- Page 1 DVTEL INC. 65 Challenger Road Ridgefield Park, NJ 07660 trk100/trk100d/trk200 Installation Manual The contents of this manual may not be reproduced or reprinted in whole or in part without the express written permission of DVTEL, INC. Rev E March 2014...
-
Page 3: Table Of Contents
Reset by Removing the Power Supply ..............17 Solo Setup ........................17 Appendix ..........................18 A.1. Technical Specifications ....................19 A.2. Connecting Leads to a Spring Clamp Terminal Block ........... 21 A.3. Solo Setup Window ...................... 22 A.4. Troubleshooting ......................24 Contacting DVTEL .........................27... - Page 4 trk100/trk100d/trk200 Installation Manual List of Figures Figure 1: trk100/trk100d Unit ........................1 Figure 2: trk200 Unit ..........................1 Figure 3: trk100, trk100d and trk200 Unit Connectivity ................1 Figure 4: trk100/trk100d Front Panel ......................3 Figure 5: trk100/trk100d Back Panel ......................4 Figure 6: trk200 Front Panel ........................
-
Page 5: Revision History
Revision History Revision History Version Date Author Comments January 2004 Elisabeth Levy First release (released as trk100 Installation and Setup Guide) July 2004 Elisabeth Levy Second release October 2004 Elisabeth Levy Third release Ver. A2 August 2009 Leigh Includes trk100d and trk200. Rev D April 2013 Alan Singer... -
Page 7: Document Information
This document contains proprietary information belonging to DVTEL, Inc. This information is supplied solely for the purpose of assisting explicitly the licensee of the DVTEL units. No part of this document contents may be used for any other purpose, disclosed to any third party or reproduced by any means, electronic or mechanical, without the express prior written permission of DVTEL, Inc. -
Page 8: Document Conventions
DVTEL, Inc. and its agents make no guarantees or warranties to the suitability for the users’ intended use. DVTEL, Inc. accepts no responsibility for improper use or incomplete security and safety measures. - Page 9 Document Information Warning: 1. Only qualified trained personnel should service and repair this equipment. 2. Observe local codes and laws and ensure that installation and operation are in accordance with fire, security and safety standards. Electrical Safety Notice and Warnings Warning: 1.
-
Page 10: Site Preparation
trk100/trk100d/trk200 Installation Manual Caution: To avoid damage from overheating or unit failure, assure that there is sufficient temperature regulation to support the unit’s requirements (cooling/heating). Operating temperature should be kept in the range 0° to 50°C (32° to 122°F), with no more than 95% non-condensing humidity. -
Page 11: Introduction
Introduction 2 Introduction The trk100, trk100d and trk200 units are self-contained video analytic IP encoders that monitor the video input from a camera, providing real-time detection and autonomous tracking capabilities. The trk100 provides a single video channel with CIF resolution ... -
Page 12: Items Included In The Package
Terminal block spring clamp connectors (for relay outputs and alarm inputs) Documentation and utilities CD Note: An AC adaptor matching the unit’s electrical specifications (part number DVT-PWR-40W) can be purchased from DVTEL. Related Documentation: HTML Edition Units User’s Guide ... -
Page 13: Trk100/Trk100D Hardware Description
Introduction 2.2.1 trk100/trk100d Hardware Description trk100/trk100d Front Panel 2.2.1.1 Following is a description of the front panel of the trk100/trk100d unit. Figure 4: trk100/trk100d Front Panel Item Description RS232/RS485 For controlling a Pan/Tilt/Zoom camera via an RS232 or RS485 serial interface. Serial Interface Caution: (RJ45) - Page 14 trk100/trk100d/trk200 Installation Manual trk100/trk100d Back Panel 2.2.1.2 The following image shows the back panel of the trk100/trk100d unit. Figure 5: trk100/trk100d Back Panel The back panel of the unit includes the following connections: Item Description POWER For powering the unit from a 12VDC power source. The unit includes 4 LEDs.
-
Page 15: Trk200 Hardware Description
Introduction 2.2.2 trk200 Hardware Description trk200 Front Panel 2.2.2.1 Following is a description of the front panel of the trk200 unit. Figure 6: trk200 Front Panel Item Description RS232/RS485 For controlling a Pan/Tilt/Zoom camera via an RS232 or RS485 serial interface. Serial Interface Caution: (RJ45) - Page 16 trk100/trk100d/trk200 Installation Manual Item Description AUDIO OUT Used for talking through a loudspeaker connected to the unit to people located near the camera being monitored. One RCA connector is provided for each (RCA) channel. See Connecting a Loudspeaker to the Unit (page 14).
- Page 17 Introduction Item Description External Terminal block for the following connections: Device ALARM INPUT: Single alarm input connection (a set of two wires) used to Connections receive alarm signals from an external device — for example, a fire sensor, PIR (passive infrared) sensor, fence sensor, etc.
-
Page 19: Installing And Connecting The Unit
Installing and Connecting the Unit 3 Installing and Connecting the Unit This section describes how to install and connect the unit and includes the following sections: Installing the Unit (page 9) Connecting the Unit (page 9) Resetting the Unit (page 17) Note: After connecting the unit, proceed to configure the unit as described in the HTML Edition... -
Page 20: Grounding The Unit
3.2.2 Connecting the Unit to the Power Supply You can power the unit by using the 12VDC power supply provided by DVTEL or from a power outlet. An AC adaptor matching the required specifications can be purchased as an accessory from DVTEL. -
Page 21: Connecting The Unit To The Network
Installing and Connecting the Unit 3.2.3 Connecting the Unit to the Network By default, the unit is shipped with the factory default IP address 192.168.123.10. Caution: Before connecting the unit to the network, set the unit IP address according to your specific network requirements to avoid address conflicts. -
Page 22: Connecting The Video Source (Camera) To The Unit
trk100/trk100d/trk200 Installation Manual To change the unit’s IP address Insert the CD included in the package in your computer’s disk drive. Run the dna.exe file by clicking the icon. The DNA application opens and the device is displayed in the window. Select the unit by right-clicking on it. -
Page 23: Connecting A Microphone To The Unit
Installing and Connecting the Unit Repeat steps 1 and 2 for each video source (camera) you want to connect to the unit. Note: For PTZ cameras, you must connect the control lines of the PTZ camera in order to use the pan, tilt, and zoom operability. For more information, see Connecting PTZ Camera Control Lines to the Unit (page 14). -
Page 24: Connecting A Loudspeaker To The Unit
trk100/trk100d/trk200 Installation Manual 3.2.6 Connecting a Loudspeaker to the Unit Use the supplied audio splitter cable to connect a loudspeaker to the unit and make announcements near the camera from a microphone connected to the Video Management System PC. The audio output from the unit provides Line Out levels. -
Page 25: Connecting The Analog Video Output To An Analog Device
Installing and Connecting the Unit To connect the PTZ camera control lines Connect the PTZ camera control lines to either the RS232 or RS485 spring clamp terminal block connectors. For more information on how to use the spring clamp terminal block connectors, Connecting Leads to a Spring Clamp Terminal Block (page 21). -
Page 26: Connecting The Unit To Control An External Device (Using Relay Outputs)
trk100/trk100d/trk200 Installation Manual To connect an external alarm to the unit Connect the leads from the external device dry contact output, using the spring clamp terminal block into the terminal contacts marked - (ALARM IN) and + (ALARM IN). See Connecting Leads to a Spring Clamp Terminal Block (page 21). -
Page 27: Resetting The Unit
Installing and Connecting the Unit Warning: The signal from the relay output of the unit is for use as an indicator, not for direct control of a device. Caution: To prevent damage to the unit, do not exceed the voltage and current ratings for the relay terminals. -
Page 28: Appendix
trk100/trk100d/trk200 Installation Manual Appendix The appendix contains the following sections: Technical Specifications (page 19) Connecting Leads to a Spring Clamp Terminal Block (page 21) Solo Setup Window (page 22) Troubleshooting (page 24) -
Page 29: Technical Specifications
Appendix A.1. Technical Specifications Following are the trk100, trk100d and trk200 technical specifications: Video Input Channels trk100 trk100d trk200 Number of Intelligent Video Analysis Channels Analog Video Inputs TV Standard Composite 1Vp-p (PAL or NTSC) Physical Connector 1 x BNC 75Ω 1 x BNC 75Ω... - Page 30 trk100/trk100d/trk200 Installation Manual Power Source Voltage 12VDC, 0.5 A Power Consumption Physical Dimensions Dimensions (mm) 189 x 36 x 164 mm (W x H x D) Dimensions (inches) 7-7/16" x 1-13/32" x 6-7/16” (W x H x D) Mounting Shelf-mount Environmental Specifications Operating 0°...
-
Page 31: Connecting Leads To A Spring Clamp Terminal Block
Appendix A.2. Connecting Leads to a Spring Clamp Terminal Block The unit is delivered with two terminal block connectors. The connectors enable you to connect wires for either relay output or alarm input and then connect them to the unit. Figure 12: Spring Clamp Terminal Block To connect a wire to the spring clamp terminal block Strip the insulation form the end of each wire that is to be connected to the terminal... -
Page 32: Solo Setup Window
trk100/trk100d/trk200 Installation Manual A.3. Solo Setup Window The Solo Setup function enables you to install and setup a camera without requiring another person’s assistance. To perform a Solo Setup Open the Setup > Analytics > Depth window. The following screen is displayed: Figure 14: Solo Setup Window Open the Solo Setup tab. - Page 33 Appendix Select a folder where to store the clip. Recording starts when the folder is selected. Walk through various locations across the vertical axis of the camera’s field of view in order to place ground and height markers and guidelines in the clip. Press Stop Recording Proceed to the tab for Step 1: Ground &...
-
Page 34: Troubleshooting
trk100/trk100d/trk200 Installation Manual A.4. Troubleshooting This section provides useful information and remedies for common situations where problems may be encountered. Problem Possible Solution No network connection Hardware issues: Check that the network is working and the unit is powered ... - Page 35 Appendix Problem Possible Solution Bad output video Check the source video signal quality by connecting an quality analog monitor to the video source. If video quality is acceptable, connect the video source to the unit. Check that the cables are connected securely. This includes junction boxes and amplifier that may be used.
- Page 36 trk100/trk100d/trk200 Installation Manual Problem Possible Solution Relay outputs are not Check the unit settings to confirm that the relay output is working enabled. Refer to the HTML Edition Units User’s Guide for details. Check that a proper rule for activating a relay output has been defined in the unit or activate it manually.
-
Page 37: Contacting Dvtel
邮件: info@dvtel.com To request the latest versions of firmware and software or to download other product-related documents, visit http://www.dvtel.com/support. If you have obtained a login, go to our support gateway. For assistance, email us at support@dvtel.com or phone 1-888-DVTEL77.
