2017 OWNER'S MANUAL
owner.ford.com
ford.ca
October 2016
First Printing
Owner's Manual
Focus
Litho in U.S.A.
HM5J 19A321 AA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FOCUS 2017 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ford FOCUS 2017

Summary of Contents for Ford FOCUS 2017

  • Page 1 2017 OWNER’S MANUAL owner.ford.com ford.ca October 2016 First Printing Owner’s Manual Focus Litho in U.S.A. HM5J 19A321 AA...
  • Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2016 All rights reserved. Part Number: HM5J 19A321 AA 201608 20160831132745...

  • Page 4: Table Of Contents

    Symbols Glossary..........7 Driver and Passenger Airbags....39 Data Recording..........9 Front Passenger Sensing System....40 California Proposition 65......11 Side Airbags.............42 Perchlorate............11 Driver Knee Airbag.........43 Ford Credit............11 Safety Canopy ..........44 Replacement Parts Recommendation........12 Crash Sensors and Airbag Indicator..45 Special Notices..........12 Airbag Disposal..........46 Mobile Communications Equipment.............13...
  • Page 5 Table of Contents Anti-Theft Alarm..........69 Information Displays General Information........91 Steering Wheel Trip Computer..........94 Adjusting the Steering Wheel....70 Information Messages.........95 Audio Control...........70 Voice Control.............71 Climate Control Cruise Control...........71 Manual Climate Control......103 Information Display Control......71 Automatic Climate Control......104 Heated Steering Wheel........72 Hints on Controlling the Interior Climate............106 Wipers and Washers Heated Windows and Mirrors....108...
  • Page 6 Table of Contents Front Parking Aid..........152 Unique Driving Character- istics Active Park Assist.........153 Rear View Camera........159 Auto-Start-Stop...........126 Cruise Control Fuel and Refueling Principle of Operation.........162 Safety Precautions........128 Using Cruise Control........162 Fuel Quality - E85........129 Fuel Quality - Gasoline.......130 Driving Aids Fuel Filler Funnel Location......130 Driver Alert............164 Running Out of Fuel........131...
  • Page 7 Table of Contents Automatic Transmission Fluid Roadside Emergencies Check............222 Roadside Assistance........189 Brake Fluid Check........222 Hazard Warning Flashers......190 Clutch Fluid Check - Manual Fuel Shutoff...........190 Transmission..........222 Jump Starting the Vehicle......191 Washer Fluid Check........223 Post-Crash Alert System......193 Changing the 12V Battery......223 Checking the Wiper Blades......224 Customer Assistance Changing the Front Wiper Blades..224 Getting the Services You Need....194...
  • Page 8 3 Troubleshooting......392 Motorcraft Parts - 2.0L.......272 Vehicle Identification Number....273 Accessories Vehicle Certification Label.......274 Accessories...........405 Transmission Code Designation....274 Capacities and Specifications - 1.0L Ford Protect EcoBoost ..........275 Ford Protect...........407 Capacities and Specifications - 2.0L...............278 Scheduled Maintenance Audio System General Maintenance Information..409 General Information........282...
  • Page 9 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 10: Introduction

    Introduction ABOUT THIS MANUAL Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about your vehicle, the greater the safety and pleasure you will get from driving it.
  • Page 11 Introduction Cabin air filter Front airbag E67017 Front fog lamps Check fuel cap Fuel pump reset Child safety door lock or unlock Fuse compartment Child seat lower anchor Hazard warning flashers Child seat tether anchor Heated rear window Cruise control E71340 Heated windshield Do not open when hot...

  • Page 12: Data Recording

    In order to properly diagnose and service your vehicle, Ford Motor Company Power window lockout (Ford of Canada in Canada), and service and repair facilities may access or share among them vehicle diagnostic information received through a direct...
  • Page 13 Ford of Canada privacy policy at is recorded by the event data recorder www.ford.ca, including our U.S. data under normal driving conditions and no storage and use of service providers in personal data or information (e.g., name,...

  • Page 14: California Proposition 65

    Terms and Conditions. See SYNC (page 298). US Only Ford Credit offers a full range of financing and lease plans to help you acquire your vehicle. If you have financed or leased your vehicle through Ford Credit, thank you for your business.

  • Page 15: Replacement Parts Recommendation

    A great way to know for sure you are getting this level Call 1-800-727-7000. of protection is to use genuine Ford For more information about Ford Credit replacement collision parts. and access to the Account Manager, go to Warranty on Replacement Parts www.fordcredit.com.

  • Page 16: Mobile Communications Equipment

    We do not recommend appropriately used, particularly in or endorse the use of aftermarket plug-in emergency situations. Safety must be devices unless approved by Ford. The paramount when using mobile vehicle Warranty will not cover damage communications equipment to avoid caused by an aftermarket plug-in device.
  • Page 17 Introduction recommendations and specifications that are unique to your vehicle. This Owner’s Manual is written primarily for the U.S. and Canadian Markets. Features or equipment listed as standard may be different on units built for export. Refer to this Owner’s Manual for all other required information and warnings.

  • Page 18: Environment

    Environment PROTECTING THE ENVIRONMENT You must play your part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps toward this aim. Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 19: Child Safety

    Child Safety GENERAL INFORMATION WARNINGS Technician (CPST) to make sure that you See the following sections for directions properly install the child restraint in your on how to properly use safety restraints vehicle and that you consult your for children. pediatrician to make sure you have a child restraint appropriate for your child.

  • Page 20: Installing Child Restraints

    Child Safety Recommendations for Safety Restraints for Children Child Child size, height, weight, or age Recommended restraint type Use a child safety seat Infants or Children weighing 40 lb (18 kg) or less (sometimes called an toddlers (generally age four or younger). infant carrier, convertible seat, or toddler seat).
  • Page 21 Child Safety Use a child safety seat (sometimes called • Place the vehicle seat upon which the an infant carrier, convertible seat, or child seat will be installed in the upright toddler seat) for infants, toddlers, or position. children weighing 40 pounds (18 •...
  • Page 22 Child Safety 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. E142875 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward E142530 until all of the belt is pulled out.
  • Page 23 1 inch (2.5 centimeters) of movement anchor, if a top tether strap has been for proper installation. provided with your child seat. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is properly installed. In Canada, check with your local St.
  • Page 24 Child Safety Use of Inboard Lower Anchors from the Outboard Seating Positions (Center Seating Use) WARNING The standardized spacing for LATCH lower anchors is 11 inches (28 centimeters) center to center. Do not use LATCH lower anchors for the center seating position unless the child seat manufacturer's instructions permit and specify using anchors spaced at least as...
  • Page 25 Child Safety Combining Safety Belt and LATCH Lower Anchors for Attaching Child Safety Seats When used in combination, either the safety belt or the LATCH lower anchors may be attached first, provided a proper installation is achieved. Attach the tether strap afterward, if included with the child seat.
  • Page 26 If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 27: Booster Seats

    Child Safety • Can the child sit all the way back BOOSTER SEATS against their vehicle seat back with knees bent comfortably at the edge of WARNING the seat cushion? Never place, or allow a child to place, • Can the child sit without slouching? the shoulder belt under a child's arm •...
  • Page 28 Child Safety If, with a backless booster seat, you cannot find a seating position that adequately supports your child's head, a high back booster seat would be a better choice. Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest...

  • Page 29: Child Restraint Positioning

    Child Safety If the booster seat slides on the vehicle WARNINGS seat upon which it is being used, placing a conjunction with the instructions and rubberized mesh sold as shelf or carpet warnings provided by your vehicle liner under the booster seat may improve manufacturer.

  • Page 30: Child Safety Locks

    Child Safety Recommendations for attaching child safety restraints for children Use any attachment method as indicated below by X LATCH LATCH Safety belt Safety belt Safety belt Combined (lower (lower and top and LATCH only Restraint weight of anchors anchors tether (lower Type...
  • Page 31 Child Safety The childproof locks are located on the rear edge of each rear door and must be set separately for each door. Left-Hand Side Turn counterclockwise to lock and clockwise to unlock. Right-Hand Side Turn clockwise to lock and counterclockwise to unlock.

  • Page 32: Seatbelts

    Seatbelts PRINCIPLE OF OPERATION WARNINGS When possible, all children 12 years old and under should be properly WARNINGS restrained in a rear seating position. Always drive and ride with your Failure to follow this could seriously seatback upright and the lap belt increase the risk of injury or death.

  • Page 33: Fastening The Seatbelts

    Seatbelts The seatbelt pretensioners at the front seating positions are designed to tighten the seatbelts when activated. In frontal and near-frontal crashes, the seatbelt pretensioners may be activated alone or, if the crash is of sufficient severity, together with the front airbags. The pretensioners will activate when the Safety Canopy is deployed.
  • Page 34 Seatbelts Pregnant women should always wear their In addition, the retractor is designed to lock seatbelt. The lap belt portion of a if the webbing is pulled out too quickly. If combination lap and shoulder belt should this occurs, let the belt retract slightly and be positioned low across the hips below pull webbing out again in a slow and the belly and worn as tight as comfort will...

  • Page 35: Seatbelt Height Adjustment

    Seatbelts Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the seatbelt is now in the automatic locking mode. How to Disengage the Automatic Locking Mode Unbuckle the combination lap and shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode.

  • Page 36: Seatbelt Reminder

    Seatbelts Conditions of operation If... Then... The driver's safety belt is not buckled The safety belt warning light illuminates 1- before the ignition switch is turned to the 2 minutes and the warning chime sounds on position... 4-8 seconds. The driver's safety belt is buckled while the The safety belt warning light and warning indicator light is illuminated and the chime turn off.
  • Page 37 Seatbelts If... Then... You and the front seat passenger buckle The Belt-Minder feature will not activate. your safety belts before you switch the ignition on or less than 1-2 minutes elapse after you switch the ignition on... You or the front seat passenger do not The Belt-Minder feature activates, the buckle your safety belts before your vehicle safety belt warning light illuminates and a...

  • Page 38: Child Restraint And Seatbelt Maintenance

    Seatbelts 3. For the seating position you are Ford Motor Company recommends that switching off, buckle then unbuckle the all safety belt assemblies in use in vehicles safety belt three times at a moderate involved in a crash be replaced. However, speed, ending in the unbuckled state.
  • Page 39 Ford Motor Company dealers. Only Ford seatbelt extensions made by the original equipment seatbelts manufacturer should be used with Ford seatbelts. Ask your authorized dealer if your extension is compatible with your Ford vehicle restraint system.

  • Page 40: Personal Safety System

    Personal Safety System How Does the Personal Safety The Personal Safety System provides an System Work? improved overall level of frontal crash protection to front seat occupants and is The Personal Safety System can adapt the designed to help further reduce the risk of deployment strategy of the safety devices airbag-related injuries.

  • Page 41: Supplementary Restraints System

    Supplementary Restraints System The airbags are a supplemental restraint PRINCIPLE OF OPERATION system and are designed to work with the safety belts to help protect the driver and WARNINGS right front passenger from certain upper Airbags do not inflate slowly or body injuries.

  • Page 42: Driver And Passenger Airbags

    Supplementary Restraints System Proper Driver and Front Passenger DRIVER AND PASSENGER Seating Adjustment AIRBAGS WARNING WARNINGS National Highway Traffic Safety Never place your arm or any objects Administration (NHTSA) over an airbag module. Placing your recommends a minimum distance arm over a deploying airbag can of at least 10 inches (25 centimeters) result in serious arm fractures or other between an occupant’s chest and the...

  • Page 43: Front Passenger Sensing System

    Supplementary Restraints System WARNINGS Do not stow objects in the seatback map pocket or hang objects off a seatback if a child is in the front passenger seat. Do not place objects under the front passenger seat or between the seat and the center console.
  • Page 44 Supplementary Restraints System Note: The passenger airbag status indicator The front passenger sensing system is OFF and ON indicator lamps illuminate for designed to enable (may inflate) the front a short period of time when the ignition is passenger's frontal airbag anytime the first turned on to confirm it is functional.

  • Page 45: Side Airbags

    • Rear passenger feet and knees resting person with disabilities, contact the Ford or pushing on the seat. Customer Relationship Center. See The conditions listed above may cause the Getting the Services You Need (page weight of a properly seated occupant to 194).

  • Page 46: Driver Knee Airbag

    Supplementary Restraints System The system consists of the following: WARNINGS • A label or embossed side panel Do not use accessory seat covers. indicating that side airbags are fitted The use of accessory seat covers to your vehicle. may prevent the deployment of the side airbags and increase the risk of injury •...

  • Page 47: Safety Canopy

    Supplementary Restraints System The Safety Canopy deploys during SAFETY CANOPY significant side crashes or when a certain likelihood of a rollover event is detected WARNINGS by the rollover sensor. The Safety Canopy Do not place objects or mount is mounted to the roof side-rail sheet equipment on or near the headliner metal, behind the headliner, above each at the siderail that may come into...

  • Page 48: Crash Sensors And Airbag Indicator

    Supplementary Restraints System Properly restrain children 12 years old and The restraints control module also under in the rear seats. The Safety Canopy monitors the readiness of the above safety will not interfere with children restrained devices plus the crash and occupant using a properly installed child or booster sensors.

  • Page 49: Airbag Disposal

    Supplementary Restraints System The fact that the seatbelt pretensioners or airbags did not activate for both front seat occupants in a crash does not mean that something is wrong with the system. Rather, it means the restraints control module determined the accident conditions (for example, crash severity, belt usage) were not appropriate to activate these safety devices.

  • Page 50: Keys And Remote Controls

    Keys and Remote Controls Note: The remote control contains sensitive GENERAL INFORMATION ON electrical components. Exposure to moisture RADIO FREQUENCIES or impact may cause permanent damage. This device complies with Part 15 of the REMOTE CONTROL - VEHICLES FCC Rules and with Industry Canada license-exempt RSS standard(s).
  • Page 51 Keys and Remote Controls To release the key blade: Press and hold the buttons on the edges of the transmitter to release the cover. Carefully remove the cover. 2. Remove the key blade. Programming a New Remote Control To program an additional remote control See Security (page 67).

  • Page 52: Remote Control - Vehicles With: Integrated Key Transmitter

    Keys and Remote Controls REMOTE CONTROL - VEHICLES WITH: INTEGRATED KEY TRANSMITTER Integrated Keyhead Transmitter Equipped) E125860 Note: Do not touch the battery contacts or the printed circuit board with the screwdriver. 5. Carefully remove the battery with the E142585 screwdriver.
  • Page 53 Keys and Remote Controls Reprogramming the Unlocking Function Note: When you press the unlock button, either all the doors are unlocked or only the driver door is unlocked. Pressing the unlock button again unlocks all the doors. Press and hold the unlock and lock buttons on the remote control simultaneously for E138620 at least four seconds with the ignition off.

  • Page 54: Remote Control - Vehicles With: Keyless Entry With Remote Start

    Keys and Remote Controls REMOTE CONTROL - VEHICLES WITH: KEYLESS ENTRY WITH REMOTE START Intelligent Access Key (If Equipped) E138618 Note: Your vehicle keys came with a security label that provides important key cut information. Keep the label in a safe place for future reference.
  • Page 55 Keys and Remote Controls Sounding the Panic Alarm 2. Twist a thin coin under the tab hidden (If Equipped) behind the key blade head to remove Press the button to activate the the battery cover. alarm. Press the button again or switch the ignition on to E138624 deactivate it.

  • Page 56: Replacing A Lost Key Or Remote Control

    Keys and Remote Controls • Your vehicle battery has no charge. Note: If you remote start your vehicle with an intelligent access transmitter, you must • The powertrain fault indicator was on press the push button ignition switch on the the last time you drove your vehicle.

  • Page 57: Mykey

    MyKey • Driver assist features, if equipped on PRINCIPLE OF OPERATION your vehicle, are forced on: parking aid and Blind Spot Information System MyKey allows you to program keys with (BLIS) with cross traffic alert. restricted driving modes to promote good driving habits.

  • Page 58: Creating A Mykey

    MyKey • Various vehicle speed minders can be CREATING A MYKEY set. Once you select a speed, it will be shown in the display, followed by an Use the information display to create a audible tone when the preselected MyKey: vehicle speed is exceeded.

  • Page 59: Clearing All Mykeys

    MyKey Note: You can clear or change your MyKey CLEARING ALL MYKEYS settings at any time during the same key cycle as you created the MyKey. Once you You can clear or change your MyKey have switched the vehicle off, however, you settings using the information display will need an admin key to change or clear control on the steering wheel.

  • Page 60: Checking Mykey System Status

    START SYSTEMS MyKey is not compatible with non Ford-approved, aftermarket remote start systems. If you choose to install a remote start system, see an authorized dealer for a Ford-approved remote start system. MYKEY TROUBLESHOOTING All Vehicles Condition Potential Causes I cannot create a MyKey.
  • Page 61 MyKey Condition Potential Causes I lost the only admin key. Purchase a new key from an authorized dealer. I lost a key. Program a spare key. See Passive Anti-Theft System (page 67). The MyKey distance does The MyKey is not being used by the intended user. not accumulate.

  • Page 62: Doors And Locks

    Doors and Locks Opening a Rear Door From the Inside LOCKING AND UNLOCKING Pull the interior door handle twice to You can use the power door lock control unlock and open a rear door. The first pull or the remote control to lock and unlock unlocks the door and the second pull your vehicle.
  • Page 63 Doors and Locks Mislock The system allows you to unlock, operate and lock your vehicle without using a key If any door or the liftgate or luggage or remote control. compartment is open, or if the hood is open on vehicles with an anti-theft alarm or remote start, the horn will sound twice and the direction indicators will not flash.
  • Page 64 Doors and Locks The locking sensors are on the front door If both front doors are closed, you can lock handles. your vehicle by any method, regardless of whether the key is in the ignition or not. Touch a locking sensor once to lock your vehicle and arm the alarm.
  • Page 65 Doors and Locks Autounlock The lamps turn off if: • The ignition is on. Autounlock unlocks all the doors when all • You press the remote control lock of the following occur: button. • The ignition is on, all the doors are •...

  • Page 66: Manual Liftgate

    Doors and Locks Opening the Liftgate or Luggage WARNINGS Compartment Make sure to close and latch the liftgate to prevent drawing exhaust With the Remote Control fumes into your vehicle. This will also prevent passengers and cargo from falling Press twice within three seconds out.

  • Page 67: Keyless Entry

    Doors and Locks Closing the Liftgate E155976 A handle is located inside the liftgate to help with closing. E138637 You can use the keypad to do the KEYLESS ENTRY (If Equipped) following: • Lock or unlock the doors. SECURICODE KEYLESS ENTRY •...

  • Page 68: Interior Luggage Compartment Release - 4-Door

    Doors and Locks To program additional personal entry Locking and Unlocking the Doors codes, repeat Steps 1-3, then for Step 4: Locking All Doors • Press 3·4 to save personal code 2. Press and hold 7·8 and 9·0 on the keypad •...
  • Page 69 Doors and Locks Your vehicle is equipped with a release handle that provides a means of escape for children and adults if they become locked inside the luggage compartment. Adults should familiarize themselves with the operation and location of the release handle.

  • Page 70: Security

    Note: The system is not compatible with well as a remote control. non-Ford aftermarket remote start systems. If your intelligent access keys are lost or Use of these systems may result in engine...
  • Page 71 Security Insert the first previously programmed Programming a Spare Intelligent coded key into the ignition. Access Key 2. Switch the ignition from off to on. Keep You must have two previously the ignition on for at least 3 seconds, programmed coded keys and the new but no more than 10 seconds.

  • Page 72: Anti-Theft Alarm

    Security If programming was unsuccessful, wait 10 seconds and repeat Steps 1 through 12. If programming remains unsuccessful, have your vehicle checked by an authorized dealer. ANTI-THEFT ALARM The system will warn you of an unauthorized entry to your vehicle. It will be triggered if any door, the luggage compartment or the hood is opened without using the key, remote control or...

  • Page 73: Steering Wheel

    Steering Wheel ADJUSTING THE STEERING WHEEL WARNING Do not adjust the steering wheel when your vehicle is moving. Note: Make sure that you are sitting in the correct position. See Sitting in the Correct Position (page 110). E95179 3. Lock the steering column. AUDIO CONTROL Select the required source on the audio unit.

  • Page 74: Voice Control

    Steering Wheel CRUISE CONTROL Volume down. Seek down or previous. Seek, Next or Previous Press the seek button to: • Tune the radio to the next or previous stored preset. • Play the next or the previous track. Press and hold the seek button to: •...

  • Page 75: Heated Steering Wheel

    Steering Wheel HEATED STEERING WHEEL Equipped) E189138 Press the button to switch the system on. The LED on the switch illuminates when the system is on. Note: The system only operates when the engine is running. Press the button to switch the system off. The system automatically controls the temperature to avoid overheating.

  • Page 76: Wipers And Washers

    Wipers and Washers Note: Move to position O marked on the WINDSHIELD WIPERS wiper lever to switch off. Note: Fully defrost the windshield before Intermittent Wipe you switch the windshield wipers on. Note: Make sure you switch the windshield wipers and vehicle power off before using an automatic car wash.

  • Page 77: Rear Window Wiper And Washers

    Wipers and Washers When you shift into reverse (R) and the front wipers are on, the rear wiper may automatically turn on to intermittent wipe. Rear Window Washer E197528 To operate the washers and spray the windshield, pull the lever toward you. When you release the lever, the wipers will operate for a short time.

  • Page 78: Lighting

    Lighting GENERAL INFORMATION LIGHTING CONTROL Condensation in Lamp Assemblies Exterior lamps have vents to accommodate normal changes in air pressure. Condensation can be a natural by-product of this design. When moist air enters the lamp assembly through the vents, there is a possibility that condensation can occur when the temperature is cold.

  • Page 79: Autolamps

    Lighting Push the lever away from you to switch When the lighting control is in the the high beam on. autolamps position, the headlamps automatically turn on in low light situations Push the lever forward again or pull the or when the wipers activate. lever toward you to switch the high beams off.

  • Page 80: Instrument Lighting Dimmer

    Lighting INSTRUMENT LIGHTING DAYTIME RUNNING LAMPS DIMMER WARNING Note: You disable the manual dimmer The daytime running lamps system when you adjust the setting to Auto does not activate the rear lamps and Dimming in the information display. See may not provide adequate lighting Information Displays (page 91).

  • Page 81: Automatic High Beam Control

    Lighting 4. The lighting control is in the autolamps Note: Typical road dust, dirt and water position. spots do not affect the performance of the automatic high beam control. However, in 5. The headlamps are off. cold or inclement weather conditions, you The other lighting control switch positions may notice a decrease in the availability of do not activate the daytime running lamps,...

  • Page 82: Front Fog Lamps

    Lighting The indicator lamp illuminates DIRECTION INDICATORS to confirm when the system is ready to assist. Manually Overriding the System E162681 Push the lever up or down to use the direction indicators. E169254 Note: Tap the lever up or down to make the direction indicators flash three times to Push or pull the lever to switch between indicate a lane change.

  • Page 83: Ambient Lighting

    Lighting Center Mounted Lamp Side Mounted Lamp E139419 E139420 Map lamp. Door function switch. Left-hand side map lamp. All lamps on switch. Right-hand side map lamp. Door function switch. AMBIENT LIGHTING All lamps on switch. Adjust the ambient lighting using the touchscreen.

  • Page 84: Windows And Mirrors

    Windows and Mirrors One-Touch Up POWER WINDOWS (If Equipped) Lift the control fully and release it. Press WARNINGS or lift it again to stop the window. Do not leave children unattended in Window Lock your vehicle and do not let them play with the power windows.

  • Page 85: Exterior Mirrors

    Windows and Mirrors Accessory Delay Close the window twice until it reaches (If Equipped) the point of resistance and let it You can use the window controls for reverse. several minutes after switching off the 2. Close the window a third time to the ignition or until opening either front door.
  • Page 86 Windows and Mirrors Fold-Away Exterior Mirrors Push the mirror toward the door window glass. Make sure that you fully engage the mirror in its support when returning it to its original position. Heated Exterior Mirrors (If Equipped) See Heated Windows and Mirrors (page 108).

  • Page 87: Interior Mirror

    Windows and Mirrors Illuminated Vanity Mirror INTERIOR MIRROR (If Equipped) WARNING Do not adjust the mirror when your vehicle is moving. Note: Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum or ammonia-based cleaning products.
  • Page 88 Windows and Mirrors Opening and Closing the Moonroof E138669 Press and release the rear of the control to open the moonroof. The moonroof stops short of the fully opened position. Note: This position helps to reduce wind noise or rumbling that may happen with the moonroof fully open.

  • Page 89: Instrument Cluster

    Instrument Cluster GAUGES E212417 Tachometer. Information display. Speedometer. Engine coolant temperature gauge. Fuel Gauge. Vehicle Settings and Personalization Information Display See General Information (page 91). Compass (If Equipped) Engine Coolant Temperature Displays the vehicle’s heading direction. Gauge Odometer WARNING Records the total distance traveled by your Never remove the coolant reservoir vehicle.

  • Page 90: Warning Lamps And Indicators

    Instrument Cluster If the needle enters the red section, the WARNING LAMPS AND engine is overheating. Stop the engine, INDICATORS switch the ignition off and determine the cause once the engine has cooled down. The following warning lamps and See Engine Coolant Check (page 218). indicators alert you to a vehicle condition that may become serious.
  • Page 91 Instrument Cluster Auto-Start-Stop Indicator Cruise Control Indicator It illuminates when the engine It illuminates when you switch has automatically stopped. It the system on. flashes to inform you when the E71340 See Using Cruise Control engine needs to restart. The (page 162).
  • Page 92 Instrument Cluster Lamps on Indicator If it flashes, engine misfire may be occurring. Increased exhaust gas It illuminates when you switch temperatures could damage the catalytic the headlamp low beam or the converter or other vehicle components. side and rear lamps on. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have Lane Keeping Aid Warning Lamp...

  • Page 93: Audible Warnings And Indicators

    Instrument Cluster See Information Messages (page 95). AUDIBLE WARNINGS AND INDICATORS Oil Pressure Warning Lamp Key in Ignition Warning Chime WARNING Sounds when you open the driver's door If it illuminates when you are driving and you have left the key in the ignition. do not continue your journey, even if the oil level is correct.

  • Page 94: Information Displays

    Trip 1 and 2 Option to display all the values on screen. Speed Trip Odometer Average Fuel Ford EcoMode Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 95 Information Displays Trip 1 and 2 Gear Shifting Anticipation Speed Ford EcoMode Inst Fuel Econ Distance to E Trip Timer Outside Temp. Option to select for navigation display. See Trip Computer (page 94). Information Driver Alert MyKey MyKey Info System Check...
  • Page 96 Information Displays Settings Tire Monitor Lane Keeping Vehicle settings Auto Engine Off Compass Display Calibrate Set Zone Chimes Park Slot Information Warning Lighting Traffic (R/L) Auto Highbeam Rain Light Ambient Light Dimming Hdlamp Delay Remote Start Climate Control Heater - A/C Rear Defrost Driver Seat Passengr Seat...

  • Page 97: Trip Computer

    Information Displays Settings Always On or User Selectable 911 Assist Always On or User Selectable Max Speed xx MPH (xx km/h) or Off Speed Warning xx MPH (xx km/h) or Off Volume Limiter Do Not Disturb Always On or User Selectable Clear MyKeys Hold OK to Clear All MyKeys Display...

  • Page 98: Information Messages

    Information Displays You need to confirm certain messages INFORMATION MESSAGES before you can access the menus. The message indicator illuminates to supplement some messages. The indicator is red or amber depending on the severity of the condition and it remains on until the condition is resolved. A system-specific symbol with a message indicator may supplement some messages.
  • Page 99 Information Displays Automatic Engine Shutdown Message Action Engine Shuts Off In Displays if the engine is going to automatically turn off. {seconds to shut off:#0} Seconds Engine Shut Off For Fuel Displays if the engine automatically turns off to improve fuel Economy economy.
  • Page 100 Information Displays Blind Spot Information and Cross Traffic Alert System Message Action Blindspot Low visibility Displays when the blind spot information system and cross See manual traffic alert system sensors are blocked. See Blind Spot Information System (page 169). Blindspot right sensor The system has detected a fault that requires service.
  • Page 101 See Hill Start Assist (page 146). Keyless Entry Message Action Ford KeyFree Key inside Displays if you leave a vehicle key in the luggage compartment vehicle and switch the ignition on or try to lock your vehicle. See Keyless Starting (page 118).
  • Page 102 Information Displays Lighting Message Action Brake lamp Bulb fault Displays if a brake lamp bulb fails. Low beam Bulb fault Displays if a low beam bulb fails. Headlamp fault Service Displays if an electrical malfunction occurs with the headlamp required system.
  • Page 103 Information Displays Message Action MyKey Park aid cannot Displays when a MyKey is in use and the user tries to switch be deactivated the parking aid system off. Key is Already a MyKey Displays when trying to create a MyKey with a key already designated as a MyKey.
  • Page 104 Information Displays Starting System Message Action Press brake to start Displays when you start your vehicle as a reminder to fully press the brake pedal. Cranking time exceeded Displays if your vehicle fails to start. See Starting and Stopping the Engine (page 118). Steering System Message Action...
  • Page 105 Information Displays Message Action See Using Traction Control (page 148). Transmission Message Action Transmission malfunc- Have your vehicle checked as soon as possible. tion Service now Transmission over- The transmission is overheating and needs to cool. Stop your heating Stop safely vehicle as soon as it is safe to do so, switch the engine off and allow the transmission to cool.

  • Page 106: Climate Control

    Climate Control MANUAL CLIMATE CONTROL E196989 Fan speed control: Adjusts the volume of air circulated in the vehicle. A/C: Press the button to switch the air conditioning on or off. Air conditioning cools your vehicle using outside air. To improve the time to reach a comfortable temperature in hot weather, drive with the windows open until you feel cold air through the air vents.

  • Page 107: Automatic Climate Control

    Climate Control Recirculated air: Press the button to switch between outside air and recirculated air. The air currently in the passenger compartment recirculates. This can reduce the time needed to cool the interior and reduce unwanted odors from entering your vehicle. Heated seats (if equipped): Press the button to switch the heated seats on and off.
  • Page 108 Climate Control A/C: Press the button to switch the air conditioning on or off. Air conditioning cools your vehicle using outside air. To improve the time to reach a comfortable temperature in hot weather, drive with the windows open until you feel cold air through the air vents.

  • Page 109: Hints On Controlling The Interior Climate

    Climate Control Dual Zone Temperature Control Note: To improve the time to reach comfort in hot weather, drive with the windows fully Select a temperature for the passenger’s open until you feel cold air through the air side using the rotary control on the vents.
  • Page 110 Climate Control Recommended Settings for Heating Vehicle with manual climate control Vehicle with automatic climate control Adjust the fan speed to the center Press the AUTO button. setting. Adjust the temperature control to the Adjust the temperature control to the midway point of the hot settings.

  • Page 111: Heated Windows And Mirrors

    Climate Control Side Window Defogging in Cold Weather Vehicle with manual climate control Vehicle with automatic climate control Select the windshield air vents using the Press the defrost button. air distribution buttons. Press the A/C button. Adjust the temperature control to the desired setting.

  • Page 112: Remote Start

    Climate Control Last Settings For additional cabin air filter information, or to replace the filter, see an authorized You can set the climate control to operate dealer. using the last climate control settings through the information display setting: REMOTE START Remote Start >...

  • Page 113: Seats

    Seats We recommend that you follow these SITTING IN THE CORRECT guidelines: POSITION • Sit in an upright position with the base of your spine as far back as possible. WARNINGS • Do not recline the seat backrest more Do not recline the seat backrest too than 30 degrees.
  • Page 114 Seats Rear center head restraint WARNINGS The adjustable head restraint is a safety device. Whenever possible, it should be installed and properly adjusted when the seat is occupied. Failure to adjust the head restraint properly could reduce its effectiveness during certain impacts.

  • Page 115: Manual Seats

    Seats Installing the Head Restraint WARNINGS Rock the seat backward and forward Align the steel stems into the guide sleeves after releasing the lever to make sure and push the head restraint down until it that it is fully engaged. locks.

  • Page 116: Rear Seats

    Seats E194195 Power Lumbar (If Equipped) E187688 E156656 REAR SEATS Press the unlock buttons down. Folding the Seatback 2. Push the seatback forward. Note: Before lowering the seatback(s), remove the outboard head restraints. See Head Restraints (page 110). Note: Your vehicle may have split seatbacks that must be folded individually.
  • Page 117 Seats When raising the seatback(s), make sure you hear the seat latch into place and that no red portion is visible on the release button on both sides. Flip Up Seat Cushions (If Equipped) WARNING Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback.

  • Page 118: Heated Seats

    Seats HEATED SEATS (If Equipped) WARNING People who are unable to feel pain to their skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical conditions, must exercise care when using the heated seat.

  • Page 119: Auxiliary Power Points

    Auxiliary Power Points 12 Volt DC Power Point To prevent the battery from running out of charge: WARNINGS • Do not use the power point longer than Do not plug optional electrical necessary after switching the vehicle accessories into the cigar lighter off.

  • Page 120: Storage Compartments

    Storage Compartments CENTER CONSOLE OVERHEAD CONSOLE Stow items in the cupholder carefully as items may become loose during hard braking, acceleration or crashes, including hot drinks which may spill. Available console features include: E131605 Press near the rear edge of the door to open it.

  • Page 121: Starting And Stopping The Engine

    Starting and Stopping the Engine GENERAL INFORMATION IGNITION SWITCH WARNINGS Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. Do not park, idle or drive your vehicle on dry grass or other dry ground E72128 cover.
  • Page 122 Starting and Stopping the Engine Switching the Ignition On to Note: Releasing the brake pedal during Accessory Mode engine starting stops the engine cranking. Failure to Start The system does not function if: • The passive key frequencies are jammed. •...
  • Page 123 Starting and Stopping the Engine Vehicles with Automatic Transmission Move the gearshift lever to park (P). 2. Press the push button ignition switch. Note: The ignition, all electrical circuits and all warning lamps and indicators will be turned off. Stopping the Engine When Your Vehicle is Moving WARNING Switching off the engine when the...

  • Page 124: Starting A Gasoline Engine

    Starting and Stopping the Engine Once your vehicle starts, it remains running • Make sure the transmission is in park until you press the push button ignition (P). switch, even if your vehicle does not detect • Switch the ignition key to position II. If a valid passive key.
  • Page 125 Starting and Stopping the Engine Fast Restart The fast restart feature allows you to restart the engine within 20 seconds of switching it off, even if a valid key is not present. Within 20 seconds of switching the engine off, press the brake pedal and press the button.
  • Page 126 Starting and Stopping the Engine counting down from 30 seconds. If you do 3. Apply the parking brake. not intervene within 30 seconds, your Note: This switches off the ignition, all vehicle shuts down. Another message electrical circuits, warning lamps and appears in the information display to indicators.

  • Page 127: Engine Block Heater

    Starting and Stopping the Engine Guarding Against Exhaust Fumes The heater acts as a starting aid by warming the engine coolant. This allows WARNING the climate control system to respond quickly. The equipment includes a heater If you smell exhaust fumes inside element (installed in the engine block) and your vehicle, have your vehicle a wire harness.
  • Page 128 Starting and Stopping the Engine • Make sure the system is unplugged and properly stowed before starting and driving your vehicle. Make sure the protective cover seals the prongs of the block heater cord plug when not in use. • Make sure the heater system is checked for proper operation before winter.

  • Page 129: Unique Driving Characteristics

    Unique Driving Characteristics Note: To obtain maximum benefit from the AUTO-START-STOP (If Equipped) system, move the transmission selector lever to neutral and release the clutch pedal The system reduces fuel consumption and during any stop of longer than three CO2 emissions by shutting down the seconds.
  • Page 130 Unique Driving Characteristics • The driver door is opened. • The driver safety belt is not fastened. • The transmission is in Sport or Manual modes (automatic transmission only). The system may automatically restart the engine under certain conditions, for example: •...

  • Page 131: Fuel And Refueling

    Fuel and Refueling • Automotive fuels can be harmful or SAFETY PRECAUTIONS fatal if swallowed. Fuel such as gasoline is highly toxic and if WARNINGS swallowed can cause death or Do not overfill the fuel tank. The permanent injury. If fuel is swallowed, pressure in an overfilled tank may call a physician immediately, even if no cause leakage and lead to fuel spray...

  • Page 132: Fuel Quality - E85

    Fuel and Refueling Note: Use of any fuel other than those FUEL QUALITY - E85 (If Equipped) recommended can impair the emission control system and cause a loss of vehicle Choosing the Right Fuel - Flex Fuel performance. Vehicles Do not use: Flex fuel vehicles have one of the following •...

  • Page 133: Fuel Quality - Gasoline

    Fuel and Refueling Switching Between E85 and Do not use any fuel other than those Gasoline recommended because they could lead to engine damage that will not be covered by We do not recommend repeatedly the vehicle Warranty. alternating between E85 and gasoline. If Note: Use of any fuel other than those you switch from using E85 to gasoline, or recommended can impair the emission...

  • Page 134: Running Out Of Fuel

    Fuel and Refueling RUNNING OUT OF FUEL WARNINGS Do not try to pry open or push open Running out of fuel can cause damage not the capless fuel system with foreign covered by the vehicle Warranty. objects. This could damage the fuel system and its seal and cause injury to you If your vehicle runs out of fuel: or others.

  • Page 135: Catalytic Converter

    Fuel and Refueling 5. Fully close the fuel tank filler door. REFUELING 6. Clean the fuel filler funnel and place it back in your vehicle or correctly dispose WARNINGS of it. When refueling always shut the engine off and never allow sparks or Note: Extra funnels can be purchased from open flames near the fuel tank filler an authorized dealer if you choose to...
  • Page 136 Fuel and Refueling E206911 Left-hand side. To open the fuel filler door, press the center rear E139202 edge of the fuel filler door and Note: When you insert the correct size fuel then release. pump nozzle a spring loaded inhibitor will Right-hand side.

  • Page 137: Fuel Consumption

    Fuel and Refueling 5. Insert a fuel pump nozzle or the fuel filler funnel provided with your vehicle in to the fuel tank filler pipe opening. This action should dislodge any debris that may be preventing the fuel filler inlet from fully closing. Note: If this action corrects the problem the message may not reset immediately.

  • Page 138: Emission Control System

    Fuel and Refueling Calculating Fuel Economy • Fuel economy may decrease with lower temperatures. Do not measure fuel economy during the • Fuel economy may decrease when first 1,000 mi (1,600 km) of driving (this is driving short distances. your engine’s break-in period). A more •...
  • Page 139 (OBD-II) that your vehicle and to its emissions system. monitors the engine’s emission control If you use anything other than Ford, system. The system protects the Motorcraft or Ford-authorized parts for environment by making sure that your...
  • Page 140 Fuel and Refueling If the service engine soon indicator remains The OBD-II system checks the emission on, have your vehicle serviced at the first control system during normal driving. A available opportunity. Although some complete check may take several days. malfunctions detected by the OBD-II may If the vehicle is not ready for I/M testing, not have symptoms that are apparent,...

  • Page 141: Transmission

    Transmission 5. Release the parking brake, then slowly MANUAL TRANSMISSION - 6- release the clutch pedal while slowly SPEED MANUAL pressing on the accelerator. TRANSMISSION (MMT6) During each shift, the clutch pedal must be fully pressed to the floor. Make sure the Using the Clutch floor mat is properly positioned so it doesn't interfere with the full extension of...

  • Page 142: Transmission (Mtx-75)

    Transmission MANUAL TRANSMISSION - 5- SPEED MANUAL TRANSMISSION (MTX-75) Using the Clutch Note: Failure to fully depress the clutch pedal to the floor may cause increased shift efforts, prematurely wear transmission components or damage the transmission. Note: Do not drive with your foot resting on the clutch pedal or use the clutch pedal to hold your vehicle at a standstill while E99067...

  • Page 143: Automatic Transmission

    Transmission 2. Fully depress the clutch pedal then If reverse gear is not fully engaged, press start the engine. the clutch pedal down and shift the gearshift lever to the neutral position. 3. Press the brake pedal and shift the Release the clutch pedal for a moment, gearshift lever to first or reverse gear.
  • Page 144 Transmission The PowerShift 6-speed, dual-clutch Park (P) automatic transmission is designed to offer This position locks the transmission and drivers both enhanced fuel efficiency and prevents the wheels from turning. fun to drive performance. This transmission’s dual-clutch technology uses Reverse (R) electronically shifted clutches to operate two separate transmissions all in a small With the gearshift lever in reverse (R), your...
  • Page 145 Transmission In order to prevent the engine from running You can achieve extensive manual control at too low an RPM, which may cause it to by moving the gearshift lever to the sport stall, SelectShift still automatically makes (S) position. some downshifts if it has determined that •...
  • Page 146 Transmission Brake-Shift Interlock WARNINGS Do not drive your vehicle until you verify that the brake lamps are working. When doing this procedure, you will be taking your vehicle out of park (P) which means your vehicle can roll freely. To avoid unwanted vehicle movement, always fully set the parking brake prior to doing this procedure.
  • Page 147 Transmission 3. Insert the screwdriver (or similar tool) into the access hole and press the lever foreword while pulling the gearshift lever out of the park (P) position and into the neutral (N) position. 4. Remove the tool and reinstall the panel.

  • Page 148: Brakes

    Brakes Brake Assist GENERAL INFORMATION Brake assist detects when you brake Note: Occasional brake noise is normal. If rapidly by measuring the rate at which you a metal-to-metal, continuous grinding or press the brake pedal. It provides continuous squeal sound is present, the maximum braking efficiency as long as you brake linings may be worn-out.

  • Page 149: Parking Brake

    Brakes Press the brake pedal firmly. PARKING BRAKE 2. Pull the lever up slightly. Vehicles With Automatic 3. Press the release button and push the Transmission lever down. WARNING HILL START ASSIST Always set the parking brake fully and leave your vehicle with the WARNINGS transmission selector lever in position P.
  • Page 150 Brakes The system will activate automatically on any slope that will cause significant vehicle rollback. For vehicles with a manual transmission, you can switch this feature off using the information display. See Information Displays (page 91). The system will remain on or off depending on how it was last set.

  • Page 151: Traction Control

    Traction Control Using the Information Display PRINCIPLE OF OPERATION Controls The traction control system helps avoid You can switch this feature off or on in the drive wheel spin and loss of traction. information display. See General If your vehicle begins to slide, the system Information (page 91).

  • Page 152: Stability Control

    Stability Control If a fault occurs in either the stability PRINCIPLE OF OPERATION control or the traction control system, you may experience the following conditions: WARNINGS • The stability and traction control light Vehicle modifications involving illuminates steadily. braking system, aftermarket roof racks, suspension, steering system, •...

  • Page 153: Using Stability Control

    Stability Control E72903 Vehicle without stability control skidding off its intended route. Vehicle with stability control maintaining control on a slippery surface. USING STABILITY CONTROL The system automatically turns on each time you switch the ignition on. You cannot switch the stability control system off, but when you shift into reverse (R), the system deactivates.

  • Page 154: Parking Aids

    Parking Aids Note: The sensing system cannot be turned PRINCIPLE OF OPERATION off when a MyKey is present. See Principle of Operation (page 54). WARNINGS Note: If you attach certain add-on devices To help avoid personal injury, please such as a trailer or bike rack, the rear sensing read and understand the limitations system may detect that add-on device and of the system as contained in this...

  • Page 155: Front Parking Aid

    Parking Aids E187330 Coverage area of up to 28 in (70 cm) from the front bumper. There is decreased E130178 coverage area at the outer corners. Coverage area of up to 6 ft (1.8 m) from The system sounds an audible warning the rear bumper.

  • Page 156: Active Park Assist

    Parking Aids Parallel Park Out Assist automatically ACTIVE PARK ASSIST steers your vehicle out of a parallel parking space (hands-free) while you control the Parallel Parking, Perpendicular accelerator, gearshift and brakes. The Parking, Parallel Park Out Assist system visually and audibly guides you to enter traffic.
  • Page 157 Parking Aids • A foreign object damages or obstructs When driving at a speed less than 22 mph the front or rear bumper or side (35 km/h) the system automatically scans sensors. both sides of your vehicle for an available parking space.
  • Page 158 Parking Aids E130108 Using Active Park Assist - When you think your vehicle is properly Perpendicular Parking parked, or you hear a solid tone from the parking aid (accompanied by a display Press the active park assist message and a chime), bring your vehicle button twice to search for a to a complete stop.
  • Page 159 Parking Aids Note: The system always offers the last When you shift the transmission into detected parking space (for example, if your reverse (R), with your hands off the wheel vehicle detects multiple spaces while you (and nothing obstructing its movement), are driving, it offers the last one).
  • Page 160 Parking Aids Deactivating the Active Park The system determines the clearance to Assist Feature the front and rear of your vehicle and automatically steers your vehicle out of a Manually deactivate the system by: parallel parking space (hands-free) while you control the accelerator, gearshift and •...
  • Page 161 Parking Aids The system does not offer a particular space The sensors may be covered (for example, snow, ice or dirt buildup). Covered sensors can affect the system's functionality. There is not enough room in the parking space for your vehicle to safely park. There is not enough space for the parking maneuver on the opposite side of the parking space.

  • Page 162: Rear View Camera

    Parking Aids REAR VIEW CAMERA (If Equipped) WARNINGS The rear view camera system is a reverse aid supplement device that still requires the driver to use it in conjunction with the interior and exterior mirrors for maximum coverage. Objects that are close to either corner of the bumper or under the bumper, might not be seen on the screen due to the limited coverage of the...
  • Page 163 Parking Aids Note: When towing, the camera only sees what is being towed behind your vehicle. This might not provide adequate coverage as it usually provides in normal operation and some objects might not be seen. In some vehicles, the guidelines may disappear once the trailer tow connector is engaged.
  • Page 164 Parking Aids The fixed and active guidelines fade in and • Your vehicle speed sufficiently out depending on the steering wheel increases. position. The active guidelines are not • You shift your vehicle into park (P). shown when the steering wheel position Selectable settings for this feature are ON is straight.

  • Page 165: Cruise Control

    Cruise Control The indicator appears in the PRINCIPLE OF OPERATION information display. E71340 Cruise control lets you maintain a set speed without keeping your foot on the Setting the Cruise Speed accelerator pedal. You can use cruise control when your vehicle speed is greater Drive to desired speed.
  • Page 166 Cruise Control Press and release OFF when the system is in stand by mode or switch the ignition off. Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 167: Driving Aids

    Driving Aids Note: The system assists you when driving DRIVER ALERT on fast main roads and freeways. Principle of Operation Note: The system calculates an alertness level at vehicle speeds above approximately WARNINGS 40 mph (65 km/h). The system is designed to aid the The system automatically monitors your driver.

  • Page 168: Lane Keeping System

    Driving Aids System Display Resetting the System When active the system runs automatically You can reset the system by: in the background and only issue warnings • Switching the ignition off and on. if required. You can view the status at any •...
  • Page 169 Driving Aids System Settings WARNINGS If damage occurs in the immediate The system has optional setting menus area surrounding the sensor, have available. The system stores the your vehicle checked as soon as last-known selection for each of these possible. settings.
  • Page 170 Driving Aids System Display E165517 E151660 Alert When you switch on the system, an overhead graphic of a vehicle with lane markings will display in the information Alert + Aid – Provides an assistance display. If you select aid mode when you steering torque input toward the lane switch on the system, a separate white center.
  • Page 171 Driving Aids • The road has no or poor lane markings Yellow: Indicates that the system is in the camera field-of-view. providing or has just provided a lane keeping aid intervention. • The camera is obscured or unable to detect the lane markings due to Red: Indicates that the system is providing environmental conditions (significant or has just provided a lane keeping alert...

  • Page 172: Blind Spot Information System

    Driving Aids Why is the feature not available (line markings are gray) when I can see the lane markings on the road? Lane width too narrow or too wide Camera not calibrated after a windshield replacement Driving on tight roads or on uneven roads Why does the vehicle not come back toward the middle of the lane, as expected, in the Aid or Aid + Alert mode? High cross winds...
  • Page 173 Driving Aids Note: The Blind Spot Information System The Blind Spot Information System does not prevent contact with other vehicles illuminates an amber alert indicator in the or objects; nor detect parked vehicles, outside mirror on the side of your vehicle people, animals or infrastructure (fences, the approaching vehicle is coming from.

  • Page 174: Cross Traffic Alert

    Driving Aids Switching the System Off and On Note: Do not apply bumper stickers and/or repair compound to these areas, this can You can temporarily switch the Blind Spot cause degraded system performance. Information System off in the information If the system detects a degraded display.
  • Page 175 Driving Aids Cross Traffic Alert is designed to detect fully obstructed. Reversing slowly helps vehicles that approach with a speed up to increase the coverage area and 37 mph (60 km/h). Coverage decreases effectiveness. when the sensors are partially, mostly or E142440 In this first example, the left sensor is only partially obstructed;...
  • Page 176 Driving Aids Zone coverage also decreases when Information System (page 169). If the parking at shallow angles. Here, the left Blind Spot Information System is blocked, sensor is mostly obstructed; zone coverage Cross Traffic Alert is also blocked. A on that side is severely limited. corresponding message appears in the information display as soon as you shift System Lights, Messages and...

  • Page 177: Eco Mode

    Driving Aids System Errors Note: Frequent short trips, where the engine does not fully warm up, will also increase If Cross Traffic Alert senses a problem with fuel consumption the left or right sensor a message will The system is accessed using the appear in the information display.

  • Page 178: Steering

    Driving Aids Steering Tips STEERING If the steering wanders or pulls, check for: Electric Power Steering • Correct tire pressures. WARNINGS • Uneven tire wear. The electric power steering system • Loose or worn suspension has diagnostic checks that components. continuously monitor the system.

  • Page 179: Load Carrying

    Load Carrying Removing the Cover REAR UNDER FLOOR STORAGE Cargo Management System Equipped) E174241 Note: You must repeat the steps on both sides of your vehicle. Open the liftgate and disconnect the tether by pulling it out. E142445 2. Rotate the luggage cover upward. The system is located in the floor of the cargo area.
  • Page 180 Load Carrying following terms for determining Tire and Loading Label Information your vehicle’s weight rating, with Example: or without a trailer, from the vehicle’s Tire and Loading Information label or Safety Compliance Certification label. E198719 Payload PAYLOAD E143816 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 181 Load Carrying Payload is the combined weight GAWR (Gross Axle Weight of cargo and passengers that your Rating) vehicle is carrying. The maximum GAWR is the maximum allowable payload for your vehicle appears weight that a single axle (front or on the Tire and Loading label.
  • Page 182 Load Carrying vehicle’s braking system is rated Safety Compliance Certification Label for operation at Gross Vehicle Example: Weight Rating, not at Gross Combined Weight Rating.) Separate functional brakes should be used for safe control of towed vehicles and for trailers where the Gross Combined Weight of the towing vehicle plus the trailer exceed the Gross Vehicle Weight...
  • Page 183 Load Carrying Steps for determining the Helpful examples for calculating correct load limit: the available amount of cargo and luggage load capacity 1. Locate the statement "The combined weight of occupants Suppose your vehicle has a and cargo should never exceed 1400-pound (635-kilogram) cargo XXX kg or XXX lb."...
  • Page 184 Load Carrying - 1200 = - 240 pounds. No, you do Special Loading Instructions not have enough cargo capacity for Owners of Pick-up Trucks to carry that much weight. In and Utility-type Vehicles metric units, the calculation would WARNING be: 635 kilograms - (2 x 99 kilograms) - (12 x 45 kilograms) = When loading the roof racks, 635 - 198 - 540 = -103 kilograms.

  • Page 185: Towing

    Do not tow with a WARNING slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If Your vehicle is not approved the vehicle is towed incorrectly, or by any for trailer towing.

  • Page 186: Towing The Vehicle On Four Wheels - 1.0L Ecoboost , Automatic Transmission

    Towing Recreational Towing You can tow your vehicle with all four wheels on the ground or with the front WARNING wheels off the ground by using a tow dolly. If you are using a tow dolly, follow the Your vehicle is not approved for instructions specified by the equipment recreational towing with all four provider.
  • Page 187 Towing You can flat-tow (all wheels on the Note: The anti-theft system does not work ground, regardless of the powertrain and until you reconnect the battery cable. transmission configuration) your disabled Note: The maximum towing speed is vehicle (without access to wheel dollies, 70 mph (112 km/h).
  • Page 188 Towing Note: There is no limit on towing distance. After towing, start the engine within 15 minutes of reconnecting the battery cable. See Changing the 12V Battery (page 223). Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 189: Driving Hints

    Driving Hints There are also some things you may want BREAKING-IN to avoid doing because they reduce your fuel economy: You need to break in new tires for approximately 300 mi (480 km). During • Avoid sudden or hard accelerations. this time, your vehicle may exhibit some •...

  • Page 190: Floor Mats

    Driving Hints Before driving through standing water, WARNINGS check the depth. Never drive through water Pedals that cannot move freely can that is higher than the bottom of the front cause loss of vehicle control and rocker area of your vehicle. increase the risk of serious personal injury.

  • Page 191: Installation Procedure

    Driving Hints E142666 To install floor mats, position the floor mat so that the eyelet is over the retention post and press down to lock in. To remove the floor mat, reverse the installation procedure. Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 192: Roadside Emergencies

    Towing — independent service contractors, if not prohibited by state, To fully assist you should you have a local or municipal law, shall tow Ford vehicle concern, Ford Motor Company of eligible vehicles to an authorized dealer Canada, Limited offers a complimentary within 35 mi (56 km) of the roadside assistance program.

  • Page 193: Hazard Warning Flashers

    Canadian customers who require roadside repair fuel leaks after a collision may assistance, call 1-800-665-2006. increase the risk of fire and serious injury. Ford Motor Company recommends Vehicles Sold in Canada: Using that the fuel system be inspected by an Roadside Assistance authorized dealer after any collision.

  • Page 194: Jump Starting The Vehicle

    Roadside Emergencies Connecting the Jumper Cables Note: When you try to restart your vehicle after a fuel shutoff, the vehicle makes sure WARNING that various systems are safe to restart. Once your vehicle determines that the Do not attach the cables to fuel lines, systems are safe, then the vehicle will allow engine rocker covers, the intake you to restart.
  • Page 195 Roadside Emergencies Removing the Jumper Cables 2. Connect the other end of the positive (+) cable to the positive (+) terminal Remove the jumper cables in the reverse of the assisting battery. order that they were connected. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery.

  • Page 196: Post-Crash Alert System

    Roadside Emergencies POST-CRASH ALERT SYSTEM The system flashes the direction indicators and sounds the horn (intermittently) in the event of a serious impact that deploys an airbag (front, side, side curtain or Safety Canopy) or the safety belt pretensioners. The horn and indicators will turn off when: •...

  • Page 197: Customer Assistance

    Mailing address perform a repair after taking your vehicle to the authorized dealer. Repairs will be Customer Relationship Centre made using Ford or Motorcraft® parts, or Ford Motor Company of Canada, Limited remanufactured or other parts that are P.O. Box 2000 authorized by Ford.

  • Page 198: In California (U.s. Only)

    In some states within the United States, conform the vehicle to its applicable you must directly notify Ford in writing express warranties if, within the first 18 before pursuing remedies under your months of ownership of a new vehicle or...

  • Page 199: The Better Business Bureau (Bbb) Auto Line Program (U.s. Only)

    BBB AUTO LINE During mediation, a representative of the 3033 Wilson Boulevard, Suite 600 BBB will contact both you and Ford Motor Arlington, Virginia 22201 Company to explore options for settlement of the claim. If an agreement is not reached...

  • Page 200: Utilizing The Mediation/Arbitration Program (Canada Only)

    Before exporting your vehicle to a foreign Canadian dealers. In those cases where country, contact the appropriate foreign you continue to feel that the efforts by Ford embassy or consulate. These officials can of Canada and the authorized dealer to...

  • Page 201: Ordering Additional Owner's Literature

    (VIN) and new ORDERING ADDITIONAL address with Ford Global Trade Services OWNER'S LITERATURE by emailing, expcso@ford.com. If you are in another foreign country, To order the publications in this portfolio, contact the nearest authorized dealer.

  • Page 202: Reporting Safety Defects (U.s. Only)

    However, Obtaining a French Owner’s NHTSA cannot become involved Manual in individual problems between you, your dealer, or Ford Motor French Owner’s Manual can be obtained Company. from your authorized dealer or by contacting Helm, Incorporated using the...
  • Page 203 Customer Assistance Transport Canada Contact Information Website www.tc.gc.ca/eng/motorvehiclesafety/safevehicles-defectinvestigations- index-76.htm (English) Website www.tc.gc.ca/fra/securiteautomobile/VehiculesSecuritaires-Enquetes- index-76.htm (French) Phone 1–800–333–0510 Ford of Canada Contact Information Website www.ford.ca Phone 1–800–565-3673 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 204: Fuses

    Fuses FUSE SPECIFICATION CHART Engine Compartment Fuse Box E129925 Ampere Fuse Circuits protected rating Anti-lock Braking System pump. Traction control valve. Traction control valve. Heated rear window. Heater blower motor. Start-stop module. Engine management systems. Exhaust gas re-circulation relay. Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 205 Fuses Ampere Fuse Circuits protected rating Starter motor. Rear power window (without door control unit). Transmission control module. Cooling fan – 1.0L EcoBoost. Not used. Not used. Windshield wipers. Traction control module. Horn. Brake lamp switch. Battery monitoring system. Relay coils, lighting control switch module. Right-hand partially heated windshield element.
  • Page 206 Fuses Ampere Fuse Circuits protected rating Total mass air flow sensor - 2.0 GDI. Ignition coils - 1.0L EcoBoost. Run on water pump. Variable valves. Canister purge valve. Crankshaft position sensor. Universal heated exhaust gas oxygen sensor. Canister purge valve. Active grille shutter.
  • Page 207 Fuses Relay Relay Type Circuits switched Micro relay Intercooler fan. Micro relay Horn. Micro relay Front window defroster (partially heated windscreen). Not used. Micro relay Rear wiper. Not used. Not used. Power relay Delayed accessory power. Not used. Mini relay Starter relay.

  • Page 208: Passenger Compartment Fuse Box

    Fuses Passenger Compartment Fuse Box E129926 Ampere Fuse Circuits protected rating Fuel pump supply. Not used. Not used (spare). Passive anti-theft system supply. Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 209 Fuses Ampere Fuse Circuits protected rating Interior lamps, driver's door switch pack, glove box, ambient lighting, electric moonroof. Front cigar lighter. 2nd row power point. Not used (spare). Not used. Not used. Luggage compartment lid release. Driver's door lock. Information and entertainment display. 7.5A Global Positioning System.

  • Page 210: Luggage Compartment Fuse Box

    Fuses Ampere Fuse Circuits protected rating Central locking ground. Driver's door unlock ground. Voltage quality monitoring (KL15). Manual air conditioning heater module. 7.5A Forward looking camera. Radio. Moonroof module. Restraint system. Occupant weight sensor. Heated steering wheel. Not used. Not used. Luggage Compartment Fuse Box E129927 Ampere...
  • Page 211 Fuses Ampere Fuse Circuits protected rating Door module (left-hand front) (electric windows, central locking, heated exterior mirrors). Door module (right-hand front) (electric windows, central locking, heated exterior mirrors). Door module (left-hand rear) (electric windows). Door module (right-hand rear) (electric windows). Not used.
  • Page 212 Fuses Ampere Fuse Circuits protected rating Not used. Blind spot monitor. Rear view camera without start stop module. Parking aid module. Not used. Not used. Not used. Not used. Not used. Not used. Not used. Not used. Not used. Not used. Not used.

  • Page 213: Changing A Fuse

    Fuses Relay Relay Type Circuits switched Power relay Ignition switch. Not used. Not used. Not used. Not used. Not used. CHANGING A FUSE Fuses WARNING Always replace a fuse with one that has the specified amperage rating. E217331 Using a fuse with a higher amperage If electrical components in the vehicle are rating can cause severe wire damage and not working, a fuse may have blown.
  • Page 214 Fuses Fuse Types E207206 Callout Fuse Type Micro 2 Micro 3 Maxi Mini M Case J Case J Case Low Profile Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 215: Maintenance

    Maintenance Working with the Engine On GENERAL INFORMATION WARNING Have your vehicle serviced regularly to help maintain its roadworthiness and resale To reduce the risk of vehicle damage value. There is a large network of and/or personal burn injuries, do not authorized dealers that are there to help start your engine with the air cleaner you with their professional servicing...
  • Page 216 Maintenance 3. Lift the hood and support it with the prop rod. 4. To close the hood, remove the support rod from the catch and secure correctly. 5. Lower the hood and allow it to drop under its own weight for the last 8 in to 12 in (20 cm to 30 cm).

  • Page 217: Under Hood Overview - 1.0L Ecoboost

    Maintenance UNDER HOOD OVERVIEW - 1.0L ECOBOOST E141341 Brake and clutch fluid reservoir (right-hand drive). See Brake Fluid Check (page 222). Engine oil filler cap. See Engine Oil Check (page 216). Brake and clutch fluid reservoir (left-hand drive). See Brake Fluid Check (page 222).

  • Page 218: Under Hood Overview - 2.0L

    Maintenance UNDER HOOD OVERVIEW - 2.0L E212129 Engine coolant reservoir. See Engine Coolant Check (page 218). Engine oil filler cap. See Engine Oil Check (page 216). Brake and clutch fluid reservoir. See Clutch Fluid Check (page 222). Battery. See Changing the 12V Battery (page 223). Engine compartment fuse box.

  • Page 219: Engine Oil Dipstick - 1.0L Ecoboost

    Maintenance 2. Run the engine until it reaches normal ENGINE OIL DIPSTICK - 1.0L operating temperature. ECOBOOST 3. Make sure that your vehicle is on level ground. 4. Switch the engine off and wait 15 minutes for the oil to drain into the oil pan.

  • Page 220: Oil Change Indicator Reset

    Turn it counterclockwise and remove will be displayed. 6. Release the accelerator and brake 3. Add engine oil that meets Ford pedals. specifications. See Capacities and The message confirming that the reset Specifications (page 275). You may is complete will no longer be displayed.

  • Page 221: Engine Cooling Fan

    Maintenance Maintain coolant concentration within ENGINE COOLING FAN 48% to 50%, which equates to a freeze point between -30°F (-34°C) and -34°F WARNING (-37°C). Coolant concentration should be Keep your hands and clothing clear checked using a refractometer. We do not of the engine cooling fan.
  • Page 222 Maintenance Note: Coolants marketed for all makes and Note: In case of emergency, you can add a models may not be approved to Ford large amount of water without coolant in specifications and may cause damage to order to reach a vehicle service location.

  • Page 223: Focus (Cdh) Canada/United States Of America, Hm5J 19A321 Aa Enusa, Edition Date: 201608, First Printing

    Maintenance Severe Climates A warning lamp illuminates and a message may appear in the If you drive in extremely cold climates: information display. • It may be necessary to increase the coolant concentration above 50%. • A coolant concentration of 60% provides improved freeze point If the engine reaches a preset protection.

  • Page 224: Focus (Cdh) Canada/United States Of America, Hm5J 19A321 Aa Enusa, Edition Date: 201608, First Printing

    Maintenance Your vehicle has limited engine power At this time, you may notice the coolant when in the fail-safe mode, drive your temperature gauge moves toward the red vehicle with caution. Your vehicle does not zone and a message may appear in the maintain high-speed operation and the information display.

  • Page 225: Automatic Transmission Fluid Check

    Only use brake fluid from a sealed container. Contamination with dirt, Only use fluid that meets Ford water, petroleum products or other specifications. materials may result in brake system damage or failure.

  • Page 226: Washer Fluid Check

    CHANGING THE 12V BATTERY When a low voltage battery replacement is necessary, see an authorized dealer to replace the low voltage battery with a Ford WARNINGS recommended replacement low voltage Batteries normally produce explosive battery that matches the electrical gases which can cause personal requirements of the vehicle.

  • Page 227: Checking The Wiper Blades

    9. Drive the vehicle at least 12 mi (20 km) the battery should only be replaced with to completely relearn the idle and fuel a Ford recommended replacement battery trim strategy. that matches the electrical requirements Note: If you do not allow the engine to of the vehicle.

  • Page 228: Changing The Rear Wiper Blades

    Maintenance Service Position Note: You can also move the wiper arms to the service position manually when the ignition is off. Do not move the wiper arms to the service position manually when the ignition is on. The wiper arms lock when you switch the ignition on.

  • Page 229: Adjusting The Headlamps

    Maintenance Note: Make sure that the wiper arm does Headlamp Aiming Target not spring back against the glass when the wiper blade is not attached. Lift the wiper arm. E142592 8 ft (2.4 m) Ground to the center of the headlamp low beam bulb 25 ft (7.6 m) E130060...

  • Page 230: Removing A Headlamp

    Maintenance E199411 Note: There may be an identifying mark on the lens to help you locate the center of the bulb. Note: To see a clearer light pattern while adjusting one headlamp, you may want to E164485 block the light from the other headlamp. 5.

  • Page 231: Changing A Bulb

    Maintenance CHANGING A BULB WARNING Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb by only its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated.
  • Page 232 Maintenance Cornering Lamp (If Equipped) Remove the headlamp. See Removing a Headlamp (page 227). E133106 2. Carefully remove the cover. 3. Disconnect the electrical connector. 4. Release the clip and remove the bulb. Headlamp High Beam Remove the headlamp. See Removing a Headlamp (page 227).
  • Page 233 Maintenance 2. Carefully remove the cover. 3. Remove the bulb holder by pulling it straight out. 4. Remove the bulb by pulling it straight out. Front Fog Lamp Remove fog lamp grille from the front fascia then unscrew the fog lamp. E184153 2.
  • Page 234 Maintenance Rear Lamps - 4 Door E133714 Direction indicator and rear lamp E133703 bulb. 2. Remove the wing nuts and detach the Brake lamp bulb. clip. Brake Lamp, Rear Lamp and Direction 3. Remove the lamp. Indicator E133713 4. Disconnect the electrical connector. 5.
  • Page 235 Maintenance Rear Lamps - 5 Door Brake Lamp, Rear Lamp and Direction Indicator E133111 Carefully remove the cover. E184159 Brake and rear lamp bulb. Side marker lamp bulb. Direction indicator bulb. Reverse lamp bulb. E133112 2. Remove the wing nuts and detach the clip.

  • Page 236: Bulb Specification Chart

    Maintenance LED Rear Lamps (If Equipped) These lamps have LED bulbs. Contact an authorized dealer. Replacing Licence Plate and High Mounted Brake Lamp Bulbs These lamps have LED bulbs. Contact an authorized dealer. BULB SPECIFICATION CHART Replacement bulbs are specified in the chart below.
  • Page 237 Maintenance Function Trade number Direction indicator - rear (4-door) P27/7W Direction indicator - rear (5-door) 3757 NAK Rear and brake lamps P27/7W Rear lamps (4-door) * Rear lamp (5-door high series) Sidemarker - rear (5-door) * Sidemarker - rear (High series) Backup lamp * License plate lamp * High-mount brake lamp...

  • Page 238: Changing The Engine Air Filter

    Maintenance 2. Remove the air filter element from the CHANGING THE ENGINE AIR air filter housing. FILTER 3. Wipe any dirt or debris from the air cleaner assembly to make sure no dirt WARNING gets in the engine and to make sure you To reduce the risk of vehicle damage have a good seal.

  • Page 239: Drive Belt Routing - 1.0L Ecoboost

    Maintenance 5. Install the air cleaner assembly lid and tighten the four fasteners. DRIVE BELT ROUTING - 1.0L ECOBOOST E163197 DRIVE BELT ROUTING - 2.0L E189146 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 240: Vehicle Care

    Vehicle Care GENERAL INFORMATION CLEANING PRODUCTS Your dealer has many quality products For best results, use the following products available to clean your vehicle and protect or products of equivalent quality: its finishes. Materials Name Specification Motorcraft® Bug and Tar Remover (U.S.) Motorcraft®...

  • Page 241: Cleaning The Exterior

    Vehicle Care Name Specification Premium Glass Cleaner / Nettoie-vitres de qualité supérieure (Canada) ZC-23 (U.S.) CXC-100 (Canada) Motorcraft® Wheel and Tire Cleaner (U.S.) Wheel and Tire Cleaner / Nettoyant pour roues et pneus (Canada) ZC-37-A (U.S. & Canada) Exterior Chrome Parts CLEANING THE EXTERIOR •...

  • Page 242: Waxing

    Vehicle Care • Use a spray with a 40° wide spray • Do not allow wax to come in contact angle pattern. with any non-body (low-gloss black) colored trim. The wax will discolor or • Keep the nozzle at a 12 in (305 mm) stain the parts over time.

  • Page 243: Cleaning The Windows And Wiper Blades

    Vehicle Care • Never wash or rinse any ignition coil, CLEANING THE INTERIOR spark plug wire or spark plug well, or the area in and around these locations. WARNINGS • Cover the battery, power distribution Do not use cleaning solvents, bleach box, and air filter assembly to prevent or dye on the vehicle’s safety belts, water damage when cleaning the...

  • Page 244: Cleaning The Instrument Panel And Instrument Cluster Lens

    Vehicle Care Wipe up spilled liquid using a clean, CLEANING THE INSTRUMENT soft cloth as quickly as possible. PANEL AND INSTRUMENT 2. Use Motorcraft Premium Leather and CLUSTER LENS Vinyl Cleaner or a commercially available leather cleaning product for WARNING automotive interiors.

  • Page 245: Repairing Minor Paint Damage

    Vehicle Care You should: Note: Industrial-strength or heavy-duty cleaners in combination with brush agitation • Remove dust and loose dirt with a to remove brake dust and dirt, could wear vacuum cleaner. away the clear coat finish over a period time. •...
  • Page 246 Vehicle Care General • With your foot on the brake, shift through all the gears while the engine • Store all vehicles in a dry, ventilated is running. place. • We recommend that you change the • Protect from sunlight, if possible. engine oil before you use your vehicle again.

  • Page 247: Body Styling Kits

    Vehicle Care Miscellaneous BODY STYLING KITS • Make sure all linkages, cables, levers The distance between the underside of and pins under your vehicle are covered your vehicle and the ground is less than with grease to prevent rust. that of other models. Drive with extreme •...

  • Page 248: Wheels And Tires

    Wheels and Tires Information About Uniform TIRE CARE Tire Quality Grading Important Information for 235/40R18 Low-Profile Tires and Wheels If your vehicle is equipped with 235/40R18 tires, they are low-profile tires. These tires and wheels are designed to give your vehicle a sport appearance.
  • Page 249 Transportation-Tire quality to lowest are AA, A, B, and C. The grades: The U.S. Department of grades represent the tire’s ability Transportation requires Ford to stop on wet pavement as Motor Company to give you the measured under controlled following information about tire...
  • Page 250 Wheels and Tires Federal Motor Vehicle Safety PSI: Pounds per square inch, a Standard No. 139. Grades B and A standard unit of air pressure. represent higher levels of Cold tire pressure: The tire performance on the laboratory pressure when the vehicle has test wheel than the minimum been stationary and out of direct required by law.
  • Page 251 Wheels and Tires Information Contained on the A. P: Indicates a tire, designated Tire Sidewall by the Tire and Rim Association, that may be used for service on Both U.S. and Canada Federal cars, sport utility vehicles, regulations require tire minivans and light trucks.
  • Page 252 Wheels and Tires G. H: Indicates the tire's speed Letter Speed rating rating. The speed rating denotes rating the speed at which a tire is 168 mph (270 km/h) designed to be driven for extended periods of time under a standard 186 mph (299 km/h) condition of load and inflation Note: For tires with a maximum...
  • Page 253 Wheels and Tires J. Tire Ply Composition and *Traction: The traction grades, Material Used: Indicates the from highest to lowest are AA, A, number of plies or the number of B, and C. The grades represent the layers of rubber-coated fabric in tire's ability to stop on wet the tire tread and sidewall.
  • Page 254 Wheels and Tires The tire suppliers may have C. Maximum Load Dual lb (kg) additional markings, notes or at psi (kPa) cold: Indicates the warnings such as standard load, maximum load and tire pressure radial tubeless, etc. when the tire is used as a dual, defined as four tires on the rear Additional Information axle (a total of six or more tires on...
  • Page 255 Inflate all tires to the width of the tire in millimeters inflation pressure recommended from sidewall edge to sidewall by Ford Motor Company. edge. In general, the larger the number, the wider the tire. C. 80: Indicates the aspect ratio which gives the tire's ratio of height to width.
  • Page 256 Safety automatic service station gauges Compliance Certification Label may be inaccurate. Ford (affixed to either the door hinge recommends the use of a digital pillar, door-latch post, or the door or dial-type tire pressure gauge...
  • Page 257 Wheels and Tires When weather temperature 3. Add enough air to reach the changes occur, tire inflation recommended air pressure. pressures also change. A 10°F Note: If you overfill the tire, release (6°C) temperature drop can air by pressing on the metal stem cause a corresponding drop of in the center of the valve.
  • Page 258 Wheels and Tires Inspecting Your Tires and Tire Wear Wheel Valve Stems Periodically inspect the tire treads for uneven or excessive wear and remove objects such as stones, nails or glass that may be wedged in the tread grooves. Check the tire and valve stems for holes, cracks, or cuts that may permit air leakage and repair or replace the...
  • Page 259 This provided by Ford. The information identifies and recommended tire and wheel size Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 260 Use of any tire or wheel 2. Lubricate the tire bead and not recommended by Ford can wheel bead seat area again. affect the safety and performance of your vehicle, which could result 3.
  • Page 261 Highway Hazards The use of wheels or tires not No matter how carefully you drive recommended by Ford Motor there is always the possibility that Company may affect the you may eventually have a flat tire operation of your tire pressure on the highway.
  • Page 262 Wheels and Tires Tire and Wheel Alignment Tire Rotation A bad jolt from hitting a curb or WARNING pothole can cause the front end If the tire label shows of your vehicle to become different tire pressures for the misaligned or cause damage to front and rear tires and the vehicle your tires.

  • Page 263: Using Snow Chains

    • Install snow chains securely, make sure originally provided by Ford. Use of they do not touch any wiring, brake any tire or wheel not recommended by lines or fuel lines.

  • Page 264: Tire Pressure Monitoring System

    Wheels and Tires Please note that the TPMS is not a TIRE PRESSURE MONITORING substitute for proper tire maintenance, and SYSTEM it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation WARNING has not reached the level to trigger illumination of the TPMS low tire pressure The tire pressure monitoring system telltale.
  • Page 265 Wheels and Tires Changing Tires With a Tire Understanding Your Tire Pressure Pressure Monitoring System Monitoring System The tire pressure monitoring system measures pressure in your four road tires and sends the tire pressure readings to your vehicle. The low tire pressure warning light will turn on if the tire pressure is significantly low.
  • Page 266 Wheels and Tires Low tire pressure Possible cause Customer action required warning light Solid warning light Tire(s) under-inflated Make sure tires are at the proper pres- sure. See Inflating your tires in this chapter. After inflating your tires to the manufacturer’s recommended pressure as shown on the Tire Label (located on the edge of driver’s door or the B-Pillar),...

  • Page 267: Changing A Road Wheel

    If you must use a sealant, the by Ford. If the dissimilar spare tire or wheel Ford Tire Mobility Kit sealant should be is damaged, it should be replaced rather used.
  • Page 268 Wheels and Tires 1. T-type mini-spare: This spare tire • Use commercial car washing begins with the letter T for tire size and equipment. may have Temporary Use Only molded in • Use snow chains on the end of the the sidewall.
  • Page 269 Wheels and Tires WARNINGS Never get underneath a vehicle that is supported only by a jack. If the vehicle slips off the jack, you or someone else could be seriously injured. Do not attempt to change a tire on the side of the vehicle close to moving traffic.

  • Page 270: Driving At High Speed

    Wheels and Tires Stowing the Flat Tire The full-size road wheel can be stowed in the spare tire compartment. Lift the carpeted wheel cover at an angle to access the spare tire compartment. 2. Place the wheel in the spare tire well with the valve stem facing down.

  • Page 271: Lug Nuts

    M12 x 1.5 100 lb.ft (135 Nm) *Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. E184089 Your tires may require additional inflation pressure for operation at speeds greater than 100 mph (160 km/h).

  • Page 272: Capacities And Specifications

    Capacities and Specifications ENGINE SPECIFICATIONS - 1.0L ECOBOOST Engine 1.0L EcoBoost Cubic inches Required fuel Minimum 87 octane Firing order 1-2-3 Ignition system Coil on plug Spark plug gap 0.026 – 0.030 in. (0.65 – 0.75 mm) Compression ratio 10.0:1 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 273: Engine Specifications - 2.0L

    Capacities and Specifications ENGINE SPECIFICATIONS - 2.0L Engine 2.0L GDI Cubic inches Required fuel Minimum 87 octane or E85 Firing order 1-3-4-2 Ignition system Coil on plug Spark plug gap .034 - .036 in. (.85 - .95 mm) Compression ratio 12.0:1 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 274: Motorcraft Parts - 1.0L Ecoboost

    Rear window wiper blade WW-1295 We recommend Motorcraft replacement parts available at your Ford dealer or at fordparts.com for scheduled maintenance. These parts meet or exceed Ford Motor Company’s specifications and are engineered for your vehicle. Use of other parts may impact vehicle performance, emissions and durability.

  • Page 275: Motorcraft Parts - 2.0L

    Rear window wiper blade WW-1295 We recommend Motorcraft replacement parts available at your Ford dealer or at fordparts.com for scheduled maintenance. These parts meet or exceed Ford Motor Company’s specifications and are engineered for your vehicle. Use of other parts may impact vehicle performance, emissions and durability.

  • Page 276: Vehicle Identification Number

    Capacities and Specifications VEHICLE IDENTIFICATION NUMBER The vehicle identification number is located on the left-hand side of the instrument panel. E142477 World manufacturer identifier Brake system, Gross Vehicle Weight Rating, Restraint Devices and their locations Make, vehicle line, series, body type Engine type Check digit...

  • Page 277: Vehicle Certification Label

    Capacities and Specifications VEHICLE CERTIFICATION TRANSMISSION CODE LABEL DESIGNATION E167469 E167814 The National Highway Traffic Safety The transmission code is on the Safety Administration Regulations require that a Compliance Certification Label. The Safety Compliance Certification Label be following table shows the transmission affixed to a vehicle and prescribe where code along with the transmission the Safety Compliance Certification Label...

  • Page 278: Capacities And Specifications - 1.0L Ecoboost

    We recommend that you use Motorcraft Quantity oil and fluids for your vehicle. Only use fluid that meets Ford specifications. 0.7 qt (0.7 L) Note: Use of other fluids may lead to The quantity of engine oil required to raise...
  • Page 279 Capacities and Specifications Name Specification Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake WSS-M6C65-A2 Fluid (U.S.) DOT 4 LV High Performance Motor Vehicle Brake Fluid / Liquide de frein automobile haute performance DOT 4 LV (Canada) PM-20 (U.S. & Canada) Motorcraft®...
  • Page 280 Capacities and Specifications Using oil and fluids that do not meet the defined specification and viscosity grade may lead to: • Component damage which may not be covered by the vehicle Warranty. • Longer engine cranking periods. • Increased emission levels. •...

  • Page 281: Capacities And Specifications - 2.0L

    Capacities and Specifications E240522 CAPACITIES AND SPECIFICATIONS - 2.0L WARNING The air conditioning refrigerant system contains refrigerant under high pressure. Only qualified personnel should service the air conditioning refrigerant system. Opening the air conditioning refrigerant system can cause personal injury. Capacities Item Capacity...
  • Page 282 We recommend that you use Motorcraft Quantity oil and fluids for your vehicle. Only use fluid that meets Ford specifications. 0.7 qt (0.7 L) Note: Use of other fluids may lead to The quantity of engine oil required to raise...
  • Page 283 Capacities and Specifications Name Specification R-1234yf Refrigerant PAG Oil / Huile PAG pour frigorigène R-1234yf (Canada) YN-35 (U.S. & Canada) Motorcraft® Multi-Purpose Grease Spray (U.S.) ESB-M1C93-B Motorcraft® Multi-Purpose Grease Spray / Graisse multiusage (Canada) XL-5-A (U.S. & Canada) Penetrating and Lock Lubricant (U.S.) Penetrating Fluid / Liquide dégrippant (Canada) XL-1 (U.S.) CXC-51-A (Canada)
  • Page 284 Capacities and Specifications Alternative Engine Oil for we recommend that you use the following Extremely Cold Climates alternative engine oil in extremely cold climates, where the ambient temperature To improve engine cold start performance, reaches -22.0°F (-30°C) or below. Materials Name Specification Motorcraft®...

  • Page 285: Audio System

    Audio systems capable of recognizing and may not function correctly when used in playing MP3 and WMA individual tracks Ford CD players. and folder structures work as follows: • There are two different modes for MP3...

  • Page 286: Audio Unit - Vehicles With: Sync

    Audio System • MP3 and WMA folder mode represents AUDIO UNIT - VEHICLES WITH: a folder structure consisting of one SYNC level of folders. The CD player numbers all MP3 and WMA tracks on the disc WARNING (noted by the MP3 or WMA file extension) and all folders containing Driving while distracted can result in MP3 and WMA files, from F001 (folder)
  • Page 287 Audio System E184901 VOL and Power: Press to switch the system on and off. Turn the control to adjust the volume. Function buttons: Select different functions of the audio system depending on which mode you are in (such as Radio mode or CD mode). CD slot: Insert a CD.
  • Page 288 Audio System TUNE and Play or Pause: In radio mode, turn to search the frequency band in individual increments. Press to mute the station. In media mode, turn to select a new track. Press to either play or pause a track. This button also mutes the radio sources.

  • Page 289: Audio Unit - Vehicles With: Sony Audio System

    Audio System Note: The touchscreen system controls AUDIO UNIT - VEHICLES WITH: most of the audio features. See your MyFord SONY AUDIO SYSTEM Touch information. WARNING Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road.
  • Page 290 Audio System TUNE: In radio mode, press to manually search through the radio frequency band. In SIRIUS mode, press to find the previous or next available satellite radio station. Eject: Press to eject a CD. SOUND: Press to access settings for Treble, Midrange, Bass, Fade or Balance. Volume: Turn to adjust the volume.
  • Page 291 Audio System SIRIUS Scan Select for a brief sampling of all available channels. Show ESN Select to view your satellite radio electronic serial number (ESN). You need this number when communicating with Sirius to activate, modify or track your account. Channel Guide Select to view available satellite radio channels.
  • Page 292 Audio System CD Settings Scan All Select to scan all disc selections. Scan Folder Select to scan all music in the current MP3 folder. CD Compression Select to bring soft and loud passages together for a more consistent listening level. Clock Settings Set Time Select to set the time.

  • Page 293: Audio Unit - Vehicles With: Satellite Radio

    Audio System Note: Depending on your vehicle option AUDIO UNIT - VEHICLES WITH: package, your system may look different SATELLITE RADIO from what you see here. Note: Some features, such as Sirius satellite WARNING radio, may not be available in your location. Driving while distracted can result in Check with an authorized dealer.
  • Page 294 Audio System E184902 VOL and Power: Press to switch the system on and off. Turn the control to adjust the volume. Function buttons: Select different functions of the audio system depending on which mode you are in (such as Radio mode or CD mode). CD slot: Insert a CD.

  • Page 295: Digital Radio

    Audio System TUNE and Play or Pause: In radio mode, turn to search the frequency band in individual increments or jump to the next station of the station list. Press to mute the station. In media mode, turn to select a new track. Press to either play or pause a track.
  • Page 296 Audio System than analog broadcasts with free, When HD Radio broadcasts are active, you crystal-clear audio and no static or can access the following functions: distortion. For more information, and a • Scan allows you to hear a brief guide to available stations and sampling of all available stations.
  • Page 297 Audio System In order to provide the best possible technology. Independent entities own and experience, use the contact form to report operate each station. These stations are any station issues found while listening to responsible for ensuring all audio streams a station broadcasting with HD Radio and data fields are accurate.

  • Page 298: Satellite Radio

    SIRIUS® broadcasts a variety of music, HD Radio logos are proprietary trademarks news, sports, weather, traffic and of iBiquity Digital Corp. Ford Motor entertainment satellite radio channels. For Company and iBiquity Digital Corp. are not more information and a complete list of...
  • Page 299 Audio System SIRIUS satellite radio is a For more information on extended subscription-based satellite radio service subscription terms (a service fee is that broadcasts a variety of music, sports, required), the online media player and a news, weather, traffic and entertainment complete list of SIRIUS satellite radio programming.

  • Page 300: Usb Port

    Audio System Message Condition Action Questions? Call Your satellite service is no Contact SIRIUS at 1-888- longer available. 539-7474 to resolve 1-888-539-7474 subscription issues. None found All the channels in the Use the channel guide to selected category are either turn off the Lock or Skip Check Channel Guide skipped or locked.

  • Page 301: Sync

    SYNC GENERAL INFORMATION E198355 • Use the advanced voice recognition SYNC is an in-vehicle communications system. system that works with your Bluetooth-enabled cellular phone and • Charge your USB device (if your device portable media player. This allows you to: supports this).
  • Page 302 SYNC Sunday, 10:30am-7:30pm EST. When using SYNC: • Do not operate playing devices if the In the United States, call 1-800-392-3673. power cords or cables are broken, split In Canada, call 1-800-565-3673. or damaged. Place cords and cables Times are subject to change due to out of the way, so they do not interfere with the operation of pedals, seats, holidays.

  • Page 303: Using Voice Recognition

    SYNC module. Ford Motor This system helps you control many Company and Ford of Canada will not features using voice commands. This access the system data for any purpose allows you to keep your hands on the other than as described absent consent, a wheel and focus on what is around you.
  • Page 304 SYNC System Interaction and Feedback The default setting is to a higher level of interaction in order to help you learn to use The system provides feedback through the system. You can change these settings audible tones, prompts, questions and at any time.

  • Page 305: Using Sync With Your Phone

    SYNC To adjust this setting press the voice button, when prompted say: Voice Command Action and Description voice settings Then any of the following: phone confirmation on When enabled, this feature will prompt you to confirm any voice initiated call command prior to the call being placed.
  • Page 306 SYNC Other features, such as text messaging 4. When prompted on your cell phone’s using Bluetooth and automatic phonebook display, confirm that the PIN provided download, are phone-dependent features. by SYNC matches the PIN displayed To check your phone's compatibility, see on your cell phone.
  • Page 307 SYNC Depending on your phone's capability and SYNC may prompt you with more cell your market, the system may prompt you phone options. Your cell phone may also with questions, such as setting the current prompt you to give SYNC permission to phone as the primary phone (the phone access information.
  • Page 308 SYNC Voice Command To access text messages say: [text] (messages | message) Voice Command help [text] (messages | message) ___ is a dynamic listing that should be the Then say any of the following: name of a contact in your phonebook. For (listen to | read) ([text] message) example you could say "Call Home".
  • Page 309 SYNC on the steering wheel or select the end call option in the audio display. Voice Command Receiving Calls (connect | You can state the name of device) ___ the desired device, such as Accepting calls “My iPhone”,“My Galaxy” or“My iPod”. SYNC may When receiving a call, you can answer the ask you to confirm the type call by pressing the accept call button on...
  • Page 310 SYNC Menu Item Description and action Mic. off Switch your vehicle's microphone off. To switch the microphone on, select the option again. Privacy Switch a call from an active hands-free environment to your cellular phone for a more private conversation. When selected, the audio display indicates the call is private.
  • Page 311 SYNC Display Description and action Dial a number Enter numbers using the audio system's numeric keypad. Phonebook Access your downloaded phonebook. 1. Press the OK button to confirm and enter. You can use the options at the bottom of the screen to access an alphabetical category quickly.
  • Page 312 SYNC Using the screen you also have the following options: Menu Description and action Item Ignore Select this option, or do nothing, and the message goes into your text message inbox. View Select the view option to open the text message. Once selected, you have the ability to have the message read to you, to view other messages.
  • Page 313 SYNC Sending a Text Message Note: You can send text messages either by choosing a contact from the phonebook Note: You can only send a text message to and selecting the text option from the audio one recipient at a time. display or by replying to a received message Select the send option when the in the inbox.
  • Page 314 SYNC Menu Item Phonebook preferences Add contacts Push the desired contacts on your cellular phone. See your device's manual on how to push contacts. Press the OK button to add more contacts from your phonebook. Delete When a message asking you to delete appears, select the option to confirm.
  • Page 315 SYNC Menu Item Description and action 2. When a message to begin pairing appears in the audio display, search for SYNC on your phone. See your phone's manual if necessary. 3. When prompted on your cell phone’s display, confirm that the PIN provided by SYNC matches the PIN displayed on your cell phone.
  • Page 316 SYNC Scroll to select from the following options: Display Description and action Bluetooth on Check or uncheck this option to switch the system's Bluetooth interface off or on. Select this option, and then press the OK button to change the option's status. Set defaults Return to the factory default settings without erasing your indexed information (such as phonebook, call history, text...

  • Page 317: Sync Applications And Services

    SYNC Note: The SYNC 911 Assist feature must be SYNC APPLICATIONS AND set on before the incident. SERVICES (If Equipped) Note: The SYNC 911 Assist feature only operates in the U.S., Canada or in a territory In order for the following features to work, in which 911 is the emergency number.
  • Page 318 SYNC Setting 911 Assist On or Off • A connected Bluetooth-enabled phone must have adequate network coverage, Press Menu then select battery power and signal strength. • The vehicle must have battery power Menu Action and Description and be located in the U.S., Canada or Item in a territory in which 911 is the SYNC-Applications...
  • Page 319 Note: For information on available apps, supported smartphone devices and Accessing an App's Menu troubleshooting tips please visit the Ford When an app is running through SYNC, website. press the right arrow button on the steering Availability of SYNC AppLink enabled Apps wheel control to access the app menu.
  • Page 320 SYNC To Access Using Voice Commands Press the voice button then when prompted say: Menu Item Action and Description mobile (apps | Say the name of the application after the tone. applications) The app should start. When an app is running through SYNC, you can press the voice button and speak commands specific to the app, for example "Play Playlist Road Trip".
  • Page 321 This includes Data is sent to Ford in the United States any additional charges incurred due to through the connected device. The driving in areas when roaming out of a home information is encrypted and includes your network.

  • Page 322: Using Sync With Your Media Player

    SYNC There are three possible statuses: Menu Item Action and Description Update Needed The system has detected a new app requiring authorization or a general permissions update is required. Up-To-Date No update is required. Updating... The system is trying to receive an update. Update settings Menu Item Action and Description...
  • Page 323 SYNC To Connect Using Voice Commands To Connect Using the System Menu Plug the device into one of the vehicle's Plug the device into one of the vehicle's USB ports. USB ports. 2. Press the MEDIA button and select Press the voice button and when either USB 1 or USB 2 from the media prompted, say: source list in the audio display.
  • Page 324 SYNC Voice Command Description and Action (USB [stick] | iPod | MP3 You can now play music by saying any of the appropriate [player]) voice commands. You can say any of the voice commands that appear within open and close brackets that are separated by |.
  • Page 325 SYNC Command Description and Action shuffle [all] [on] Plays the current playlist in a random order. (Not all devices support this command.) shuffle off ((who's | who is) this | who plays this | At any time during playback, you can press (what's | what is) playing [now] | (what the voice button and ask the system what is | which) (song | track | artist) is this |...
  • Page 326 SYNC Message Description and Action Options This will enter the media menu. Then any of the following: Message Description and Action Shuffle Choose to shuffle or repeat your music. Once you make your choice, it remains on until you switch it off. Repeat track Choose to shuffle or repeat your music.
  • Page 327 SYNC If there are media files, you have the following options: Display Description and Action Play all Play all indexed media files from your device one at a time in numerical order. Press the OK button to select. The first track title appears in the display.
  • Page 328 SYNC Display Description and Action 2. Scroll to browse indexed media files on the device, and then press the OK button. Reset USB Resets the USB index. After the new indexing is complete, you can choose what to play from the USB song library. You can use the buttons at the bottom of the audio display to jump to a certain alphabetical category quickly.
  • Page 329 SYNC Voice Commands for Audio Voice Command Sources ((who's | who is) this | who plays this | Your voice system allows you to change (what's | what is) playing [now] | (what audio sources with a simple voice | which) (song | track | artist) is this | command.
  • Page 330 SYNC Voice Command Voice Commands [tune [to]] FM 2 [tune [to]] SAT 2 preset ___ [tune [to]] (FM ___ | ___ [FM]) [tune [to]] SAT 3 preset ___ [tune [to]] FM preset ___ tune [to] [Sirius] FM ___ HD ___ Help [tune [to]] Sirius You can say the...

  • Page 331: Sync Troubleshooting

    SYNC Use the website at any time to check your Voice Command phone's compatibility, register your account and set preferences as well as (shuffle | random | mix) (CD [player] | access a customer representative via an disc) [on] online chat (during certain hours). Visit (shuffle | random | mix) folder [on] www.SYNCMyRide.com, www.SYNCMyRide.ca or...
  • Page 332 SYNC Phone issues Issue Possible cause(s) Possible solution(s) If the missing contacts are stored on your SIM card, try moving them to the device memory. Remove any pictures or special ring tones associ- ated with the missing contact. Depending upon your phone, you may have to grant SYNC permission to access your phonebook contacts.
  • Page 333 SYNC Phone issues Issue Possible cause(s) Possible solution(s) Turn off the Auto phone- book download setting. This is a phone-dependent Go to the website to review feature. your phone's compatibility. Text messaging is not Try turning off the device, working on SYNC. This may be a possible resetting the device or phone malfunction.
  • Page 334 SYNC USB and media issues Issue Possible cause(s) Possible solution(s) Make sure you correctly connect the device to SYNC, The device is not connected. and that you have pressed play on your device. Your music files may not contain the correct artist, Make sure that all song song title, album or genre details are populated.
  • Page 335 SYNC Voice command issues Issue Possible cause(s) Possible solution(s) Say the song or artist exactly as listed. If you say "Play Artist Prince", the system does not play music by Prince and the Revolution You may be saying the or Prince and the New name differently than the Power Generation.
  • Page 336 SYNC Voice command issues Issue Possible cause(s) Possible solution(s) The system works better if The system may not be you list full names, such as reading the name the same "Joe Wilson" rather than way you are saying it. "Joe". Contacts in your phonebook Do not use special charac- may be very short and...
  • Page 337 Possible solution(s) login on the app on the phone before using them with AppLink. Also, some may have a "Ford SYNC" setting, so check the app's settings menu on the phone. Closing and restarting apps may help SYNC find the application if you cannot discover it inside the vehicle.
  • Page 338 Force close or uninstall the a limited number of apps you do not want SYNC bluetooth ports apps can to find. If the app has a "Ford I can only see some of the use to connect. If you have SYNC" setting, disable that...

  • Page 339: General Information

    SYNC Getting to Know Your System GENERAL INFORMATION The SYNC 3 system allows you to interact WARNING with a variety of features using the touchscreen and voice commands. By Driving while distracted can result in integrating with your Bluetooth-enabled loss of vehicle control, crash and phone, the touchscreen provides easy injury.
  • Page 340 SYNC Item Menu Item Action and Description Status Bar This bar displays icons and messages pertaining to current system activities including climate settings, voice commands and phone functions such as text messages. Home This button is available on the main screens. Pressing it takes you to the home screen view.
  • Page 341 SYNC E223058 Callout Item Description Microphone Mute This icon displays when your phone's microphone is muted. A caller cannot hear you. Mute This icon displays when the audio system is muted. Download This icon displays when SYNC 3 has received a soft- ware update.
  • Page 342 SYNC Callout Item Description 911 Assist Off This icon displays when 911 Assist is set to off and your phone is connected to SYNC. Bluetooth Alert This icon displays when there is an active Bluetooth alert. Bluetooth This icon displays to show an active Bluetooth connection.
  • Page 343 SYNC Cleaning the Touchscreen SEEK NEXT: • While in radio mode, press to seek You can remove fingerprints with a dry, between memory presets. clean, soft cloth. • While in USB, Bluetooth Audio or CD If dirt or fingerprints are still on the screen, mode, press to seek between songs or apply a small amount of alcohol to the press and hold to fast seek.
  • Page 344 Website Do not wait for 911 Assist to make an emergency call if you can do it www.owner.ford.com yourself. Dial emergency services www.syncmyride.ca immediately to avoid delayed response www.syncmaroute.ca time which could increase the risk of serious injury or death after a crash.
  • Page 345 SYNC To make sure that 911 Assist works If you do not cancel the call, and SYNC correctly: makes a successful call, a pre-recorded message plays for the 911 operator, and • SYNC must be powered and working then the occupant(s) in your vehicle is able properly at the time of the incident and to talk with the operator.
  • Page 346 SYNC Safety Information • Do not leave playing devices in your vehicle during extreme conditions as it WARNING could cause them damage. See your device's user guide for further Driving while distracted can result in information. loss of vehicle control, crash and •...
  • Page 347 Visit the website to sign up and register. You can choose to download the update onto a USB drive or use Wi-Fi to deliver Website automatic updates. www.owner.ford.com www.syncmyride.ca USB Updates www.syncmaroute.ca To use the USB update you need to log...
  • Page 348 SYNC You will need an empty USB drive. Please You must also give the system permission check the website for minimum to update automatically. Upon vehicle requirements. Once you have inserted the delivery, the System asks you if you would USB drive into your computer, choose to like to use the automatic update feature.
  • Page 349 Times are subject to change due to access to your vehicle's SYNC 3 module. holidays. Ford Motor Company and Ford of Canada Privacy Information do not access the system data for any purpose other than as described absent...

  • Page 350: Home Screen

    SYNC HOME SCREEN E207616 Item Tile Home screen display Audio Shows the active media source. If your vehicle does not have navigation, this space contains the compass. Phone The name of the connected phone appears on the screen. The status of the phone features also appear. This includes signal strength, battery charge, 911 assist setting state (On or Off), text messaging and roaming.

  • Page 351: Using Voice Recognition

    SYNC Item Tile Home screen display If your vehicle does not have navigation, this space contains the audio information. If equipped. You can access each feature controlled by You can touch any of the feature displays SYNC 3 through a variety of commands. to access that feature.
  • Page 352 SYNC Audio Voice Commands Included here are some of the most popular commands for each SYNC 3 ___ is a dynamic listing, meaning that for feature. audio voice commands it can be the name of a Sirius channel or a channel number, a radio frequency number, or the name of a artist, album, song or a genre.
  • Page 353 SYNC Phone Voice Commands You can use voice commands to connect your Bluetooth-enabled phone to the Pairing a Phone system. To pair your phone, press the voice button and when prompted, say: Voice command Description Pair Phone Follow the on-screen instructions to complete the pairing process.
  • Page 354 SYNC Text Message Voice Commands To access text message options, press the voice button and say: Voice command Description Listen to Message Listen to text message ___ You can say the number of the message you would like to hear. Reply to Message ___ is a dynamic listing, meaning that for Navigation Voice Commands...
  • Page 355 SYNC In addition, you can say these commands when a route is active: Voice command Description Cancel Route Cancels the current route. Detour Allows you to select an alternate route. Repeat Instruction Repeats the last guidance prompt. Show Route Shows the current route. Where Am I Provides current location.
  • Page 356 SYNC SiriusXM Traffic and Travel Link SiriusXM Traffic and Travel Link may not Voice Commands be available in all markets. Activation and (If Equipped) a subscription are required. You can say the following commands to access SiriusXM Traffic and Travel Link: Voice command Description Show Traffic...

  • Page 357: Entertainment

    SYNC Note: Depending on the current climate To disable this automatic fan speed control settings, the fan speed may reduction feature during voice sessions, automatically go down while issuing voice press and hold the climate control AC and commands or while making and receiving Recirculated air buttons simultaneously, phone calls via SYNC to reduce the amount release and then increase fan speed within...
  • Page 358 SYNC You can access these options using the touchscreen or voice commands. Message Message and description Sources Sources Press this button to select the source of Direct Tune media you want to listen to. Presets Menu item SIRIUS The name of the USB that is plugged in displays here. Bluetooth Stereo Apps If you have SYNC 3 compatible apps on your connected smart phone, they...
  • Page 359 This includes canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes. Note: This receiver includes the eCos real-time operating system.
  • Page 360 SYNC Menu item Action and description Replay Replay audio on the current channel. You can replay approx- imately 45 minutes of audio as long as you remain tuned to the current station. Changing stations erases the previous audio. Live When you are in replay mode, you are not able to select a different preset until you return to live audio.
  • Page 361 SYNC Troubleshooting tips Message Cause Action Acquiring Signal Radio requires more than two No action required. This seconds to produce audio for message should disappear the selected channel. shortly. Satellite antenna fault There is an internal module or If this message does not clear system failure present.
  • Page 362 SYNC HD Radio technology is the digital The HD logo is grey when acquiring a digital evolution of analog AM/FM radio. Your station, and then changes to orange when system has a special receiver that allows digital audio is playing. When this logo is it to receive digital broadcasts (where available, you may also see Title and Artist available) in addition to the analog...
  • Page 363 SYNC HD Radio Reception and Station Troubleshooting Potential reception issues Reception area If you are listening to a multicast station and you are on the fringe of the reception area, the station may mute due to weak signal strength. If you are listening to HD1, the system changes back to the analog broadcast until the digital broadcast is available again.
  • Page 364 HD Radio and the HD and http://www.ibiquity.com/automotive/ HD Radio logos are proprietary trademarks report_radio_station_experiences of iBiquity Digital Corp. Ford Motor Company and iBiquity Digital Corp. are not responsible for the content sent using HD Radio technology. Content may be...
  • Page 365 SYNC Bluetooth Stereo or USB access media that you store on your Bluetooth device or USB device such as Bluetooth Stereo and USB allow you to music, audio books or podcasts. The following buttons are available for Bluetooth and USB: Button Function Repeat...
  • Page 366 SYNC Button Function Composers A-Z Jump This button allows you to choose a specific letter to view within the category you are browsing. Explore Device If available, this allows you to browse the folders and files on your USB device. Supported Media Players, Formats USB Ports and Metadata Information...

  • Page 367: Phone

    SYNC 4. Confirm that the six-digit number PHONE appearing on your phone matches the six-digit number on the touchscreen. WARNING 5. The touchscreen indicates when the Driving while distracted can result in pairing is successful. loss of vehicle control, crash and 6.

  • Page 368: Phone Menu

    To check your phone’s compatibility, see your phone’s manual or visit the Phone Menu website: This menu becomes available after pairing Websites a phone. owner.ford.com E205447 Item Menu Item Action and Description Recent Call Displays your recent calls. List You can place a call by selecting an entry from this list.
  • Page 369 SYNC Item Menu Item Action and Description You can also sort the calls by selecting the drop down menu at the top of the screen. You can choose: Incoming Outgoing Missed Contacts All of your contacts from your phone display in alphabetical order.
  • Page 370 SYNC To call a number in your contacts, To accept the call, select: select: Menu Item Menu Item Action and Description Accept Contacts You can then select the Note: You can also accept the call by name of the contact you pressing the phone button on the steering want to call.
  • Page 371 SYNC Item Item Privacy Transfer the call to End Call Immediately end a the cell phone or phone call. You can back to SYNC 3. also press the button on the Text Messaging steering wheel. Note: Downloading and sending text Keypad Press this to access messages using Bluetooth are cell...

  • Page 372: Navigation

    SYNC 2. Select Apple CarPlay on the To disable this feature from the touchscreen. Settings screen, select: To disable this feature from the Menu Item Settings screen, select: Android Auto Preferences Menu Item Your device is listed if SYNC detects Apple CarPlay Preferences Android Auto.
  • Page 373 SYNC 3D city models are complete 3D models Re-center the map by pressing of entire city areas including navigable this icon whenever you scroll the roads, parks, rivers and rendered buildings. map away from your vehicle’s 3D landmarks and city models appear in current location.
  • Page 374 SYNC Destination Mode To set a destination, press: Menu Item Description Destination Enter a navigation destination in any of the following formats: Search Street Address (number, street, city, state) For example "12 Mainstreet Dearborn MI" Partial Address (number, street) if searching in current state (number, street and zip code (or postal code in Canada)) if searching out of state You can enter unique addresses that contain door number prefixes...
  • Page 375 SYNC Menu Item Description Delete Select this option to remove all previous destinations. Home Select to navigate to your set Home destination. The time it takes to travel from your current location to Home displays. To set your Home, press: Home A prompt appears asking if you would like to create a favorite for home.
  • Page 376 SYNC Menu Item Description See All Press to view additional categories. Once you have selected a category, follow the menus to find what you are looking for. Inside of these categories you can search by: Nearby Along Route Near Destination In a City Once you have chosen your destination, press: Menu Item...
  • Page 377 SYNC Menu Item Action and Description The navigation map shows your estimated time of arrival, remaining travel time and the distance to your destination. SYNC 3 may not always announce vehicle arrival at the exact point of your destination and you may have to cancel a route manually. During active navigation, touch the bottom Navigation Menu of the screen to view the menu and other...
  • Page 378 SYNC Button Navigation Press this button to adjust your preferences. See Settings (page 380). Settings Where Am I? Provides your current location city and the nearest road. The following are only available on the menu during an active navigation route: Cancel Route The system asks for confirmation and then returns you to the map mode screen.
  • Page 379 SYNC Menu Item Add Waypoint The waypoint list then appears and you are able to re-order all of your waypoints by selecting the menu icon on the right hand side of the location. You can select up to five waypoints. You can also have the system set the order Optimize Order for you by pressing:...

  • Page 380: Apps

    Note: We encourage you to review the www.here.com/mapcreator. HERE smartphone app’s terms of service and evaluates all reported map errors and privacy policies because Ford is not responds with the result of their responsible for your app or its use of data. investigation by e-mail.
  • Page 381 AppLink is only possible when Android Auto select a mobile app using the system. or Apple CarPlay are disabled. Some apps Note: Ford reserves the right to limit may only be accessible in the car through functionality or deactivate mobile apps at Applink and others only through Android any time.
  • Page 382 We recommend by SiriusXM Traffic and Travel Link. against the use of any hand-held device Note: Neither Sirius nor Ford is responsible while driving and encourage the use of for any errors or inaccuracies in the SiriusXM voice-operated systems when possible.

  • Page 383: Settings

    SYNC Menu Item Action and Description Area Select to choose from a listing of weather locations. Sports Info Touch this button to view scores and schedules from a variety of sports. You can also save up to 10 favorite teams for easier access.
  • Page 384 SYNC Media Player device is the active audio source. Pressing the button allows you to access the This button is available when a media following options for active devices only. device such as a Bluetooth Stereo or USB Menu Item Action and Description Podcast Speed For some Apple devices, SYNC 3 can adjust the playback speed of...
  • Page 385 SYNC Menu Item Action and Description Clock Format Select how time displays. Auto Time Zone When active, the clock adjusts to time zone changes. Update This feature is only available in vehicles with navigation. Reset Clock to When selected, the vehicle clock resets to GPS satellite time. GPS Time Bluetooth The system automatically saves any...
  • Page 386 4. The touchscreen indicates when the pairing is successful. Website 5. Your phone may prompt you to give owner.ford.com the system permission to access www.syncmyride.ca information. To check your phone’s www.syncmaroute.ca compatibility, see your phone’s manual or visit the website.
  • Page 387 SYNC Menu Item Action and Description First Name Last Name Re-download Select this option to re-download your contact list manually. Contacts Delete Contacts Select this option to delete the in vehicle contact list. Deleting the in vehicle list does not erase the contact list on the connected phone. Menu Item Action and Description Set Phone Ringtone...
  • Page 388 SYNC You can enable and disable the following options as well: Menu Item Action and Description Mute Audio in When enabled, vehicle audio (such as radio or apps) is muted for the Privacy duration of the phone call even when the phone call is in privacy. Roaming When enabled, an alert displays that your phone is roaming when Warning...
  • Page 389 SYNC Menu Item Action and Description FM HD Radio Activation of this feature allows you to listen to HD radio broadcasts. AM HD Radio (Dependent on current radio source, If Avail- able) Radio Text This feature is available when FM Radio is your active media source. Activate this feature to have the system display radio text.
  • Page 390 SYNC Route Preferences Menu Item Second Level Messages, Actions and Descriptions Route Preferences Then select any of the following: Preferred Route Choose to have the system display your chosen route type. Shortest Fastest Always Use ___ Bypass route selection in destination programming. The system only Route calculates one route based on your preferred route setting.
  • Page 391 Note: All Mobile Apps may not be Mobile Apps compatible with the system. Note: Standard data rates will apply. Ford You can enable the control of compatible is not responsible for any additional charges mobile apps running on your Bluetooth or you may receive from your service provider, USB device on SYNC 3.
  • Page 392 Note: Ford is not responsible or liable for General any damages or loss of privacy relating to usage of an app, or dissemination of any...
  • Page 393 SYNC Menu Item Automatic System Updates When you activate this option, the system automatic- ally updates when you have an available Internet connection through a Wi-Fi network or mobile connection. About Information pertaining to the system and its software. Software Licenses Documentation of the software license for the system.
  • Page 394 SYNC Door Keypad Code enter the five-digit factory set code. You can find this code on the owner's wallet Select this button to add or erase a card in the glove box or from your personal door keypad code. To add or authorized dealer.

  • Page 395: Sync 3 Troubleshooting

    PIN, please contact To check your cell phone's compatibility, the Customer Relationship Center. visit the Ford website. United States: 1-800-392-3673 Canada: 1-800-565-3673 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 396 SYNC Website Website www.syncmyride.ca owner.ford.com www.syncmaroute.ca Cell phone issues Issue Possible cause Possible solution There is back- The audio control ground noise settings on your cell Refer to your device's manual about audio during a phone phone may be affecting adjustments.
  • Page 397 SYNC Cell phone issues Issue Possible cause Possible solution You must switch on your cell phone and the automatic phonebook download feature on SYNC 3. This is a cell phone- Check your cell phone's compatibility. dependent feature. Try switching your cell phone off, resetting it or removing the battery, then try again.
  • Page 398 SYNC Cell phone issues Issue Possible cause Possible solution Replying to text messages using SYNC 3 is not supported by iPhone. Text messages from WhatsApp and Face- book Messenger are not supported. Your cell phone must support downloading This is a cell phone- text messages through Bluetooth to receive dependent feature.
  • Page 399 SYNC USB and Bluetooth Stereo issues Issue Possible cause Possible solution This is a device- Bluetooth audio Make sure you connect the device to SYNC dependent feature. does not 3 and that you have started the media The device is not stream.
  • Page 400 SYNC Wi-Fi Issues Issue Possible cause Possible solution Failed connection. Password error. Verify password. Weak signal. Check for a poor Wi-Fi signal. Multiple Access points Use a unique name for your within range with the same SSID, don’t use the default SSID.
  • Page 401 SYNC Wi-Fi Issues Issue Possible cause Possible solution SYNC 3 is not seen when SYNC 3 does not currently SYNC 3 currently does not searching for Wi-Fi networks provide a hotspot. provide a hotspot from your phone or other devices. Software download takes Poor signal strength, too far Check the signal quality...
  • Page 402 AppLink. Also, some may have a "Ford SYNC" setting, so check the app's settings menu on the phone. Closing and restarting apps may help SYNC 3 find the application if you cannot discover it inside the vehicle.
  • Page 403 SYNC AppLink issues Issue Possible cause(s) Possible solution(s) On an iPhone with iOS7+, to force close an app, double tap the home button then swipe up on the app to close it. Tap the home button again, then select the app again to restart it.
  • Page 404 3 to find. If the app has a I can only see some of the can use to connect. If you "Ford SYNC" setting, disable AppLink apps running on my have more AppLink apps on that setting in the app's...
  • Page 405 SYNC Voice command issues Issue Possible cause Possible solution You may be using the Review the media voice commands at the wrong voice commands. beginning of the media section. Say the song or artist name exactly as it is displayed on your device. For example, say "Play Artist Prince"...
  • Page 406 SYNC Voice command issues Issue Possible cause Possible solution The SYNC 3 voice control system is having SYNC 3 applies the phonetic pronunciation trouble recog- rules of the selected language to the names You may be saying the nizing foreign stored on your media player or USB flash foreign names using the tracks, artists,...
  • Page 407 5 seconds the screen will go black. Allow 1-2 minutes for the system reset to complete. You may then resume using the SYNC 3 system. For additional assistance with SYNC 3 troubleshooting please call or visit the Ford Website. Ford Support...

  • Page 408: Accessories

    Lifestyle Ford Accessories are available for your • Tablet cradle.* vehicle through an authorized Ford dealer. Ford Motor Company will repair or replace • Ash cup and smokers packages. any properly authorized dealer-installed • Roof racks and carriers.* Ford Original Accessory found to be...
  • Page 409 Contact an authorized Ford dealer for the accessories or components to your manufacturer's limited warranty details, vehicle, you may adversely affect and request a copy of the Ford Licensed battery performance and durability. In Accessories product limited warranty addition, you may also adversely affect from the accessory manufacturer.

  • Page 410: Ford Protect

    If you bring your car into your dealer for Vehicle Limited Warranty coverage. When service, we’ll give you a loaner to use for you visit your Ford Dealer, Insist on Ford the day. Protect Extended Service Plans! Extended Rental Benefits...
  • Page 411 Ford Protect Extended This information is subject to change. For Service Plan specialists at 800-367-3377. more information; visit your local Ford of Ford Protect Extended Service Plan Canada dealer or www.ford.ca to find the P.O. Box 321067...

  • Page 412: Scheduled Maintenance

    If you do not use Ford authorized parts they you sell or trade it. Keep all receipts for may not meet our specifications and completed maintenance with your vehicle.
  • Page 413 When the oil change message appears in Additives and Chemicals the information display, it is time for an oil This owner's manual and the Ford change. Make sure you perform the oil Workshop Manual list the recommended change within two weeks or 500 miles additives and chemicals for your vehicle.
  • Page 414 Scheduled Maintenance Check every month Engine oil level. Function of all interior and exterior lights. Tires (including spare) for wear and proper pressure. Windshield washer fluid level. Check every six months Battery connections. Clean if necessary. Body and door drain holes for obstructions. Clean if necessary. Cooling system fluid level and coolant strength.

  • Page 415: Normal Scheduled Maintenance

    Scheduled Maintenance Multi-Point inspection Accessory drive belt(s) Hazard warning system operation Battery performance Horn operation Engine air filter Radiator, cooler, heater and air conditioning hoses Exhaust system Suspension components for leaks or damage Exterior lamps operation Steering and linkage Tires (including spare) for wear and proper Fluid levels ;...
  • Page 416 Scheduled Maintenance When to expect the message prompting you to change your oil Interval Vehicle use and example Normal Normal commuting with highway driving 7500-10000 miles No, or moderate, load or towing (12000-16000 km) Flat to moderately hilly roads No extended idling Severe Moderate to heavy load or towing 5000-7499 miles...
  • Page 417 Scheduled Maintenance At every oil change interval as indicated by the information display Inspect steering linkage, ball joints, suspension and tie-rod ends. Lubricate if equipped with grease fittings. Inspect the wheels and related components for abnormal noise, wear, looseness or drag.

  • Page 418: Special Operating Conditions Scheduled Maintenance

    Scheduled Maintenance Perform the services shown in the SPECIAL OPERATING following tables when specified or within CONDITIONS SCHEDULED 3000 miles (4800 kilometers) of the OIL MAINTENANCE CHANGE REQUIRED message appearing in the information display. If you operate your vehicle primarily in any •...
  • Page 419 1800 miles (3000 kilometers). useful life. Ford Motor Company, however, urges you to have all recommended maintenance services performed at the specified intervals and to record all vehicle service.

  • Page 420: Scheduled Maintenance Record

    Scheduled Maintenance Engine Air Filter and Cabin Air Filter and dirty conditions. Vehicles operated in Replacement these conditions require frequent inspection and replacement of the engine The life of the engine air filter and cabin air air filter and cabin air filter. filter is dependent on exposure to dusty SCHEDULED MAINTENANCE RECORD Dealer stamp...
  • Page 421 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 422 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 423 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 424 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 425 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 426 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 427 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 428 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 429 Scheduled Maintenance Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Dealer stamp Repair Order #: Distance: Engine hours (optional): Multi-point inspection (recommended): Signature: E146852 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...

  • Page 430: Appendices

    COMPANY nor its suppliers shall be include software licensed or owned by liable for any damages arising out of Ford Motor Company and its affiliates errors in the speech recognition ("FORD MOTOR COMPANY"). Those process. It is your responsibility to...
  • Page 431 • Single EULA: The end user • Additional Software/Services: The documentation for the DEVICES and SOFTWARE may permit FORD MOTOR related systems and services may COMPANY, third party software and contain multiple EULAs, such as service suppliers, its affiliates and/or...
  • Page 432 DEVICES. electronic form, you may print one copy of UPGRADES AND RECOVERY MEDIA: such electronic documentation. If the SOFTWARE is provided by FORD EXPORT RESTRICTIONS: You MOTOR COMPANY separate from the acknowledge that the SOFTWARE is DEVICES on media such as a ROM chip, subject to U.S.
  • Page 433 Should you have any questions concerning are driving. Pull over in a safe and legal this EULA, or if you desire to contact FORD manner before attempting to access a MOTOR COMPANY for any other reason,...
  • Page 434 Appendices substitute for your personal judgment. Your Responsibilities and Assumptions of Any route suggestions made by this Risk system should never replace any local • You agree to each of the following:(a) traffic regulations or your personal Any use of the SOFTWARE while judgment or knowledge of safe driving driving an automobile or other vehicle practices.
  • Page 435 "AS IS" AND “AS AVAILABLE”, WITH ALL COMPANY SHALL BE FOUND IN THE FAULTS AND WITHOUT WARRANTY OF WARRANTY INFORMATION INCLUDING ANY KIND, AND FORD MOTOR COMPANY WITH YOUR OWNER GUIDE. TO THE HEREBY DISCLAIMS ALL WARRANTIES EXTENT THAT THERE IS ANY CONFLICT...
  • Page 436 Consumer-Related Disputes will also litigate any dispute in small claims court apply. To commence arbitration, submit a in your county of residence or FORD Commercial Arbitration Rules Demand for MOTOR COMPANY’S principal place of Arbitration form to the AAA. You may...
  • Page 437 AAA’s and arbitrator’s fees and court (Section c) or in arbitration (Section expenses. If you reject FORD MOTOR d). The one-year period begins when the COMPANY’S last written settlement claim or dispute first could be filed. If such...
  • Page 438 Appendices 1. Safe and Lawful Use 2. Account Information You acknowledge that devoting attention You agree: (a) when registering the to the TeleNav Software may pose a risk TeleNav Software, to provide TeleNav with of injury or death to you and others in true, accurate, current, and complete situations that otherwise require your information about yourself, and (b) to...
  • Page 439 Appendices distribute, sublicense or otherwise is dependent on the accuracy of transfer the TeleNav Software to navigation, as the maps or functionality others, except as part of your of the TeleNav Software are not permanent transfer of the TeleNav intended to support such high risk Software;...
  • Page 440 Appendices REASON WHATSOEVER (INCLUDING, to the exclusive jurisdiction of the WITHOUT LIMITATION, ALL DAMAGES courts of the County of Santa Clara, REFERENCED HEREIN AND ALL California. The United Nations DIRECT OR GENERAL DAMAGES IN Convention on Contracts for the CONTRACT, TORT (INCLUDING International Sale of Goods shall not NEGLIGENCE) OR OTHERWISE), THE apply.
  • Page 441 Appendices conferred by implication, statute, inducement, estoppel or otherwise, and The headings in this Agreement are for TeleNav and its suppliers and licensors convenience of reference only, will not be hereby reserve all of their respective rights deemed to be a part of this Agreement, other than the licenses explicitly granted and will not be referred to in connection in this Agreement.
  • Page 442 Appendices HERE holds a non-exclusive license from Restrictions. Except where you have been the United States Postal Service® to specifically licensed to do so by Telenav, publish and sell ZIP+4® information. and without limiting the preceding paragraph, you may not use this Data (a) ©United States Postal Service®...
  • Page 443 Appendices PARTICULAR PURPOSE OR export laws, rules or regulations prohibit NON-INFRINGEMENT. Some States, HERE from complying with any of its Territories and Countries do not allow obligations hereunder to deliver or certain warranty exclusions, so to that distribute Data, such failure shall be extent the above exclusion may not apply excused and shall not constitute a breach to you.
  • Page 444 Appendices B. Canada Data. The following provi- NOTICE OF USE sions apply to the Data for Canada, CONTRACTOR (MANUFACTURER/ which may include or reflect data from SUPPLIER) NAME: HERE third party licensors (“Third Party Data”), including Her Majesty the Queen CONTRACTOR (MANUFACTURER/ in Right of Canada (“Her Majesty”), SUPPLIER) ADDRESS: c/o Nokia, 425...
  • Page 445 Appendices 2. Copyright Notice: In connection with either express or implied, arising by each copy of all or any portion of the law or otherwise, including but not Data for the Territory of Canada, Client limited to, effectiveness, complete- shall affix in a conspicuous manner the ness, accuracy or fitness for a following copyright notice on at least particular purpose.
  • Page 446 Appendices A. Third Party Notices. Any and all copies II. Mexico. The following provision applies of the Data and/or packaging relating to the Data for Mexico, which includes thereto shall include the respective Third certain data from the Instituto Nacional Party Notices set forth below and used de Estadística y Geografía (“INEGI”): as described below corresponding to...
  • Page 447 Appendices is conditioned on Client’s obtaining prior V. Europe Territory written consent from Kartografie a.s.; (c) such license for selling or distributing A. Use of Certain Traffic Codes in Europe with respect to Data for the Territory of Switzerland is conditioned on Client’s 1.
  • Page 448 Appendices Austria “© Bundesamt für Eich- Spain “Información geográfica und Vermessungswesen” propiedad del CNIG” Croatia Sweden “Based upon electronic Cyprus, data © National Land Estonia, Survey Sweden.” Latvia, Switzerland “Topografische Lithuania, Grundlage: © Bundesamt Moldova, für Landestopographie. Poland, Slovenia E. Respective Country Distribution. Client and/or acknowledges that HERE has not Ukraine...
  • Page 449 Appendices with or in communication with any Product incorporates data which is © positioning devices or any mobile or 20XX Telstra Corporation Limited, GM wireless-connected electronic or computer Holden Limited, Intelematics Australia devices, including without limitation Pty Ltd and Continental Pty Ltd. cellular phones, palmtop and handheld B.
  • Page 450 Appendices No Other Warranty: Export Control EXCEPT FOR THE LMITED WARRANTY You agree not to export to anywhere any SET FORTH ABOVE AND TO THE EXTENT part of the Data provided to you or any PERMITTED BY APPLICABLE LAW, NAV2 direct product thereof except in AND ITS LICENSORS (INCLUDING THEIR compliance with, and with all licenses and...
  • Page 451 Appendices 2000-2007 Gracenote. Gracenote or any Gracenote Data (except in a Tag Software, copyright © 2000-2007 associated with a music file) to any third Gracenote. This product and service may party. YOU AGREE NOT TO USE OR practice one or more of the following U.S. EXPLOIT GRACENOTE CONTENT, Patents 5,987,525;...
  • Page 452 Appendices GRACENOTE SERVERS OR GRACENOTE (1) This device may not cause harmful CONTENT. GRACENOTE COLLECTIVELY interference, and AND SEPARATELY RESERVE THE RIGHT (2) this device must accept any TO DELETE DATA AND/OR CONTENT interference received, including FROM THE COMPANIES' RESPECTIVE interference that may cause undesired SERVERS OR, IN THE CASE OF operation.
  • Page 453 Appendices We will use reasonable endeavours to provide the SUNA Traffic Channel 24 hours Website a day, 365 days a year. The SUNA Traffic www.sunatraffic.com.au/termsandcon- Channel may occasionally be unavailable ditions/ for technical reasons or for planned maintenance. We will try to perform maintenance at times when congestion is 2.

  • Page 454: Type Approvals

    Appendices WARNING Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
  • Page 455 Appendices E207833 E206300 Mexico South Africa E207831 Morocco E206303 E206301 South Korea E206302 Taiwan E207832 Singapore Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 456 Appendices E206305 Ukraine E207830 United States Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 457 Focus (CDH) Canada/United States of America, HM5J 19A321 AA enUSA, Edition date: 201608, First Printing...
  • Page 458 Index Low Fuel Minder...........90 Parking Brake On Warning Chime....90 Audio Control...........70 Seek, Next or Previous.........71 See: Climate Control.........103 Audio System..........282 About This Manual...........7 General Information.........282 Audio Unit - Vehicles With: Satellite See: Brakes............145 Radio.............290 ABS driving hints Audio Unit - Vehicles With: Sony Audio See: Hints on Driving With Anti-Lock System............286 Brakes..............145...
  • Page 459 Index Replacing Licence Plate and High Mounted Brake Lamp Bulbs.........233 Changing a Fuse...........210 Battery Fuses...............210 See: Changing the 12V Battery......223 Changing a Road Wheel......264 Blind Spot Information System....169 Dissimilar Spare Wheel and Tire Assembly Switching the System Off and On....171 Information.............264 System Errors............171 Tire Change Procedure........265...
  • Page 460 Index Coolant Check Driving Through Water.......186 See: Engine Coolant Check......218 Crash Sensors and Airbag Indicator..45 See: Daytime Running Lamps......77 Creating a MyKey..........55 Programming/Changing Configurable Settings...............55 Cross Traffic Alert...........171 Eco Mode............174 False Alerts............173 Resetting Eco Mode...........174 Switching the System Off and On....174 Type 1...............174 Economical Driving........186 System Errors............174...
  • Page 461 Getting the Services You Need....194 US Only..............11 Away From Home..........194 Ford Protect...........407 Ford Protect Extended Service Plan (CANADA ONLY).........408 Handbrake Ford Protect Extended Service Plans (U.S. Only)..............407 See: Parking Brake..........146 Front Fog Lamps..........79 Hazard Warning Flashers......190 Front Parking Aid..........152 Headlamp Adjusting Front Passenger Sensing System....40...
  • Page 462 Index Hill Start Assist..........146 Switching the System On and Off....147 Using Hill Start Assist........147 Keyless Entry...........64 Hints on Controlling the Interior SECURICODE KEYLESS ENTRY Climate............106 KEYPAD..............64 Cooling the Interior Quickly......107 Keyless Starting..........118 General Hints............106 Failure to Start............119 Heating the Interior Quickly......106 Fast Restart............120 Recommended Settings for Cooling ..107 Starting Your Vehicle..........119...
  • Page 463 Index Smart Unlocks for Intelligent Access Keys...............61 Luggage Covers..........176 Navigation............369 Removing the Cover...........176 cityseeker..............376 Lug Nuts Destination Mode..........371 See: Changing a Road Wheel.......264 Map Mode............369 Lug Nuts............268 Navigation Map Updates.........377 Navigation Menu..........374 SiriusXM Traffic and Travel Link....377 Waypoints.............375 Maintenance...........212 Normal Scheduled Maintenance...412 General Information...........212 Intelligent Oil-Life Monitor ......412...
  • Page 464 Index Pairing Your Cell Phone for the First Remote Control - Vehicles With: Keyless Entry..............47 Time..............364 Phone Menu............365 Changing the Remote Control Battery..48 Receiving Calls............367 Intelligent Access Key.........47 Smartphone Connectivity......368 Locating Your Vehicle.........49 Text Messaging..........368 Programming a New Remote Control..48 Post-Crash Alert System......193 Remote Control - Vehicles With: Keyless Power Door Locks...
  • Page 465 Index Running Out of Fuel........131 Snow Chains Adding Fuel From a Portable Fuel See: Using Snow Chains.........260 Special Notices..........12 Container............131 Filling a Portable Fuel Container....131 New Vehicle Limited Warranty......12 On Board Diagnostics Data Link Connector............13 Special Instructions..........12 Safety Canopy ..........44 Special Operating Conditions Scheduled Safety Precautions........128 Maintenance..........415...
  • Page 466 Index SYNC Troubleshooting......328 Transporting the Vehicle......182 Trip Computer..........94 All Values..............94 Average Fuel Consumption......94 Tailgate Distance to Empty..........94 See: Manual Liftgate...........63 Outside Air Temperature........94 Technical Specifications Resetting the Trip Computer......94 See: Capacities and Specifications....269 Trip Odometer............94 The Better Business Bureau (BBB) Auto Trip Timer..............94 Line Program (U.S.
  • Page 467 Index Text Messaging..........308 Airbag Warning Lamp.........87 Using Traction Control.......148 Anti-Lock Brake System Warning Switching the System Off.......148 Lamp..............87 System Indicator Lights and Auto-Start-Stop Indicator........88 Messages............148 Blind Spot Information System Using a Switch.............148 Indicator.............88 Using the Information Display Brake System Warning Lamp......88 Controls.............148 Cruise Control Indicator........88 Using Voice Recognition......300...

Table of Contents

Save PDF
