Welcome to the growing group of value−conscious people who drive Toyotas. We are proud of the advanced engineering and
quality construction of each vehicle we build.
This Owner's Manual explains the operation of your new Toyota. Please read it thoroughly and have all the occupants
follow the instructions carefully. Doing so will help you enjoy many years of safe and trouble−free motoring. For
important information about this manual and your Toyota, read the following pages carefully.
When it comes to service, remember that your Toyota dealer knows your vehicle very well and is interested in your complete
satisfaction. Your Toyota dealer will provide quality maintenance and any other assistance you may require.
If there is not a Toyota dealer near you, please call the following number:
:
U.S. OWNERS
D
When traveling in the U.S. mainland or Canada:
Toyota Customer Experience Center
D
Hawaii:
Servco Automotive Customer Services
Please leave this Owner's Manual in this vehicle at the time of resale. The next owner will need this information also.
All information and specifications in this manual are current at the time of printing. However, because of Toyota's policy of
continual product improvement, we reserve the right to make changes at any time without notice.
Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may
find some explanations for equipment not installed on your vehicle.
Please access our websites for further information.
D
The U.S. mainland
www.toyota.com
Hawaii
www.toyotahawaii.com
D
©
2006 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in whole or in part, without the written permission of Toyota
Motor Corporation.
Foreword
Toll−free:1−800−331−4331
Toll−free:1−888−272−5515
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Land Cruiser 2007 and is the answer not in the manual?

Questions and answers

Related Manuals for Toyota Land Cruiser 2007

Summary of Contents for Toyota Land Cruiser 2007

  • Page 1 Please access our websites for further information. The U.S. mainland www.toyota.com Hawaii www.toyotahawaii.com © 2006 TOYOTA MOTOR CORPORATION All rights reserved. This material may not be reproduced or copied, in whole or in part, without the written permission of Toyota Motor Corporation.

  • Page 2: Important Information About This Manual

    Important information about this manual Safety and vehicle damage warnings Safety symbol Throughout this manual, you will see safety and vehicle dam- age warnings. You must follow these warnings carefully to avoid possible injury or damage. The types of warnings, what they look like, and how they are used in this manual are explained as follows: CAUTION This is a warning against anything which may...

  • Page 3: Occupant Restraint Systems

    None of these systems, either indi- Toyota encourages you and your family to take the time vidually or together, can ensure that there is no injury to read Section 1−3 of this Owner’s Manual carefully.

  • Page 4: Event Data Recorder

    Toyota recommends you to read the provisions in Sec- D Engine speed tion 1−3 carefully and refer to them as needed during your time of ownership of this vehicle.
  • Page 5 D SRS airbag deployment data Toyota will not disclose the data recorded in an EDR to a third party except when: D SRS airbag system diagnostic data D An agreement from the vehicle’s owner (or the leas- If your vehicle is equipped with a vehicle stability con-...
  • Page 6 New vehicle warranty Important health and safety information about your Toyota Your new vehicle is covered by the following Toyota limited warranties: D New vehicle warranty CAUTION D Emission control systems warranty D Others WARNING: Engine exhaust, some of its constitu- For further information, please refer to the “Owner ’s...
  • Page 7 TEMS, SRS airbag system and seat belt pretensioner system, This vehicle should not be modified with non−genuine be sure to check with your Toyota dealer for precaution- Toyota products. Modification with non−genuine Toyota ary measures or special instructions regarding installa- products could affect its performance, safety or durabili- tion.
  • Page 8 Owner’s Manual. For details about tire infla- service shop or by your Toyota dealer before you dis- tion pressure and load limits, see pages 330 and pose of your vehicle.
  • Page 9 Leak detection pump On−pavement and off−road driving tips This pump performs fuel evaporation leakage check. This check is done approximately five hours after the This vehicle belongs to the utility vehicle class. Utility engine is turned off. So you may hear sound coming vehicles have a significantly higher rollover rate than from underneath the luggage compartment for several other types of vehicles.
  • Page 11 U −8 Quick index D If a service reminder indicator or warning buzzer comes on ..D If your vehicle will not start ........D If your engine stalls while driving .
  • Page 12 The Toyota authorized Repair Manual is packed with literally everything you need to know to perform your own maintenance in virtually every area of your new vehicle.
  • Page 13 The repair manual outlines exactly what main- The repair manual for LAND CRUISER may be tenance is required and clearly explains how to do the purchased from any Toyota dealer or the Mate- work yourself step−by−step. rial Distribution Center. To purchase the repair...
  • Page 14 WE REALLY CARE ABOUT YOU PLEASE BUCKLE UP Toyota has made a special effort to encourage use of seat belts. Toyota belts are: Comfortable Easy to use Convenient We encourage you to use your belts every time you drive.

  • Page 15: Operation Of Instruments And

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Overview of instruments and controls Instrument panel overview ........Instrument cluster overview .

  • Page 16: Instrument Panel Overview

    Instrument panel overview "View A 1. Side vents 2. Side defroster outlets 3. Instrument cluster 4. Center vents 5. Electric moon roof switches and/or personal lights 6. Tire pressure warning select switch (in the glove box) 7. Glove box 8. Power door lock switches 9.
  • Page 17 "View B (Vehicles with navigation system) 1. Headlight, turn signal and front fog light switches 2. Cruise control switch 3. Ignition switch 4. Wiper and washer switches 5. Emergency flasher switch 6. Navigation system including air condi- tioning controls (See separate “Navigation System Owner’s Manual”.) 7.
  • Page 18 "View B (Vehicles without navigation system) 1. Headlight, turn signal and front fog light switches 2. Cruise control switch 3. Ignition switch 4. Wiper and washer switches 5. Emergency flasher switch 6. Clock, outside temperature and trip in- formation display 7.
  • Page 19 "Lower part of center cluster panel 1. Ashtray 2. Cigarette lighter 3. Power outlet...

  • Page 20: Instrument Cluster Overview

    Instrument cluster overview 11C501b 1. Voltmeter 4. Tachometer 8. Odometer and two trip meters 2. Speedometer 5. Height control indicator light 9. Trip meter reset knob 3. Service reminder indicators and 6. Engine oil pressure gauge 10. Fuel gauge indicator lights 7.

  • Page 21: Indicator Symbols On The Instrument Panel

    Indicator symbols on the instrument panel ∗ 1 ∗ 1 Brake system warning light Tire pressure warning light ∗ 1 ∗ 1 Driver’s seat belt reminder light Unengaged “Park” warning light Automatic transmission fluid temperature warning ∗ 1 Charging system warning light ∗...
  • Page 22 Automatic transmission indicator lights Vehicle stability control system off indicator ∗ 1 light Vehicle stability control system and active ∗ 1 traction control system warning light Active traction control system indicator light Slip indicator light ∗ 3 Roll sensing of curtain shield airbags off indicator light ∗...

  • Page 23: Table Of Contents

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Keys and Doors Keys ............Engine immobilizer system .

  • Page 24: Keys

    When using a key containing a trans- 1. Master keys (black)—These keys work ponder chip, observe the following in every lock. Your Toyota dealer will precautions: need one of them to make a new key with a built−in transponder chip.
  • Page 25 z Do not use the key with electromag- netic materials. z When starting the engine, do not z Do not bend the key grip. use the key with other transponder z Do not cover the key grip with any keys around (including keys of oth- material that cuts off electromagnet- er vehicles) and do not press other ic waves.

  • Page 26: Engine Immobilizer System

    Toyota dealer. need additional keys, duplicates can be the electronic code in the chip corre- made by a Toyota dealer using the key The indicator light stays on except sponds to the registered ID code for number.

  • Page 27: Wireless Remote Control

    The This device complies with Part 15 of the indicator light will go off. FCC Rules. Operation is subject to the For your Toyota dealer to make a new key following two conditions: with a built−in transponder chip,...
  • Page 28 The wireless remote control key is an If you lose your wireless remote control electronic component. Observe the follow- key, contact your Toyota dealer as soon ing instructions in order not to cause dam- as possible to avoid the possibility of age and trouble to the key.
  • Page 29 NOTE: *The 2−step unlocking function can vehicle. be changed. **The turn signal lights can be set not to flash. Ask your Toyota deal- er for details.
  • Page 30 The alarm will last for 1 minute. To stop NOTICE: Connect the equipment into an outlet the alarm midway, push the “PANIC”, This equipment has been tested and on a circuit different from that to “LOCK” or “UNLOCK” switch, or unlock found to comply with the limits for a which the receiver is connected.
  • Page 31 1. Remove the screw, and then the cover. 2. Remove module from z Replace only with same or frame. equivalent type recommended by a Toyota dealer. z Dispose of used battery according to the local laws. Replace the battery by following these procedures:...

  • Page 32: Side Doors

    After replacing the battery, check that the neously.* key operates properly. If the key still does NOTE: *The 2−step unlocking function can not operate properly, contact your Toyota be changed. Ask your Toyota dealer for dealer. details.
  • Page 33 LOCKING UNLOCKING WITH POWER DOOR LOCK SWITCH Push the switch. To lock: Push the switch down on the front side. To unlock: Push the switch down on the l12093a rear side. All the side doors and back door lock or unlock simultaneously.
  • Page 34 —Automatic door locking and unlocking functions AUTOMATIC DOOR LOCKING CAUTION You can select the following functions: Locking linked with the shift position Before driving, be sure that the doors closed locked, especially All doors are automatically locked when when small children are in the ve- the selector lever is moved out of “P”...
  • Page 35 You can set or cancel the automatic To select the locking linked with the AUTOMATIC DOOR UNLOCKING door locking functions: vehicle speed: You can select the following functions: Be sure to apply the parking brake when 1. Close all doors and turn the ignition Unlocking linked with the shift posi- performing the following operations.

  • Page 36: Power Windows

    Power windows You can set or cancel the automatic To select the unlocking linked with the unlocking functions: ignition switch: Be sure to apply the parking brake when 1. Close all doors and turn the ignition performing the following operations. switch to the “ON”...
  • Page 37 Window lock switch 12C011a l12088a 12C007b Automatic operation: Push the switch OPERATING THE PASSENGERS’ WIN- Automatic operation: Push the switch completely down or pull it completely up, DOWS completely down or pull it completely up, and then release it. The window will fully and then release it.
  • Page 38 CAUTION Never leave anyone (particularly a small child) alone in your vehicle, To avoid serious personal injury, you especially with the ignition key still inserted. Otherwise, must do the following. could power window Before you close the power win- switches and get trapped in a win- dows, always make sure there is dow.

  • Page 39: Power Quarter Windows

    Power quarter windows Back door CAUTION To avoid serious personal injury, you must do the following. Before you close the power quarter windows, always make sure there is nobody around the power quarter windows. You must also make sure the hands and other parts of the bodies of all occupants are kept completely inside...
  • Page 40 Pull the handle toward you and pull LOCKING AND UNLOCKING FROM IN- Push the handle and push down the down the lower side of the back door. SIDE lower side of the back door. When closing the back door, make sure To lock: Push the knob.
  • Page 41 CAUTION CAUTION Keep the back door closed while Before driving, be sure that the back driving. This not only keeps the door is closed and locked, especially luggage from being thrown out but when small children are in the ve- also prevents exhaust gases from hicle.

  • Page 42: Hood

    Hood Theft deterrent system To open the hood: 2. In front of the vehicle, pull up the To deter vehicle theft, the system is auxiliary catch lever and lift designed to sound an alarm if any of 1. Pull the hood lock release lever. The hood.
  • Page 43 The system will automatically be set after If any of the side door or back door is 30 seconds. When the system is set, the unlocked without the key or wireless re- indicator light will start flashing again. mote control key and the key is not in the ignition switch, all the side doors and 4.

  • Page 44: Fuel Tank Cap

    CAUTION reconnected. If the system does not work properly, Do not smoke, cause sparks or al- have it checked by your Toyota dealer. low open flames when refueling. The fumes are flammable. When opening the cap, do not re- move the cap quickly. In hot weath-...

  • Page 45: Electric Moon Roof

    CAUTION Make sure the cap is installed se- curely to prevent fuel spillage in the event of an accident. Use only a genuine Toyota fuel tank 12C006b cap for replacement. It is designed to regulate fuel tank pressure. Sliding operation 2.
  • Page 46 If the moon roof can- rear side. switch. not be operated properly, have it checked by your Toyota dealer. The roof will open and stop partway 30 Jam protection function (closing opera- mm (1.2 in.) from the fully opened posi- tion only): If something gets caught be- tion.
  • Page 47 CAUTION Never leave anyone (particularly a small child) alone in your vehicle, To avoid serious personal injury, you especially with the ignition key still inserted. Otherwise, must do the following. could use the moon roof switches While the vehicle is moving, always and get trapped in the roof open- keep the heads, hands and other ing.
  • Page 49 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Occupant restraint systems Seats ............Front seats .

  • Page 50: Seats

    Front seats— —Front seat precautions Seats While the vehicle is being driven, all ve- Driver seat Slightly recline the back of hicle occupants should have the seatback seat. Although vehicle designs vary, upright, sit well back in the seat and prop- CAUTION many drivers can achieve the 250 erly wear the seat belts provided.
  • Page 51 —Seat adjustment precautions Front passenger seat Front seats (with SRS side airbags) CAUTION CAUTION CAUTION Do not adjust the seat while the vehicle is moving as the seat may The SRS front passenger airbag The SRS side airbags are installed in unexpectedly move and cause the also deploys...
  • Page 52 —Adjusting front seats 1. SEAT POSITION AND SEAT CUSHION CAUTION ANGLE ADJUSTING SWITCH Move the control switch in the desired Avoid reclining seatback direction. more than needed. The seat belts pro- Releasing the switch will stop the seat at vide maximum protection in a frontal that position.

  • Page 53: Armrest

    Rear seats— —Rear seat precautions Armrest Tumbling the seats will enlarge the lug- CAUTION gage compartment. See “Cargo and lug- gage” on page 257 for precautions when Do not adjust the seat while the loading luggage. vehicle is moving. Be careful that the seat does not hit a passenger or luggage.
  • Page 54 —Moving second seat —Adjusting second seats third seat entry SEATBACK ANGLE ADJUSTING LEVER Lean forward and pull the lever toward you. Then lean back to the desired angle and release the lever. CAUTION Avoid reclining the seatback any more than needed. The seat belts provide maximum protection in a frontal or rear collision when the second seat passengers are sitting...
  • Page 55 —Tumbling second seat CAUTION After returning the seat, make sure the seat is securely locked by push- ing forward and rearward on the top of the seatback and by trying to pull I13378b I13340a up the edge of the bottom cushion. BEFORE TUMBLING SECOND SEAT 2.
  • Page 56 TUMBLING SECOND SEAT 2. Unlock the seat cushion. Swing the 3. Hook the strap. whole seat up and forward. 1. Lower the outer head restraint to the When returning the second seat to its lowest position and pull up the cen- original position, put the holding strap into ter head restraint.
  • Page 57 CAUTION When returning seats to their original position, observe the following pre- cautions in order to prevent personal injury in a collision or sudden stop: Make sure the seat is securely locked by pushing forward and rear- ward on the top of the seatback and by trying to pull up the edge of the bottom cushion.
  • Page 58 —Adjusting third seats —Tumbling third seats SEATBACK ANGLE ADJUSTING LEVER Lean forward and pull the lever toward you. Then lean back to the desired angle and release the lever. CAUTION I13377b Avoid reclining the seatback any more than needed. The seat belts provide maximum protection in a frontal or rear collision when the third seat passengers are sitting up...
  • Page 59 I13262c 2. Make sure the shoulder belt passes TUMBLING THIRD SEAT 2. Unlock the seat cushion and slide through the hanger when folding the the whole seat the rear−most 1. Lower the head restraint to the low- third seat. position while pulling up the handle. est position.
  • Page 60 13c558 13c559 13c557a 3. Swing the whole seat up. 4. Hook the strap. 5. Remove the seat hook covers from the back of the seat cushion, and When returning the third seat to its origi- install them over the seat hooks. nal position, put the holding strap into the hole.
  • Page 61 —Removing third seats CAUTION When returning seats to their original position, observe the following pre- cautions in order to prevent personal injury in a collision or sudden stop: Make sure the seat is securely locked by pushing forward and rear- ward on the top of the seatback and by trying to pull up the edge of the bottom cushion.

  • Page 62: Head Restraints

    Head restraints CAUTION When reinstalling the seat, be care- ful not to hit the seat against you When removing or reinstalling the or inside of the vehicle. seat, observe the following precau- Install each seat in the same posi- tions to prevent personal injury: tion from which it was removed.

  • Page 63: Seat Heaters

    Seat heaters For your safety and comfort, adjust the Right side CAUTION head restraint before driving. front seat To raise: Pull it up. Occupants must use caution when op- To lower: Push it down while pressing the erating the seat heater because it lock release button.

  • Page 64: Seat Belts

    Seat belts— —Seat belt precautions Toyota strongly urges that the driver and Do not allow any children to stand up or NOTICE passengers in the vehicle be properly re- kneel on either rear or front seats. An strained at all times with the seat belts...
  • Page 65 —Fastening 3−point seat belts CAUTION Be careful not to damage the belt webbing or hardware. Take care that Persons should ride in their seats they do not get caught or pinched in the seat or doors. properly wearing their seat belts whenever vehicle...
  • Page 66 If the seat belt does not function normally, immediately contact your Toyota dealer. Do not use the seat until the seat belt is fixed, because it cannot protect an adult occupant or your child from death or serious...
  • Page 67 CAUTION Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be l13197b kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in a colli- sion.
  • Page 68 If the seat belt does not function Keep as low on hips as possible normally, immediately contact your Toyota dealer. Do not use the seat Sit up straight and well back in the Remove excess length of the belt and until the seat belt is fixed, because seat.
  • Page 69 Toyota dealer free of charge. Please contact your local Toyota dealer so that the dealer can order the proper re- quired length for the extender. Bring the heaviest coat you expect to wear for prop- er measurement and selection of length.
  • Page 70 Make sure the front passenger oc- Do not use the seat belt extender cupant classification indicator light when installing child restraint indicates “ON” when using the seat system on the front or rear passen- belt extender for the front passen- ger seat.
  • Page 71 If the seat belt does not function normally, immediately contact your The driver and front passenger seat belt Toyota dealer. Do not use the seat pretensioners are designed to be acti- until the seat belt is fixed, because vated in response to a severe frontal...
  • Page 72 The front passenger’s seat belt pretension- CAUTION er will not activate if no passenger is detected in the front passenger seat by Make sure the roll sensing of cur- the front passenger occupant classification tain shield airbags indicator system. However, the front passenger’s light is not on.
  • Page 73 Failure to follow these instructions able the system, which could result switch can result in death or serious inju- in death or serious injury. ries. Consult your Toyota dealer 5. Seat belt pretensioner assemblies about any repair and modification. 6. Airbag sensor assembly...
  • Page 74 Do not perform any of the following assemblies, curtain shield airbag sensor changes without consulting your assemblies, driver’s seat position sensor, Toyota dealer. Such changes driver’s seat belt buckle switch, front pas- interfere with proper operation of the senger occupant classification system and...

  • Page 75: Srs Airbags

    In the following cases, contact your Toyota The SRS (Supplemental Restraint Sys- dealer as soon as possible: tem) front airbags are designed to pro-...
  • Page 76 The driver and front passenger can child restraint system. Toyota The SRS front passenger airbag will not be killed or seriously injured by the strongly recommends that all in- activate if there is no passenger sitting in inflating airbags if they do not wear fants and children be placed in the the front passenger seat.
  • Page 77 The SRS front airbags are designed to deploy in severe (usually frontal) colli- sions where the magnitude and duration of the forward deceleration of the ve- Hitting a curb, Falling into or hicle exceeds the designed threshold edge of pavement jumping over a level.
  • Page 78 8. Driver’s seat position sensor Deployment of the airbags happens in a fraction of a second, so the airbags must 9. Airbag sensor assembly inflate with considerable force. While the 10. Airbag module for driver system is designed to reduce serious inju- (airbag and inflator) ries, primarily to the head and chest, it The airbag sensor assembly consists of a...
  • Page 79 Toyota strongly recommends that: wearing it. In this case, the driver’s The driver sit as far back as pos-...
  • Page 80 “Child should not hold objects in their serious injury. restraint” on page 83. arms or on their knees. Failure to follow these instructions can result in death or serious injury. Consult your Toyota dealer about any repair and modification.
  • Page 81 Toyota dealer. It may assemblies, curtain shield airbag sensor dangerously interfere with the SRS assemblies, driver’s seat position sensor, front airbags operation.
  • Page 82 The SRS side airbag on the passenger seat will not activate if there is no pas- In the following cases, contact your Toyota The SRS (Supplemental Restraint Sys- senger sitting in the front passenger seat. dealer as soon as possible:...
  • Page 83 To ensure maximum protection child restraint system. Toyota in an accident, the driver and all strongly recommends that all in- passengers vehicle must fants and children be placed in the...
  • Page 84 When you push the roll sensing of curtain CAUTION shield airbags off switch for a few sec- onds with the ignition switch on, the roll Make sure the roll sensing of cur- sensing of curtain shield airbags off indi- tain shield airbags indicator...
  • Page 85 Collision from the rear Collision from the front The angle of Skidding vehicle vehicle tip−up hitting a curb Vehicle rollover is marginal stone The SRS side airbag and curtain shield The SRS side airbags are not generally The curtain shield airbags may inflate airbag system may not activate if the designed to inflate if the vehicle is in- if the angle of vehicle tip−up is margin-...
  • Page 86 Collision from Falling into or jump- Hitting a curb, edge of Collision from 13c538d the front ing over a deep hole pavement or hard sur- the rear face Pitch end over end Landing hard or vehicle falling The curtain shield airbags are not gen- The SRS side airbags and curtain shield The SRS side airbag and curtain shield erally designed to inflate if the vehicle...
  • Page 87 7. Curtain shield airbag sensors When the airbags inflate, they produce a CAUTION fairly loud noise and release some smoke 8. Side and curtain shield airbag sensors and residue along with non−toxic gas. This 9. Airbag sensor assembly SRS side airbags and curtain shield does not indicate a fire.
  • Page 88 Sit up straight and well back in the seat, distributing your weight evenly in the seat. Do not apply excessive weight to the outer side of the seats with a side airbag and to the front and rear pillar, front, center 13c562 and rear garnish and roof interior with the curtain shield airbag.
  • Page 89 Do not allow anyone to kneel on the passenger seat, facing the pas- senger’s side door, since the side airbag and curtain shield airbag could inflate with considerable speed and force. Otherwise, he/she may be killed or seriously injured. 13c563 Special care should be taken espe- cially when you have a small child in the vehicle.
  • Page 90 Do not hook a hanger, heavy or sharp pointed objects on the coat hook. If the curtain shield airbags inflate, those items will be thrown away with great force or the curtain shield airbags may not activate cor- 13c800b rectly, resulting in death or serious injury.
  • Page 91 Such changes may disable curtain shield airbags to inflate ac- Toyota dealer. Such changes can in- the system or cause the curtain cidentally, resulting in death or seri- terfere with proper operation of the shield airbags to inflate accidental- ous injury.
  • Page 92 It goes off after about 6 seconds. This or seat belt pretensioners. Contact your means the SRS side airbags and curtain Toyota dealer as soon as possible. shield airbags are operating properly. The light does not come on when the ignition key is turned to the “ON”...
  • Page 93 —Front passenger occupant classification system In the following cases, contact your Toyota Your vehicle is equipped with a front dealer as soon as possible: passenger occupant classification sys- tem. This system detects the conditions Any of the SRS side airbags and cur- 1.
  • Page 94 If the front passenger occupant classifica- Make sure that the “ON” indicator is illu- tion system determines that a person of minated when an adult is seated in the adult size sits in the front passenger seat front passenger seat. If the “OFF” indica- but the “OFF”...
  • Page 95 Condition and operation in the front passenger occupant classification system Indicator/ warning light Devices Condition detected by Curtain shield Front passenger Front Side airbag on Front the front passenger Front airbag in the occupant SRS warning passenger’s the front passenger’s occupant classification passenger front...
  • Page 96 CAUTION Do not recline the front passenger Wear the seat belt properly. seatback so far that it touches a Make sure the front passenger’s To avoid potential death or serious rear seat. This cause seat belt tab has not been left in- “OFF”...

  • Page 97: Child Restraint

    Child restraint— —Child restraint precautions Toyota strongly urges the use of ap- When it is unavoidable to install the Toyota strongly urges use of propriate child restraint systems for forward−facing child restraint sys- proper child restraint system which children. tem on the front passenger seat, conforms to the size of the child, The laws of all 50 states in the U.S.A.
  • Page 98 —Child restraint system A child restraint system for a small A forward−facing child restraint sys- Do not use the seat belt extender child or baby must itself be properly should allowed when installing child restraint restrained on the seat with the lap por- installed on front passenger system on the front or rear passen-...
  • Page 99 —Types of child restraint system Child restraint systems are classified into the following 3 types depending on the child’s age and size. (A) Infant seat (B) Convertible seat (C) Booster seat Install the child restraint system following the instructions provided by its manufac- turer.
  • Page 100 —Installation with 2−point type seat belt (A) INFANT SEAT INSTALLATION 1. Run the center lap belt through or CAUTION around the infant seat following the An infant seat must be used in rear− instructions provided by its manufactur- facing position only. Do not install a child restraint sys- er and insert the tab into the buckle tem on the third seat if it interferes...
  • Page 101 2. While pressing the infant seat firmly Contact your Toyota dealer CAUTION against the seat cushion and seatback, immediately. Do not install the child tighten the lap belt by pulling its free...
  • Page 102 3. To remove the infant seat, press the (B) CONVERTIBLE SEAT INSTALLATION CAUTION buckle release button. A convertible seat must be used in for- ward−facing or rear−facing position de- Do not install a child restraint sys- pending on the age and size of the tem on the third seat if it interferes child.
  • Page 103 1. Run the center lap belt through or 2. While pressing convertible seat Contact your Toyota dealer around the convertible seat following firmly against the seat cushion and immediately. Do not install the child instructions provided...
  • Page 104 —Installation with 3−point type seat belt 13c564 3. To remove the convertible seat, press (A) INFANT SEAT INSTALLATION CAUTION the buckle release button. An infant seat must be used in rear− facing position only. Push and pull the child restraint sys- tem in different directions to be sure it is secure.
  • Page 105 Child restraint systems installed on the third seat should not contact the second seatbacks. 13c565 Do not install a child restraint sys- CAUTION tem on the second (or third) seat if Never install a rear−facing child re- it interferes with the lock mecha- nism of the front (or second) seats.
  • Page 106 1. Run the lap and shoulder belt through 2. Fully extend the shoulder belt to put it Contact your Toyota dealer or around the infant seat following the in the lock mode. When the belt is immediately. Do not install the child...
  • Page 107 3. While pressing the infant seat firmly 4. To remove the infant seat, press the CAUTION against the seat cushion and seatback, buckle release button and allow the let the shoulder belt retract as far as belt to retract completely. The belt will Push and pull the child restraint sys- it will go to hold the infant seat secure- move freely again and be ready to...
  • Page 108 Install the child restraint system on the 6. While pressing convertible seat front passenger seat only when it is un- firmly against the seat cushion and avoidable. Your vehicle is equipped with a seatback, let the shoulder belt retract front passenger occupant classification...
  • Page 109 Remove the child restraint the front passenger airbag and side Never install a rear−facing child re- system and contact your Toyota dealer. airbag on the front passenger seat straint system on the front passen- could deploy.
  • Page 110 On vehicle with side airbags and curtain shield airbags, do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front or rear pillar, front, center or rear 13c568 13c501b garnish or roof interior from which...
  • Page 111 1. Run the lap and shoulder belt through Contact your Toyota dealer or around the convertible seat following immediately. Do not install the child instructions provided restraint system on the seat until manufacturer and insert the tab into the seat belt is fixed.
  • Page 112 2. Fully extend the shoulder belt to put it 3. While pressing convertible seat CAUTION in the lock mode. When the belt is firmly against the seat cushion and then retracted even slightly, it cannot seatback, let the shoulder belt retract Push and pull the child restraint sys- be extended.
  • Page 113 13c569 13c570 Move seat fully back 4. To remove the convertible seat, press (C) BOOSTER SEAT INSTALLATION CAUTION the buckle release button and allow the A booster seat must be used in for- belt to retract completely. The belt will ward−facing position only.
  • Page 114 On vehicle with side airbags and CAUTION curtain shield airbags, do not allow the child to lean his/her head or Always make sure the shoulder belt any part of his/her body against the is positioned across the center of door or the area of the seat, front child’s shoulder.
  • Page 115 Contact your Toyota dealer immediately. Do not install the child 13C001 restraint system on the seat until the seat belt is fixed. 2. To remove the booster seat, press the...
  • Page 116 Symbol 13C003 13C004 Anchor brackets Use the anchor bracket located behind the TO USE THE ANCHOR BRACKET: 2. Fix the child restraint system with second seat on the floor to attach the top the seat belt. 1. Remove the head restraint. strap.
  • Page 117 —Installation with child restraint lower anchorages 13C005 13C529 13c571 Most upright position 4. Replace the head restraint. The lower anchorages for the child re- CHILD RESTRAINT SYSTEM INSTALLA- straint system interfaced with TION FMVSS225 specification are installed in 1. Fold down the seatback and back to the second seat.
  • Page 118 3. Type A—Latch the hooks of lower straps onto anchorages tighten the lower straps. Type B—Latch the buckles onto the anchorages 13C532f 13C009b If your child restraint system has a top strap, it should be anchored. (For the installation of the top strap, see “—Using a top strap”...
  • Page 119 CAUTION When using the lower anchorages for the child restraint system, be sure that there are no irregular ob- jects around the anchorages or that the seat belt is not caught. Push and pull the child restraint system in different directions to be sure it is secure.
  • Page 121 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Steering wheel and Mirrors Power tilt and telescopic steering wheel ..... . . Outside rear view mirrors .

  • Page 122: Power Tilt And Telescopic Steering Wheel

    This feature can be set inoperative. Ask ries. your Toyota dealer.

  • Page 123: Outside Rear View Mirrors

    —Power rear view mirror control Outside rear view mirrors— CAUTION Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to mishandle the vehicle and an accident may occur resulting in death or serious inju- ries.

  • Page 124: Anti−Glare Inside Rear View Mirror

    Anti−glare inside rear view mirror— —Folding rear view mirrors NOTICE If ice should jam the mirror, do not operate the control or scrape the mir- ror face. Use a spray de−icer to free the mirror. 13C010b The rear view mirrors can be folded Adjust the mirror so that you can just backward for parking in compact areas.
  • Page 125 —Compass (vehicles without navigation system) When the ignition key is inserted and turned on, the inside rear view mirror al- ways turns on in the “AUTO” mode. When the inside air temperature is low, it may take a little longer for the mirror to darken in response to the detection of 13c570b 13c013...
  • Page 126 Pushing the “AUTO” button for longer NOTICE than 3 seconds turns on or off the compass display. Do not put magnets or a metal object near the inside rear view mirror. Do- The compass may not show the correct ing this may cause malfunction of the direction in the following conditions: compass sensor.
  • Page 127 If the direction is displayed several sec- onds after adjustment, the calibration is finished. CAUTION Do not adjust the display while the vehicle is moving. Be sure to adjust the display only when the vehicle is stopped. 13C015b Zone number L Hawaii is included in zone 6.
  • Page 128 Do not adjust the display while the If calibration cannot be performed because vehicle is moving. Be sure to adjust of the magnetized vehicle, etc., take your the display only when the vehicle is vehicle to Toyota dealer. stopped.

  • Page 129: Sun Visors

    Sun visors— —Vanity mirror To block out glare, move the sun visor. To block the glare from the front when the To use the vanity mirror, swing down main sun visor is swung down, swing the main sun visor and open the cover. To block out glare from the front—Swing down the second sun visor.
  • Page 131 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Lights, Wipers and Defogger Headlight and turn signals ........Emergency flashers .

  • Page 132: Headlight And Turn Signals

    NOTE: *The operating condition or sensi- tivity can be changed. Ask your Toyota dealer for details. HEADLIGHTS The automatic light control sensor is on the top of the passenger’s side instrument...
  • Page 133 “LOCK” but- ton on the wireless remote control key turns off the headlights. NOTE: *The time before turning off the lights can be changed. Ask your Toyota dealer for details. NOTICE To prevent the battery from being dis-...

  • Page 134: Emergency Flashers

    Emergency flashers Instrument panel light control NOTICE To prevent the battery from being dis- charged, do not leave the switch on longer than necessary when the en- gine is not running. To turn on the emergency flashers, To adjust the brightness of the instru- push the switch.

  • Page 135: Front Fog Lights

    Front fog lights Interior lights To turn on the interior light, slide the switch. The interior light switch has the following positions: “ON”—Keeps the light on all the time. “OFF”—Turns the light off. “DOOR”— —Center: Turn the light on when any of side doors and back door are opened.

  • Page 136: Personal Lights

    One front door will be closed with the lock knob pushed forward while the other doors are locked. NOTE: *The interior lights can be set not to come on or the duration of lighting can be changed. Ask your Toyota dealer for details. Center...

  • Page 137: Ignition Switch Light

    Ignition switch light Windshield wipers and washer To turn on the personal light, push the switch on side 1. To turn the lights off, push the switch on side 2. PERSONAL LIGHTS CUT OFF OPERA- TION When the ignition switch is “OFF” and any personal lights in the vehicle stay lighting on, the lights will cut off automatically after 30 minutes.

  • Page 138: Rear Window Wiper And Washer

    To squirt washer fluid on the rear window, blocked. If a nozzle becomes blocked, twist the knob upward or downward as far contact your Toyota dealer to have the vehicle serviced. as it will go (position 3 or 4). The knob...

  • Page 139: Rear Window Defogger

    Rear window defogger Outside rear view mirror heaters Make sure you turn the defogger off when the surfaces are clear. Leaving the defog- ger on for a long time could cause the battery discharge, especially during stop−and−go driving. The defogger is not designed for drying rain water or for melt- ing snow.
  • Page 140 CAUTION Since the mirror surfaces can get hot, do not touch them when the mirror heater switch is on. Make sure you turn the mirror heaters off when the surfaces are clear. Leaving the mirror heaters on for a long time could cause the battery to discharge, especially during stop−and−go driving.

  • Page 141: Engine Oil

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Gauges, Meters and Service reminder indicators Fuel gauge ..........Engine coolant temperature gauge .

  • Page 142: Fuel Gauge

    Fill the fuel tank immediately. The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Toyota dealer as soon as possible. 15C004 The gauge indicates the approximate...

  • Page 143: Engine Oil Pressure Gauge

    If the engine oil pressure should stay be- low the normal range, pull off the road to a safe place and stop the engine immedi- ately. Call a Toyota dealer or qualified repair shop for assistance. Engine oil pressure may not build up when the engine oil level is too low.

  • Page 144: Voltmeter

    Voltmeter Tachometer NOTICE Do not let the indicator needle get into the red zone. This may cause severe engine damage. The voltmeter tells whether the battery The tachometer indicates engine speed is charged discharged. Check in thousands of rpm (revolutions per while the engine is running—the needle minute).

  • Page 145: Odometer And Two Trip Meters

    Odometer and two trip meters 3. Trip meter reset knob—Resets the two trip meters to zero, and also change the meter display. To change the meter display, quickly push and release the knob. The meter display changes in the order from the odometer to trip meter A to trip meter B, then back to the odometer each time you push.

  • Page 146: Service Reminder Indicators And Warning Buzzers

    Service reminder indicators and warning buzzers If the indicator or buzzer comes on... Do this. If parking brake is off, stop immediately and contact Toyota dealer. (indicators and buzzer) Fasten driver’s seat belt. (indicators and buzzer) Fasten front passenger’s seat belt.
  • Page 147 If the indicator or buzzer comes on... Do this. Take vehicle to Toyota dealer immediately. Take vehicle to Toyota dealer. If brake system warning light is also on, stop immedi- ately and contact Toyota dealer. Close all side doors and back door.
  • Page 148 It is dangerous to continue driving Depressing the brake pedal repeatedly a safe place and contact your Toyota normally when the brake fluid level is may turn on the warning light and dealer.

  • Page 149: Engine Oil

    Once the ignition key is turned to “ON” or safe place and contact your Toyota “START”, the reminder light flashes if a You need to reset the light after the en- dealer.
  • Page 150 Have your vehicle the tank as soon as possible. after taking several driving trips. checked by your Toyota dealer as soon as If the lamp will not go off even after sev- possible. eral trips, contact your Toyota dealer as Even if the abnormality of the electronic soon as possible.
  • Page 151 Contact your It goes off after about 6 seconds. This pant classification system. Toyota dealer as soon as possible to means the SRS airbags and seat belt service the vehicle. pretensioners are operating properly.
  • Page 152 Although it is no problem to continue If the light does not go off, call a Toyota (j) Open Door Warning Light dealer or qualified repair shop for assis-...
  • Page 153 OFF” indicator light come on, have your the key when you open the driver’s door 5. Turn the ignition key to “ON”, but do vehicle checked by Toyota dealer as soon with the ignition key in the “ACC” or not start the engine.

  • Page 154: Trip Information Display

    Trip information display (vehicles without navigation system) The following information is shown with Average vehicle speed Driving distance after engine starting the ignition key turned on. Each time The average vehicle speed is calculated The driving distance after engine start- you push the “MODE”...
  • Page 155 Available driving range Average fuel consumption after re- Current fuel consumption fueling The available driving range is calcu- The current fuel consumption is calcu- lated and displayed depending on the The average fuel consumption after re- lated and displayed based on the driv- amount of remaining fuel.
  • Page 157 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Audio system Reference ..........Using your audio system .

  • Page 158: Audio System

    —some basics Reference This section describes some of the basic SWITCHING BETWEEN FUNCTIONS features on Toyota audio systems. Some Push “AM·SAT”, “FM”, “TAPE” or “DISC” information may not pertain to your sys- if the system is already on but you want tem.
  • Page 159 Satellite tuner technology notice: TONE AND BALANCE You must enter into a separate service Toyota’s satellite radio tuners are awarded For details about your system’s tone and agreement with the XMr radio in order to Type Approval Certificates from XMr Sat-...
  • Page 160 For the installation performed during antenna extension. The of the window tint, consult with maximum extension length is 850 mm your Toyota dealer. (33.5 in.). Every time you turn the radio on, the antenna will extend to its previous posi- tion.
  • Page 161 YOUR COMPACT DISC PLAYER CAUTION When you insert a disc, gently push it in with the label side up. Before extending the antenna, confirm The discs set in the player are played that no one is close enough to get continuously, starting with disc number 1.
  • Page 162 —Controls and features Details of specific buttons, controls, and features are described in the alphabetical list that follows. 17c517d...
  • Page 163 The button number will appear on the *: Use of satellite radio requires XMr tuner the discs will be automatically cancelled. display. and service. Contact your Toyota dealer for details. (Program) To tune in to a preset station: Push the button for the station you want.
  • Page 164 “AM” to switch from cassette or compact display. *: Use of satellite radio requires XMr tuner disc operation to radio operation. To stop the tape while it is fast forward- and service. Contact your Toyota dealer AUDIO−TUNE Knob ing, push fast...
  • Page 165 After FM button your vehicle to your Toyota dealer. pushing the button, insert a compact disc. Push “FM” to turn on the radio and select DISC At this time, the indicators on both sides the FM band. “FM1” or “FM2” will appear of the slot are flashing.
  • Page 166 Loading multiple compact discs— RAND (Random) RDS (Radio Data System) display To load multiple compact discs, push and There are two random features—you can The radio will automatically switch to the hold (until you hear a beep when the au- either listen to the tracks on all the com- RDS mode to receive an RDS station dio system is on).
  • Page 167 The player will repeat all the tracks on the the surrounding antenna cable. See a another channel. disc you are listening to. When the disc Toyota certified dealer. “– – –”: The channel you selected is no ends, the player will automatically go back “UPDATING”: longer available.
  • Page 168 *: Use of satellite radio requires XMr tuner XMr satellite radio*— Compact Disc Player and service. Contact your Toyota dealer You can either scan the currently selected There are two scan features—you can ei- for details. channel category or scan only the preset...
  • Page 169 *: Use of satellite radio requires XMr tuner After the beginning of the tape is the amount of channel separation to prev- and service. Contact your Toyota dealer reached, the player will automatically ent the weak signal from creating noise.
  • Page 170 : Use of satellite radio requires XMr If the entire disc or track title does not tuner and service. Contact your Toyota appear on the display, push and hold the If the entire the message is not displayed, dealer for details.

  • Page 171: Audio System Operating Hints

    *: Use of satellite radio requires XMr tuner RADIO RECEPTION Each time you push the “ ” or “ ”, the and service. Contact your Toyota dealer Usually, a problem with radio reception program type changes as in the following: for details.
  • Page 172 *: Use of satellite radio requires XMr tuner ened, and there is another strong station and service. Contact your Toyota dealer nearby on the FM band, your radio may for details. tune in the second station until the origi-...
  • Page 173 CARING FOR YOUR CASSETTE PLAYER Avoid using cassettes with a total play- If this equipment does cause harmful AND TAPES ing time longer than 100 minutes (50 interference to radio or television re- minutes per side). The tape used in For the best performance for your cas- ception, which can be determined by these cassettes is thin and could get...
  • Page 174 CARING FOR YOUR COMPACT DISC PLAYER AND DISCS The player is intended for use with 12 cm (4.7 in.) discs only. Extremely high temperatures can keep your compact disc player from working. On hot days, use the air conditioning to cool the vehicle interior before you listen to a disc.
  • Page 175 NOTICE z Do not use special shaped, trans- parent/translucent, low quality or la- beled discs such as those shown in the illustrations. The use of such discs may damage the player or changer, or it may be impossible to eject the disc. z This system is not designed for use Correct Wrong...

  • Page 176: Rear Seat Audio System

    Rear seat audio system (b) When the radio mode is selected “ ” button: Push this button to select a preset station on the preset but- ton of the front audio system. Each push of the button changes to the station with higher numbered preset button.

  • Page 177: Audio Remote Controls (Steering Switches)

    Audio remote controls (steering switches) (c) When the “TAPE” mode is selected (e) Some basics “ PROG ” button: Push this button This system cannot be used if the audio system is not turned on. to select the other side of a cassette tape.
  • Page 178 XMr satellite radio*— To select a preset channel, push the “ ” or “ ” side of the switch. Repeat until a desired channel is found. *: Use of satellite radio requires XMr tuner and service. Contact your Toyota dealer for details.

  • Page 179: For Vehicle Equipped With Navigation System, Please Refer To The Separate "Navigation System Owner's Manual

    SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Air conditioning system Front air conditioning system: Controls ..........Air flow selector settings .

  • Page 180: Front Air Conditioning System: Controls

    Front air conditioning system— —Controls 1. Temperature selector knob 2. “AUTO” button 3. Temperature display 4. Fan speed display 5. Air flow display 6. “MODE” button 7. “A/C” button 8. Windshield air flow button 9. Fan speed control button 10. Air intake control button 11.
  • Page 181 “AUTO” button “MAX COLD” appears when you adjust to maximum cooling, and “MAX HOT” ap- For automatic operation of the air condi- pears when you adjust to maximum warm- tioning, press the “AUTO” button. An indi- ing. cator light will illuminate to show that the automatic operation mode has been se- “OFF”...
  • Page 182 4. Floor/Windshield—Air flows mainly When the “A/C” button is not pressed in, from the floor vents and windshield pressing “MODE” button turns off the air vents. conditioning. It is recommended that you close the For details about air flow selector setting, lower vent.
  • Page 183 If this happens, take your ve- hicle to a Toyota dealer for service. Air intake control button Press the button to select the air source. An indicator light will illuminate to show which air intake mode is being selected.

  • Page 184: Air Flow Selector Settings

    —Air flow selector settings —Operating tips To cool off your Toyota after it has been parked in the hot sun, drive with the windows open for a few minutes. This vents the hot air, allowing the air conditioning to cool the interior more quickly.
  • Page 185 If following another vehicle on a dusty Heating Air conditioning road, or driving in windy and dusty For best results, set controls to: For best results, set controls to: conditions, it is recommended that the air intake control button be temporarily Fan speed—“AUTO”...

  • Page 186: Instrument Panel Vents

    —Instrument panel vents Defogging Defrosting The inside of the windshield The outside of the windshield For best results, set controls to: For best results, set controls to: Temperature— Towards high temperature Temperature—Towards high temperature to heat; Air intake—FRESH (outside air) low temperature to cool Air flow—WINDSHIELD Air intake—FRESH (outside air)
  • Page 187 Lower vent If air flow control is not satisfactory, check the instrument panel vents. The instrument panel vents may be opened or closed as shown. For removing frost or fog, it is recom- mended that you close the lower vent when you use the “Floor”, the “Floor/Wind- shield”...

  • Page 188: Rear Air Conditioning System

    Rear air conditioning system— —Controls 1. Rear air conditioning on−off switch 2. “AUTO” button 3. Air flow selector 4. Fan speed selector 5. Temperature selector 6. “OFF” button 18c507b...
  • Page 189 Rear air conditioning on−off switch Temperature selector To turn the rear air conditioning on, press Move the lever to adjust the tempera- the “REAR” switch. To turn the rear air ture—to the right to warm, to the left to conditioning off, press the switch again. cool.

  • Page 190: Air Flow Selector Settings

    —Air flow selector settings 18c508a Warm air Cool air...
  • Page 191 SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Other equipment Clock ............Outside temperature display .

  • Page 192: Clock

    Clock Outside temperature display To reset the hour: Push the “H” button. To reset the minutes: Push the “M” button. The key must be in the “ACC” or “ON” position. If quick adjustment to a full hour is de- 18C510 sired, push the “:00”...

  • Page 193: Rear View Monitor System

    Rear view monitor system The display indicates between the range The rear view monitor system assists CAUTION of –22°F and 122°F. the driver by displaying an image of the view behind the vehicle while back- The key must be in the “ON” position. Never depend on rear...
  • Page 194 When replacing the tires, please consult If the back of the vehicle is hit, the your Toyota dealer. If you replace the position and mounting angle of the tires, the area displayed on the screen camera may change. Be sure to may change.
  • Page 195 AREA DISPLAYED ON SCREEN When water droplets are adhering to the camera, or when humidity is high Image is displayed approximately level (for example, when it rains) on screen. When foreign matter (for example, The area detected by the camera is snow or mud) adheres to the camera limited.

  • Page 196: Cigarette Lighter And Ashtray

    Do not hold the cigarette lighter pressed mitted by the camera, the light source appears to have a vertical streak above and below it. Use a Toyota genuine cigarette lighter or equivalent for replacement.

  • Page 197: Power Outlets

    Power outlets The power outlets are designed for power supply for car accessories. To use them, open the lids as shown in the following illustrations. The key must be in the “ACC” or “ON” position to be used. NOTICE z To prevent the fuse from being blown, do not use the electricity over the total vehicle capacity of...

  • Page 198: Roll Sensing Of Curtain Shield Airbags Off Switch

    Roll sensing of curtain shield airbags off switch In a severe side impact, the curtain shield CAUTION airbags on impacted side will inflate even if the roll sensing function is turned off. Make sure the roll sensing of cur- If the ignition switch is turned to “ACC” or tain shield airbags off indicator light “LOCK”...

  • Page 199: Rear Console Box

    Rear console box Glove box Garage door opener Buttons Indicator light To use the rear console box, open as To use the glove box, do this. The garage door opener (HomeLink shown in the illustration. Universal Transceiver) is manufactured un- To open: Pull the lever.
  • Page 200 The battery side of the hand−held trans- mitter must be pointed away from the HomeLink during the programming pro- HomeLink cess. For Canadian users, follow the procedure 19C514 19C515 in “Programming an entrance gate/Pro- gramming all devices in the Canadian 25 to 75 mm market”.
  • Page 201 6. Repeat steps 2 through 5 for each re- 1. Locate the “training” button on the ceil- maining HomeLink button to program ing mounted garage door opener motor. another device. The exact location and color of the button may vary by brand of garage Programming a rolling code system door opener.
  • Page 202 Canadian market To program other devices such as home 1. Decide which of the 3 HomeLink but- security systems, home door locks or tons you want to program. lighting, contact your authorized Toyota dealer for assistance. 2. Place your hand−held gate/device 19C517 transmitter 25 to 75 mm (1 to 3 in.)
  • Page 203 FCC Rules and with RSS−210 of the IC ceiver call the: When programming the HomeLink Rules. Operation is subject to the fol- Toyota Customer Experience Center at lowing two conditions: (1) This device Universal Transceiver, you may be 1−800−331−4331 (U.S.A.)

  • Page 204: Auxiliary Boxes

    Auxiliary boxes— To use the auxiliary boxes, open as shown in the following illustrations. CAUTION To reduce the chance of injury in case of an accident or a sudden stop, always keep the auxiliary box closed while driving. Type A (luggage compartment) Type C (rear console) Type B (luggage compartment)

  • Page 205: Cup Holders

    —First−aid kit holder —Warning reflector holder Cup holders The cup holder is designed for holding cups or drink−cans securely. To use them, observe the following illustra- tions. CAUTION Do not place anything else other than cups or drink−cans in the cup holder, such items...
  • Page 206 19C008 For front seats For front seat For second seats The cup holder can be adjusted to the To use a cup holder in the console box. size of cups by changing the separator 1. Open the console box lid. Pull down position or moving the separator arms.

  • Page 207: Card Holder

    Card holder Tie−down hooks For third seats (left−hand side) You can store a card in the slot as To secure your luggage, use the tie− shown in the illustration. down hooks as shown above. See “Cargo and luggage” on page 257 for precautions when loading luggage.

  • Page 208: Cargo Net Hooks

    Cargo net hooks Roof luggage carrier Side Cross knobs rails Upper knob Roof rails These hooks are designed to hang car- The roof luggage carrier consists of ADJUSTING THE POSITION OF CROSS go net. roof rails and sliding cross rails. RAILS: To hang the cargo net, use the cargo net 1.
  • Page 209 Follow the manufacturer’s instructions and precautions when installing the attach- ments or their equivalent. CAUTION When you load cargo on the roof lug- gage carrier, observe the following: Place the cargo so that its weight is distributed evenly between the front and rear axles.

  • Page 210: Floor Mat

    Floor mat If driving for a long distance, on rough roads, or at high speeds, stop the vehicle now and then dur- ing the trip to make sure the cargo remains in its place. Do not exceed 70 kg (154 lb.) cargo weight on the roof luggage carrier.

  • Page 211: Coat Hooks

    Coat hooks To use the coat hook, push the hook. CAUTION Do not hook a hanger, heavy or sharp pointed object on the coat hook. If curtain shield airbags inflate, those items will be hurled away with great force or the curtain shield air- bags may not active correctly.

  • Page 213: Engine Oil

    SECTION INFORMATION BEFORE DRIVING YOUR TOYOTA Information before driving your Toyota Off−road vehicle precautionss .......

  • Page 214: Off−Road Vehicle Precautionss

    Off−road vehicle precautions This vehicle belongs to the utility ve- CAUTION hicle class, which has higher ground clearance and narrower tread in relation Always observe the following precau- to the height of its center of gravity to tions to help minimize the risk of se- make it capable of performing in a wide rious personal injury or damage to variety of off−road applications.

  • Page 215: Break−In Period

    To help prevent gas station mix−ups, your hicle more sensitive side to the future economy and long life of Toyota has a smaller fuel tank opening. winds than an ordinary passenger your vehicle: The special nozzle on pumps with un- car. Slowing down will allow you Avoid full−throttle...
  • Page 216 10% ethanol or 15% If you detect heavy knocking even when Automotive manufacturers in the U.S., MTBE. If you use gasohol in your Toyota, using the recommended fuel, or if you Europe and Japan have developed a...

  • Page 217: Fuel Pump Shut Off System

    Operation in foreign countries GASOLINE QUALITY The fuel pump shut off system stops sup- If you plan to drive your Toyota in plying fuel to the engine when the engine another country... In a very few cases, you may experience stalls or an airbag inflates upon collision.

  • Page 218: Three−Way Catalytic Converter

    The three−way catalytic converter is the z Use only unleaded gasoline. vehicle in for a check−up as soon emission control devices installed in as possible. Remember, your Toyota z Do not drive with an extremely low the exhaust system. dealer knows your vehicle and its fuel level;...

  • Page 219: Engine Exhaust Cautions

    It contains carbon monoxide, which periodic inspections required by the is a colorless and odorless gas. It gases to be drawn into the vehicle. Toyota Maintenance Schedule. For can cause unconsciousness or even To allow proper operation of your scheduled maintenance information, death.

  • Page 220: Facts About Engine Oil Consumption

    (1.1 qt./600 miles, 0.9 Imp.qt/600 regularly. Toyota recommends that the oil by the high temperature combustion miles) level be checked every time you refuel gases during the combustion process.

  • Page 221: Iridium−Tipped Spark Plugs

    In this case, the brakes may not work mance or smooth drivability. properly. If they do not work well, depress the brake pedal firmly. If the brake system warning light comes on, immediately stop your vehicle and contact your Toyota deal-...
  • Page 222 The brake system warning light may stay ANTI−LOCK BRAKE SYSTEM Depressing the brake pedal on slippery on for about 60 seconds after the ignition (with “ABS” warning light) road surfaces such as on a manhole cov- key is turned to “ON” position. It is nor- er, a steel plate at a construction site, The anti−lock brake system is designed mal if the light turns off after a while.
  • Page 223 CAUTION Anti−lock brake system is not de- signed to shorten the stopping dis- overestimate anti−lock tance: Always drive at a moderate speed and maintain a safe distance brake system: Although the anti−lock brake system assists in providing ve- from the vehicle in front of you. hicle control, it is still important to Compared with vehicles without an anti−lock brake system, your vehicle...
  • Page 224 Toyota dealer. When the “ABS” warning light is on (and Have your Toyota dealer perform the bed- In this case, not only the anti−lock the brake system warning light is off), the ding−down.

  • Page 225: Brake Pad Wear Limit Indicators

    Toyota CAUTION dealer as soon as possible. Expensive ro- tor damage can result if the pads are not Do not allow more than one person replaced when necessary. to get on the rear step bumper at a time.

  • Page 226: Limited−Slip Differential

    This is the primary identification number Use only a spare tire of the same for your Toyota. It is used in registering size, construction and load capacity the ownership of your vehicle. as the original tires on your Toyota because damage to the limited−slip...

  • Page 227: Theft Prevention Labels

    —Engine number Theft prevention labels Suspension and chassis Your new vehicle carries theft preven- CAUTION tion labels which are approximately 47 mm (1.85 in.) by 12 mm (0.47 in.) or 56 Do not modify the suspension/chassis mm (2.20 in.) by 16 mm (0.63 in.). with lift kits, spacers, springs, etc.

  • Page 228: Tire Information

    Tire information— —Tire symbols This illustration indicates typical tire symbols. 1. Tire size—For details, see “Tire size” on page 250. 2. DOT Tire Identification Number (TIN)—For details, see “DOT and Tire Identification Num- ber (TIN)” on page 249. 3. Tire ply composition and materi- als—Plies mean a layer of rubber−...
  • Page 229 —DOT and Tire Identification Number (TIN) 7. “TUBELESS” or “TUBE TYPE” The “DOT” symbol certifies that the —A tubeless tire does not have a tire conforms to applicable Federal tube inside the tire and air is direct- Motor Vehicle Safety Standards. ly filled in the tire.
  • Page 230 —Tire size —Name of each section of tire 20c506a 21A007a 21A006a This illustration indicates typical tire 1. Section width 1. Bead size. 2. Tire height 2. Sidewall 1. Tire (P=Passenger car, 3. Wheel diameter 3. Shoulder T=Temporary use) 4. Tread 2.
  • Page 231 150 would wear conditions on specified government purchasers of Toyota vehicles with in- one and a half (1−1/2) times as well test surfaces of asphalt and concrete. formation on uniform tire quality grad-...
  • Page 232 Temperature A, B, C—The tempera- ture grades are A (the highest), B, and C, representing the tire’s resis- tance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
  • Page 233 —Glossary of tire terminology Tire related term Meaning tire inflation pressure when the vehicle has been parked for at least 3 hours Cold tire inflation pressure or more, or it has not been driven more than 1.5 km or 1 mile under that condition the maximum cold inflation pressure to which a tire may be inflated and it is Maximum inflation pressure...
  • Page 234 Tire related term Meaning the combined weight of those installed regular production options weighing over 2.3 kg (5 lb.) in excess of those standard items which they replace, not pre- Production options weight viously considered in curb weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim Vehicle capacity weight the rated cargo and luggage load plus 68 kg (150 lb.) times the vehicle’s desig-...
  • Page 235 Tire related term Meaning the load on an individual tire that is determined by distributing to each axle its share of the curb weight, accessory weight, and normal occupant weight Vehicle normal load on the tire (distributed in accordance with Table 1 that follows) and dividing by two Weather side the surface area of the rim not covered by the inflated tire Table 1–...

  • Page 236: Vehicle Load Limits

    Vehicle load limits Vehicle load limits include total load NOTICE CAUTION capacity, seating capacity, towing ca- pacity and cargo capacity. Follow the Even if the number of occupants Do not apply the load more than load limits shown below. Total load ca- are within the seating capacity, each load limit.

  • Page 237: Cargo And Luggage

    Cargo and luggage— —Stowage precautions When stowing cargo and luggage in NOTICE D Never allow anyone to ride in or on the vehicle, observe the follow- the luggage compartment. It is ing: Do not load the vehicle beyond not designed for passengers. the vehicle capacity weight giv- D Put cargo and luggage in the lug- They should ride in their seats...
  • Page 238 —Capacity and distribution Cargo capacity depends on the to- (4) The resulting figure equals the tal weight of the occupants. available amount of cargo and luggage load capacity. For exam- (Cargo capacity) = (Total load capac- ple, if the “XXX” amount equals ity) –...
  • Page 239 379 kg – 176 kg = 203 kg. CAUTION (834 lb. – 388 lb. = 446 lb.) Weight of removed As shown in the above example, if the third seat Even if the total load of occu- number of occupants increases, the pant’s weight and the cargo load Cargo cargo and luggage load equaling the...

  • Page 240: Types Of Tires

    Types of tires Determine what kind of tires your All season tires, however, do not have vehicle is originally equipped with. adequate traction performance compared with snow tires in heavy or 1. Summer tires loose snow. Also, all season tires fall Summer tires are high−speed capabil- short in acceleration and handling ity tires best suited to highway driving...

  • Page 241: In Case Of An Emergency

    SECTION IN CASE OF AN EMERGENCY In case of an emergency If your vehicle will not startt ........If your engine stalls while driving .

  • Page 242: If Your Vehicle Will Not Startt

    2. If the engine still will not start, it needs work, your key may be broken. Have the adjustment or repair. Call a Toyota key checked at your Toyota dealer. If 3. If the light is out, dim or goes out dealer or qualified repair shop.
  • Page 243 If the engine still will not start, it needs which is poisonous and corrosive. adjustment or repair. Call a Toyota dealer Wear protective safety glasses when or qualified repair shop for assistance. jump starting, and avoid spilling acid on your skin, clothing, or ve- hicle.
  • Page 244 JUMP STARTING PROCEDURE 1. If the booster battery is installed in Discharged battery Jumper cable another vehicle, make sure the vehicles are not touching. Turn off all unneces- sary lights and accessories. Booster When boosting, use the battery of battery matching or higher quality.
  • Page 245 If the cause of your battery discharging is not apparent (for example, lights left on), When making connections, you should have it checked at your Toyota avoid serious injury, do not lean over dealer. the battery or accidentally let the jumper cables or clamps touch any- thing except the correct battery termi- nals or the ground.

  • Page 246: If Your Engine Stalls While Driving

    CAUTION After arriving at a safe place, stop the vehicle and call a Toyota dealer for 2. If coolant or steam is boiling out of the If the engine is not running, the pow- assistance.

  • Page 247: If You Have A Flat Tire

    You should have it checked as 4. If the engine drive belt is broken or the soon as possible at your Toyota dealer. 5. Read the following instructions coolant is leaking, stop the engine im- mediately.
  • Page 248 NOTICE CAUTION D Make sure to set the jack prop- erly in the jack point. Raising z Do not continue driving with When jacking, be sure to observe the vehicle with jack improper- a deflated tire. Driving even a the following to reduce the possi- ly positioned will damage the short distance can damage a bility of personal injury:...
  • Page 249 —Required tools and spare tire 1. Get the required tools and spare Turn the jack joint by hand. To remove the spare tire under the tire. luggage compartment: To remove: Turn the joint in direction 1 Tool bag 1 until the jack is free. 1.
  • Page 250 When connecting a jack handle exten- 2. Remove the access hole cover on 3. Insert the jack handle end into the sion with a jack handle end, use a the rear bumper with a flathead lowering screw through the access jack handle to tighten the bolts on the screwdriver.
  • Page 251 —Blocking the wheel 4. After the tire is lowered completely When storing the spare tire, put it in 2. Block the wheel diagonally op- to the ground, remove the holding place with the outer side of the wheel posite the flat tire to keep the bracket as shown in the illustration.
  • Page 252 —Removing wheel ornament —Loosening wheel nuts CAUTION Never use oil or grease on the bolts or nuts. The nuts may loos- en and the wheels may fall off, which could cause a serious ac- cident. 3. Remove the wheel ornament. 4.
  • Page 253 —Positioning the jack JACK POINTS: Front—Under the frame side rail Left rear—Under the rear axle housing Right rear—Under the bracket on the rear axle housing Make sure the jack is positioned on a level and solid place. Put a jack handle, jack handle exten- sions, and jack handle end together as shown in the illustration.
  • Page 254 —Raising your vehicle NOTICE Tighten all the joints securely. Otherwise, the extension may come off and it may damage the paint or vehicle body. When connecting a jack handle exten- 6. After making sure no one is in sion with another extension and a jack the vehicle, raise it high enough handle end, use a jack handle to tight- so that the spare tire can be...
  • Page 255 —Changing wheels To raise the vehicle, insert the jack handle end into the joint of the jack (it is a loose fit) and turn it clockwise with the handle, making sure the han- dle remains firmly fitted onto the jack handle extension.
  • Page 256 —Reinstalling wheel nuts —Lowering your vehicle CAUTION Never use oil or grease on the bolts or nuts. Doing so may lead to overtightening the nuts and damaging the bolts. The nuts may loosen and the wheels may fall off, which could cause a seri- ous accident.
  • Page 257 —Reinstalling wheel ornament Tighten each nut a little at a time in CAUTION the order shown. Repeat the process until all the nuts are tight. D Take due care in handling the ornament to avoid unexpected CAUTION personal injury. D When lowering the vehicle, D Do not attach a heavily dam- make sure all portions of your aged plastic wheel ornament.

  • Page 258: If Your Vehicle Becomes Stuck

    If your vehicle becomes stuck —After changing wheels 11. Check the air pressure of the re- If your vehicle becomes stuck in snow, CAUTION mud, sand, etc., then you may attempt to placed tire. rock the vehicle free by moving it forward Adjust the air pressure to the specifi- Before driving, make sure all the and backward.

  • Page 259: If Your Vehicle Needs To Be Towed

    If towing is necessary, we recommend NOTICE (a) Towing with wheel lift type truck— you have it done by your Toyota dealer or a commercial tow truck service. In If you rock your vehicle, observe the —From front consultation with them, have your ve- following precautions to prevent dam- hicle towed using either (a) or (b).
  • Page 260 “Active height control suspension” on page 167. (c) Towing with sling type truck If towing is necessary, we recommend you to have it done by your Toyota (a) Towing with wheel lift type truck NOTICE dealer or a commercial tow truck ser- Use a towing dolly under the wheels not vice.
  • Page 261 —Emergency towing hook precautions Before emergency towing, check that CAUTION CAUTION the hook is not broken or damage and that the installation bolts are not loose. Use extreme caution when towing ve- If the engine is not running, the pow- Fasten the towing cable or chain se- hicle.

  • Page 262: If You Cannot Shift Automatic Transmission Selector Lever

    If the towing vehicle can hardly move, do not forcibly continue the If you cannot shift the selector lever towing. Contact your Toyota dealer out of “P” position to other positions or a commercial tow truck service even though the brake pedal is de- for assistance.

  • Page 263: If You Lose Your Keys

    Toyota dealer if you can give them the key number and master key. Even if you lose only one key, contact your Toyota dealer to make a new key. If you lose all your master keys, you cannot make new keys; the whole engine immobi- lizer system must be replaced.
  • Page 265 SECTION − DO−IT−YOURSELF MAINTENANCE Introduction Engine compartment overview ....... Fuse locations .

  • Page 266: Engine Compartment Overview

    Engine compartment overview 1. Suspension fluid reservoir 2. Engine oil filler cap 3. Brake fluid reservoir 4. Fuse block 5. Battery 6. Windshield and rear window washer fluid tank 7. Engine oil level dipstick 8. Condenser 71C004f 9. Radiator 10. Engine coolant reservoir 11.

  • Page 267: Fuse Locations

    Fuse locations Spare fuses i71002d Spare fuses 71C510a...

  • Page 268: Do−It−Yourself Service Precautions

    Right after driving, engine warranty coverage. Read separate automatically start to run if the air compartment—the engine, radiator, Toyota Warranty statement for details and conditioning is on. exhaust manifold, power steering suggestions. Use eye protection whenever you fluid reservoir spark...

  • Page 269: Parts And Tools

    Remember all Toyota parts are de- trode. Do not dispose of used oil and fil- signed in metric sizes, so your tools must...
  • Page 270 Tools: CHECKING AND REPLACING FUSES Funnel (only for adding coolant) Parts (if replacement is necessary): CHECKING BRAKE FLUID Fuse with same amperage rating as original Parts (if level is low): ADDING WASHER FLUID SAE J1703 or FMVSS No.116 DOT 3 brake fluid Parts: Tools:...

  • Page 271: Engine Oil

    SECTION − DO−IT−YOURSELF MAINTENANCE Engine and Chassis Checking the engine oil level ....... . . Checking the engine coolant level .

  • Page 272: Checking The Engine Oil Level

    Checking the engine oil level NOTICE Low level Full level Be careful not to drop engine oil on the vehicle components. If the oil level is below or only slightly above the low level, add engine oil of the same type as already in the engine. Remove the oil filler cap and add engine oil in small quantities at a time, checking Add oil...

  • Page 273: Engine Oil

    ENGINE OIL SELECTION SAE 5W−30 is the best choice for good fuel economy, and good starting in cold “Toyota Genuine Motor Oil” is used in weather. your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent If SAE 5W−30 oil is not available, SAE to satisfy the following grade and viscos- 10W−30 oil may be used.

  • Page 274: Checking The Engine Coolant Level

    Toyota engines. Do not use plain water alone. If you can find no leak, have your Toyota Please contact your Toyota dealer for fur- dealer test the cap pressure and check ther details about “Toyota Genuine Motor for leaks in the cooling system.

  • Page 275: Checking The Radiator And Condenser

    If any of the above parts are extremely dirty or you are not sure of their condi- tion, take your vehicle to a Toyota dealer. CAUTION To prevent burning yourself, be care- ful not to touch the radiator or con- denser when the engine is hot.

  • Page 276: Checking Brake Fluid

    Checking brake fluid If the level is low, add SAE J1703 or NOTICE FMVSS No. 116 DOT 3 brake fluid to the brake reservoir. Only use the Suspension fluid AHC for the active height control suspen- Refilling brake fluid: sion. If you fill other fluids such as 1.

  • Page 277: Checking Power Steering Fluid

    Checking power steering fluid Clean all dirt from outside of the reservoir NOTICE tank and look at the fluid level. If the fluid is cold, the level should be in the “COLD” If you spill some of the fluid, be sure If cold range.

  • Page 278: Checking Tire Inflation Pressure

    Checking tire inflation pres- sure CAUTION The reservoir may be hot so be care- ful not to burn yourself. NOTICE Avoid overfilling, or the power steer- ing could be damaged. 72c502b Type A Type B...
  • Page 279 Keep your tire inflation pressures D Always use a tire inflation pres- Tire inflation at the proper level. sure gauge. The appearance of pressure gauge a tire can be misleading. Besides, The recommended cold tire inflation tire inflation pressures that are pressures, tire sizes and the com- even just a few pounds off can de- bined weight of occupants and cargo...
  • Page 280 D A greater possibility of tire waste fuel, reduce the comfort of driv- damage from road hazards ing, reduce tire life and make your ve- hicle less safe to drive. If a tire frequently needs refilling, have it checked by your Toyota deal-...

  • Page 281: Checking And Replacing Tires

    Checking and replacing tires The tires on your Toyota have built−in If air loss occurs while driving, do not Tread wear indicator tread wear indicators to help you continue driving. Driving even a short know when the tires need replace- distance can damage a tire beyond ment.
  • Page 282 Using any other size or type of tire Toyota recommends all four tires, CAUTION may seriously affect handling, ride, or at least both front or rear tires speedometer/odometer calibration, be replaced as a set. Observe the following instruc- ground clearance, and clearance be- See “If you have a flat tire”...

  • Page 283: Rotating Tires

    To equalize tire wear and help ex- Do not use tires other than those men- tend tire life, Toyota recommends tioned above. Do not install studded tires that you rotate your tires accord- without first checking local regulations for ing to the maintenance schedule.
  • Page 284 SNOW TIRE INSTALLATION CAUTION Side chain Snow tires should be installed on all wheels. Observe following instructions. Installing snow tires on the rear wheels Otherwise, an accident may occur re- only can lead to an excessive difference sulting in death or serious injuries. in road grip capability between the front Do not use snow tires other than and rear tires which could cause loss of...

  • Page 285: Replacing Wheels

    When installing chains on your tires, care- Correct replacement wheels are available When driving with chains installed, fully follow the instructions of the chain be sure to drive carefully. Slow at your Toyota dealer. manufacturer. down before entering curves...

  • Page 286: Aluminum Wheel Precautions

    Otherwise, an accident may occur re- sulting in death or serious injuries. When balancing your wheels, use only Toyota balance weights or equivalent Do not use wheels other than the and a plastic or rubber hammer. manufacturer’s recommended size,...
  • Page 287 SECTION − DO-IT-YOURSELF MAINTENANCE Electrical components Checking battery condition ........Battery recharging precautions .

  • Page 288: Checking Battery Condition

    Checking battery condition— —Precautions —Checking battery exterior CAUTION If electrolyte gets on your skin, Ground cable Terminals thoroughly wash the contact area. If BATTERY PRECAUTIONS you feel pain or burning, get medi- cal attention immediately. The battery produces flammable and explosive hydrogen gas.

  • Page 289: Battery Recharging Precautions

    To return the moon roof to normal, Have battery Dark White see “Electric moon roof” on page 31. checked by your NOTICE Toyota dealer. Never recharge the battery while the Clear or Have battery engine is running. Also, be sure all light checked by your accessories are turned off.

  • Page 290: Checking And Replacing Fuses

    Checking and replacing fuses Type A fuses can be pulled out by the pull−out tool. The location of the pull−out tool is shown in the illustration. Type A If you are not sure whether the fuse has blown, try replacing the suspected fuse with one that you know is good.

  • Page 291: Adding Washer Fluid

    Add washer gain access to the bulbs. When replacing tem. Have your Toyota dealer correct it as fluid. a bulb, make sure the ignition switch and soon as possible.
  • Page 292 Hold a bulb pooled inside light, contact your only by its plastic or metal case. Interior lights — Toyota dealer. Do not touch the glass part of a Personal lights bulb with bare hands. Type A — Bulb Light bulbs Type Type B —...
  • Page 293 —Headlights 73c005a 1. Open the hood. 2. Left−hand headlight and right−hand 3. Pull the bulb out of the bulb base. head light (high beam): Left−hand headlight: Remove If the connector is tight, wiggle it. Turn the bulb base counterclockwise washer inlet. to the front of the vehicle.
  • Page 294 Right−hand headlight (low beam): Install the bulb base by turning it counterclockwise to the front of the vehicle. Left−hand headlight: Remove washer inlet. Aiming is not necessary after replacing the bulb. When aiming adjustment is nec- essary, contact your Toyota dealer.
  • Page 295 Use a flathead screwdriver. 3. Install a new bulb base by turning it clockwise to the front of the vehicle. Aiming is not necessary after replacing the bulb. When aiming adjustment is nec- essary, contact your Toyota dealer.
  • Page 296 —License plate lights a: Rear turn signal light b: Back–up light...

  • Page 297: Specifications

    SECTION SPECIFICATIONS Specifications Dimensions and weightss ........Engine .

  • Page 298: Dimensions And Weightss

    Dimensions and weights Engine Fuel Overall length mm (in.) 4890 (192.5) Model: Fuel type: 4.7L V8 (2UZ−FE) Unleaded gasoline, Octane Rating 87 Overall width mm (in.) 1940 (76.4) (Research Octane Number 91) or higher. ∗ 1 Type: Overall height mm (in.) 1875 (73.8) ∗...

  • Page 299: Service Specifications

    Coolant type: DENSO SK20R11 “Toyota Super Long Life Coolant” is used IFR6A11 in your Toyota vehicle at factory fill. In Spark plug gap, mm (in.): order to avoid technical problems, only use 1.1 (0.043) “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non−sili-...
  • Page 300 No.2 or Molybdenum—disulfide lithium Hypoid gear oil API GL−5 changing automatic transmission base chassis grease, NLGI No.2 fluid, use only “Toyota Genuine ATF Recommended oil viscosity: WS” (ATF JWS3324 or NWS9638) to aid Above –18_C (0_F) in assuring maximum transmission per- SAE 90 formance.
  • Page 301 BRAKES Minimum pedal clearance when depressed with the force of 490 N (50 kgf, 110 lbf) with the engine running, mm (in.): 116 (4.6) Pedal free play, mm (in.): 1 – 6 (0.04 – 0.24) Pad wear limit, mm (in.): 1.0 (0.04) Lining wear limit, mm (in.): 1.0 (0.04)

  • Page 302: Tires

    Tires Tire size and inflation pressure: kPa (psi) Front Rear Spare Tire size Wheel size Normal Trailer Normal Trailer Normal Trailer driving towing driving towing driving towing 220 (32) 240 (35) P275/60R18 111H 200 (29) 220 (32) 220 (32) 240 (35) Wheel nut torque, N·m (kgf·m, ft·lbf): 131 (13.4, 96.6) NOTE: For complete information on tires (e.g.

  • Page 303: Fuses

    Fuses Engine compartment Left side kick panel Right side kick panel Fuses 8. HAZ−TRN 15 A: Emergency flashers, 18. BAT 30 A: All components in “ECU−B2” Turn signal lights 1. ABS NO.2 40 A: Anti−lock brake sys- 19. TEL 7.5 A: No circuit 9.
  • Page 304 34. AHC−B 15 A: 52. DIFF 20 A: Four−wheel drive system Active height control sus- pension (AHC) 53. WASHER 15 A: Windshield washer 35. FUEL HTR 20 A: Fuel heater 54. RADIO 10 A: Audio system 36. POWER HTR 7.5 A: Power heater 55.
  • Page 305 70. RR A/C 30 A: Rear air conditioning system 71. RH SEAT 30 A: Power seat system 72. AIR PUMP 50A: Multiport fuel injection system/Sequential multiport fuel injec- tion system 73. A/F HTR 15A: Multiport fuel injection system/Sequential multiport fuel injec- tion system...
  • Page 307 SECTION REPORTING SAFETY DEFECTS FOR U.S. OWNERS AND UNIFORM TIRE QUALITY GRADING Reporting safety defects for U.S. owners and uniform tire quality grading Reporting safety defects for U.S. ownerss ....
  • Page 308 However, NHTSA cannot become involved in individual prob- lems between you, your dealer, or Toyota Motor Sales, U.S.A., Inc.

Table of Contents
