Inspiron 15
Copyright © 2014 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and
intellectual property laws. Dell and the Dell logo are trademarks of Dell Inc. in the United States and/or other
jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies.
2014 ‑ 03
Rev. A00
Regulatory model: P28F | Type: P28F005
Computer model: Inspiron 15‑3531
Views
Specifications
NOTE: The images in this document may differ from your computer
depending on the configuration you ordered.
Advertisement
Table of Contents
Related Manuals for Dell Inspiron 3531
Summary of Contents for Dell Inspiron 3531
- Page 1 Copyright © 2014 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and intellectual property laws. Dell and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies.
- Page 2 Views Specifications Front Front Left Right Power and battery‑status light Media‑card reader Base Indicates the power and battery status of the computer. Reads from and writes to media cards. • Solid white: Power adapter is connected and the battery is fully charged. • Off: —...
- Page 3 Views Specifications Left Front Left Right Power‑adapter port Headset port Base Connect a power adapter to provide power to your Connect a headphone, a microphone, or a headphone computer and charge the battery. and microphone combo (headset). HDMI port Connect a TV or another HDMI‑in enabled device. Provides video and audio output.
- Page 4 Views Specifications Right Front Left Right Security‑cable slot Base Connect a security cable to prevent unauthorized movement of your computer. Display...
- Page 5 Press and hold for 10 seconds to force shut‑down the Press to right‑click. computer. Display NOTE: You can customize the power‑button behavior in Power Options. For more information, see Me and My Dell at dell.com/support. Left‑click button Press to left‑click.
-
Page 6: Display View
Views Specifications Display Front Left Right Microphone Camera‑status light Base Provides high‑quality digital sound input for audio Turns on when the camera is in use. recording, voice calls, and so on. Camera Allows you to video chat, capture photos, and record videos. -
Page 7: Dimensions And Weight
Specifications Views Dimensions and Weight Height 25.3 mm (1 in) Width 376 mm (14.80 in) Depth 259 mm (10.20 in) Weight (maximum) 2.15 kg (4.70 lb) NOTE: The weight of your laptop varies depending on the configuration ordered and the manufacturing variability. Dimensions and System Ports and... -
Page 8: System Information
Specifications Views System Information Computer model Inspiron 15‑3531 Processor • Intel Celeron Dual Core • Intel Pentium Quad Core Chipset Integrated in processor Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery... -
Page 9: Memory
Specifications Views Memory Slot One SODIMM slot Type DDR3L Speed Up to 1600 MHz NOTE: The processor installed on your computer allows the memory to run only at 1333 MHz speed. Configurations supported 4 GB Dimensions and System Ports and Memory Communications Video... -
Page 10: Ports And Connectors
Specifications Views Ports and Connectors External: Two USB 2.0 ports Audio/Video • One headset port • One HDMI port Internal: Mini Card One half mini‑card slot for WLAN Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer... - Page 11 Specifications Views Communications Wireless Wi‑Fi 802.11 b/g/n Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter Reader Environment...
- Page 12 Specifications Views Video Controller Intel HD Graphics Memory Shared system memory Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter Reader Environment...
- Page 13 2.5 W Microphone Single digital microphone in the camera assembly Volume controls Program menus and keyboard media‑control keys. To learn about your computer keyboard shortcut keys, see the Quick Start Guide at dell.com/support. Dimensions and System Ports and Memory Communications...
- Page 14 Specifications Views Storage Interface • SATA 1.5 Gbps • SATA 3 Gbps Hard drive One 2.5‑inch drive (supports Intel Smart Response Technology) Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter...
-
Page 15: Media-Card Reader
Specifications Views Media‑Card Reader Type One 3‑in‑1 slot Cards supported • SD card • SD High Capacity (SDHC) card • Memory Stick (MS) Pro Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad... - Page 16 0 degree (closed) to 140 degrees Pixel pitch 0.252 mm Controls Brightness can be controlled using keyboard shortcut keys. To learn about your computer keyboard shortcut keys, see the Quick Start Guide at dell.com/support. Dimensions and System Ports and Memory Communications...
- Page 17 Specifications Views Keyboard Type Chiclet keyboard Shortcut keys Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. To type the alternate character, press Shift and the desired key. To perform secondary functions, press Fn and the desired key.
- Page 18 Specifications Views Camera Resolution: Still image 0.92 megapixels Video 1280 x 720 (HD) at 30 fps (maximum) Diagonal viewing angle 74 degrees Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter...
- Page 19 Specifications Views Touchpad Resolution: Horizontal 1560 dpi Vertical 2553 dpi Dimensions: Width 54 mm (2.13 in) Height 98 mm (3.86 in) Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter Reader...
- Page 20 Specifications Views Battery Type 4‑cell “smart” lithium ion (40 WHr) Dimensions: Height 20 mm (0.79 in) Width 272.40 mm (10.72 in) Depth 49.30 mm (1.94 in) Weight 0.26 kg (0.57 lb) Voltage 14.80 VDC Charging time when the computer is off 4 hours (approximate) Operating time...
-
Page 21: Power Adapter
Specifications Views Power Adapter Type 65 W Input voltage 100 VAC–240 VAC Input frequency 50 Hz–60 Hz Input current 1.50 A/1.60 A/1.70 A/2.50 A Output current 3.34 A Rated output voltage 19.50 VDC Temperature range: Operating 0°C to 40°C (32°F to 104°F) Storage –40°C to 70°C (–40°F to 158°F) Dimensions and... -
Page 22: Computer Environment
Specifications Views Computer Environment Airborne contaminant level G1 as defined by ISA‑S71.04‑1985 Operating Storage Temperature range 0°C to 40°C (32°F to 104°F) –40°C to 70°C (–40°F to 158°F) Relative humidity (maximum) 10% to 90% (non‑condensing) 10% to 95% (non‑condensing) Vibration (maximum) 0.66 GRMS 1.30 GRMS Shock (maximum)
