressing F7 key.
11. Go to SETTINGS > Advanced > Intel(R) Rapid Storage Technology.
12. Select Create RAID Volume and press Enter key.
...\Intel(R) Rapid Storage Technology\
Create RAID Volume
Create RAID Volume
Name:
RAID Level:
Select Disks:
PCIe, XXXXX XXXXXXXX-XXXX, XXXGB
PCIe, XXXXX XXXXXXXX-XXXX, XXXGB
Strip Size:
Capacity (MB):
Create Volume
13. Enter in a volume name.
14. Select the RAID level.
15. Use Space key to select the both PCIe SSDs.
16. If creating RAID 0, select the Strip Size; it is recommended that it be left at the
default value.
17. Go to the Create Volume field and press Enter.
[RAID Mode]
[Enabled]
[Enabled]
[Enabled]
Volume1
[RAID0(Stripe)]
[X]
[X]
[XXKB]
XXXXXX
RAID Configuration
115
