4. Y/C CIRCUIT

(1) No Video in EE Mode,
No Video in EE Mode
Does the Video signal
appear at the IC301 Pin48?
YES
Is 5V applied to the IC301
Pins18, 24, 42, 55, 72, 91?
YES
Does the Video signal
appear at the IC301 Pin65?
YES
Does the Video signal
appear at the IC501 Pin19?
YES
Does the Video signal
appear at the Emitter termi-
nal of the Q307, Q308?
NO
Check the 24Pin of Tuner.
NO
Check the 5.2VT, 5.3VA
Line. (Power Circuit)
NO
Is I 2 C BUS signal applied to
the IC301 Pins68, 69?
YES
Chck the path of the signal
NO
between the IC301 Pin65
and IC501 Pin17.
Does the 12VT, 5.4VA
NO
appear at the Emitter termi-
nal of the Q804, Q308.
YES
Replace the Q804, Q308.
3-10
Check the System Circuit.
NO
(Refer to 'SYSTEM I
CHECK Trouble Shooting')
Check C316. (AGC)
NO
Replace the IC301.
Check the 12VT, 5.4VA
Line. (Power Circuit)
2 C BUS
YES
