Description:
The Vortexgear POK3R is the perfect solution for limited spaces in situations. Built up 3
kinds of layout, it features individually programmable keys with 3 layers customization
options, all easily set through what you want.
Main Specification:
1. Tiny size keyboard with 61/62 keys
2. Cherry MX inside
3. Arbitrary programming
4. PBT Keycaps
5. Individual LED coding (Backlit version only)
6. 3 layers customization
7. Built-up 3 kind of layout (Qwerty, Dvorak, Colemak)
8. Metal bezel
Package Content
1. Keyboard x 1
2. USB Cable x 1
POK3R User manual
Advertisement
Table of Contents
Related Manuals for Vortex POK3R
Summary of Contents for Vortex POK3R
-
Page 1: Package Content
POK3R User manual Description: The Vortexgear POK3R is the perfect solution for limited spaces in situations. Built up 3 kinds of layout, it features individually programmable keys with 3 layers customization options, all easily set through what you want. Main Specification: 1. - Page 2 Programming Instruction Note: The POK3R built in 4-layers. The default layer can not be programmed. Only layer 2~layer 4 can be. FN + R_ctrl, M,<,> and ? keys are fixed can not be programmed. Step 1. Choose the layer (FN+<,> or ? key) which you want to programming.
- Page 3 FN composite keys FN General keys Remark Key code change PrtSc ScrLk Pause Home PgUp PgDn Backspace “ ’ Switching Layer Remark Default Spacebar left LED off Spacebar left LED <, Layer 2 showing BLUE color. Spacebar left LED >. Layer 3 showing RED color Spacebar left LED...
- Page 4 DIP Switch function description: SW 1 SW 2 Layout Remark Colemak Dvorak Default = OFF Qwerty Qwerty Remark SW 3 CapsLock = FN CapsLock = CapsLock Default = OFF Change FN&PN R_CTRL Shall not be SW 4 FN&PN in any position in the original position changed to FN or PN Others:...
