Open saved data
1.
Touch "Open file" icon
2.
Select file opening method.
・New
:
Create a new sheet
・Open as a new file
・Add to the current sheet
Turn off power
1.
Shut down computer.
2.
Press POWER button
[Notice]
Status of Power LED
・Green lit
・Orange lit
・Green flashing
Square menu structure
・Pen1~3:Draw lines.
・Eraser:Erase hand-drawn lines.
・Select :Select an object.
・Redo :Redo the immediately preceding
・View :Enlarge the view of the whiteboard,
・Undo :Cancel the immediately preceding
Tool bar structure (in bottom)
①
②
① "Pin" button: Touch to switch between the pin / do not pin settings.
② Sheet list
: Shows the sheets as thumbnails.
③ Settings
: Displays the pen software settings screen.
④ Search box : You can search for text and handwritten characters
in the box.
⑤ Sheet navigation buttons:Touch the sheet navigation button
⑥ Page No. of the current sheet:
on "Square menu".
:
Open data as a new file
:
Add data to the current sheet
in left bottom.
: Power on
: Power off (Standby mode)
: Input signal standby mode
You can move/enlarge/rotate
/delete/copy.
canceled operation.
change the display position and pages.
operation.
③
④
to change the displayed sheet.
3.
Read the file.
・Select the saved location and touch "OK".
4.
Select the file and touch "OK".
3.
Turn off on display main power.
⑤
⑥
⑦
⑦ Add sheet button:When the last sheet is displayed,
⑧ Board list: Touch to display the list of boards as thumbnail images.
*If you have already open overlay board, you can not add this.
⑨ Minimize : The software will be minimized in the task tray.
⑩ Window / Maximize : Displays the software in a window.
* Whiteboard mode only..
⑪ Quit : The software is exited.
・Drawing Object:Draw a figure or line/arrow.
・Paste:Pastes a copied object.
・Open:Open a file.
・Text :Enter text by software key board.
・Insert image:
:Insert an image file.
:Insert Screen capture.
・Save:Save file.
・All function:Displays all functions in list view.
・Print:Print file.
You can select current sheet or all.
⑧
⑨
⑩
⑪
press to add a sheet at the end.
:Add White board
:Add overlay board
4
