Miranda Kaleido-X16 User Manual page 382

Tally Interface Devices
Zodiak Production Switcher
2 In the Tools pane, select one of the logical sources you previously configured (see
"Assigning Zodiak Tallies, Input Names, and Output Names to Logical Sources" above)
from the filtered Channels/Sources list, and then drag it onto the appropriate monitor.
3 Repeat
appropriate monitors in your layout.
4 Click the first UMD whose dynamic text and tally reporting behavior you with to set,
after unlocking the composite monitor that contains it if applicable (see
Composite
5 In the Properties pane, click the Left tally source level box, and then select the alarm
level you wish to monitor.
Alarm level selection for the left tally in a UMD
6 Click the Right tally source level box, and then select the appropriate alarm level, if
applicable.
7 Click the Text label level box, and then select the text level you wish to monitor.
374
step 2 until you have assigned all the sources you wish to monitor to the
Monitor, on page 260).
Unlocking a
