- Page 1 High Definition Video Camera HC-W850P Model No. HC-W850PC HC-W850PU HC-W850EB HC-W850EE HC-W850EF HC-W850EG HC-W850EP HC-W850GC HC-W850GK HC-W850GW HC-W858EG HC-W850MGK HC-W850MGN HC-V750P HC-V750PC HC-V750EB HC-V750EE HC-V750EF HC-V750EG HC-V750EP HC-V750GC © Panasonic Corporation 2014 Unauthorized copy- ing and distribution is a violation of law.
-
Page 2: Table Of Contents
HC-V757EG HC-V730EE HC-V750MGN Colour (K)...Black Type (W)...White Type (only HC-W850EF/W858EG/V757EG/V730EE) TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -----------------------------------------------3 11 Block Diagram --------------------------------------------------- 68 1.1. General Guidelines ----------------------------------------3 11.1. Overall Block Diagram---------------------------------- 68 1.2. Leakage Current Cold Check ---------------------------3 11.2. Camera Circuit Block Diagram ----------------------- 69 1.3. -
Page 3: Safety Precautions
1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check (See Figure. 1) 1. IMPORTANT SAFETY NOTICE There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check. -
Page 4: Warning
2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip"... -
Page 5: Caution For Ac Cord (For Eb
2.3.2.3. How to Replace the Fuse A replacement fuse cover can be purchased from your local Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety. -
Page 6: How To Replace The Lithium Battery
NOTE: This Lithium battery is a critical component. (Type No.: ML-614S/DN Manufactured by Energy Company, Panasonic Corporation) It must never be subjected to excessive heat or discharge. It must therefore only be fitted in requirement designed specifically for its use. -
Page 7: Service Navigation
3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2. -
Page 8: How To Define The Model Suffix (Ntsc Or Pal Model)
How to Define the Model Suffix (NTSC or PAL model) There are nine kinds of HC-W850/W858/W850M/V750/V757/V750M/V730. • a) HC-W850M, V750M (Japan domestic model) • b) HC-W850P, V750P • c) HC-W850PC, V750PC • d) HC-W850EB/EF/EG/EP, W858EG, V750EB/EF/EG/EP, V757EG • e) HC-W850EE, V750EE •... -
Page 9: Formatting
3.4. Formatting The following formatting is for HC-W850EB/EP, HC-V750EB/EP. The page number in this page does not show the page number of this service manual. -
Page 10: Baking Of Replacement Ic And Defective P.c.b
3.5. Baking of replacement IC and defective P.C.B. When replacing the CSP/BGA/QFN type IC mounted on the P.C.B., the problem of IC crack or foil pattern breaking in the P.C.B. might sometimes occur by rapid heating. In order to improve the success rate of IC replacement for repair, it would be required to work out baking of replacement IC and defective P.C.B. -
Page 11: Specifications
4 Specifications The following specification is for HC-W850EB/EP, HC-V750EB/EP. Some specifications may differ depending on model suffix. The page number in this chapter does not show the page number of this service manual. -
Page 17: Location Of Controls And Components
5 Location of Controls and Components The following description is for HC-W850EB/EP, HC-V750EB/EP. Some descriptions may differ depending on model suffix. The page number in this chapter does not show the page number of this service manual. -
Page 22: Service Mode
6 Service Mode Indication method of the service menu 1. Keep pressing the “Power” button, “Zoom lever” to W side and “Recording/Playback” button for more than 3 seconds until the top screen of the Service Mode Menu being displayed. Service mode menu Screen display Contents Function... -
Page 23: Model/Destination Settings
6.1. Model/Destination Settings Touch the [ 2 ] of LCD, select model/destination settings. Operation specifications Function description • Change the Model/Destination Display the lists of model/distination which the unit can be changed, if a shipment setup is finished. Therefore in some cases, the model/destination that is currently set is only displayed. End method of operation •... -
Page 24: Lock Search And Error History Indication
6.2. Lock Search and Error History Indication Touch the [ 4 ] of LCD, select Lock search and error history indication. Operation specifications Indication contents 1. Main Camera • Lock search history indication of main camera Display the main camera system error cord for three histories saved in EEPROM. •... -
Page 25: Power On Self Check Result Display
6.3. Power ON Self Check Result Display Touch the [ 5 ] of LCD, select Power ON self check result display. Operation specifications Indication contents • Power ON self check result display Function to diagnose correct function of the device and interface between devices result display. Display the following communication test result. -
Page 26: Adjustment Function For The Service
6.4. Adjustment function for the Service Touch the [14] of LCD, select the adjustment function for the service. Operation Specifications (until before the start of the adjustment) Function description The service adjustment do setup and adjustment of the following items required in the field service. For a detailed content, such as the adjustment procedure, refer to “9 Measurements and Adjustments”. -
Page 27: Restore The Backed Up Adjustment Data
6.5. Restore the backed up adjustment data Touch the [15] of LCD, select restoring the backed up adjustment data from SD card to the unit. Operation Specifications Function description Restore the adjustment data to new or repaired Main P.C.B. from SD card that the data backed up from original Main P.C.B. before repairs or replacement. -
Page 28: Touch Panel Calibration
6.6. Touch Panel Calibration Touch the [16] of LCD, select the calibration of touch panel. Operation Specifications Function description Calibrate the touch positions of the touch panel. End method of operation • Press the power button to turn the unit off. 6.7. -
Page 29: Service Fixture & Tools
7 Service Fixture & Tools 7.1. When Replacing the Main P.C.B. After replacing the MAIN P.C.B., be sure to achieve adjustment. 7.2. Service Position This Service Position is used for checking and replacing parts. Use the following Extension cables for servicing. Parts No. -
Page 30: Disassembly And Assembly Instructions
8 Disassembly and Assembly Instructions 8.1. Disassembly Flow Chart for the Unit This is a disassembling chart. When assembling, perform this chart conversely. -
Page 31: Pcb Location
8.2. PCB Location... -
Page 32: Disassembly Procedure For The Unit
8.3. Disassembly Procedure for the Item Fig. Removal Wi-Fi Frame Unit (Fig. D11) Screw (Q) x 2 Unit Lens Frame Unit, Convex x 3 Barrier Motor Unit Hooking part x 2 (Fig. D12) Wi-Fi Frame Unit Item Fig. Removal Screw (R) x 1 Side Case-L Unit (Fig. - Page 33 Item Fig. Removal Item Fig. Removal 13 (HC-V750/V757/V750M/ (Fig. D25) Screw (Y) x 2 19 Kurupon Unit, (Fig. D35) Screw (h) x 2 V730) Front P.C.B. Screw (Z) x 2 Locking tab x 2 LCD Hinge Unit Locking tab x 9 Convex x 2 LCD Case (T) Unit FR Earth Angle...
- Page 34 8.3.1. Removal of the Side Case-L Unit (Fig. D2) (Fig. D1)
- Page 35 8.3.2. Removal of the Top Case, Top Operation (Fig. D4) (Fig. D3)
- Page 36 (Fig. D5) (Fig. D6)
- Page 37 8.3.3. Removal of the Front Case Unit (Fig. D7) (Fig. D8)
- Page 38 8.3.4. (except HC-V730) Removal of the 8.3.5. Removal of the Photo Light DRV. NFC P.C.B. Unit, Wi-Fi P.C.B. P.C.B. Unit (Fig. D10) 8.3.6. Removal of the Wi-Fi Frame Unit, Lens Frame Unit, Barrier Motor Unit (Fig. D11) (Fig. D9)
- Page 39 (Fig. D13) (Fig. D12)
- Page 40 8.3.7. Removal of the Camera Lens Unit 8.3.8. Removal of the Main P.C.B., SD Holder P.C.B. (Fig. D14) (Fig. D15)
- Page 41 (Fig. D17) 8.3.9. (HC-W850M/V750M only) Removal of the ESD P.C.B. Unit (Fig. D18) (Fig. D16)
- Page 42 8.3.10. Removal of the BR Frame Unit, Speaker, LCD Unit (Fig. D20) (Fig. D19)
- Page 43 8.3.12. (HC-W850/W858/W850M) Removal of the LCD Hinge Unit, Sub Camera Unit (Fig. D21) 8.3.11. Removal of the BATT. Catcher P.C.B. (Fig. D22) (Fig. D23)
- Page 44 8.3.13. (HC-V750/V757/V750M/V730) Removal of the LCD Hinge Unit (Fig. D24) (Fig. D25)
- Page 45 8.3.14. Removal of the Monitor P.C.B., LGP Unit, LCD (Fig. D26) (Fig. D27)
- Page 46 8.3.15. Removal of the Mic P.C.B. (Fig. D28) (Fig. D29)
- Page 47 8.3.16. Removal of the Front Base, Barrier R, Barrier F, Photo Light P.C.B. (Fig. D30) (Fig. D31)
- Page 48 8.3.17. Removal of the Front Ring, Hood 8.3.18. Removal of the Front Case, Front Piece Ornament Unit, Mic Case Unit (Fig. D32) (Fig. D33)
- Page 49 8.3.19. Removal of the Kurupon Unit, Front P.C.B. (Fig. D34) (Fig. D35)
- Page 50 8.3.20. Removal of the MOS Unit 8.3.22. Removal of the 2nd Stepping Motor (Fig. D36) 8.3.21. (HC-W850/W858/W850M) Removal of the IR Kudou Unit (Fig. D38) (Fig. D37)
- Page 51 8.3.23. Removal of the 3rd Stepping Motor 8.3.24. Removal of the 4th Stepping Motor (Fig. D39) (Fig. D40)
-
Page 52: Measurements And Adjustments
9 Measurements and Adjustments 9.1. Electric Adjustment • Adjustment method is different from a conventional High definition video camera. • An exclusive jig are necessary for electric adjustment. • Connection method of the main unit and an exclusive adjustment jig as follows. Figure of connection Figure of image when adjustment... - Page 53 Part Number of jig 1. Basic Jig Item Contents AC adaptor Bandled with camcorder AC Cable Bandled with camcorder 2. Optical Jig for Camera Adjustment Item Part number Remarks Light box VFK1164TDVLB/RFKZ0523* Need external power supply: 12V ± 0.1V /1.8A or over Collimator with focus chart VFK1164TCM02/VFK1164TCM03 Same as DSC...
- Page 54 [Level Shot Adjutment Chart]...
- Page 55 9.1.1. About Light Box When using VFK1164TDVLB Light Box If using VFK1164TDVLB Light Box, remove the lens connection ring by loosing thumbscrew and three hexagon screws. * RFKZ0523 Light Box has no lens connection ring. How to remove the Front Hood In order to utilize maximum of the diffusing surface of light box, some adjustment items need the distance between diffusing surface of light box and camera body becomes several cent-meters.
- Page 56 9.1.2. Adjustment Items Adjustment item as follows.
-
Page 57: Adjustment Procedure
9.1.3. Adjustment Procedure All adjustments except “Touch Panel Calibration”, “Factory Setting” and “NFC Initialization” performs using “14 Adjustment function for the service” in service mode menu. “Touch Panel Calibration” is performed using 16 of service mode menu and “Factory Setting” is performed using 1, “NFC Initializa- tion”... - Page 58 [Adjustment Procedure] Adjustments and settings are performed following order: 1. Model setting 2. Filename setting for backup to SD card 3. Backing up adjustment data to SD card 4. Checking switches 5. Camera adjustment (Iris, Gyro, OIS, Missing pixels) 6. Zoom/tracking adjustment (with Zoom hysteresis adjustment) 7.
-
Page 66: Factory Setting
10 Factory Setting 10.1. How To Turn On The Factory Settings? 1. While the power is turned OFF, keep pressing the “Power” button, “Zoom lever” to W side and “Recording/Playback” button for more than 3 seconds until the top screen of the Service Mode Menu being displayed. 2. -
Page 67: What Is The Factory Settings
10.2. What Is The Factory Settings? The factory settings clean up and/or refresh the following settings. 1. Setting Values of menu. 2. Clear the time and date setting. 3. Close the lens cover 4. Initialize the Wi-Fi data settings (except HC-V730) 5. -
Page 68: Block Diagram
11 Block Diagram 11.1. Overall Block Diagram HC-W850/W858/W850M only SUB CAMERA NOTE : VIDEO SIGNAL IC203 CAMERA : AUDIO SIGNAL MOS IMAGE BRIDGE IC SENSOR : CLK or CONTROL LINE IC205,252 GATE IC COLOR LCD PANEL IC901 LCD COLOR LENS(F1.8-3.6 20x) DRIVER ZOOM/ MOS IMAGE... -
Page 69: Camera Circuit Block Diagram
11.2. Camera Circuit Block Diagram IC3401 (VENUS ENGINE) RL3403 RL3404 RL3401 RL3402 RL3407 RL3408 RL3406 RL3405 LVDS CKP SENS LVDSCAP G27 LVDS RXCAP LVDS CK M SENS LVDSCAM LVDS RXCAM PW 3.2V LVDS A P SENS LVDS0P LVDS RX0P PW MOS2.8VA LVDS A M SENS LVDS0M LVDS RX0M... -
Page 70: System Control Circuit Block Diagram
11.3. System Control Circuit Block Diagram IC3401 (VENUS ENGINE) FP905 AD TPY RIGHT X RIGHT AD TPX BOT Y BOT TOUCH PANEL X LEFT UNIT AD TPY LEFT AD TPX TOP Y TOP QR3413 QR3411 SEL1 ON LOW PW REG3V PW REG1.8V SEL2 ON LOW CARD LED B... -
Page 71: Video/Audio Signal Process(1) Circuit Block Diagram
11.4. Video/Audio Signal Process(1) Circuit Block Diagram PW DDR1.2V PW DDR1.2V PW RTCVREG25 QR3415 QR3416 QR3414 IC3414 (RESET) PW HDMI5V PW RTCVREG25 PW RTCVREG25 PW RTCVREG25 DDR POW ON H (To IC1241/1262/1291-4) JK6003 HDMI MINI CONNECTOR IC3404 (NAND FLASH ROM/1G-bit) VDD CD PW RTCVREG25 Q3401... -
Page 72: Video/Audio Signal Process(2) Circuit Block Diagram
11.5. Video/Audio Signal Process(2) Circuit Block Diagram IC3401 IC3701 (VENUS ENGINE) (AVIO) Q4801 PW REG5V PMHP PMAD0 IC3702 MICIN0L G MIC OUT L (SINGLE CLOCK GENERATOR) CHARGE PUMP SVDD RL3701 PMAD0 or PMAD1 MICIN0R G MIC OUT R PMAD1 CLK27 M CLKIN CLKOUT INPUT... -
Page 73: Lens Drive Circuit Block Diagram
11.6. Lens Drive Circuit Block Diagram IC3401 (VENUS ENGINE) FP6008 IR ABS IRFILABS LEN 2G ZLEDCONT 2G ZABS 2GZABS LEN 3G ZLEDCONT 3G ZABS 3GZABS LEN 4G ZLEDCONT LEDCONT LEN 4G ZABS 2GZOOM 3GZOOM 4GZOOM 4GZABS LEN TOUT IR ENC LENS TEMP SHTR OPEN Q774... -
Page 74: Power Supply Circuit Block Diagram
11.7. Power Supply Circuit Block Diagram HC-W850/W858/W850M only Please check the Fuse Resistor and IC Protector JK6401 PW CAM2.1V IP6401 when an output voltage does not output. NOREG R1001 IC1471 FUSE RESISTOR: PW STNOREG DC IN PW 5V (To IC7001-14) (R1001/R1002/R1271/R1503/R6003) (POWER-DISTRIBUTION PW HDM5V... -
Page 75: Wiring Connection Diagram
12 Wiring Connection Diagram 12.1. Interconnection Diagram GND WIRE PHOTO LIGHT P.C.B. (FOIL SIDE) : (COMPONENT SIDE) except HC-V730 except HC-V730 RL7501 RL7503 NFC P.C.B. UNIT Wi-Fi P.C.B. RL7502 MOS UNIT LENS UNIT NFC FPC Wi-Fi FPC PHOTO LIGHT WIRE PHOTO LIGHT DRV. - Page 76 HC-W850/W858/W850M HC-V750/V757/V750M/V730 TO MAIN P.C.B. TO MAIN P.C.B. FP6001 FP201 TO MAIN P.C.B. FP6001 MONITOR FPC MONITOR FPC FP904 FP904 VCORE IOVDD VCORE VPP MTP (OPEN) IOVDD VPP MTP (OPEN) LCD UNIT HSYNC VSYNC DCLK HSYNC CP4BM VSYNC CP4BP DCLK CP4AM CP4AP CP4BM...
