Page 1 X60 Series Operator's Manual SECTION ORIGINAL INSTRUCTIONS CONTENTS Valid for the following tractor mod- TRACTOR IDENTIFICATION INTRODUCTION, GUARANTEE els with cab X60.20 SAFETY NOTES X60.30 X60.40 X60.50 COMMANDS INSTRUMENTS AND PROGRAMMING OPERATION TYRES, WHEELS, BALLASTING REGULAR SERVICE INTERVALS ELECTRICAL SYSTEM...
Page 2 This manual was compiled in compliance with the the ISO 3600 standards and the here contained instructions comply the requirements of the Machinery Directive 2006/42/EC and Directive 2010/52/EC in force in the Euro- pean Community. For tractors sold or used outside the European Community, local laws will prevail. Main protections on the tractors discussed in this manual.
Page 3 Contents Table of contents Page n. Section 1 Contents ....................3 Tractor identification ................6 Introduction ..................... 7 Warranty, pre-delivery inspections and installation ........ 7 Warranty claim ..................7 Spare parts warning ................8 If you move ....................8 Post-warranty service ................8 Safety ....................... 8 Section 2 Safety Notes .................... 9 Regular use ....................9 Safety alert symbols and terms ............
Page 4 Contents Table of contents Page n. Section 4 Instruments and programming ............. 61 Instrument cluster ................. 62 Warning lamps ..................63 LCD display ................... 64 Menu display ..................65 Accessory menu ..................78 Clock settings ..................89 Section 5 Operation ....................91 General Operation ................. 92 Before starting the engine ..............92 Run-in procedure ................... 92 Starting procedure ................. 93 Cold temperature operation ..............
Page 5 Contents Table of contents Page n. Section 7 Maintenance ..................167 Recommendations before you service ..........168 Service access ..................169 Lubricants and fuel chart ..............171 Service/hour meter ................172 Service indicator lamps and gauges ........... 173 First service operations ............... 173 Routine maintenance guide ............... 174 10 hours or daily service ..............176 Maintenance, after 50 hours ............... 181 Maintenance, after 100 hours ............. 186 Maintenance, after 250 hours ............. 194 Maintenance, after 500 hours ............. 199 Maintenance, after 1000 hours ............208 Maintenance, after 2000 hours ............
Page 6: Tractor Identification
Tractor identification Machine identification data Tractor identification number The tractor and its main components are identified The vehicle identification number is punched both on by serial numbers and/or manufacturing codes. Here the data plate and on the right-hand front side of the under the positions of the various identification data weight frame. (2) are illustrated. (Fig.1-3) Tractor identification data NOTE: Identification data should be communicated to your The engine has its own serial number stamped on the Dealer for requests of spare parts or service.
Page 7 Introduction INTRODUCTION Also compliance with and strict adherence to the opera- tion service and maintenance conditions specified by the Manufacturer are substantial part of the intended use. NOTE: This manual is distributed with tractors all over the world. The equipment indicated as standard or If the tractor must be used in very heavy-duty conditions optional may vary according to the country where the (e.g. deep water or extremely muddy soils), you should ask tractor operates. Please ask your Dealer for full details of your Dealer for specific instructions, to avoid invalidating the equipment available in your country.
Page 8 Introduction POST-WARRANTY SERVICE WARRANTY CLAIM A correct installation, followed by a regular maintenance, During the warranty period it is advisable to let your Dealer can do much to prevent malfunctions or breakdowns. If perform every repair and servicing. In this way the Dealer is able to keep under control operation and performances operation problems should be however encountered du- ring the warranty period, the warranty should be claimed of your new tractor. with the following procedure. In order to obtain the best performances from your tractor, The Dealer by whom you purchased the tractor should it is important to go on with regular checks and servicing be promptly informed, stating model and serial number. even after the warranty is expired. Make use of your local It is most important that there should be no delay, and Dealer for all major tractor services: a trained engineer will spot any problems between one service and the next. you should realise that, even where the original failure is covered by warranty, if the failure is not repaired imme- diately, warranty cover may not apply. Our engineers are regularly trained and updated on the product, servicing techniques and the use of modern You should give your Dealer as many information as service tools and diagnostic equipment. They receive regular Service Bulletins, have all Workshop Manuals and possible, for instance work hours, current type of work...
Page 9 Safety notes Chapter 2 Safety notes REGULAR USE This is an agricultural tractor, whose function consists essentially in traction power. It is therefore specially designed to push, pull, carry or operate some interchangeable implements for agricultural purpose, or to tow agricultural trailers. This machine must be driven and operated by an operator suitably instructed, firmly seated and wearing a fastened seat belt. This machine is NOT designed: - To be driven or operated standing or from outside the cab or the operator’s seat, or without a fastened seat belt. - To lift persons. - To transport persons, within or outside the cab or the operator’s seat, in any condition (work or road transport). - To be used in hazardous atmosphere. - To be used in forestry. - To be equipped with front loaders if the tractor is not provided with a suitable structure to protect the operator’s seat from falling and projected objects. More basic rules - Keep the cab doors closed while the machine is being used. - The machine must be used only by a skilled operator who knows perfectly controls and driving technique. - External controls of hitch and electro-hydraulic power take-off (if equipped) must be operated standing on one side outside the tractor and keeping oneself out of the overall width of mudguards. It is expressly forbidden to operate the controls from the rear of the tractor or standing on the inner side of wheels. - Before any operations, carefully analyze all risks and check that the user is skilled enough to safely operate the machine. WARNING: Improper use of the machine, specially on rough terrain or slopes, can make it tilt over. Pay particular attention in case of rain, snow, ice or anyway on slippery ground.
Page 10 Safety notes SAFETY ALERT SYMBOLS AND TERMS This safety symbol means WARNING! BEWARE! YOUR SAFETY IS IN DANGER! This alert symbol draws your attention on important warnings on the implement, in the manual or anywhere else. Pay great attention whenever you see this symbol: there is a great danger of serious or deadly injuries. Follow the instruc- tions given in the warning. WHY IS SAFETY IMPORTANT FOR YOU? « ACCIDENTS CAN MAIM and KILL « « ACCIDENTS COST A HIGH PRICE « « ACCIDENTS can be AVOIDED « SAFETY - TRACTOR AND IMPLEMENT [4.2.a] •...
Page 11 Safety notes SAFETY - FOLLOWING A SAFETY Keep in mind that this safety section is written only for this type of machine. Practice all other usual and customary PROGRAM safe working precautions, and above all - REMEMBER - Safe use of the tractor SAFETY IS YOUR RESPONSIBILITY. YOU CAN PREVENT Only qualified and authorized operators are able to use SERIOUS INJURY OR DEATH. farming tractors in safety. To be qualified you must under- stand the written instructions supplied in this Operator SAFETY - DANGER, WARNING AND Instruction Book, have training in the work area, and know the safety rules and regulations for the job. CAUTION Some regulations stat, for instance, that no one younger Whenever you see the words and symbols shown below, than 18 may use machines with engines (according to used in this book and on decals, you MUST take note of European directives). Tractors are such machines. It is their instructions as they relate to personal safety.
Page 12 Safety notes SAFETY - CAB [4.1.q][4.1.o] The safety cab is designed on purpose for this tractor series and complies with all law requirements concerning safety and noise level. (Fig.2-1) The safety cab complies with international safety stan- dards prescribed by laws in force. It must NEVER be drilled or modified in order to install accessories or implements. The cab components MUST NOT be welded, nor repaired if damaged. Never attach tow chains or ropes to the cab main frame. DE LUXE CAB WARNING: Tractors equipped with De Luxe cab have a protection (FOPS) against objects and loads that might fall from above in typi- Fig.2-1...
Page 13 Safety notes PRECAUTIONS FOR WORKING IN SAFETY Protect yourself NEVER take any risks. Wear all protective clothing and any personal protection devices called for by the work conditions. (Fig. 2-3). The following personal safety devices are always necessary: - Hearing protection. - Safety shoes. WARNING: the tractor is not protected against dangerous matters and emissions.
Page 14 Safety notes Know your equipment Know your tractor. Know how to operate all equipment on your machine and the implements and attachments used with it. Know the purpose of all the controls, gauges and dials. Know the rated load capacity, speed range, braking and steering characteristics, turning radius, and operating clearances. Keep in mind that rain, snow, ice, loose gravel, soft ground, etc. can change the way your tractor operates.. Under poor conditions, slow down and be extra careful, engage four-wheel drive, if fitted. Study the DANGER, WARNING or CAUTION safety Fig.2-6 signs on your tractor and the information signs also.
Page 15 Safety notes Check the equipment WARNING: Diesel fuel or hydraulic fluid un- Before you begin your working day, take time to check der pressure can pierce the skin or eyes and your tractor and ensure that all systems are in good ope- cause serious personal injury, blindness or rational condition. death. Fluid leaks under pressure may not be visible. Use a piece of cardboard or wood to find leaks.
Page 16 Safety notes Clean the tractor WARNING: Hot parts of the machine are suita- • bly guarded, wherever possible. This does not Keep work surfaces and engine compartments clean. exclude, however, that great care should be • Before cleaning the machine, always lower imple- used when working on the machine, to avoid ments to the ground, engage the first gear, engage burns or scalding.
Page 17 Safety notes If the tractor must be lifted for servicing, take it to a sui- tably equipped workshop. Carry out the following operations before any operation about the tractor: engage the four-wheel drive, the first gear and the parking brake and put chocks to the wheels touching the ground. Before lifting the tractor, avoid its swinging by means of wooden wedges applied to the front axle (Fig.2-9b): the chocks must avoid any swinging of the tractor. Use jack lifts of suitable capacity and apply them at the centre of the front and rear axles (Fig. 2-9b and Fig.2-9c) paying due attention to weight distribution. [4.1.k] No decals for the lifting point are applied on the tractor, as they would be too difficult to apply in the available spaces and would be all too easily removed or effaced during normal operation of the tractor. Apply the jack lift to the Fig.2-9b lifting points (Fig. 2-10a ) according to the type of operation and following the safety procedures given before. WARNING: DO NOT raise the tractor using the tow hook.
Page 18 Safety notes Safety at starting [4.1.c] WARNING: Make sure that there is enough ventilation before starting the engine. Never start the engine in an enclosed space. Exhaust fumes may cause asphyxiation (Fig.2-10b). Make sure that the tractor dual brake pedals are locked together at all times unless you are making turns in the field which require independent use of the brakes. Make sure the brakes are properly adjusted so that both brakes engage at the same time. Adjust the seat and fasten your seat belt (if applicable, Fig.2-10b according the description in this book), Always start the engine from the operator’s seat, after depressing the clutch pedal, with all the transmission levers and PTO and auxiliary spool valve control levers...
Page 19 Safety notes DIRECTIONS TO AVOID IMPROPER USE OF THE TRACTOR WORKING IN SAFETY Do not start the tractor without ensuring a perfect com- mand of speed and steering controls (Fig.2-14). WARNING: An unbalanced tractor could over- turn and cause injury or death. If required, put ballast weights on their front support and on rear wheels as described in this section of the Operation chapter.
Page 20 Safety notes Beware of other people • Think about what you are going to do. N e v e r a l - low persons that are not qualified or suitably skilled to operate your tractor. They could be a danger for themselves or for others. WARNING: Your tractor is designed to be ope- rated by one person. DO NOT allow others to ride on the tractor or the implement (Fig.2- 16).
Page 21 Safety notes Risk of overturning For your safety, tractors must be equipped with original safety belts (Fig.2-18). In case of overturning, hold firmly the steering wheel e DO NOT try to get off the seat until the tractor has come to a stop. If the doors are locked, leave the tractor through the duly indicated emergency exits (Fig.2-18). IMPORTANT: The safe working practices listed here- under concerns only a few cases of overturning risk. The list is therefore NOT comprehensive of all possible cases. [4.1.m] To avoid side overturns •...
Page 22 Safety notes • Avoid crossing steep slopes if possible. If you must do so, avoid any holes or depressions on the downhill side. Avoid any stumps, rocks, bumps or raised areas on the uphill side. When operating near ditches or banks, always keep your tractor behind the shear line (A, Fig.2-22). Avoid ditches, embankments and river banks which might cave in (Fig.2-21). Fig.2-21 Fig.2-22 • If you need cross a steep slope, do not steer uphill, but slow down and take a wide turn. Always drive straight up or down a slope, never across it. When travelling up or down a slope, keep the heavy end of the tractor and the implement pointed uphill. (Fig.2-23) •...
Page 23 Safety notes To avoid rear overturns WARNING: Hitching to the rear axle, or any other point above the swinging drawbar, can cause a rear overturn. • DO NOT pull anything using the top link connection, or from any point above the centre line of the rear axle. Always use an approved drawbar, and only use a drawbar pin that locks into place. •...
Page 24 Safety notes • Start slowly and increase your speed gradually. DO NOT rev the engine or drop the clutch. If the tractor is attached to a heavy load, or immovable object, improper clutching may cause overturn (Fig.2-30 and 2-31). • If the front part of the tractor begins lifting, disengage the clutch at once (Fig.2-29). • If your tractor is bogged down in mud or frozen to the ground, DO NOT attempt to drive forwards. The tractor can spin around its rear wheels and overturn (Fig.2-29). Lift any attached implement and attempt to BACK OUT. If this is not possible, tow it out with another vehicle.
Page 25 Safety notes General operating hazards [4.2.e][4.2.b] • Ensure that the PTO shield (1) is in place and that the cap (2) is fitted when the PTO driveline is not in use (Fig. 2-32). • Before connecting, disconnecting, cleaning or adjusting implements driven by the power take-off, disengage the PTO, turn the engine off, remove the ignition key and make sure that the PTO shaft is at standstill (Fig.2-33). • Ensure that all the PTO driveline guards are in place and observe all safety signs (Fig. 2-33). • Make sure that everyone stands clear of the tractor before engaging the PTO. During stationary use of your tractor, always shift the gear lever, the reverse...
Page 26 Safety notes Implements and attachments [4.5.1.1] WARNING: Use exclusively front loader ap- proved by the tractor’s manufacturer, with CE mark and parallelogram type. The installation and modification of the tractor must be car- ried out with the highest technical standards by specialised workshops with qualified personnel.
Page 27 Safety notes • Check for correct coupling between tow hook and trailer. See the Towing Attachments chapter. • Use ballast weight as recommended. NEVER add more ballast to compensate a higher load than allowed. Reduce load. • Only North American markets. A safety chain will help control drawn equipment should it be acciden- tally separated from the drawbar while transporting. Using the proper adaptor parts, attach the chain to the tractor drawbar support or other specified anchor location. Provide only enough slack in the chain to permit turning. See your Dealer for a chain with a...
Page 28 Safety notes • Wait for traffic to clear before entering a public road. • Beware of blind intersections. Slow down until you have a clear view. • DO NOT attempt to pass at any intersection. • Slow down for turns and curves. • Make wide, gentle turns. • Signal your intent to slow, stop or turn. • Shift to a lower gear before going up or downhill. (Fig.2-40) •...
Page 29 Safety notes Further notes On loose soil, wheel slip can exceed 12%. If wheel slip is found to be greater than this amount, The following notes are designed to complete the Opera- proceed with care as operating conditions might tion and Maintenance Manual to ensure that your tractor quickly become unstable and cause early tyre wear. always works safely, reliably and efficiently. In certain conditions, it might be better to add ballast in order to reduce wheel slip, but this increases the Tractors are mainly designed for hitching implements that workload of the transmission and thus reduces the are held by a drawbar or three-point linkage or for driving working life of the tractor. implements using the PTO. Read the operation handbook or ask your Dealer who will be able to help you ascertain the maximum ballast To obtain the greatest possible towing force, particularly weight you can use in normal working conditions. when using a tractor with dual rear wheels, you should observe the following rules concerning axle loads and Using dual wheels or wider tyres, the tractor will have wheel slip.
Page 30 Safety notes Economy PTO. Operating a dry-disc clutch. As shown in the Operation and Maintenance Manual, Most tractors with a manual gearshift are equipped the economy PTO on large tractors is a feature that with a dry-disc clutch for changing gear. makes it possible to use the PTO at standard speed using lower engine RPM rates. Since the clutch slips every time the gear is changed, it can cause a certain amount of wear and thus cre- This feature can only be used when the implements ate heat. To ensure long life for the clutch, it is thus powered by the PTO are to be used only for light advisable to reduce the load of the tractor and reduce operations, such as for sprinklers or rakes, which engine speed when starting up the tractor from a require less than 30 H.P .
Page 31 Safety notes Risks deriving from exposure to Other effects Noise does not just determine aural sensation. For levels noise exceeding* 70 dBA, it causes stress by means of the Noise characteristics and measurement cerebral integration centers and determines a specific Noise is a pressure variation in an elastic medium, gener- neurovegetative reaction responsible for effects that lead ally the air, produced by the vibration of a material body to cardiocirculatory and gastroenteric diseases. (source) that determines an undesired and often annoy- Amongst these, it is worthwhile noting: an increase in ing acoustic sensation. Noise is mainly characterized by: •...
Page 32 Safety notes POSITIONS OF THE SAFETY DECALS All markets (North America excluded) WARNING: Decals must be always readable. Failing this, ask your Dealer for new ones. Fig.2-43 Position on tractors with cab DECAL 1 DECAL 3 WARNING: Very hot surfaces. The hands and fingers could be WARNING: Danger of entangle- scorched.
Page 33 Safety notes Decal 10 DECAL 5 WARNING: General warning. Turn off DANGER: Risk of the engine and remove the ignition being crushed. DO key before any servicing operations NOT short across and before getting off the machine for starter terminals any reason.
Page 34 Safety notes DECAL 20 DECAL 15 WARNING: Risk DANGER: Risk of entanglement. of damage to the Keep clear of rotating shafts. Be tractor compo- careful NOT to get caught up by nents. (In particular, the cardan shaft of the PTO drive- the circuit of the line.
Page 35 Safety notes Decal 25 WARNING: Danger of liquid under pressure being ejected from hydraulic circuits. Decal 23 WARNING: Use individual protections during work, such as overalls, heavy duty gloves and safety foo- twear. Decal 26 WARNING: Emergency exit indication. Decal 24 [4.1.p][4.5.3] WARNING: Tractors with cab have no protection against harmful substances and dusts (protection level...
Page 36 Safety Notes POSITIONS OF THE SAFETY DECALS (North American Tractors) WARNING: Decals must be always readable. Failing this, ask your Dealer for new ones. DECAL 2 DECAL 1 WARNING WARNING Keep your hands well Warning: Very hot sur- clear of the fan blades faces.
Page 37 Safety Notes DECAL 8 DANGER WARNING Choose a suitable PTO Serious personal injury speed for the use of the Start only from seat or machine damage with transmission and may result from over- implement. speed of PTO driven PTO in neutral. equipment.
Page 38 Safety Notes DECAL 15 CAUTION WARNING WARNING: Consult the opera- tion and maintenance manual Personal injury could result from PTO driveline separation. for information about safety and 1. Drawbar supplied provides standard distance “A”. Do not change. how to use the tractor. SHAFT SIZE DISTANCE “A”...
Page 39 Controls - Cab Section 3 Controls - Cab...
Page 40 Controls - Cab TRACTOR ACCESS [4.1.e] WARNING: Do not jump on or off the tractor. Cab Door Lock It may cause injuries. Always face the tractor, use the hand rails and steps, and get on or The ignition key is also used to lock or unlock the cab off slowly.
Page 41 Controls - Cab Operator present sensor The seat cushion acts as a switch. The moment no load is sensed (the operator’s own weight) an alarm sounds. WARNING: To warn the operator of incorrect usage, the tractor has an automatic alarm system that sounds when the operator is not correctly seated in driving position while the machine is being used.
Page 42 Controls - Cab SEAT [4.1.a] WARNING: Do not adjust the seat while driving. Loss of control and injury can result. Mechanical suspension seat - Tractors with cab NOTE: The standard mechanical seat is offered as option for ROPS (footstep) tractors with waterproof cover. 4. WEIGHT ADJUSTMENT CONTROL AND WEIGHT 1. FORE/AFT ADJUSTMENT CONTROL - INDICATOR - Without the operator in the seat, turn the...
Page 43 Controls - Cab 5. ARMRESTS - Raise or lower armrests. 9. CUSHION TILT ADJUSTMENT (Deluxe seat only) - Lift lever to adjust seat cushion tilt angle. 6. BACK REST REMOVAL/HEIGHT ADJUSTMENT (if equipped) - Raise or lower the back rest to the required 10. CUSHION FORE/AFT ADJUSTMENT (Deluxe seat height. Pull up past end stop to remove the back rest. only) - Lift lever to adjust seat cushion depth. 7. LUMBAR ADJUSTMENT CONTROL - Turn the adjust- ment knob as required. 8. SWIVEL ADJUSTMENT CONTROL (only Deluxe seat) - Lift the lever to adjust the seat as required. NOTE: There is no fore/aft adjustment in the offset posi- tions.
Page 44 Controls - Cab Air suspension seat - Tractors with cab 5. HEIGHT & WEIGHT ADJUSTMENT CONTROL - Lift and 1. FORE/AFT ADJUSTMENT CONTROL - Lift lever and release for automatic weight adjustment. Lift and hold to adjust seat as required, release lever to lock in position. raise, or push and hold to lower. 2. ARMRESTS - Raise or lower armrests. NOTE: Seat must be lowered before the automatic weight adjustment can be made. 3. BACK REST ADJUSTMENT CONTROL - Lift control to tilt as required. Release the lever to lock in position. IMPORTANT: Never operate the compressor for longer than 1 minute.
Page 45 Controls - Cab 10. THERMIC SEAT CUSHION (only Super Deluxe seat) (if 7. CUSHION TILT ADJUSTMENT (Deluxe seat only) - Lift lever to adjust seat cushion tilt angle. equipped) - Depress the switch to operate seat heating. Press the switch again to turn the heater OFF . 8. CUSHION FORE/AFT ADJUSTMENT (Deluxe seat only) 11. MANUAL LUMBAR ADJUSTMENT CONTROL - Turn - Lift lever to adjust seat cushion depth. the adjustment knob as required. 9. BACK REST REMOVAL/HEIGHT ADJUSTMENT (if 12. AIR LUMBAR ADJUSTMENT CONTROL (only Deluxe equipped) - Raise or lower the back rest to the required seats) - Operate the switches as required. height. Pull up past end stop to remove the back rest. IMPORTANT: Never operate the compressor for longer than 1 minute.
Page 46: Seat Belt
Controls - Cab Seat Belt Mechanical suspension seat (if equipped) WARNING: Always securely fasten your safety belt. Your tractor is equipped with a ROPS cab for your protection. The seat belt can help insure your safety if it is properly used and maintained.
Page 47 Controls - Cab Passenger Seat Passenger Seat Safety The passenger seat allows a colleague to ride in safety (if equipped). and comfort. IMPORTANT: 1. Children are NOT allowed to use the passenger seat. 2. The left-hand door MUST be closed at all times when- ever the passenger seat is occupied and the tractor is in motion.
Page 48 Controls - Cab STEERING COLUMN ADJUSTMENT WARNING: Do not adjust the steering column while driving. Adjusting the steering column while driving can cause loss of control resulting in injury or death. Column Tilt Adjustment Telescopic Column Adjustment The steering column can be moved in or out at any tilt The steering column can be adjusted up or down as position.
Page 49 Controls - Cab CONTROLS Controls on the dashboard 1. THERMOSTART (COLD START) SWITCH (if equipped) 5. KEY SWITCH - The key switch has four positions as (Only equipped on engines with mechanical injection follows: system) 2. SWITCH FOR UPPER HEAD LIGHTS (if equipped with front hitch) - With the front lamp switch in third position, Off Position - Turn from On/Contact position press the front of the switch down: upper head lamps will anticlockwise to stop the tractor. The key turn on and main head lamps will go off. can only be removed from this position. 3. ROTATING BEACON SWITCH (if equipped) 4. HAZARD WARNING SIGNAL SWITCH Accessory Position - The radio can be operated in this position and some of the cluster displays; this position is also used for programming the digital instrument...
Page 50 Controls - Cab 6. HEAD LAMP SWITCH - Direction Turn Signal, Hi/Low Beam Switch and Horn. Three Position Switch A. First Position - All lamps OFF. TURN SIGNALS: B. Second Position - Front position lamps, tail lamps, li- cense plate lamps and the side console illumination lamp Position 1 = right-hand indicator operated. will illuminate. Also analog cluster illumination lamps will be ON. Position 2 = left-hand indicator operated. C. Third Position - Front side lamps, tail lamps, license NOTE: Self cancelling switch only: The turn signal lamps plate lamps, the side console illumination lamp and main will continue to flash until the steering wheel is turned in head lamps will illuminate.
Page 51 Controls - Cab Highway/Public Road Operation Use of amber hazard warning lights - Comply with road traffic laws, including any speed restrictions and the correct use of Hazard Amber hazard warning are operated by turning the main Warning Lamps and SMV Symbol. light switch clockwise to the 1st and 2nd position. - Connect the brake pedals together with the brake pedal interlock. This will ensure uniform braking and maximum stopping ability. - Check clearance before going under electric power lines, bridges etc.
Page 52 Controls - Cab Tractor Warning Lamp Usage - Rest Rotating Beacon Of World Tractors (if equipped). - The rotating amber beacon must be used according to The flashing amber warning lamps must be used ac- cording to road traffic laws. local road traffic laws. The rotating amber beacon is operated by pressing the The amber warning lamps are used to indicate a hazard switch (2) with the flashing beacon symbol. to other road users. To operate, press the switch (1) as shown above. ALL the amber warning lamps will flash ON and OFF. Slow Moving Vehicle (SMV) Symbol (if equipped).
Page 53 Controls - Cab Forward/Neutral/Reverse switch Pedal Controls 1. CLUTCH PEDAL - Used to temporarily disengage drive. POWERSHUTTLE GEARBOX (XTRASHIFT TRACTORS) Gradually and completely releasing the clutch pedal for a controlled smooth start and gear changes. Use the Forward/Neutral/Reverse (F/N/R) shuttle lever to 2. THROTTLE PEDAL change direction of travel. 3. BRAKE PEDALS - The left brake pedal stops the left rear wheel and the right brake pedal stops the right rear wheel. When using the tractor in the field, the pedals may Position 1=Forward be used independently to make turns easier. When driving on roads, the pedals MUST be locked together. WARNING: Extra weight and bad traction conditions, such as mud or ice, increase your NEUTRAL - Neutral stopping distance.
Page 54 Controls - Cab CONTROLS ON RIGHT-HAND PANEL 13. FRONT LOADER CONTROL LEVER (if provided) Refer to the loader manual or to your dealer for informa- tion about correct use of the loader. 1. UP/DOWN SWITCH, HITCH 2. FOUR-WHEEL DRIVE (if equipped) 3. DIFFERENTIAL LOCK SWITCH CONTROLS ON LOWER RIGHT- HAND PANEL NOTE:NEVER use four-wheel drive for light work or when driving the tractor on public roads. WARNING: Tractors equipped with four-wheel drive (4WD) have a better drive and can cope with steeper slopes.
Page 55: Park Brake
Controls - Cab Park brake 1. HITCH CONTROLLER 1. PARK BRAKE LEVER 2. PARK BRAKE BUTTON 3. PARK-LOCK ENGAGEMENT LEVER (optional) The park brake (1) is located at the LH side of the opera- tors seat. Pull the lever fully up to engage the park brake. If you set the tractor in motion, release the parking brake after putting the tractor in neutral (see note). Press the button (2) on the end of the lever, then lower the lever to release the brake. When the parking brake is engaged, the warning lamp on the instrument cluster will illuminate when the key switch is turned to ON. The master warning lamp will flash when A. HITCH DROP RATE CONTROL KNOB. the engine is started. B. HITCH MAX. LIFT CONTROL KNOB. See hitch description in this manual. The lamps will go off when the brake is disengaged. 2. 2-3 SPEED REAR PTO LEVER NOTE: When a gear is engaged (1, 2, 3, 4) with the en- 3. THREE-WAY SOCKET gine running and the parking brake angaged, an audible 4. CIGARETTE LIGHTER alarm will sound.
Page 56 Controls - Cab All non-metallic components within the cab comply with the ISO 3795 standard. The cab is approved according to OECD codes concerning ROPS test (protection against overturning) and safety belts. The cab is made of steel sections and is fastened to the tractor by means of a double system of rubber dampers (silent block) protecting the driver's seat both from vibrations and from engine noise. The noise peak is therefore limited to low values, for more comfort for...
Page 57 Controls - Cab Heating, air circulation and air con- ditioning in De Luxe cab [4.1.b] 1 - Air conditioning switch: - Press to turn air conditioning on. - Press the switch again to turn it off. 2 - Temperature control knob A - Warm air B - Cold air 3 - Fan speed switch 0 - OFF I - Slow 2 - Middle 3 - Fast Ventilation The cab ventilation is operated by means of 6 air vents.
Page 58 Controls - Cab ADJUSTMENTS WITHIN CAB [4.1.b] (De Luxe) Cab cooling from the outside Pressurized cab (dusty or windy environment) - Turn the fan control on the required position, from (I) for minimum cooling to (III) for maximum cooling. WARNING: Cab air filters remove dust in the air, but are not capable of removing chemi- - Open all air vents. cals used in spraying crops or in weed con- trol.
Page 59 Controls - Cab Operation of air conditioning unit Internal Mirror (If provided) To operate the air conditioner, the blower must be on. The blower speed, temperature control and all vents must be adjusted to obtain the best cooling for the ambient temperature and dust conditions. Under normal operating conditions, and with the windows and doors closed, tem- peratures in the cab of 6°C to 15°C (10°F to 25°F) less than the ambient temperature will occur. When operating the air conditioner system, the moisture level is decreased. NOTE: During cold weather, with ambient temperature above 0°C (-32°F), operate the air conditioner at least once per month, for a period of 10 to 15 minutes.
Page 60 Controls - Cab MISCELLANEOUS 1 - Quick couplings of the "Push-Pull" type for auxiliary spool valves for remote controls. 2 - Window washer liquid reservoir. 3 - Oil spillage collector. Oil union for hydraulic trailer brakes 4 - (optional, depending on markets). 5 - Trailer air brake unions (optional, depending on markets). 6 - Rear 7-pin power socket for trailer.
Page 61 Instruments and Programming Section 4 Instruments and Programming...
Page 62 Instruments and Programming Instrument Cluster 1. FUEL LEVEL GAUGE 7. WARNING LAMPS - see following pages for more details. 2. LOW FUEL WARNING LAMP 8. MAIN DIGITAL DISPLAY - see following pages for more 3. AIR PRESSURE GAUGE or LOGO (if provided) - Indicates details. system pressure for pneumatic trailer brakes. 9. ENGINE REV COUNTER 4. RED WARNING LIGHT - LOW SYSTEM PRESSURE FOR PNEUMATIC TRAILER BRAKES 10. ADJUSTMENT PUSH BUTTONS - To go to MENUS and Functions in the digital display. 5. ENGINE COOLANT TEMPERATURE GAUGE UP - Upward arrow DOWN - Downward arrow - Blue area: low temperature. MENU - Book icon - Yellow area: normal operating temperature. - Red area: overheating.
Page 63: Indicator Lamps
Instruments and Programming Indicator Lamps Warning lamps LCD Icons Hydraulic filter clogging, red. 27 Creeper engaged Warning light for low pressure in transmission 28 Radar present (not available) hydraulic circuit, red. 29 Water detected in fuel (if provided). Drain fuel Battery charge, red. filter. Engine fault warning, yellow. Ask your Dealer's 30 Service interval indicator. Service the tractor. workshop for help. 31 Heater - Wait-to-start. Low engine oil pressure, red. Electronic engine - Wait for the lamp to go off before (Not valid) Low level of DEF (Diesel Emission starting the engine. Fluid), yellow. Mechanical engine - To operate the heater, press the (Not used) Low oil level in hydraulic trailer brake heater button that activates the lamp. The lamp is circuit, red. controlled by a timer: as soon as it goes off, release 4WD engaged, yellow. the button and start the engine. Differential lock engaged, yellow. 32 Forward speed indicator. 10 Parking brake engaged, red.
Page 64 Instruments and Programming LCD Display Layout 1. Engine rev counter 2. Hitch position up/down and lift percentage amount. 3. Indicator for gear engaged and reverse shuttle lever in neutral. 4. Drive direction indicator 5. Indicator for speed in kph or mph If the following figure is displayed at ignition, the speed indicator is not provided: ask your dealer. 6. Speed and PTO function display. 7. Menu Display 8. Clock...
Page 65 Instruments and Programming Display MENU The menu system for the cluster is operated by using the three buttons on the left-hand panel. DOWN MENU The menu system is divided into 2 parts: 1-Operating menu Accessed by using the UP/DOWN arrows when the key is on. 2-Accessories Menu Is shown automatically when the key is turned to the Accessory position. 1.1 Operating menu When the ignition is on, either with or without the engine running the Working Menu can be cycled through by using the UP and DOWN buttons. After key-on the cluster will always default to the PTO/hours screen. As soon as Engine speed goes above 500 RPM for more than 2 seconds, the display will show the last selected working menu option before previous key off. The diagram below shows the menu path when using the DOWN button, if UP is pushed the direction is reversed. NOTE: Count of worked area is active only if the engine is running and implement width is set on a value different from “0”. 1) Power take-off / hours 2) Worked area 3) Distance...
Page 66 Instruments and Programming 1.1.1 PTO/Hour Display The screen shows: Time - 13:24 Total hours accumulated by the tractor - 1262.3 PTO mode currently selected - 540 Rear PTO RPM - 0 The arrow indicates the PTO menu is active. Use: The following combination of screens can be displayed: Rear Power Take-Off These screenshots are self-configured according to the PTO type present and to the selected PTO. The screenshots display the rear PTO speed of 540, 540E and 1000. Front Power Take-Off While inside the PTO menu (as indicated by the arrow on the right-hand side), the operator may use the MENU button to scroll the values of front and rear PTO speed. Rear power take-off overspeed - 540/540E: When the PTO shaft revolves faster than 630 RPM, the yellow PTO lamp on the instrument lights up and the buzzer sounds. - 1000: When the PTO shaft revolves faster than 1170 RPM, the yellow PTO lamp on the instrument lights up and the buzzer sounds. Reduce the engine rated speed to reduce the rear PTO shaft speed. Front power take-off overspeed -1000: The front PTO speed value and the front PTO symbol blink on the display. Reduce the engine rated speed to reduce the front PTO shaft speed.
Page 67 Instruments and Programming Rear Power Take-Off [4.2.d] According to the PTO on board, the display will show the following: This display will be configured as follows: 1 - Rear/front PTO selected The selected PTO display indicates that the LCD is showing whether the front or rear PTO was engaged. The MENU button displays one of these indications. 2 - Arrow indicating the PTO/hour menu is selected. The arrow indicates that in this moment the functions of the PTO/hours menu are selected for display. By means of the UP and DOWN buttons the operator can scroll the different MENU options and the arrow indicates which view has been selected. 3 - PTO instantaneous speed - RPM Indicates the actual speed of the engaged PTO. If the PTO is not engaged, the display shows "0". If when the PTO is dis- engaged a value different from "0" is shown, that means a dragging effect is present. Ask your Dealer's workshop for help. 4 - PTO speed selected The “PTO speed selected” display indicates 540 or 540E or 1000 (or 1000E, if applicable) according to tractor configuration and to the PTO speed that is selected by the speed selector lever. Front Pto - Ignition key ON. The front PTO can be displayed in the lower area of the left-hand LCD (select PTO display by the up/ down arrows and press the MENU button). The display shows the front PTO speed, as calculated from engine speed rate with gear engaged in the factory setting. If the front PTO is not active, the display reads 0. If the front PTO is engaged, the value of the rev speed rate is shown on the LCD screen. When the key is switched to OFF, the front PTO view is cancelled, and when the key is switched to ON, the procedure starts again at the first start of the front PTO. WORK HOURS The display shows the actual hours worked by the tractor. The count is only active when the engine is running. The value displayed ranges from 0.0 to 9999.9. When the maximum value is reached, the displayed value ranges from 10000 to 60000. When 60000 is reached, the count will stop.
Page 68 Instruments and Programming 1.1.2 Area worked If the down button is pushed the Area Worked menu is selected: The screen shows: Time - 13:24 Area units selected - Acres Area worked - 28.3 Acres PTO mode currently selected - 1000 Rear PTO RPM - 0 The arrow indicates the Area menu is selected. If the counter is operating, this arrow will flash when the menu is selected. Each time the menu is selected, the counter will display "AUTO" or "Man" (MANUAL) 2 seconds long before displaying the relative value. The operator is thus informed about the settings actually active. (See selection) Use: - The first screenshot shows the area worked in the units preset in the accessory menu. The units are Acres or Hectares. - One decimal place will be shown until the amount of units reaches 9999.9, at this point the counter will show 10000+. If 99999 is exceeded the counter will reset. - Counter can work in two different modes. Mode selection is available into accessory menu (see Auto Function Settings): Manual Mode: when activated by the operator, the counter counts every time the tractors is moving (if implement width has been previously defined) until the operator stops it. Auto Mode: if implement width has been previously defined, the counter starts and stops to count auto- matically when the tractor is moving and either the hitch is down or the Remote implement switch is on.
Page 69 Instruments and Programming 1.1.3 Distance travelled If the down button is pushed again the Distance Travelled menu is selected: The screen shows: Time - 13:24 Distance units selected - Km Distance travelled/worked - 208.3 Km PTO mode currently selected - 1000 Rear PTO RPM - 0 The arrow indicates the Distance menu is selected. If the counter is operating, this arrow will flash when the menu is selected. Each time the menu is selected, the counter will display "AUTO" or "Man" (MANUAL) 2 seconds long before displaying the relative value. The operator is thus informed about the settings actually active. Use: - The first screen shows the distance travelled/worked in the units preset in the Accessory menu. To indicate a distance shorter than 1 mile/1 km, the display shows the following symbol corresponding to the 5th digit: - One decimal place will be shown until the amount of...
Page 70 Instruments and Programming 1.1.4 Calibration Menu If the down button is pushed again the top level of the Calibration menu is selected: The screen shows: Time - 13:24 Calibration menu selected PTO mode currently selected - 1000 Rear PTO RPM - 0 The arrow indicates the Calibration menu is active. Use: - After the Calibration menu has been selected, by pressing the MENU button the operator can choose which controller to calibrate. The following screen is shown: The instrument cluster is the first default controller to be calibrated. After entering this menu, you may display the calibration state by means of the bottom part on the display that normally shows PTO speed rate. WARNING: The operator may only perform the calibrations quoted in the Opera- tor column in the following table. The operator MAY NOT perform the operations quoted in the column NOT FOR THE OPERATOR.
Page 71 Instruments and Programming NOTE: If the indication " - - - " appears, during calibration selection, in the area of the display where the calibration status is shown, tje selected calibration is not available owing to some problem in the system. Ask your Dealer for help. - If the cluster is already calibrated, the operator can choose another controller by pressing the UP or DOWN buttons.
Page 72 Instruments and Programming 1.1.5.1 ICh Calibration sub-menu, hitch position display This calibration defines the hitch position display. When the LCD shows "ICh" and the PTO display shows "0", the operator has to press the "MENU" button to access the hitch calibration menu. Now the LCD will show "1", i.e. "ready to start". The instrument is waiting for the operator to lower the hitch down to mini- mum height. When the hitch reaches the minimum height, press "MENU" to save the lowest limit of hitch travel, which is stored as "0%". The code "10" is displayed for 2 seconds, followed by the code "11". Now the instrument is waiting for the operator to raise the hitch to its upper limit. Make sure the Upper Limit Control is set to maximum position. When the hitch reaches the maximum height, press "MENU" to save the upper limit of hitch travel, which is stored as "100%". The code "20" is displayed for 2 seconds, followed by the code "50" to show that the calibration was properly performed. Press MENU for longer than 2 seconds to exit Calibration and go to another menu. ICh calibration sequence Calibration index Display PTO Description 0 Calibration mode not accessed 1 Ready to start - waiting for hitch down Hitch lowest limit stored - 0% Waiting for hitch up Hitch upper limit stored - 100% Calibration OK ICh calibration errors Calibration index Display PTO Description 100...
Page 73 Instruments and Programming 1.1.6 Work timer menu If the down button is pushed again the Work Timer menu is selected: The screen shows: Time - 13:24 Work Timer - 0 minutes, 0 seconds PTO mode currently selected - 1000 Rear PTO RPM - 0 The arrow indicates the Work Timer menu is active. Each time the menu is selected, the counter will display "AUTO" or "Man" (MANUAL) 2 seconds long before displaying the relative value. The operator is thus informed about the settings actually active. Use: - When the Timer menu is first entered the display will show the screen above on the right. - The timer will show minutes and seconds up to 99 minutes and 59 seconds. - When the timer reaches 99 minutes and 59 seconds it will automatically change to show hours and minutes, and an ‘h’ will be displayed on the left-hand side. - If the timer is allowed to run continuously to 99 hours and 59 minutes it will reset to 00:00 and then the count will start again.
Page 74 Instruments and Programming - Counter could work in two different modes. Mode selection is available into Accessory menu (see Auto Function Settings): Manual Mode: the timer counts every time the operator activates it until the operator stops it. Auto Mode: the counter starts and stops to count automatically when the hitch is down or the Remote implement switch is on. Auto and Manual mode will increment the same counter value. Counter Activation: - Pushing the MENU button for less than 2 secs starts/stops the Work Timer (only for Manual mode). - P ushing the menu button for longer than 2 seconds when counter is visualized and not active resets the Timer. - If pushed for longer than 2 seconds when active, the counter will stop (only for Manual mode). - If the UP or DOWN arrows are pressed to change the menu function selected when the Timer is active, the count will go on. Note: 1) Only work time function will be activated in manual mode.
Page 75 Instruments and Programming 1.1.7 Error menu When an error is active on the tractor, an exclamation mark will show on the left-hand side of the display. Once activated, the exclamation mark shall stay on 4 seconds at least. In this case, the Error menu can be accessed by pressing DOWN when in the PTO/Hours menu or UP when in the Area Worked menu. When operator enters into Error menu, error codes active in that moment remain frozen until operator exits the menu. It is possible to add new errors, but not to deactivate the errors shown. The screen shows: Time - 13:24 Error menu selected PTO mode currently selected - 1000 Rear PTO RPM - 0 The arrow indicates the Error menu is active. When the Error menu is first entered, the display will show the screen above. The PTO readout is still active. - Pushing the MENU button will enter into the second level of the menu structure. This is a list of the ECUs on the trac- tor and the quantity of errors on each one. The list will only be populated when there is an active error for a particular controller. This will mean the operator does not have to scroll through the whole list to find the error.
Page 76 Instruments and Programming In the example below the Engine has 4 errors: List of controllers Controller Designation Instrument Cluster PTO/Hitch Ehr Transmission Controller The following units, only if mounted on the tractor Engine (if electronic engine) Only with mounted mechanical transmission: PTO control PTO - If the MENU button is pressed again for less than 2 seconds the third level of menu will be selected. This displays the error codes from the selected controller. The controller name is moved to the part of the LCD which usually displays the clock and the SPNs /FMIs are shown below it. - Pressing the UP and DOWN buttons will scroll through all the error codes for the particular controller. - If the MENU button is pressed again for less than 2 seconds the operator may select a different module by scrolling up to level 1. - To exit the Error menu, the operator has to press the MENU button for longer than 2 seconds. This will exit to the first level where the rest of the working menu can be accessed. WARNING: When an operation ERROR is displayed, ask the Dealer's specilized personnel for help indicating the error code.
Page 77 Instruments and Programming 2.1 Accessories Menu If the ignition is turned to the accessory position the accessory menu is shown. Before the menu is shown, the software version of the tractor is shown for 2 seconds after initialisation of the cluster. The image below shows the installed software version. After this the cluster defaults to the first part of the accessory menu. Key: IC= Instument Cluster C= McCormick B = Model Code 0 300 = installed software version...
Page 78 Instruments and Programming The menu structure for the Accessory menu will be as follows: 1) MPH/KPH 2) Acres/Hectars 3) Tyre size 4) Implement width 5) Service timer 6) Engine constant* 7) Rear and front PTO options* 8) Not used 9) Switch detecting gear selector lever in NEUTRAL available* 10) Tractor model code* 11) Previous work hours* 12) Auto functions adjustment* 13) Lighting adjustment 14) Clock setting To scroll the menu, the operator will push the UP or DOWN button. The diagram shows the menu path when using the UP button. If DOWN is pushed, the direction is reversed. * These calibrations are NOT AVAILABLE TO THE OPERATOR. Do not enter these menus. Entering this menus will affect the tractor operation.
Page 79 Instruments and Programming 2.1.1 MPH/KPH The default first part of the accessory menu is used to set the units for Distance Travelled and Vehicle Speed. The units can be Kilometres or Miles. The display section usually reserved to the clock shows "AC", to signify the menu is accessed, and then a number to show the part of the menu currently being viewed. This first screen shows the units currently selected, in the example above this is Miles. Both the Mi for the distance covered and the MPH for vehicle speed are showing on the display. To change to metric units: 1- Press the MENU button 2- The MI and MPH will flash...
Page 80 Instruments and Programming 2.1.2 Acres/Hectars Press the UP button to go to the next menu section, that is used to set the units for the Area Worked. The units can be Acres or Hectares. This first screen will show the units currently selected, in the example above this is Acres. The Ac symbol is showing on the display. To change to Hectares: 1- Press the MENU button 2- The code Ac will flash. 3- Press UP or DOWN to scroll between the options. 4- Now the code HA will flash. 5- To save this new setting press and hold the MENU button for longer than 2 seconds (the symbols will stop flashing) and press the UP and DOWN buttons to access other parts of the menu. - If the key is turned to the off position before the new value is set the old value is used. - Any values saved in the Area Worked memory will be converted to the new units.
Page 81 Instruments and Programming 2.1.3 Tyre size Press the UP button to go to the next menu section, that is used to set tyre size most suitable to your tractor. The units are mm and the Static Loaded Radius of the tyre is used. This first screen will show "0705" as the current setting used as an example. The text tyr is shown at the bottom of the screen. To change the tyre size: 1- Press the MENU button 2- The actual tyre size will flash (e.g. 0705). 3- Press UP or DOWN to scroll in units of 1 from 0300 to 1033 mm. 4- To save this new setting press and hold the MENU button for longer than 2 seconds (the numbers will stop flashing) and press the UP and DOWN buttons to access other parts of the menu. - If the key is turned to the off position before the new value is set the old value is used. - If there is a Distance Travelled value in the memory, it will not be changed when the tyre size is altered. Note: This value can also be modified by dynamic calibration, see the corresponding chapter.
Page 82 Instruments and Programming Rear Tyre Rolling Radius REAR INDEX RADIUS* (mm) TYRES 13.6R28/13.6-28 * IMPORTANT: The rolling radius depends on tyre manu- 14.9R28/14.9-28 facturer, tyre wear, tyre pressure and load. For a more 16.9-28 o 16.9R28 accurate rolling radius dimension, use the Dynamic 14.9R30/14.9-30 Mode procedure.
Page 83 Instruments and Programming 2.1.4 Implement Width Press the UP button to go to the next menu section, that is used to set the implement width. This value is used to along with the distance travelled to calculate the Area Worked. When the cluster is brand new the default value should be 0 = 0,0 centimetres. The width can be set in Feet or Centimetres. This first screen will show the current setting and units, 30.0 Feet in the example. A graphic is shown at the bottom of the screen to symbolise implement width. To change the implement width: 1- Press the MENU button 2- The actual implement width will flash (e.g. 30.0). 3- press UP or DOWN to scroll metric units in divisions of 10 between 0000 and 9990. The range of imperial units will be 0 to 199.5 in divisions of 0.5. If the MENU button is pressed now, you can directly set the unit of measurement as here described. 4- To save this new setting press and hold the MENU button for longer than 2 seconds (the numbers will stop flashing) and press the UP and DOWN buttons to access other parts of the Accessory menu. If the units need to be changed: 1- Press the MENU button 2- The actual implement width will flash. 3- Press the MENU button again and the units will flash. 4- Press UP or DOWN to switch between metric and imperial. F= Feet C= Centimetres If the MENU button is pressed now, you can directly set the width as here described. 4- To save this new setting press and hold the MENU button for longer than 2 seconds (the letter will stop flashing) and press the UP and DOWN buttons to access other parts of the Accessory menu. Note: Press MENU again after stage 3 to return to width adjustment. - If the key is turned to the off position before the new value is set the old value is used.
Page 84 Instruments and Programming 2.1.5 Service timer By pressing the UP button, the Service Timer menu is entered. This is a simple count-down timer that can be set by the operator. In normal operation, when the timer reaches 0 the spanner symbol will show on the right-hand panel of the cluster. When the cluster is brand new the default value should be 0 (inactivated). This first screen will show the time set originally (1000), the time left to run (586) and will also show the hourglass and spanner graphics to indicate which menu is being accessed. To set the Service interval: 1- Press the MENU button 2- The time left to run (586 in the example) will flash. 3- Press UP or DOWN to scroll in units of 1 from 0 to 1999. 4- To save this new setting press and hold the MENU button for longer than 2 seconds (the number will stop flashing) and the new Service Interval will be recorded on the bottom line of the left-hand panel (1000 in the example). Pressing the UP and DOWN buttons will now access other parts of the menu. If the interval is set to 0 the Service timer has been deactivated. - If the key is turned to the off position before the new value is set the old value is used. This is NOT an operator menu. DO NOT press to enter this menu. Normally this menu is programmed at your Dealer's workshop. Enter this menu only if absolutely required to add a specific service operation, Entering this menu might affect the tractor operation.
Page 85 Instruments and Programming 2.1.8 Cab suspension (not avail- 2.1.6 Engine constant Pressing UP again will go to the Engine Constant menu. able) This is a ratio used to calculate the actual engine speed Pressing UP again will go to the Cab Suspension Present from the alternator pulses. menu. The following screen is shown: The following screen is shown: This is NOT an operator menu. DO NOT press to enter this menu. This is NOT an operator menu. DO NOT enter this menu. Entering this menu might affect the tractor operation.
Page 86 Instruments and Programming 2.1.11 Previous work hours 2.1.10 Tractor model code Pressing UP again will go to the Previous Work Hours Pressing UP again will go to the Tractor Model Code menu. menu. This is used in case the instrument cluster should The following screen is shown: be replaced for any reason. The following screen is shown: This is NOT an operator menu. This is NOT an operator menu. DO NOT enter this menu. DO NOT enter this menu.
Page 87 Instruments and Programming 2.1.12 Auto Function Settings Pressing UP again will go to the Auto Function setting menu, to define if area worked, distance travelled or work timer counter needs to be set as manual or auto mode. This means that all these counters will depend from the position of the hitch (automatic) or from the start/stop menu button (manual). When the cluster is brand new, the default value should be Manual for all the functions. The first screen is the following: depending on the current settings of Area worked (Auto/Man). "AFu" means Auto Function. To change the Auto Function Settings: 1- Press the MENU button 2- The arrow below area worked symbol will start to flash. 3- Press UP or DOWN to switch between Area Worked, Distance Travelled and Working Time Counter with arrow still flashing under the relevant symbol. The following screen should appear (depending on current settings - Auto/Man) 4- Once the right sub-menu to be modified has been selected, push Menu button again and the relevant Auto/Man text (depending on current settings saved) will start to flash whilst arrow will go steady on. 5- press UP or DOWN button to change the settings. 6- To save this new setting press the MENU button, the text will stop flashing, the arrow will flash again and you go back to point 3. 7- Pressing the UP and DOWN buttons will now access the other sub-menu of the Accessory menu. 8- Pressing and holding the MENU button longer than 2 seconds, you may in any moment save the current settings and quit the menu. Pressing the UP and DOWN buttons will now access other parts of the Accessory menu. If the key is turned to the OFF position before the new value is set, the old value is used.
Page 88 Instruments and Programming 2.1.13 Screen brightness adjustment Pressing UP again will go to the Screen Brightness menu. By this menu the operator can set the brightness of the lamps and of the LCD when the sidelights are on. The brightness by day cannot be adjusted. The value goes from 1 to 10, where: - 1 means lamp light = 5% and LCD/indicators brightness = 13% of max. capacity. - 10 means lamp light = 45% and LCD/indicators brightness = 53% of max. capacity. The default value is = 5 that means lamp light = 13% and LCD/indicators brightness = 24% of max. capacity. The screenshot is the following, according to the brightness setting. "nbr" indicates brightness adjustment at night. To adjust the brightness: 1- Press the MENU button. 2- The present value will flash. 3- Press UP or DOWN to scroll values from 1 to 10. 4- To save this new setting press and hold the MENU button for longer than 2 seconds (the number will stop flashing) and press the UP and DOWN buttons to access other parts of the Accessory menu. If the key is turned to the OFF position before the new value is set, the old value is used. NOTE: The brightness of indicators, LCD and lamps by day is set on 70% of max. capacity.
Page 89 Instruments and Programming 2.1.14 Clock setting Pressing UP again will enable the operator to set the clock. Pressing DOWN from the AC:1 original screenshot will also reach this section. The clock can also be set to be 12 or 24 hours in this menu. When the cluster is brand new the default values should be 24h and 00:00. This first screen will show the current time (22:48) and whether the clock is set to 12 or 24 hours (24h). The letters CLC will show at the bottom of the left-hand display to inform the operator this is the Clock Setting menu. To change Clock: 1- Press the MENU button 2- The hour digits will flash. 3- Press UP or DOWN to scroll in units of 1 from 00 to 12 or 24. 4- Press the MENU button again to set the hours. 5- The minutes will flash. 6- Press UP or DOWN to scroll in units of 1 from 00 to 59. 7- Press the MENU button again to set the clock on 12 or 24 hours. 8- The text in the middle line will flash. 9- Press UP or DOWN to switch between 12h or 24h. 10-At this point the time can be saved and the menu exited by pressing and holding the MENU button for longer than 2 seconds (the digits will stop flashing), then press the UP and DOWN buttons to access other parts of the Acces- sory menu. If the key is turned to the off position before the new time is set the old value is used.
Page 90 Instruments and Programming This page has been left blank intentionally...
Page 91 Operation Section 5 Operation...
Page 92 Operation GENERAL OPERATION Before Starting The Engine Start - Important recommendations WARNING: Before starting the engine, be sure Starting all operating controls are in neutral and the park brake is engaged. This will eliminate ac- WARNING: Carefully read the starting instruc- cidental movement of the machine or start up tions before starting the tractor. of power driven equipment. WARNING: Always take into account the use of the machine and the work place. Take every WARNING: Never run the engine in a closed precaution, specially if there is a high risk of building. Proper ventilation is required under fire. all circumstances. WARNING: DO NOT start the tractor from the Do the following checks before starting the tractor for ground. Always start the tractor only from the the first time. operator’s seat. 1. Make sure all persons that operate or do mainte- WARNING: DO NOT start the tractor if the bon- nance on the tractor understand that clean fuel is net is open or the guards are removed.
Page 93 Operation STARTING PROCEDURE [4.1.c] OPERATION 3 WARNING: The engine may be started only in the conditions given here under. If this fails to occur, have the tractor repaired by your Dealer or authorized service centre. WARNING: On electrically operated 4WD trac- tors, the 4WD clutch is spring loaded into en- gagement and relies on hydraulic pressure for disengagement. A failure in the 4WD hydraulic system will therefore automatically engage the 4WD even though the 4WD switch is in the disengaged position. This is a built in safety feature. DO NOT operate 4WD tractor transmis- sions with the rear wheels off the ground or re- moved, UNLESS THE FRONT WHEELS ARE ALSO JACKED UP CLEAR OF THE GROUND OR THE XTRASHIFT FRONT AXLE DRIVE SHAFT IS DISCONNECTED. Failure to do this can result in the tractor being Shift the F/N/R lever to NEUTRAL. pulled off the rear supports by the front axle. NOTE: XtraShift tractors are equipped with a neutral start WARNING: Operate controls only when seated switch in the reverse shuttle circuit. However, if the For- in the Operator's seat.
Page 94 Operation OPERATION 5 TURBO ENGINE: Allow the engine to run for a few seconds with the starter motor to allow the turbo compressor to be lubricated at a 1000-1200 RPM rate without increasing further until the engine reaches the normal operating temperature. COLD TEMPERATURE OPERATION Before you start the engine and operate your tractor during cold ambient temperatures, check the following items: - BATTERIES Must have a full charge. - FUEL: Must be clean and contain no water. Move the throttle lever to 1/4 open position. - ENGINE OIL - Must have the correct viscosity for the ambient temperature range. DO NOT mix oils differ- OPERATION 6 ent for type, characteristics and viscosity from the prescribed ones. - TRANSMISSION HYDRAULIC FLUID - The oil used must be an approved type. Use the transmission fluid prescribed by the Lubricant Chart. - COOLING SYSTEM - Must contain a minimum of 33 percent and a maximum of 50 percent ethylene glycol for protection. This ratio will vary with different market requirements. DO NOT mix protective fluids different for colour and characteristics to preserve their quality. - TYRES - If there is liquid ballast in the tyres, the tyres must have protection against freezing temperatures below 0°C. Ask your dealer for help. - STOPPING THE ENGINE. Permit the engine tempera- ture to decrease before stopping.
Page 95 Operation Starting the engine with the ther- When running at low ambient temperatures, the engine and gearbox will not heat to or keep the rated operating mostarter (if equipped) temperature at slow engine speeds. Low engine speeds in cold temperatures can cause damage to the engine WARNING: DO NOT spray ether or gasoline and gearbox. into the air induction manifold of the tractor fitted with a thermostart system. It could cause Use the following procedures to warm the engine oil explosion and injury. and transmission oil and to keep the correct operating temperatures.
Page 96 Operation Engine coolant heater (if equipped) OPERATION 4 Make sure that the PTO clutch control is on the disen- gaged position. This heater is installed in the engine block and keeps the engine coolant worm to make starting the engine easier For tractors with front PTO, disengage the control switch. in cold weather. Check that the auxiliary control valves levers are in neutral position. North American Tractors IMPORTANT: The control of the rear PTO clutch MUST be in the disengaged position or the starter motor will not operate.
Page 97: Parking The Tractor
Operation PARKING THE TRACTOR [4.1.c] Use of accessories with the tractor at standstill Turning off the engine (with engine running) - Perform the previous Operatione 1 and 2. Before operating the PTO or the hydraulic system in any OPERATION 3 way, proceed as follows: OPERATION 1 Disengage the PTO clutch control, if in use. OPERATION 4 XTRASHIFT TRACTOR Stop the tractor and bring the lever of gearbox with reverse shuttle to the NEUTRAL position. OPERATION 2 Bring the throttle lever fully back to the idle position and let the engine idle. Apply the parking brake. Engage the Park Lock (if equipped). OPERATION 5 Turn the key switch to the OFF position and remove the key. IMPORTANT: When stopping the engine after operat- Press the clutch pedal and put into neutral both the range ing under heavy load, run the engine at idle speed for lever and the gearshift lever.
Page 98 Operation Master disconnect switch (if equip- Wedges for folding wheels (if ped) equipped) Use the master disconnect switch to disconnect the bat- tery power from the electrical systems on the machine, when leaving the tractor or during servicing to prevent accidental start up. It is a good habit to always remove the key to prevent unauthorized use or accidents. IMPORTANT: Do not use the master disconnect switch to STOP the Diesel engine, or the machine power units will be damaged.
Page 99 Operation Clutch pedal operation ALWAYS use the clutch pedal during the following op- erations: - Selection or change of RANGE and GEAR, but not with POWERSHIFT ranges. - Creeper engaging and disengaging (if equipped). - When stopping the tractor. DO NOT ride the clutch pedal when the transmission is under load. Always release the clutch pedal immediately for improved clutch service life. The clutch pedal is used to temporarily disengage drive. - Pedal up = drive engaged. WARNING: - Pedal down = drive disengaged. - Never keep your foot resting on the gearshift clutch pedal when driving. Make your gear changes gradually. When the engine - Never coast down slopes with the gear lever in is under load, do not slip the clutch to accelerate, but neutral.
Page 100 Operation USE OF THE GEARBOX NOTE: At ambient temperatures of -10°C or less, the gearshift lever and the controls may be difficult to operate for the first minutes after the start, until the oil in the gearbox is not warm. IMPORTANT: If the tractor is moving, a gear should always be engaged (except when changing range, gear or direc- tion).
Page 101 Operation Gearshift lever Power Shuttle control lever The lever has 4 possible positions, corresponding to 4 totally synchronized speeds. To shift gears in the same range, just operate the lever after disengaging the drive, without stopping the tractor. Speed range selector lever Shuttle control lever. The speed range selector lever has four possible posi- tions corresponding to the creeper, low, standard and AV - Lever forward: Forward gears. high speed ranges. N - Neutral: Always move the lever to this position to Each speed range is identified by a symbol on the knob start the engine. of the lever. RM - Lever backward: Reverse gears. Four lever positions equivalent to four speed ranges. Creeper range (optional) Low range Standard range Xtrashift warning lamps For warning lamps and information on the instrument High range panel, see the Instruments and Programming Section in...
Page 102 Operation X60.20-X60.30-X60.40 - Xtrashift gearbox with Powershuttle electro-hydraulic reverse shuttle and 3 Powershift ranges under load (only available for forward gears): 36FWD + 12REV without Creeper; 48 FWD + 16 REV with Creeper. * In tractors with mechanically adjusted engine, the Overdrive is automatically downshifted as soon as a 40 kph speed is reached.
Page 103 Operation X60.50 - Xtrashift gearbox with Powershuttle electro-hydraulic reverse shuttle and 3 Powershift ranges under load (only available for forward gears): 36FWD + 12REV without Creeper; 48 FWD + 16 REV with Creeper. * In the 4th high Overdrive range the engine speed rate is reduced to 1900 RPM. ENGINE AT 2200 RPM - Speed in Kph with rear tyres 16.9 R 34 - 540/65 R 34 FORWARD...
Page 104 Operation Use of the Xtrashift Starting the engine Put in neutral: 1. Orange coloured reverse shuttle control lever at the left of the steering wheel. 2.PTO switch on the cab right-hand post. 3. Turn the ignition key clockwise to position 1 (contact), then to position 3 (engine starting). Forward starting WARNING: To start the tractor when the weather is particularly cold, it is advisable to heat the tran- smission oil by running the engine until it reaches a temperature of 20°C.
Page 105 Operation Declutch button The Declutch system allows the gear to be changed by pressing the relative orange button on the gearshift lever handle. Changing gear with the Declutch system. The Declutch button (1) practically acts as the clutch pedal. Press the button to disengage the hydraulic clutch, and keep it depressed while engaging the required gear. Release the button. Gear change with the clutch pedal (1) When the clutch pedal is depressed to change gear, Deltashift remains in the range previously engaged. Changing the range (creeper, low, standard, high) with the clutch pedal Depress the clutch pedal and wait for the tractor to stop before selecting a range (creeper - low - standard - high).
Page 106 Operation Engagement of Powershift ranges under load The gearbox provides 3 Powershift ranges (underdrive, direct drive and overdrive) that can be engaged under load in forward gears. For each engaged gear, 3 speeds are available: Underdrive - Direct - Overdrive. To select, turn the Powershift switch on the gearshift lever: changes from one range to the next are automatic and under load (Fig.4-15). Turn the switch up to shift the range up: + sign. Turn the switch down to shift the range down: -- sign. The switch always returns to the centre position. The Powershift switch can be set on any position with the tractor moving, without depressing the clutch pedal or the clutch pedal or the Declutch disengagement button.
Page 107 Operation Use of reverse shuttle under load The tractor’s driving direction is automatically reversed by pushing the orange lever at the left of the steering wheel forwards or backwards (1). The reverse shuttle is automatically controlled through the following phases: · DECELERATION · STOP · CHANGE OF DIRECTION · ACCELERATION The speed at which these phases take place by softwa- Warning: Reversing can be obtained at any spe- ed. However, to protect mechanical parts from damage, this operation should be made ONLY at speeds UNDER 10 Kph. A buzzer sounds to warn from reversing at speeds over 10 Kph. To correctly engege the reverse shuttle, reduce your speed to under 10 Kph. Use of reverse shuttle with clutch pedal The clutch pedal is used to obtain small and precise movements for certain work requirements. · Completely depress the clutch pedal (1). · Shift the orange shuttle control lever. · Wait for the reverse indicator LED to come on.
Page 108 Operation Stopping the tractor Xtrashift Always stop the tractor safely: Engage the parking brake (3), engage the Park-Lock (1) (if equipped), disen- equipped), disen- ), disen- gage the PTO, bring all the gearshift levers to neutral position, lower any implement to the ground, stop the engine and remove the ignition key BEFORE leaving the driver’s seat. Park-Lock (on request) The Xtrashift transmission is mechanically blocked by the lever engaging the Park-Lock device (1). Therefore the Park-Lock should be engaged every time you want to stop the tractor with the engine stopped, particularly when the tractor is on a slope.
Page 109 Operation Electro-hydraulic PTO The rear power take-off is fully independent from the transmission. It is engaged by means of a multi-disc oil-cooled hydraulic clutch. The PTO is engaged by means of the switch (1). An indicator light on the instrument panel comes on when the PTO is engaged. Use: engagement/disengagement Engage/disengage the front PTO (1) by the ON/OFF button switch with engine at idling speed. Disengagement Depressed button switch: disengaged PTO Fully depress the ON/OFF switch (1). The PTO indicator light on the instrument panel goes off. Released button switch: engaged PTO To engage the PTO, release the switch (1) by pulling up the locking collar (2). Always shift the switch in the OFF disengaged position after using the PTO or before starting the engine. NOTE: The engine can be started only if the PTO engagement switch is in the OFF position and the PTO engagement lever (3) is in the neutral position.
Page 110 Operation X60.50 Dual Power Dual Power also engages to improve performances during transport operation according to load, ground speed and The Dual Power system increases the available power engine speed rate. when working under load with engaged PTO. Dual Power takes advantage of the potential of the electronic engine control system to maintain steady power delivery even when there are load variations. This is done by automa- tically supplying an extra power reserve whilst the PTO is being operated, thus allowing this latter to be used in a better way while improving the performances and productivity. For power values, see the Technical Specifications chapter in this manual.
Page 111 Operation External buttons for PTO Synchronized Power Take-Off engagement (Optional) Use the buttons on the rear fender (3) for easier Use of the synchronized rear power take-off with the connection. gearbox is solely designed for towing self-driven trailers and, more generally, for all those farming implements WARNING: Danger of entanglement. Keep well which have to operate synchronised with tractor move- away from spinning shafts. Take care NOT ment and which do not require more than 40 - 45% of to remain caught up by the PTO driveline.
Page 112 Operation Speed range selection The speed range selector lever (1) allows to change from 540 RPM PTO (or 540ECO RPM) and back Two speed PTO - PTO at 540 RPM N - P TO in neutral - PTO at 1000 RPM or 540ECO RPM Three speed PTO - PTO at 540 RPM N - P TO in neutral - PTO at 1000 RPM Two speed PTO - PTO at 540ECO RPM CAUTION: When the PTO is not used, the speed range selector lever should always be in neutral position. CAUTION: Disengage the PTO clutch before switching between two speed ranges.
Page 113 Operation Interchangeable PTO shaft Different PTO output shafts are available: • diameter 1 3/8” (34.9 mm.) shaft with 21 splines for 1000 RPM power take-off, standard assembly (2). • diameter 1 3/8” (34.9 mm.) shaft with 6 splines for the 540 RPM PTO, provided with the tractor (1). CAUTION: Only use the PTO driveline for 540 RPM if the implement used requires a power greater than 56 kW (75 HP) since damages to the driveline itself and to the connected implements could injure bystanders.
Page 114 Operation PTO Safety Guards PTO error codes [4.2.e] All tractors with a power take-off have a large safety guard In case of PTO malfunction, the instrument cluster will (1) and a small tube type guard (2) for the splined output display an exclamation mark. To check the PTO error code, shaft. To prevent injury to the operator, the tractor power refer to the Error menu on the digital instrument cluster. take-off safety guard and the shields for the telescopic shaft assembly must be used. Keep the guards in place. WARNING: When an operation ERROR is displayed, ask the Dealer's specialized personnel for help indicating the error code. The Dealer's personnel has specific competences to locate the error and the type of operation to be performed.
Page 115 Operation Precautions when using the PTO IMPORTANT: When using implements that cause shock loads, always use a safety coupler between the implement and the PTO drive shaft. Before using the implement, check WARNING: PTO drivelines and implements the correct operation both of the safety coupler and of the operated by the PTO can be extremely dan- implement.
Page 116 Operation Brakes The rear and front brakes are multi-disc oil bath units. Brake action is hydraulic, controlled by pumps operated by the pedals. A brake fluid reservoir keeps the brake circuit supplied with fluid. WARNING: When changing or topping up the brake fluid in the reservoir, be absolutely sure to use the correct type of fluid as diffe- rent varieties have totally different proper- ties. These machines use an LHM mineral- based fluid which is completely different from the normal LHS synthetic fluid used on other types of tractor.
Page 117: Parking Brake
Operation Parking brake A hand lever (1) controls the parking brake. This acts, via a series of linkages, directly on the brake discs and is fully independent of the foot brakes. Parking brake engagement - Fully depress the brake pedals. - Pull the lever completely to operate the parking brake (1). - Release the brake pedals and make sure that the tractor is stopped. - If this is not the case, pull the parking brake lever with higher force. When the parking brake is engaged, the warning lamp on the instrument cluster will illuminate when the key switch is turned to ON. NOTE: The indicator light in the instrument panel lights up when the parking brake is engaged, independently of the force used for the engagement. To start the tractor, shift into gear and release the parking brake.
Page 118 Operation Hydraulic trailer brake (Approved for ITALY) [4.2.i] The tractor braking system can be equipped with a hydraulic valve (1) which, if connected to the hydraulic circuit of the trailer brakes, allows the trailer itself to be braked along with the tractor. . Comply with the following instructions to correctly connect and disconnect the flexible trailer brake tube to and from the union (2) at the rear of the tractor and to always operate in conditions of the utmost safety. The trailer-tractor connecting tube can be connected and disconnected with the engine either running or at a standstill: - With the engine at a standstill: there are no diffi- Hydraulic trailer braking tap (Approved for ITALY). culties when either connecting or disconnecting as 1 - Valve unit. there is no oil pressure in the brake circuit. 2 - Oil tap union. 3 - Indicator light on dashboard. - With the engine running: it is essential to engage the hand brake since this ensures that no pressure remains in the brake circuit. WARNING: It is extremely important to al- ways carry out this operation before deta- ching the trailer from the tractor since it en- Hydraulic trailer brake (Approved for sures the immediate action of the automatic...
Page 119 Operation TRAILER AIR BRAKE COUPLINGS [4.2.i] (if equipped, according to market) 1. YELLOW COUPLING - BRAKE SERVICE LINE (DUAL LINE SYSTEM) 2. RED COUPLING - BRAKE EMERGENCY LINE (DUAL LINE SYSTEM) 3. BLACK COUPLING - FEED AND RETURN (SINGLE LINE SYSTEM) - (OPTIONAL) WARNING: Make sure the system is at wor- king pressure before operating the brakes with a trailer(s) fitted. Failure to do this can result in injury or death. WARNING: DO NOT park an unattended tractor/trailer(s) combination using air pres- sure to apply the brakes (Dual Line Pneu-...
Page 120 Operation Locking the differential The tractors are fitted with a system for locking the differential on the rear and front axles on 4WD models. The system is used when a wheel slips because of lack of grip. To lock the differentials, just press the button (1) under the control panel of the electronic power lift for a second. A yellow function indicator on the instrument panel lights up to indicate that the diff lock is engaged. NOTE: For the best results, engage the diff lock before the wheels are likely to slip. Do not engage the lock Fully depress the top of the switch (1) to engage the while one of the wheels is actually slipping. differential lock.
Page 121: Three Point Linkage
Operation Three point linkage The three point linkage is used to connect the tractor to implements controlled by the hydraulic lift. The three-point linkage is suitable for connection to implements of 2nd class as shown by the diagram and data given in the figure. WARNING: Always take great care when using or adjusting the three point linkage. Hitching the implement To allow the lift to operate in the correct way, you must carefully check the dimensions of the implements to be coupled to the tractor. Implement hitch dimensions. a - Horizontal distance between lower link pins of the These couplings must be the same standard size as the three-point hitch and the implement’s centre of three point linkage of the tractor to prevent the whole gravity. assembly from being subjected to irregular stress du- As small as possible (the greater is the weight of the ring work, caused by dimensional incompatibility. See implement, the smaller it is). dimensions given in the figure. b- R etraction of the third point: 0 to 80 mm (0 to 3.1 in.) c- Height of top link hitch ball: 500-600 mm (19.7 to 23.6 Weight of the implement in.)
Page 122 Operation Lower links The lower links (4) transmit draft and support to the implement. The lower links are available with fixed ball- ends or with quick-hitch couplings (on request). The tractor is supplied complete with Class 2 and 3 interchangeable ball ends to be installed on the imple- ment hitch crossbar. Quick hitch couplings To hitch the implement, first pull the connecting cables (1) from the driving seat to open the hitch lock (2). Reverse the tractor towards the implement so that the lower links are in the direction of the ball-ends fixed to the crossbar of the implement. Slowly raise the links of the power lift until the ball-ends (C) automatically push against the spring-loaded quick- hitch couplings (D) and are locked into place. The hitch couplings can be opened driectly from the Quick hitch couplings. cab by means of the control cables. RH adjustable rod. C - Quick hitch coupling. D - Lock. E - Control cable. Adjustable rh lift rod The length of the rh adjustable lift rod (2) can be adju- sted by means of the relative crank (1). This adjustment is very useful since it levels the implement depending on the type of work being carried out. Turn the lever clockwise to shorten the rh vertical lift rod. Turn the lever anticlockwise to lengthen the rh vertical lift rod. On request the rh adjustable lift rod can be equipped with a hydraulic jack (3), operated from the driving seat, to adjust the cross angle of the implement.
Page 123 Operation Vertical lift rods The right and left vertical lift rods can be regulated by means of an adjustment crank in order to alter the late- ral angle of the implements. They can also be adjusted by turning the backing plate through 90°: this gives two settings, one with the plate fixed (A), the other with the plate free to slide (B). This latter position must be used for implements that require a certain freedom of sideways movement (cultivators, spaders, harrows). Fixed backing plate. Free-sliding backing plate. Backing plates for the hinge pins of the vertical rod forks. Side stabilizers The side stabilizers (1) can be set to reduce side swing of the lower links of the three-point linkage. When working with implements such as graders, rollers, hoes, weeders, etc. the side swing of the lower links can be adjusted according to the job on hand. When working instead with ploughs, disk harrows, etc. the stabilizers can be set to allow the lower links to swing freely. For the transport on road with lift links in high position, lower links side swing must be restricted independently of any previous adjustment during work. Turn the stabilizers (2) for the adjustment: – turn anti-clockwise to increase side swing of three- point linkage; – turn clockwise to reduce or even stop side swing of three-point linkage. If the three-point linkage is set on float mode, it is ne- cessary to check that side swing is simmetrical on both sides, taking the rear wheel rim as a reference. Swing the three-point linkage all to the right and measu- re the distance from lower link to wheel rim. For special requirements, the link length can be so adjusted as to offset the implement relatively to the tractor axis. In this case the links must be adjusted to...
Page 124 Operation Adjustable top link (3rd point) The adjustable top link (1) is connected to the tractor through a bearing with two holes (2). The connection hole should be selected according to the reaction to the draft control. Connection to the top hole gives a lower sensitivity, to the bottom hole a higher sensitivity to the hitch draft control. The length of the link is varied so that the angle of the implement can be regulated in relation to the ground. During work, the top link should go slightly down toward the tractor, when the lower links are parallel to the ground. Hydraulic adjustment of top link (3rd point) (on request). For works in draft control mode, remember that it is better to hitch the implement in the top hole if the carried load is particularly heavy. This way a greater uniformity of work is achieved. Important recommendations when using and adjusting the three point linkage. On request, the adjustable top link is available with a hydraulic device (1) to adjust the length of the link from WARNING: before any adjustments in the the driving place during work. three point linkage, the following operations are required: engage the first gear, engage the The top link has two holes for hitching the implement and parking brake, turn the engine off and remove...
Page 125 Operation Auxiliary cylinders [4.2.g] The hydraulic hitch can be equipped (on request) with two auxiliary cylinders, directly supplied by the hitch valve. The lifting capacity with the auxiliary cylinders, diam. 60 mm (max. pressure 200 bar) is 5000 kg. Contact your Dealer or area Agent to mount the auxiliary cylinders and relative hydraulic fittings. Supplementary cylinders.
Page 126 Operation ELECTRONICALLY CONTROLLED HYDRAULIC POWER LIFT Description The electronically controlled hydraulic power lift is avai- lable as an option on certain tractor models, depending on the requirements of the particular market. Electronic control of the power lift gives a number of major benefits. In particular, control and response signals can be processed and action taken to adjust for variations in ground conditions encountered by the im- plement in a fraction of the time possible with manual controls. To obtain the best results from the electronic control system, you must be fully familiar with the controls on the power lift control panel. A full description is given below. Power lift control panel 1 - 3-position up/down switch. A: Lowering - Work position. This depends on the way the controls (3 and 2) are regulated. B: Stop - The lift arms are unable to move in any way in the stop position. C: Lifting - Transport: the fully raised position is established by the limiter (7). 2 - Implement work depth/height control: 0 - Maximum depth. 10 - Max. height from ground. 3 - Function selector: - Position Control, turned clockwise. - Draft Control, turned anti-clockwise. - Intermediate position: mixed Draft and Position Control (INTERMIX).
Page 127 Operation USE OF THE ELECTRONIC POWER LIFT Enabling the power lift The power lift incorporates a safety device which disa- bles the hydraulic power lift controls when the engine is off or if the external controls have been used. This prevents accidental movement of the lift arms and links as a result of interference with the controls or settings while the tractor was stopped. When the engine has been started, or after the external controls have been used, simply turn the control switch (1) to position C. - If the switch is already in Pos. C, turn the switch (1) to Pos. A then back to Pos. C again. - If the switch (1) is not in Pos. C and the lift is lowered, turn switch (1) to Pos. C. WARNING: The lift arms will rise as soon as the control panel is enabled. Limit the max. lifting height with the control (7) before re- activating the electronic power lift.
Page 128 Operation Hitching an implement From the internal control panel - Turn the power lift control switch (1) to Pos. C to enable the power-lift control panel. - Turn the control switch to the working position (A). - Turn the function selector (3) clockwise to select position control mode. - Turn the knob (2) anti-clockwise to lower the arms. The arms-down indicator should light up. - Manoeuvre the tractor to the right position and hitch the implement’s ball-ends on to the ends of the links. Fit safety pins to secure the hitch. Hitch up the top link. - Turn knob (2) clockwise to raise the implement. The arms-up indicator should light up. With the external control buttons (8 - 9) There is no need to enable the power lift in order to use the external control buttons (8 - 9). To use the external controls, just press on the buttons to raise or lower the lift arms. Now enable the power lift control panel by means of the switch (1).
Page 129 Operation Operating the power lift Headland manoeuvres - Select the power lift operating mode by means of the - Raise the implement at the end of the field by setting mode selector (3). the switch (1) to Pos. C. The arms lift to the height set on the lift height limiter (7). Adjust the lift height Position 1 - Turn the knob anti-clockwise for limiter so that if a drive shaft is connected between draft control mode. Use for plou- the PTO and the implement, it is not twisted into ghing and similar operations that acute angles. This will also avoid wasting time lifting require constant tractive force. the implement to transport height. Position 6 - Turn the knob clockwise - To re-engage the implement, simply turn the switch for position control mode. The (1) to the working position (A). The implement will lo- implement will remain at a con wer at the speed set with selector (7) until is reaches stant height or depth. the position selected with knob (2). Intermed. positions “Intermix” mode. - To make the implement quickly re-engage the soil, press (2 - 3 - 4 - 5) Combining position control...
Page 130 Operation Float mode Used for implements that rest on the earth and follow the relief of the ground. - Turn switch (1) to position (A). - Turn knob (2) to position (MAX), fully anti-clockwise as far as it will go. CAUTION:Comply with the maintenance and sa- fety regulations governing the electrical system of the tractor to safeguard and protect the electronic power lift. Transporting implements - Select the maximum transport height with the selec- tor (7). - Raise the three-point linkage by turning the switch (1) to Pos. C.
Page 131 Operation AUXILIARY CONTROL VALVES [4.2.f] Control valve levers operate the corresponding valve: Joystick (4) - It is coupled to two auxiliary control valves. If lever 1 operates valve number 1, lever 2 operates valve shifted forward, it controls the 1st valve, if shifted laterally number 2 and so on. it controls the 2nd valve. The lever can be locked by (5) in three positions: - Turned anti-clockwise and downward: Every move- ment of the lever is locked in neutral. - Turned clockwise and in intermediate position: The movement forward/back is allowed to control a single control valve. To control the second control valve, the locking device must be pulled up and the lever shifted laterally. - Turned clockwise at the end of travel: The lever can be moved in every direction and controls both valves. NOTE: To ensure that the hydraulic circuit operates in a regular way, the level of the transmission oil must be frequently checked and topped up if necessary, as indi- cated in the “Checking the transmission oil level”...
Page 132 Operation REMOTE HYDRAULICS OPERATION There can be up to three remote control levers, each NOTE: If there is too much restriction in the implement having three or four positions (according to the type of cylinders or other attachments, the restriction can cause valve): a back pressure in the remote valve which will cause the remote lever on the console to return to neutral before the cylinder has reached full stroke.
Page 133 Operation Float Position (if available) To operate the remote hydraulics in a float condition, turn the lock control (2) fully counterclockwise. This will allow the control lever to go completely for- ward into the float position. The remote hydraulic control levers can be locked out of the float position. When using equipment for work where the float position is not wanted, turn the lock control one position clockwise so that the control lever cannot be moved into the float position. NOTE: Single action cylinders can be operated in a float or no float position at the same time that the hitch is operated.
Page 134 Operation Free discharge - Hydraulic Motor Operating Hydraulic Motors Return Circuit (if equipped) Connect hydraulic motors to the 1st remote circuit to make sure of a constant flow of oil to the motor. The hydraulic motor return circuit can be used to reduce restriction in the remote hydraulic motor return Stop the engine. Move remote control lever forward to line. This will result in more efficient hydraulic motor the float position. operation. Turn the locking control (1) fully anti-clockwise (three To use the hydraulic motor return circuit, connect the positions from neutral), so that the movement of the return line from the hydraulic motor or implement to the control lever is limited to two positions: retract and connector (1). float. In this way the lever has only available the two posi- tions to be used with hydraulic motors. To engage the hydraulic motor, start the engine and move the control lever forward from the float position until against the lever lock. The hydraulic motor will now operate. To disengage the hydraulic motor, move the remote control lever forward to the float position. Wait for the hydraulic motor to slowly stop. DO NOT DISENGAGE THE LEVER LOCK. Allowing the control to return to the neutral position during motor application will cause the motor to stop immediately. This may cause damage to the hydraulic motor, hoses and equipment.
Page 135 Operation Selecting the single/double acting modes (Available only on some control valve types) Some control valves can be regulated to control single- acting cylinders. To do this, just loosen the check nut (2 ) and turn the screw fully anti-clockwise (1). Now lock the check nut again. To select the double-acting mode, turn the adjuster screw (1) clockwise. Flow divider (if installed) On request, a flow divider is available (3) that is mounted on the input plate of the control valve pack and is coupled with the first auxiliary control valve, of a type specific for operation with a flow divider. Flow regulation This device regulates the oil flow to the first control valve, and is specially useful for those implements that require a very limited oil flow to obtain precise move- ments, or to regulate the speed in a hydraulic engine. It also maintains an oil flow sufficient to use the lift system and the external circuit at the same time, if only the first auxiliary valve is used. To regulate the flow, simply turn the control knob on the flow divider. Quick couplings Each control valve has two quick coupling female half-connections of the “Push-Pull” (4) type that can be WARNING: When auxiliary control valves...
Page 136 Operation USE OF FRONT POWER TAKE-OFF (if equipped) Engage the PTO as follows: OPERATION 1 Reduce the engine rpm. OPERATION 2 WARNING: Always mount the plastic guard on the PTO shaft when the PTO is not being used. The front power take-off has a 6 spline output shaft which rotates at 1000 rpm. Engagement is electrohydraulic, actuated by a three position rocker switch (OFF, ON and ENGAGED) situated on the RH side console. Depending To engage the PTO, release the switch (2) by pushing...
Page 137 Operation FRONT POWER LIFT (if equipped) [4.2.g] Hitch System Multi Valve The valve is mounted at the rear of the tractor. The multi valve has two operation modes. Valve Positions 1st mode - Double acting The front power lift is operated via the tractor’s remote hydraulic valve circuit and is double acting, (the linkage is power lifted and power lowered). The hitch is designed for Category IIIN implements. The top link has a ball end. Maximum Lift Capacity..........2800 kg IMPORTANT: Do not exceed the maximum permitted front axle operating weight when using the front hitch. 2nd mode - Single acting Observe tyre load capacities and any possible legal limitations.
Page 138 Operation Lower Links Transport position The lower links have three positions. When changing the position of the lower links, support the links when removing the retaining pins. Both lift links must be set in the same position. Rigid Position Top Link For operation with no vertical movement, install the retaining pins in the rear hole. Float position When not being used store the top link as shown above. When operating on the public highway without equip- ment attached always store the top link correctly. For operation with vertical float, independently of each other, install the retaining pins in the front hole.
Page 139: Optional Equipment
Operation Hitch Operation Optional Equipment OPERATION 1 Front Hydraulic Quick Couplers for Remote Valves (available as a kit) Lower the lower links and set for Rigid or Float applica- IMPORTANT: The front remote couplers are supplied tion, as required. from one of the rear remote valves. DO NOT use both the front and the corresponding rear remote couplers at OPERATION 2 the same time.
Page 140 Operation Towing attachments Front tow hook The tractor is equipped with a front tow hook for emer- gency operations for towing the tractor. CAUTION: DO NOT raise the machine with the tow hook. CAUTION: Use exclusively the provided hooks to tow the machine. CAUTION: Refer to licensing documents issued by Front tow hook. the Ministry of Transport to know data relating to max.
Page 141 Operation Standard sliding rear tow hooks, adjustable in height - Italian market. - CUNA ‘C’ tow hook (for the Italian market). - CUNA ‘D2’ tow hook (trailer hydraulic brakes) (for the Italian market). - CUNA C hook and CUNA drawbar, Class A (for the Italian market) - CUNA D2 hook (hydraulic trailer brake) and CUNA drawbar, Class A (for the Italian market) Standard sliding rear tow hook, adjustable in height - EEC market - EEC hook, not automatic - EEC hook, automatic - EEC hook, not automatic and EEC drawbar. - EEC hook, not automatic and EEC drawbar.
Page 142 Operation Rear tow hook, adjustable in height (type with sa- fety guards) (not-EEC markets) (Not valid for Italy and EEC markets) - Cat. C tow hook - D2 tow hook (trailer hydraulic brakes) - CUNA drawbar, Class A Cat. A drawbar The tractor may be equipped with an A-type tow hook that consists of a drawbar, for use with agricultural implements and one or two-axle trailers. Never use this type of attach- ment to tow single axle trailers, because they can apply too much weight to the drawbar. The drawbar might be damaged because it is not built to sustain vertical loads. The drawbar can be adjusted to allow correct coupling, besides to towed implements, to implements driven by PTO. It is possible to change the pivoting point of the sector on the tractor support.
Page 143 Operation Piton-Fixe (if equipped, according to market) To connect an implement/trailer, remove the spring clip and pin (1) and lift the retaining hook (2). Install the implement towing eye over the towing pin (3) and lower the retaining hook (2). Install the pin and spring clip (1). IMPORTANT: Maximum vertical load capacity depends upon the capacity of the rear tyres fitted. Refer to your Dealer for more information. Piton Fixe rear sliding draft gear - Available versions: - EEC hook, not automatic - EEC hook, automatic...
Page 144 Operation PICK UP HITCH (if fitted, on request on certain markets) Connecting an implement WARNING: Pick-Up Hitch hook (PUH) - The coupling and uncoupling of the PUH must be made strictly with the lifting device in OPERATION 1 a controlled position to ensure the proper functioning of the fastening/release of the Electronic Power Lift System hook.
Page 145 Operation OPERATION 2 OPERATION 5 Raise the hitch to maximum height. Lower the pick-up hitch using the power lift controls. IMPORTANT: Electronic power lift - Make sure LOAD CONTROL is in the (0) off position, this will prevent OPERATION 6 unwanted hitch movement when the tractor is moving at more than 0.8 km/h (0.5 mph). OPERATION 3 Make sure the auto hitch is raised to maximum height.
Page 146 Operation OPERATION 10 OPERATION 2 Lower the hitch onto the locking latches to take the weight off the hydraulic system. Remove the hitch/drawbar locating pins. IMPORTANT: The hitch must always be supported on OPERATION 3 the locking latches and NOT by the hydraulic system. If the locking latches do not lock, adjust the lift rods. If after adjustment the locking latches still do not lock see your dealer.
Page 147 Operation Towable weights [4.2.l] towable weight Make & Max horizontal Type Load CBM GTF30019 12000 kg M.R. 17101000 12000 kg GRASSI V.ORLANDI EG39 or 40000 kg EG41 40000 kg MH31 40000 kg EG40 AH31H-S 40000 kg AH31H 40000 kg AH31 40000 kg 13000 kg EG37...
Page 148 EG40 AH31H-S 40000 kg AH31H 40000 kg AH31 40000 kg 13000 kg Operation EG37 EG37 12000 kg 11000 kg DRAWBAR DROMONE 24000 kg RMF 6000 HOOK Max. vertical load relative to rear tyres and hitch/drawbar type (daN) Max vertical load in relation to tires and to hitch/drawbar type (daN) [4.2.j] Coupling see chart above DRAWBAR...
Page 149 Operation Tractor transport [4.1.j] Towing the tractor If you need to tow or push the tractor for a brief distance, remember that the power steering system will allow you to drive and steer it for a short way with the engine off. Put the following controls in NEUTRAL: 1- Reverse shuttle lever (1) 2- Gearshift lever (2) 3- Range selector lever (3) 4- (With Xtrashift only) Disengage the Park Lock (if equipped) (5) 5- Disengage the parking brake (6) 6- Make sure that the PTO engagement switch is disen- gaged (4) OFF. How to drive the tractor • To drive the tractor, you will need to excercise greater effort if the engine is at a standstill. • Slow and stop the tractor with the brake pedals latched together . •...
Page 150 Operation Towing the tractor Towing the tractor with the engine off or low pres- [4.1.j] sure hydraulic circuit not operating. Towing the tractor is not recommended, but if it should be absolutely necessary, the procedure is different depending WARNING: If the machine is towed with the on the fact that the engine is on or off, and that the low engine off (or with the low pressure hydraulic pressure hydraulic circuit is operating or not operating. circuit not operating), the brakes and steering Use the following procedures as applicable, at the fol- will not be power assisted if this depends on...
Page 151 Tyres, Wheels, Ballasting Section 6 Tyres, Wheels, Ballasting...
Page 152 Tyres, Wheels, Ballasting TYRE INFLATION SPECIFICATIONS For maximum tractor performance, always adjust the tyre Tyre pressure can also be adjusted as required to satisfy pressure within the minimum/maximum range, to conform the following requirements. with the actual load on the tyres. Under normal conditions use the minimum pressure rating for general drawbar A. Severe Service. work. Use the higher pressure rating, up to the maximum, Tyre pressure can be increased 28 kPa (0.27 bar - 4 psi) for heavy three-point hitch mounted equipment. more than the maximum pressure shown in the charts, for tyres used in severe service. Severe service includes the furrow tyre in regular ploughing operations, and in hillside operations. B. Tyres With Liquid Ballast. INFLATING Inflate the tyres 14 kPa (0.14 bar - 2 psi) more than the AT MAXIMUM...
Page 153 Tyres, Wheels, Ballasting Air Pressure Check Tyre Inflation Procedure Check the tyre inflation pressure every 50 hours of opera- DO NOT inflate a tyre that has had a complete loss of air. tion or once per week. If the tyre has lost all air pressure, have a qualified tyre mechanic service the tyre. NOTE: For best tyre life check tyre pressures as regular intervals. Too low a pressure causes early tyre wall failure. Too high a pressure causes higher tread wear or dam- age.
Page 154 Tyres, Wheels, Ballasting TYRE PRESSURES, LOAD CAPACITIES AND SERVICE Tyres can be marked in two ways, as shown in the examples below: CROSSPLY STRUCTURE: Example 12.4-24 8PR 12.4 = Nominal tyre width in inches - = Crossply structure 24 = Internal diameter 8PR = 8 ply rating For correct tyre pressures/load capacities for CROSSPLY tyres see your dealer or tyre manufacturer. RADIAL - Examples 18.4R38 710/75R34 18.4 = Nominal tyre width in inches 710 = Nominal tyre width in mm R = Radial structure 75 = Nominal aspect ratio (ratio of sidewall 38 = Internal diameter height/section width) 142 = Load index number, 142 = 2650 kg (see chart 1) R = Radial structure A8 = Speed code for 40 kph, (see chart 2) 34 = Rim diameter at the bead seat in inches...
Page 155 Tyres, Wheels, Ballasting IMPORTANT: The charts below are only a guide. Loads may vary slightly with makes of tyre. For correct loads see your dealer or tyre manufacturer. Chart 1 - Load Index Codes and Loads per Tyre INDEX kg INDEX kg INDEX...
Page 156 Tyres, Wheels, Ballasting Tyre And Wheel Service Tyre Installation To get the correct traction and cleaning action of the lugs, WARNING: Do not remove, install or make the tyres must be installed on the wheels so the tread repairs to tyres or rims. Take the tyre and pattern is turning as shown. DO NOT try to remove, repair rim to a tyre specialist where persons with or install a tractor tyre on a wheel. special training and special safety tools are available.
Page 157 Tyres, Wheels, Ballasting Wheel removing procedure WARNING: If a wheel has to be removed (e.g. to remove a punched tyre), this operation must be carried out by a suitably equipped workshop. If the suitable equipment or such a workshop are not available, take the tractor to a specialised workshop, where the tractor will be lifted with an equipment suited to its weight and dimensions.
Page 158 Tyres, Wheels, Ballasting Tyres - Front and rear tyre size combinations The following is a list of tyre types and front/rear combinations. Please ask your Dealer for information on further com- binations. On tractors with 40 Kph overdrive gearbox only tures marked as «load index A8» may be used. Front tyres Rear tyres Mod. Tyre Rim Tyre Rim X60.20 X60.40 X60.50 X60.30 420/70R 24 (130 A8) W13-24 480/70R38 (145A8) DWW15-38 11.2R24(114 A8) W10-24 16.9R30 (137A8) DW14L-30 12.4R24(119 A8) W10-24 13.6R38 (128A8) DWW12-38 12.4R24(119 A8) W10-24 18.4R30 (142A8) DWW15-30...
Page 159 Tyres, Wheels, Ballasting Adjusting the max. steering angle The maximum steering angle of the 4WD front axle can be varied depending on the type of tyre mounted and the way the tractor is used. The angle is changed by adjusting the stop screw (1) on the final drive of the axle. This adjustment is very useful when adopting minimum track since it prevents the wheels from interfering with the engine housing. The maximum steering angle is 55°. Adjusting the steering angle. 1 - Adjuster screw. 2 - Check nut. Steering limit on front fender To avoid the front fender clashing with the engine at the max. steering angle, the hub cap rotation can be stopped while leaving the kingpin free to reach the max. steering angle. Adjust the screw (2) so that it hits the bolt (1) before the hub cap clashes with the engine. Hub cap stop. 1 - Stud. 2 - Adjuster screw. 3 - Lock nut.
Page 160 Tyres, Wheels, Ballasting Adjusting wheel track 4WD axle - Adjusting wheel track The front track on 4WD tractors can be adjusted by chan- ging the position of the hubs and central wheel discs as shown in the table below. Make sure that the wheel nuts are correctly tightened to the prescribed torque wrench setting: Disk to hub: 270 Nm Rim to disk: 210 Nm WARNING: When you lift up the tractor to adjust the wheel tracks, follow the directions for lifting in the Safety Notes section. WARNING: Maximum attention must be used when dismounting the front wheels: because of their weight, a suitable hoist must be used...
Page 161 Tyres, Wheels, Ballasting Wheel track adjusting for 4WD axle Wheel disc pointing inwards Wheel disc pointing outwards Interflange 1887 mm - Wheel tracks for 4WD front axle - mm - Tyres 440/65R24 (122 A8) 1627 1740 1795 1886 1908 1999 2054 2167 480/65R24 (127 A8) 1627 1740 1795 1886 1908 1999 2054 2167 12.4R24 (119 A8) 1640 1753 1808 1873 1921 1986 2041 2154 13.6R24 (121 A8) 1627 1740 1795...
Page 162 Tyres, Wheels, Ballasting Rear track width adjustment The rear track width can be adjusted by changing the position of the rim fixing points or the central wheel discs, as shown in the table below. Torque the nuts and bolts that fix the rim to the disc to 240 Nm (1) and those that fix the disc to the wheel hub to 320 Nm (2). Always check tyre pressure. Certain track widths cannot be obtained with some tyre types (see table). WARNING: When you lift up the tractor to adjust the wheel tracks, follow the directions for lifting in the Safety Notes section. WARNING: Maximum attention must be used when dismounting the rear wheels: because of their weight, a suitable hoist must be used...
Page 163 Tyres, Wheels, Ballasting Wheel tracks for rear axle - mm - Tyres 540/65R38 (142A8) 1620 1720 1820 1920 2020 16.9R30 (137 A8) 1515 1628 1712 1915 1825 2028 540/65R34 (140 A8) 1620 1720 1820 1920 2020 600/65R34 (145 A8) 1624 1720 1820 1924...
Page 164 Tyres, Wheels, Ballasting Front ballast (if equipped) [4.2.h] Do not hitch to the three point linkage any implements that weighs more than indicated. If the implement weight or the operating conditions (slope) might destabilise the tractor, cast iron plates can be added to the front end. Front end weights can be mounted on the front of the tractor with a weight frame. The weights and weight frame are available from your Dealer. The weight frame can accomodate a max. of 7 or 9 ballast weights. Each ballast weights 45 kg (100 Lbs) and the frame weights about 100 kg. IMPORTANT: The total tractor weight with full equipment and ballast weight must never be more than the maximum allowed operating weight.
Page 165 Tyres, Wheels, Ballasting Ballasting the rear wheels [4.2.h] Two rings can be applied on each rear wheel (see figure). The first one is directly fixed to the wheel, the second one on the first ring. The total weight that can be applied is therefore: 4 rings (2+2) each weighing 60 kg: total 240 kg. WARNING: Due to the great weight of each bal- last, manual lifting of front and rear ballast weights could be dangerous for your safety. Use exclusively a hook or suitable equipment to lift front and rear ballast weights.
Page 166 Tyres, Wheels, Ballasting Ballasting with water In relation to ballasting with cast iron rings on the driving wheels, this type of weighting offers the following ad- vantages: The tractor can also be ballasted by filling the tyres with water. - Low cost. To lower the freezing point a few degrees in winter, add - Easy preparation. calcium chloride to the water in compliance with the pro- portions given in the following table. The ballast should - Improved steering. evidently be removed when the job does not require excessive draft, otherwise the soil could become exces- - The weight of the driving wheels can be regulated ac- sively compressed.
Page 167 Tyres, Wheels, Ballasting How to fill the tyres with water How to deflate the tyres – Jack up the tyre in question (Fig. 4-50) and set it with WARNING: when you prepare a solution of its valve pointing downwards. calcium chloride to ballast the tyres, NEVER EVER pour the water on to the calcium chlori- de since this could lead to a violent reaction.
Page 168 Tyres, Wheels, Ballasting This page has been left blank intentionally...
Page 169 Maintenance Section 7 Maintenance...
Page 170 Maintenance RECOMMENDATIONS BEFORE YOU SERVICE [4.1.h] - Put a warning tag, as shown below, on or near the key WARNING: Before servicing, carefully read the instructions in this section. There is a risk switch before carrying out servicing or repairs to the trac- tor. Warning tags are available from your dealer. of injury or death if servicing is not carried out or if the following instructions are not followed correctly.
Page 171: Service Access
Maintenance SERVICE ACCESS Access for inspection and mainte- How to open the bonnet Park the tractor on hard, level ground, engage the first nance gear, engage the parking brake, turn the engine off and remove the ignition key. WARNING: In particular cases it may be re- quired that an operation is carried out with - To open the bonnet, insert the tool (1) in the front slit open bonnet and running engine.
Page 172: Tool Box
Maintenance TOOL BOX The tool box position may vary according to tractor model. The tool box (if equipped) is located in front of the front part of the cab. The tool box can be removed by removing the retaining pin, located at the centre back of the tool box. Lift the tool box from the bottom outwards and upwards.
Page 173 Maintenance LUBRICANTS AND CAPACITIES COMPONENT Q.ty litres SPECIFICATIONS AMBIENT TEMPE- AGROLUBE SPECIFICATIONS RATURE AGROLUBE MUREX Concentrated antifreeze fluid to be -8° -15° -25° -35° Degrees °C used in the following percentages: COOLING CIRCUIT 17,5 Specifications: GM 1899M (1970); FORD ESE-M97B Viscosity at Viscosity at FUEL TANK...
Page 174 Maintenance SERVICING YOUR TRACTOR Engine Hour meter All tractors continued value, operation and reliability de- pend to a large extent on regular servicing. The tractors have been designed to provide easy daily and routine Use the engine hour meter, along with the Service Charts access. on the following pages, to service your machine at the correct intervals. When servicing your tractor ONLY use original service parts, oils, lubricants, coolants, filters etc. which are With the key switch in the ON position, the engine hour released or are approved, to avoid affecting the working meter shows the actual hours the engine has run the life of this tractor.
Page 175 Maintenance Service Indicator Lamps And Gauges First service operations After the first 50 hours • Change the engine oil and relative filter cartridge. After this, change the engine oil and engine oil filter at the intervals given in the ‘Routine Maintenance Table’. • Replace the fuel filters after the first 50 work hours. After this, replace the fuel filters at the intervals specified in the “Routine Maintenance Table”. • Hydraulic circuits: clean the filter on the intake of the steering and power lift circuit pumps, then clean it after every 250 hours service. • Replace the filter on the delivery of the steering circuit, then replace it every 250 hours service. • Warning and indicator lamps (see above) indicate the con- Check to make sure that all bolts, screws and nuts dition of the monitored system. If a lamp goes on when are correctly torqued. the engine is running, a service or repair are required. • Check all oil levels. If necessary, top up with oil of the prescribed type. The operation of the indicator lamps and gauges is •...
Page 176 Maintenance OPERATION Routine maintenance guide REQUIRED SERVICE POINTS Every 10 hours (or daily) (Note 1) General tractor inspection (Note 2) Front wheel nuts (Notes 3-4) Rear wheel nuts (Notes 3-4) Fuel level Transmission/hydraulic oil level 178 Engine oil level Coolant recovery reservoir level Pneumatic trailer brakes reservoir (if equipped) Every 50 hours (or weekly) (Note 1) Air pressure in tyres (Note 3) Fuel water trap - fuel filter Radiator and coolers Engine air filter valve (Note 7) (change every 1000 hours) (if equipped) Engine dry air filter cartridge (Notes 5-7) Cab air recycle filter (Note 6) Brake fluid reservoir Every 100 hours (or every 2 weeks) (Note 1) Brake adjustment Parking brake engagement check Oil level in front axle housing and front epicyclical final drives...
Page 177 Maintenance OPERATION Routine maintenance guide REQUIRED SERVICE POINTS Every 1000 hours (or once a year) Cooling system anti-freeze fluid (yearly before winter) Tappet gap 208 Fuel Injectors Transmission/hydraulic oil X 209 Steering cylinder ball joints Front axle differential and planetary oil, 4WD X 210 Starter motor and alternator Engine air intake system Engine primary air filter (Notes 5-7) X 213 Engine secondary air filter X 213 Dust discharge valve of engine air filter X 214 Cab intake air filter (Note 6) X 215 Grease door locks and hinges Air conditioner compressor (if equipped) Every 2000 hours (or every 2 years)
Page 178 Maintenance 10 HOURS OR DAILY SERVICE CAUTION: If you need to open the bonnet, follow the procedure indicated under “How to open the bonnet”. WARNING: Always use specific personal safety devices for each operation. WARNING: Maintenance operations must be carried out with the engine off. Check that the gear and the par- king brake are both engaged and that the ignition key has been removed.
Page 179 Maintenance 10 HOURS OR DAILY SERVICE Check fuel level WARNING: Hydraulic oil or diesel fuel leaking under pressure can penetrate the skin and [4.1.l] cause infection or other injury. To prevent injury: release all pressure, before discon- necting fluid lines. Before applying pressure, make sure all connections are tight and components are in good condition.
Page 180 Maintenance 10 HOURS OR DAILY SERVICE Oil level: transmission, power lift circuit and steering circuit, rear final drives Check at regular intervals the oil level in the mechanical transmission and in the power lift and steering circuits. Park the tractor on flat ground, stop the engine and lower the power lift links. Remove the dipstick (1) and check the oil level . NOTE: Allow the oil to settle in the transmission and rear final drives before checking the level.
Page 181 Maintenance 10 HOURS OR DAILY SERVICE Engine oil level For the engine, it is necessary to use a detergent oil Sup- plement 3 as indicated in the Lubricants and Fuels Chart. Detergent oils contain additives that reduce corrosion, oil oxidation and deposits and have a high dispersion power of carbon matters produced by combustion. WARNING: The following operations must be carried out with the engine off. Check that the gear and the parking brake are both engaged and that the ignition key has been removed.
Page 182 Maintenance 10 HOURS OR DAILY SERVICE Drain pneumatic trailer brake reser- Check coolant level voirs (if equipped) WARNING: Always use specific personal safety devices for each operation. Beware of burns caused by hot water and engine parts. Operate the drain valve plunger under each reservoir to Check the coolant level when the coolant is cold and with drain any water which has collected. the engine stopped. DO NOT REMOVE THE RADIATOR CAP .
Page 183 Maintenance 10 HOURS OR DAILY SERVICE Drain Fuel/Water Separator During running-in, replace the fuel filters after the first 50 work hours. Afterwards, replace the fuel filters after every 500 hours service. Regularly drain off the water that collects from the cock of the water/fuel separator filter (1).
Page 184 Maintenance 50 HOUR MAIN SERVICE WARNING: To open the bonnet, follow the procedure indicated under “How to open the bonnet”. WARNING: Always use specific personal safety devices for each operation. Beware of burns caused by hot water and engine parts. [4.1.n] Clean grille screens and radiator OPERATION 3...
Page 185 Maintenance 50 HOUR MAIN SERVICE WARNING: To open the bonnet, follow the procedure indicated under “How to open the bonnet”. WARNING: Always use specific personal safety devices for each operation. Beware of burns caused by hot water and engine parts. [4.1.n] Engine air filter discharge valve Dry air filter outer cartridge...
Page 186 Maintenance 50 HOUR MAIN SERVICE Clean cab air recirculation filter WARNING: Always use specific personal safety devices for each operation. If working in very dusty environment, the cab air recircula- tion filter should be cleaned either at suitable intervals or every 50 work hours. OPERATION 1 Remove the four screws from the recirculation grille. OPERATION 2 Remove the recirculation grille and the filter. OPERATION 3 Clean the filter using mild soap and water. Rinse with clear water and squeeze out the excess. OPERATION 4 Install the filter in the recirculation grille. OPERATION 5 Install the grille and filter. Install and tighten the screws.
Page 187 Maintenance 50 HOUR MAIN SERVICE Brake fluid reservoir At suitable intervals, check the level of the fluid in the brake reservoir. The reservoir (1) must always be kept full. Top up only with the correct brake fluid, as indicated in the Lubricants and Fuels chart. Bleeding air from the rear brake cir- cuit It becomes necessary to bleed the circuit when air enters owing to lack of oil in the relative reservoir or when the braking system is serviced. This operation should be carried out by specialized per- sonnel. If, however, you decide to do it yourself, proceed in the following way. WARNING: See the Lubricants and Fuels chart to re- WARNING: To open the bonnet, follow the procedure place and top up oil in the brake circuit (1).
Page 188: Adjusting The Brakes
Maintenance 100 HOUR MAIN SERVICE Adjusting the brakes Rear brakes Check the efficiency of the braking system regularly. The braking system must be adjusted when the free travel of the pedals (A) becomes excessive and the pedals are near to end of travel. Proceed in the following way to restore free pedal travel to its normal value of about 3.5 cm (1.4 in.) (dimension A): 1 - First make sure that there is no air in the hydraulic brake circuit. Bleed if necessary. (The presence of air in the circuit is normally denoted by a spongy braking action). 2 - Jack up the rear wheels of the tractor. 3 - Make sure that the parking brake is off. 4 - Free the brake pedals by raising the lock. 5 - Unscrew the check nut (1). Slowly tighten the adju- ster nut (2) until you can no longer turn the wheel by hand.
Page 189 Maintenance 100 HOUR MAIN SERVICE Check parking brake engagement WARNING: Always use specific personal safety devices for each operation. Beware of burns caused by hot Make sure that the ratchet locking mechanism of the tractor parts. [4.1.n] parking brake is secure and reliable. The parking brake hand lever is directly linked to the brake pedals.
Page 190 Maintenance 100 HOUR MAIN SERVICE Front axle oil level 4WD front axle Regularly check the oil level in the differential of the front axle and in the front axle side final drives. 1. Park the tractor on level ground 2. Position the final drive plugs (1) on the wheel center line. Remove the plugs and check the level. Top up if necessary with oil of the specified type through the plugs themselves..
Page 191 Maintenance 100 HOUR MAIN SERVICE General lubrication Lubricate the grease points every 100 hours or more often, depending on the working conditions. Grease Points NOTE: Use lithium grease of the prescribed type. NOTE: In severe conditions lubricate these points more frequently. NOTE: Lubricate if not used frequently and also after wash- ing with water pressure hose. Grease nipples on brake control cross link, two points.
Page 192 Maintenance 100 HOUR MAIN SERVICE 4WD front axle greasing Lubricate the following greasing nipples every 100 hours or more frequently, depending on work condi- tions. Grease Points NOTE: Use lithium grease of the prescribed type. NOTE: In severe conditions lubricate these points more frequently. NOTE: Lubricate if not used frequently and also after wash- ing with water pressure hose.
Page 193 Maintenance 100 HOUR MAIN SERVICE Maintenance of the front PTO and front 3 point hitch (if equipped) WARNING: Always use specific personal safety devices for each operation. Beware of burns caused by hot tractor parts. [4.1.n] Grease Points NOTE: Use lithium grease of the prescribed type. NOTE: In severe conditions lubricate these points more frequently.
Page 194 Maintenance 100 HOUR MAIN SERVICE Check and clean cab air intake fil- Check and clean the intake air filter every 100 hours or more often if needed. Keep the air filter clean for efficient operation of the heating and cooling system. Replace with a genuine part if damaged or when the filter can not be cleaned. WARNING: Cab air filters remove dust in the air, but are not capable of removing chemi- cals used in spraying crops or in weed con- trol.
Page 195 For best performance, this filter should be serviced more A. Tap it on a flat surface. often when working in particularly dusty environment. Replace with a genuine McCormick part if damaged or B. Blow it clean with compressed air. when the filter can not be cleaned. METHOD A IMPORTANT: Respiratory protection equipment and pro- tective clothing appropriate to the environment that the filter has been in contact with MUST be used during the cleaning of the filter.
Page 196 Maintenance 250 HOUR MAIN SERVICE Battery Check electrolyte level [4.1.l] Periodically check the level of battery acid and add WARNING: Always use specific personal safety devices for each operation. distilled water if necessary. WARNING: BATTERY ACID CAUSES SEVERE BURNS. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Antidote: EXTERNAL - Flush with water.
Page 197 Maintenance 250 HOUR MAIN SERVICE WARNING: To open the bonnet, follow the procedure indicated under “How to open the bonnet”. WARNING: Always use specific personal safety devices for each operation. Beware of burns caused by hot water and engine parts. [4.1.n] Fan and alternator belts Periodically check the tension of the alternator and fan...
Page 198 Maintenance 250 HOUR MAIN SERVICE Oil filters of the transmission and of the steering and power lift circu- The following operations for the transmission oil filters must be carried out not only at the prescribed intervals, but also whenever the indicator lights on the instrument panel come on. Warning lights for transmission and hydraulic cir- cuit oil filter blockage. 1 - Fixed light: Orange warning light for blockage of the oil filter of transmission and hydraulic circuit.
Page 199 Maintenance 250 HOUR MAIN SERVICE Filter on the delivery of the steering circuit. WARNING: Change the paper filter on the delivery after the first 50 hours service and then after every 250 hours. Also change the filter whenever the red indicator lights on the instrument panel come on.
Page 200 Maintenance 250 HOUR MAIN SERVICE Greasing points - Rear tow hooks Grease Points - Pick up Hitch ( if (according to fitted type) equipped) Various types of rear tow hooks are available depending on approvals and regulations valid in each country. Locking latches for auto hitch Moving parts should be cleaned and greased according to the fitted type of tow hook and drawbar. Check torque of bolts and nuts of the tow hook (according to the fit- ted type) Check the torque values of all bolts and nuts for ALL hitch types before the delivery, then every 250 hours.
Page 201 Maintenance 500 HOUR MAIN SERVICE For the engine, it is necessary to use a detergent oil Supplement 3 as indicated in the Lubricants and Fuels Chart. Deter- gent oils contain additives that reduce corrosion, oil oxidation and deposits and have a high dispersion power of carbon matters produced by combustion. WARNING: The following operations must be carried out with the engine off. Check that the gear and the parking brake are both engaged and that the ignition key has been removed. Personal safety devices must be worn for the indicated operations. Beware of burns caused by hot oil and engine parts.
Page 202 Maintenance 500 HOUR MAIN SERVICE To change the fuel filters - Mechanical engine Mod. X60.20-X60.30-X60.40 During running-in, the fuel filters should be changed for the first two times after every 50 hours. After- wards, replace the fuel filter cartridges every 500 hours. NOTE: Filter positions may vary according to tractor model.
Page 203 Maintenance 500 HOUR MAIN SERVICE Change Fuel/Water Separator Filter Element - Mechanical engine X60.20-X60.30-X60.40 The following operations must be carried out with the engine off. Check that the gear and the parking brake are both engaged and that the ignition key has been removed. WARNING: Always use specific personal safety devices for each operation. If you need to open the bonnet, follow the procedure indicated under “How to open the bonnet”. Beware of burns caused by hot water and engine parts.
Page 204 Maintenance 500 HOUR MAIN SERVICE To change the fuel filters - Electronic engine Mod. X60.50 During running-in, the fuel filters should be changed for the first two times after every 50 hours. After- wards, replace the fuel filter cartridges every 500 hours. NOTE: Filter positions may vary according to tractor model.
Page 205 Maintenance 500 HOUR MAIN SERVICE Change Fuel/Water Separator Filter Element - Electronic engine X60.50 The following operations must be carried out with the engine off. Check that the gear and the parking brake are both engaged and that the ignition key has been removed. WARNING: Always use specific personal safety devices for each operation. If you need to open the bonnet, follow the procedure indicated under “How to open the bonnet”. Beware of burns caused by hot water and engine parts.
Page 206 Maintenance 500 HOUR MAIN SERVICE Remove Air From Fuel System - Electronic engine X60.50 Air can enter the fuel system in the following situations: Mod.X60.50 On Mod.X60.50 tractors use the following procedure to A. If the fuel tank becomes empty or is low on fuel. remove air from the fuel system. B. After fuel system parts have been removed for service OPERATION 1 or repairs. Make sure there is fuel in the tank. C. If the tractor has been in a garage for a long period Turn the key switch to ON to energize the cut off solenoid. of time. OPERATION 2 IMPORTANT: DO NOT crank the engine before removing all the air from the fuel system or the fuel injection pump can be damaged.
Page 207 Maintenance 500 HOUR MAIN SERVICE Check function of the operator presence switch Check the switch for correct function every 500 hours of operation or at least once annually. When doing the fol- lowing checks, do so in a clear open area with no other persons or objects near the tractor: OPERATION 1 Engage the parking brake and a gear. Get up from the seat: the buzzer should sound. OPERATION 2 While sitting on the operator's seat, with the engine run- ning at low idle speed, and the F-N-R lever in NEUTRAL, without engaging the parking brake, engage the 1st gear and the slow range, and release the clutch pedal. Stand up out of the operator's seat while holding onto the steering wheel and move the F-N-R lever from NEUTRAL to either WARNING: Always use specific personal safety devices FORWARD or REVERSE. The buzzer sounds and the indi- for each operation.
Page 208 Maintenance 500 HOUR MAIN SERVICE CAUTION: If you need to open the bonnet, follow the procedure indicated under “How to open the bonnet”. WARNING: Always use specific personal safety devices for each operation. WARNING: Maintenance operations must be carried out with the engine off. Check that the gear and the parking brake are both engaged and that the ignition key has been removed.
Page 209 Maintenance 500 HOUR MAIN SERVICE OPERATION 6 WARNING: Always use specific personal safety devices for each operation. Beware of burns caused by hot tractor parts. [4.1.n] WARNING: If the locking latches do not engage correctly thecable and/or the lift rods may need adjustment.
Page 210 Maintenance 1000 HOUR MAIN SERVICE Anti-freeze in engine cooling sys- WARNING: To open the bonnet, follow the procedure indicated under “How to open the bonnet”. Once a year, before winter, check the anti-freeze fluid in WARNING: Always use specific personal safety devices the engine cooling system. for each operation. Beware of burns caused by hot See the procedure to check the engine coolant level and water and engine parts.
Page 211 Maintenance 1000 HOUR MAIN SERVICE Oil changes for the transmission, steering circuit and power lift hydraulic circuit, rear final drives. NOTE: It is advisable to change the oil for the first time after 500 hours. After this, change the oil after every 1000 hours service.
Page 212 Maintenance 1000 HOUR MAIN SERVICE WARNING: Always use specific personal safety devices for each operation. Beware of burns caused by hot tractor parts. [4.1.n] Oil changes in 4WD final drive Oil changes in 4WD front axle Front side final drives Axle housing Position the final drive plugs (1) downward. Place a vessel Place a vessel under the plug (1), Remove the plug and...
Page 213 Maintenance 1000 HOUR MAIN SERVICE WARNING: Always use specific personal safety devices for each operation. Beware of burns caused by hot tractor parts. [4.1.n] Starter motor The starter motor (1) should be thoroughly cleaned at least once a year. Particularly check the condition of the brushes and collector. Alternator Have the condition and operation of the alternator checked by a specialized workshop.
Page 214 Maintenance 1000 HOUR MAIN SERVICE Check engine air induction system Check all hoses for damage and that hose clamps are WARNING: Always stop the engine and remove the tight, correct torque = 3.4 Nm. ignition key before removing the filter elements. The primary (outer) filter is a high capacity filter designed Filter restriction indicator lamp to provide optimum protection to the engine.
Page 215 Maintenance 1000 HOUR MAIN SERVICE CAUTION: If you need to open the bonnet, follow the procedure indicated under “How to open the bonnet”. WARNING: Always use specific personal safety devices for each operation. WARNING: Maintenance operations must be carried out with the engine off. Check that the gear and the par- king brake are both engaged and that the ignition key has been removed.
Page 216 Maintenance 1000 HOUR MAIN SERVICE OPERATION 8 WARNING: Before cleaning the filter with compressed air, wear individual protections, Before installing the primary (outer) element, apply talcum in particular goggles and a mask to protect your airways. powder or similar to the inner seal face before installing the filter. Install with closed end outwards. Install the OPERATION 6 primary (outer) element, closed end outwards. NOTE: NEVER use a petroleum base lubricant on the seal area.
Page 217 Maintenance 1000 HOUR MAIN SERVICE Change cab air intake filter AC Compressor WARNING: Respiratory protection equipment Have the air conditioning system operation checked. Also and protective clothing appropriate to the check the lubricating oil level in the compressor (1). environment that the filter has been in con- tact with MUST be used during the cleaning of the filter.
Page 218 Maintenance 2000 HOUR MAIN SERVICE CAUTION: If you need to open the bonnet, follow the procedure indicated under “How to open the bonnet”. WARNING: Always use specific personal safety devices for each operation. WARNING: Maintenance operations must be carried out with the engine off. Check that the gear and the par- king brake are both engaged and that the ignition key has been removed.
Page 219 Maintenance 2000 HOUR MAIN SERVICE Precautions against freezing tem- Fuel system general inspection peratures Every 2000 hours of operation see your Dealer for an inspection of the fuel system and fuel injection nozzles. The system is filled with a mixture of water and antifreeze. Moreover, have the engine checked for tuning-up. Add the proportion of antifreeze given in the following table. To prevent dirt or water from reaching the injection parts and causing damage and decreased performance, use clean fuel, keep the fuel tank full, drain any water from the Degrees C°...
Page 220 Maintenance 2000 HOUR MAIN SERVICE Fuel tank The fuel tank is cleaned by removing the plug (1). NOTE : Drain off the sludge when the tank is almost empty and only after having placed a suitable vessel under the drain plug. NOTE: Air in the fuel circuit makes it difficult to start the engine.
Page 221 Maintenance GENERAL MAINTENANCE CAUTION: If you need to open the bonnet, follow the procedure indicated under “How to open the bonnet”. WARNING: Always use specific personal safety devices for each operation. WARNING: Maintenance operations must be carried out with the engine off. Check that the gear and the par- king brake are both engaged and that the ignition key has been removed.
Page 222 Maintenance GENERAL MAINTENANCE Bleeding air from the front brake circuit After having carefully carried out operations 1 to 7 to bleed the rear brakes, proceed in the following way: 1 - Depress both brake pedals at the same time. Use the special coupling lock to keep the pedals together. Unscrew the bleed screw (4) on the on-off valve (3) until bubble-free oil flows out. Re-tighten the screw and release the pedals. 2 - D epress both pedals at the same time and slacken off the two bleed screws (5) at the rear of the central part of the front axle. Repeat this operation until bubble-free oil flows out. NOTE: if the tractor is equipped with a valve for hydraulic trailer braking, it will also be necessary to bleed off any air in the piloting tube of this valve.
Page 223 Maintenance GENERAL MAINTENANCE Hydraulic trailer brakes To brake the trailer along with the tractor, the flexible tube of the trailer brakes must be connected to the fitting at the rear of the tractor (1). Always make sure that the two parts are clean before you connect them, to ensure that the various components operate in a perfect way. WARNING. Trailer brake approved for ITALY. When the tractor is operating, it is absolutely essential to engage the parking brake when either connecting or detaching the tube that links the tube of the trailer braking system to the quick coupling.
Page 224 Maintenance GENERAL MAINTENANCE Air conditioning system (if equipped) WARNING: Never attempt to open the air conditioning system. Liquid refrigerant can cause severe and painful frostbite. Contact your dealer, who is experienced in servicing and handling of refrigerants. AIR CONDITIONED CAB The mixture of oil and coolant in the air conditioning system is under pressure. Never ever loosen any The cab can be fitted with an air conditioning system on...
Page 225: Specifications
Maintenance GENERAL MAINTENANCE PERIODICAL INSPECTIONS GENERAL CAB MAINTENANCE (ALL At least once every three months: VERSIONS) – remove any foreign bodies from between the After servicing the external parts of the cab, proceed with evaporator and condenser fins; the following inspections: – check the tension of the compressor belt; 1. Periodically check to make sure that no water has collected in the zones covered with mats or upholstery. – allow the engine to run at a rate of 1500 rpm. In 2. Protect the hinges and locks of the doors, sun roof the meantime keep the dehydrator filter under and openable windows with water-repellent lubricating...
Page 226 Maintenance GENERAL MAINTENANCE Viscous fan drive Inspection and maintenance of safety belts (if equipped). WARNING: Always use specific personal safety devices for each operation. Beware of burns caused by hot WARNING: Securely fasten your seat belt. Your tractor parts. tractor is equipped with a ROPS cab or frame for your protection.
Page 227 Maintenance PUTTING THE TRACTOR INTO STORAGE Preparing for long idle periods Removing the tractor from storage WARNING: At the end of the idle period, when Take the following precautionary measures when your you start the engine again, pay particular tractor is not going to be used for a long period of time. attention to the instructions about starting the engine in the Operation chapter.
Page 228 Maintenance Fire prevention To carry out the operations described hereunder, see the sections relative to the maintenance of the various parts. Always use specific personal safety devices for each service operation. Fire risks can be minimized by frequent removal of accu- mulated crop material, trash or debris from the machine. Remove all crop material, trash or debris at the start of each working day. Take extra care to make sure the engine area and exhaust system are clean. It is your responsibility to remove and/or clean your ma- chine on a regular basis. Fire risk can also be minimized by prompt repairing of leaks and cleaning up fuel and oil spills. Engine fuel is flammable and can cause a fire or an explosion. DO NOT fill the fuel tank or service the fuel system near an naked flame, welding, burning cigars, cigarettes etc.
Page 229 Electrical system Section 8 Electrical system...
Page 230 Electrical system ELECTRICAL SYSTEM Battery With a maintenance free battery, it is normally not neces- sary to frequently check the electrolyte and charge levels. It is advisable, however, to periodically check the level of battery acid and to add distilled water if required. If you need to top up too often, have the battery charging system checked. Check the level of the electrolyte in each element. If top- ping up is required, proceed as follows, with the engine stopped, the battery at rest and cold, and the tractor parked on level ground. 1 - Disconnect the terminals (1) and remove the guard (2). 2 - Remove the plugs and check the liquid level. 3 - Slowly pour in the distilled water, until the top edge Side battery. of the plates is completely covered. 1- Terminal; 2 - Guard.
Page 231 Electrical system Removal and installation of batter- WARNING: Always use specific personal safety devices for each operation. OPERATION 1 Recommendations The following rules must be respected to preserve an efficient battery: - Keep the battery clean and dry, particularly on top. - If the battery acid must be topped up, use distilled water only, - Make sure that the cable terminal nuts are well fixed to the battery terminals. - Always use a wrench and not pliers to tighten and loosen the terminal nuts.
Page 232 Electrical system Battery system servicing Follow these general rules to prevent damage to the WARNING: Always use specific personal safety devices electrical system. for each operation. - Before working on the electrical system, disconnect the battery cables, ground cable first, or turn off the master switch (if equipped) and remove the key. - Do not make a reverse battery connection. - When you use a booster battery for starting, connect negative (-) to negative (-) and positive (+) to positive (+). Use the booster battery connections provided on the tractor (if equipped). See Booster Battery Connections in this manual. - When charging the tractor batteries, use the auxiliary battery connections on the tractor (if equipped). Do not attach directly to the battery terminals. Do not use a battery charging machine for starting the...
Page 233 Electrical system Connection of a booster battery to the positive battery terminal on the tractor IMPORTANT: When connecting a booster battery to the tractor positive terminal, make sure the batteries are the same voltage (i.e. 12 Volt) and the electrolyte is at the cor- rect level.
Page 234 Electrical system Starter motor Electrical system - Warnings It is absolutely forbidden to make changes or connections The starter motor should be thoroughly cleaned after to the data interconnecting lines between control periods of 1000 hours or at least once a year. Parti- units (CAN-BUS lines). They are to be considered as cularly check the condition of the brushes and collector. INVIOLABLE. All diagnostic and maintenance operations may only be carried out by authorized technicians, with specific appliances approved by Landini.
Page 235 Electrical system FUSE LOCATION AND IDENTIFICATION Fuses on dashboard - View from the front The fuses give protection to the electrical circuits of the tractor and cab. To service the fuses remove the left hand side panel from the front console. To replace a fuse, pull the fuse out of the clips and push a new fuse in. NOTE: Before replacing a blown fuse with a new, equivalent one, the cause that led to the fault should be ascertained and removed. WARNING: To carry out this operation, engage the first gear, turn off the engine, engage the parking brake and remove the ignition key.
Page 236 Electrical system Relays on dashboard - View from the front Relay Function KA1 Starter motor relay Relay 30A KA2 Rear field lights on roof, rear fenders, NAO 7-pin socket Relay 30A KA3 Differential lock and brake lights, turn indicator lights, headlights, NAO 7-pin socket and air seat Relay 30A KA4 Relay for driving beams, dipped beams, rear and front window wiper, rear and front window washer Relay 30A KA5 Field lights corner light, on front of roof and front safety handles Relay 30A KA5 Instrument, feed line to mechanical and electronic engine, transmission controller, four-wheel drive, front PTO (if equipped), trailer brakes (if equipped) and electronic hitch controller Relay 30A KA6 Brake lights control relay Relay 30A KB1 Air conditioning safety relay, Deluxe roof and Low Profile roof Relay 30A KB2 Differential lock self-retaining relay Relay 30A KB3...
Page 237 Electrical system NOTE: Before replacing a blown fuse with a new, WARNING: Always use specific personal safety devices equivalent one, the cause that led to the fault should be for each operation. ascertained and removed. WARNING: To carry out this operation, engage the first gear, turn off the engine, engage the parking brake and remove the ignition key.
Page 238 Electrical system Headlights As you can use your tractor on public roads, the lighting must comply with the applicable traffic and road regu- lations. Periodically check headlight alignment in the following way: Checking headlight alignment - Halt the tractor on level ground facing a shaded wall (preferably white). The tractor must be unloaded and the tyres correctly inflated. Mark two crosses on the wall in front of the tractor headlight centres. - Reverse the tractor 5 meters (16.4 ft) away from the wall.
Page 239 Electrical system 7-pin power socket for trailer A 7-pole power socket is installed on the rear of the trac- tor (1). This socket is used to connect the light circuits of the trailer. WARNING: Always use specific personal safety devices for each operation. Rest Of World Tractors North American Tractors Connections Connections TERMINAL N. CIRCUIT (CABLE COLOUR) 1 ..............GROUND (WHITE) 2 ............. FIELD LIGHTS (BLACK) Connections and correspondences for 7-pole power socket according to ISO-SAE standards.
Page 240 Electrical system Three-pin electrical sockets, 12V NOTE: The correct 3 pin plug to fit the sockets can be obtained from your dealer. On the right side of the dashboard FRONT VIEW A. NORTH AMERICA B. OTHER COUNTRIES Connections 1- Positive, key operated - Max. load 5A 2- Positive direct to battery - Max. load 25A 3 - Negative - Ground WARNING: Always use specific personal safety devices for each operation. On the right-hand console behind the seat. Two auxiliary electrical power sockets are provided inside the operators compartment for connecting monitors, implement controllers, C.B. radios, and other 12 volt...
Page 241 Electrical system IMPLEMENT CABLE ACCESS Access is provided for implement cables in the right hand To fit cables: corner of the rear window. OPERATION 1 Open the rear window and remove the rubber grommet by pulling upward. OPERATION 2 Cut the grommet down (1) into the centre of the circle area and then cut out the centre (2) to fit the cable(s). OPERATION 3 Fit the grommet over the cable(s) and install the grommet and cable(s) into the slots in the cab. OPERATION 4 Close the rear window. WARNING: Always use specific personal safety devices for each operation.
Page 242 Electrical system Page left intentionally blankf...
Page 243 Technical specifications ARGO TRACTORS constantly updates its range of products and therefore reserves the right to undertake modifications, if appro- priate ad necessary, without prior notice. All data and information contained in this publication could be subject to changes. Dimensions and weights are only approximate values and the equipment shown by the pictures could not correspond to stan- dard models.
Page 244 Technical specifications APPROXIMATE TRACTOR DIMENSIONS IMPORTANT: The dimensions shown on the following pages are only approximate. They depend on many factors, such as tyre size, ballast, amount of fuel, tyre pressure etc. ALL dimensions are in mm. DIMENSIONS in mm De Luxe Cab A - Height at cab roof 2710...
Page 245: Air Intake System
Technical specifications ENGINE X60.20 Type ............1104D-44TA Turbocharged Aftercooler, direct injection, four-cylinder, four-stroke ISO max. power rating ..........................92,5 HP / 68 kW Rated engine speed ............................... 2200 rpm Max. torque ................................384 Nm Max. torque rating ..............................1400 rpm X60.30 Type ............1104D-44TA Turbocharged Aftercooler, direct injection, four-cylinder, four-stroke ISO max. power rating ..........................102 HP / 74.9 kW Rated engine speed ............................... 2200 rpm Max. torque ................................412 Nm Max. torque rating ..............................1400 rpm X60.40 Type ................. 1104D-44TA Turbocharged, direct injection, four-cylinder, four-stroke ISO max. power rating ..........................110.2 HP / 81 kW Rated engine speed ............................... 2200 rpm Max. torque ................................410 Nm Max. torque rating ..............................1400 rpm X60.50 Type ............... 1104D-E44TA Turbocharged, direct injection, four-cylinder, four-stroke Max. ISO power rating, Dual Power at 2000 rpm ..................112 HP / 82.1 kW ISO power rating at 2200 rpm ......................101.45 HP / 74.6 kW Max. ISO power rating, Dual Power at PTO with engine at 2200 rpm ............121 HP / 89 kW Rated engine speed ...............................
Page 246: Rear Axle
Technical specifications Rear axle CAUTION: The technical specifications given here are only of a general kind. For technical specifications of each market, please refer to the information material Rear axle with bevel gear pair and epicyclical rear final supplied by your Dealer. drives.
Page 247 Technical specifications Power take off Brakes [4.2.d] Independent mode Rear brakes PTO engaged through a hydraulic clutch with electro- hydraulic control by means of a button in the cab. Multidisc oil-cooled brakes mounted on rear differential Engagement is modulated by a hydraulic accumulator. half shafts. The PTO driveline is stopped through an electro-hydrauli- cally controlled brake by means of the same switch used Number of friction discs: ......12 (6 per side). to control the PTO itself. Friction material ........resin-graphite. Available in the following configurations: Two speeds: Hydraulic control by means of the two pedals on the 1st type: 540/540ECO RPM driver’s right: the two pedals can be coupled together by 2nd type: 540/1000 RPM...
Page 248 Technical specifications 4WD front axle Track width adjustment Front axle in spheroidal cast iron pivoting around two To adjust the track width of the front axle and rear axle, central supports. see the tables in the “Operation” chapter. Electro-hydraulic front drive engagement by means of hydraulic clutch. Steering components Spring-On/Pressure-Off type. Power steering Propeller shaft without universal couplings installed along the longitudinal axis of the tractor. Power steering system controlled by the steering wheel. Transmission through central differential and epicyclic Telescopic steering wheel adjustable in height and tilt.
Page 249 Technical specifications Hydraulic circuit Three-point linkage [4.2.g] Two stage hydraulic gear pump powered directly by the Class 2 three-point linkage with side stabilizers to limit gears of the timing system with 40 micron double paper implement swing. filter on the intake. Adjuster crank on RH vertical link rod. Optional hydraulic The two pump stages supply: adjuster jack. 1st Stage: delivery 29,9 l/min at a 2200 RPM engine rate. Adjuster crank of LH link rod with two positions at the 20 micron paper filter on the delivery. lower end: one fixed and the other sliding. Supplies: - The power steering circuit, max. operating pressure 150 +/- 5 bar. Lower links with quick hitch mechanisms on request.
Page 250 Technical specifications Electrical system Voltage: 12 V negative ground. Cab and platform tested to OECD international standards. Noise level complies with EEC standards. Platform completely supported on Silent Block dampers Battery and cab in pressed structural steel with isothermal blue- tinted glass panes. Battery for mild climate Heating, ventilating and air-conditioning systems. Openable roof with wide visibility in an upward direction. X60.20-X60.30-X60.40: 1 X60.50: 2 Maintenance free. Complies with SAE J537 standards. Optional extras Technical details: Voltage ..............12 V Capacity ..............100 Ah - Up to four open center auxiliary control valves with hydraulic hoses and “Push-Pull” couplings. Available Battery for mild climate in various versions.
Page 251 Technical specifications Noise levels as perceived by the operator [4.3] THE FOLLOWING TABLES GIVE THE NOISE LEVEL VALUES, MEASURED FROM THE DRI- VER’S SEAT IN INSTANTANEOUS CONDITIONS IN COMPLIANCE WITH STANDARDS 2009/76/EC (DBA) - ANNEX II (WITHOUT LOAD) - AND WHEN DRIVING IN COMPLIANCE WITH STANDARD 2009/63/EC (DBA).
Page 252 Technical specifications INFORMATION PAGE ON VIBRATION LEVELS OF THE TRACTOR EXPOSITION TO VIBRATIONS [4.4] WARNING: The vibration level transmitted to the body as a whole depends on different parameters, some of them relating to the IMPORTANT: More information on Whole Body Vibra- machine, others to the terrain, others to the tion (WBV) on agricultural tractors can be found in more type of work and to any connected machine...
Page 253 Technical specifications ‘CE’ DECLARATION OF CONFORMITY “ Every tractor is accompanied by a CE Declaration of Conformity to Directive 2006/42/EC that you should receive in original together with the tractor. This Declaration indicates with which European Directive the machine complies”. The following picture is a fac-simile copy of such CE Declaration of Conformity. Argo Tractors S.p.A. 42042 Fabbrico [RE] Italia via G. Matteotti, 7 t. +39.0522.656111 f. +39.0522.656476 webmaster@argotractors.com www.argotractors.com...
Page 254 Technical specifications Issue of authorization To install any type of mounted or semi-mounted equipment not provided for by road traffic laws, it is mandatory to request the express written authorization of the vehicle manufacturer. We insist at any rate on our recommendation to mount always exclusively CE marked equipment complying with the Machinery Directive 2006/42/EC. Weights [4.2.h] Maximum weight declared by the manufacturer for road circulation IMPORTANT: DO NOT exceed the maximum load capacity of the tyres on your tractor. See Loads and Inflation Pressures recommended by tyre manufacturers. IMPORTANT: DO NOT exceed the local legal limitations of the axle loads and the total weight on the road. Maximum permitted tractor operating weight The MAXIMUM PERMITTED TRACTOR OPERATING WEIGHT includes the tractor, tractor equipment and ballast. The MAXIMUM PERMITTED AXLE OPERATING WEIGHT includes the tractor, tractor equipment, ballast and three-point hitch mounted equipment. Model Front kg Rear kg Total kg X60.20 3800 5300 7800 X60.30 3800 5300 7800...
Page 255 Technical specifications Implement attachment points [4.5.1.2]...
Page 256 Technical specifications This page has been left blank intentionally...
Page 257 Alphabetical index Adjustment of front track width ......158 Gearbox, XtraShift .............100 Adjustment of rear track width ....... 160 General information ............. 7 Adjustments, maintenance ......174 - 175 Ground speed tables, Xtrashift .........102 Air conditioner ............57 Air conditioner ............57 Air conditioning system ........174 - 175 Hand brake ..............117 Auxiliary control valves ..........131 Hazardous chemicals ..........192 Auxiliary electrical power sockets ......238 Headlights ..............236 Axle, 4WD - Steering stops ........157 Hydraulic hitch with electronic control .....126 Hydraulic trailer brakes ..........118 Battery ..............228 Before starting the engine ........92 Idle periods ...............225 Brakes................116 Indicator lamps and warning lamps ......63 Instrument cluster .
Page 258 Alphabetical index Safety ................9 Safety belts ..............46 Safety decals ............32, 36 Safety precautions ..........7, 13 Safety precautions before servicing ......168 Seats ................. 42 Starting procedure ............ 93 Steering wheel ............48 Stopping the tractor .......... 97 System checks ............14 Technical specifications ..........241 Three point hitch ............121 Towing attachments ..........140 Towing the tractor ............148 Tractor ballast ............162 Tractor identification ........... 6 Tractor start-up ............93 Tractor transport ............147 Transmission oil, level check and replacement ..................174 - 175 Transmission/hydraulic oil filter ...... 174 - 175 Travel speed .............102 Tyres ................149 Use of the tractor on public roads .......
Page 259 Contents Directive 2010/52/EC Operator’s manual Rex Orchard N° 2010/52/EC Section In particular or in addition to the requirements in standard ISO 3600:1996, the operator’s manual shall cover the following: adjustment of the seat and suspension related to the ergonomic position of the operator with respect to the controls and in order to minimise the risks from whole body vibration; use and adjustment of the system for heating, ventilation and air-conditioning, when provided; starting and stopping of the engine; 2, 5 location and method of opening of emergency exits; boarding and leaving the tractor; 2, 3 the hazard area near to the pivot axis of articulated tractors; use of special tools, if any are provided; safe methods used for service and maintenance; 2, 7 information about the interval of inspection of hydraulic hoses; instructions about how to tow the tractor; instructions about the safe use of jacks and recommended jacking points;...
Page 260 Contents Directive 2010/52/EC N° 2010/52/EC Section Noise declaration: The operator’s manual shall give the value of the noise at the operator’s ear, measured according to Directive 2009/76/CE of the European Parliament and of the Council and the noise of the tractor in motion measured according to Annex VI to Directive 2009/63/CE of the European Parliament and of the Council. Vibration declaration: The operator’s manual shall give the value of the vibration level measured according to Council Directive 78/764/EEC; Relevant operating modes of a tractor that can reasonably be expected and identified as contain- ing particular hazards are the following: work with front-end loader (risk of falling objects); forestry application (risk of falling and/or penetrating objects); 1, 2 work with crop sprayers, mounted or trailed (risk of hazardous substances). 1, 2 4.5.1 Front-end loader: 4.5.1.1 The operator’s manual shall outline the hazards associated with front-end loader work, and ex- plain how to avoid those hazards. 4.5.1.2 The operator’s manual shall indicate the fixation points on the body of the tractor where the front-end loader must be installed, together with the size and quality of the hardware to be used. If no such attachment points are foreseen, the operator’s manual shall prohibit the installation of a front-end loader. 4.5.1.3 Tractors fitted with programmable hydraulic sequencing functions shall provide information on how to connect the loader hydraulics so that this function is inoperable. 4.5.2 Forestry application: 4.5.2.1 In case of use of an agricultural tractor in a forestry application, the identified hazards are the following: toppling trees, primarily in case a rear-mounted tree grab-crane is mounted at the rear of the tractor;...
Page 261 Alphabetical index NOTE: This manual has been published for worldwide circulation. The standard and optional equipment and the availability of individual models may vary from one country to the next. McCormick reserves the right to undertake modifications without prior notice to the design and technical equipment at all times without this resulting in any obligation whatsoever to make such modifications to units already sold. Whilst every effort is made to ensure that the specifications, descriptions, photographs and illustrations in this manual are correct at the time of going to print, these are also subject to change without prior notice. The photographs and il- lustrations used in this manual may show optional equipment or may not show all standard equipment. Any reproduction or translation, even partial, is forbidden without the written authorization of McCormick.
Page 262 Alphabetical index...

This manual is also suitable for:

X60.40 X60.50 X60.30 X60.20

MCCORMICK X60 Series Operator's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for MCCORMICK X60 Series

Summary of Contents for MCCORMICK X60 Series

This manual is also suitable for:

Table of Contents
