4.4.2

Error Status

The significance of the Error Status digit depends on what
Primary Error Code is being reported. See Table 4-4.
Table 4-4: Error Status Digit
Status Digit
Status Error (Error Codes E0F0 - E142)
8 There is an error.
Parameter Error (Error Codes E150 - E1FA)
4 Value is too low.
8 Value is too high.
4.4.3

Unit ID

The Unit ID digit identifies which part of the RX System is
reporting a problem. See Table 4-5.
Table 4-5: Strata Unit ID Digit
Unit ID
1 Transmitter Unit (TXU)
4 Receiver Unit (RXU)
5 Receiver Control Unit (RCU)
Strata RX Operator's Guide/Tech Ref Manual
Meaning
4.5

Operational Problems

The information on the following pages will assist you in
troubleshooting problems that arise in the operation of your
Strata RX System.
Troubleshooting 4-10
