Quick Start Guide
DIGITAL CAMERA
En
ii
1
7
14
16
17
18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COOLPIX AW130 and is the answer not in the manual?

Questions and answers

Related Manuals for Nikon COOLPIX AW130

Summary of Contents for Nikon COOLPIX AW130

  • Page 1: Table Of Contents

    DIGITAL CAMERA Quick Start Guide Introduction Preparing for Shooting Basic Shooting and Playback Operations Using Menus Using Location Data Functions/Displaying Maps Using the Wi-Fi (Wireless LAN) Function Technical Notes Caution : Make sure to read the important precautions regarding waterproof performance (pages x–xv).

  • Page 2: Introduction

    Model Name: N1413 Introduction Read This First To get the most from this Nikon product, be sure to read “For Your Safety” (Avii–ix), “<Important> Shockproof, Waterproof, Dustproof, Condensation” (Ax), “<Important> Notes About Location Data Functions (GPS/GLONASS, Electronic Compass)” (Axvi), and “Wi-Fi (Wireless LAN Network)” (Axx), and all other instructions thoroughly and keep them where they will be read by all who use the camera.

  • Page 3: Confirming The Package Contents

    Confirming the Package Contents In the event that any items are missing, please contact the store where you purchased the camera. COOLPIX AW130 Camera strap for land Rechargeable Li-ion Digital Camera Battery EN-EL12 Charging AC Adapter USB Cable UC-E21 Brush...

  • Page 4: Information And Precautions

    Before taking pictures on important occasions (such as at weddings or before taking the camera on a trip), take a test shot to ensure that the camera is functioning normally. Nikon will not be held liable for damages or lost profits that may result from product malfunction.
  • Page 5 • Nikon reserves the right to change the specifications of the hardware and software described in these manuals at any time and without prior notice. • Nikon will not be held liable for any damages resulting from the use of this product.

  • Page 6: Conformity Marking

    For the COOLPIX AW130, the log data saved on the memory card is handled in the same way as other data. To erase the log data that is obtained but not stored on the memory card, select Create log M End all logs M Erase logs.

  • Page 7: For Your Safety

    For Your Safety To prevent damage to your Nikon product or injury to yourself or to others, read the following safety precautions in their entirety before using this equipment. Keep these safety instructions where all those who use the product will read them.
  • Page 8 Failure to observe this precaution could cause damage or fire. Use the appropriate power supply (battery, charging AC adapter, AC adapter, USB cable) Using a power supply other than those provided or sold by Nikon could result in damage or malfunction. Observe caution when handling the battery The battery may leak, overheat, or explode if improperly handled.
  • Page 9 Use appropriate cables When connecting cables to the input and output jacks, use only the cables provided or sold by Nikon for the purpose, to maintain compliance with product regulations. Handle moving parts with care Be careful that your fingers or other objects are not pinched by the moving parts.
  • Page 10 “Caring for the Product” (A18). Notes About Shockproof Performance This camera has passed Nikon’s in-house test (drop test from a height of 210 cm (7 ft) on a 5 cm (2 in.) thick plywood panel) compliant with MIL-STD 810F Method 516.5-Shock*.
  • Page 11 • If water seeps inside the camera, immediately stop using the camera. Wipe off moisture from the camera, and at once take the camera to your Nikon- authorized service representative.

  • Page 12: Before Using The Camera Underwater

    If the waterproof packing begins to deteriorate, consult your retailer or Nikon-authorized service representative. •Make sure that the waterproof packing is not detached from the camera. 3. Make sure that the battery-chamber/memory card slot cover is firmly closed.
  • Page 13 Notes About Using the Camera Underwater Observe the following precautions to prevent water from seeping inside the camera. • Do not dive into water deeper than 30 m (100 ft) with the camera. • Do not continuously use the camera underwater for 60 minutes or more. •...
  • Page 14 1. Keep the battery-chamber/memory card slot cover closed and wash off the camera with fresh water. Immerse the camera in a shallow basin filled with fresh water (such as tap water and well-water that do not contain salt) for 10 minutes. •If the buttons or switches do not operate properly, foreign substances may have adhered.
  • Page 15 To clear the fogging, remove the battery and memory card, and leave the camera with the battery-chamber/memory card slot cover open to allow the camera to adjust to the ambient temperature. • If the fogging does not clear, consult your retailer or Nikon-authorized service representative. Introduction...
  • Page 16 • The detailed map data and location name information (Points of Interest: POI) of the People’s Republic of China (“China”) and the Republic of Korea are not provided for the COOLPIX AW130. Notes about record location data functions and log recording •...
  • Page 17 Notes about measurement functions The COOLPIX AW130 is a camera. Do not use this camera as a navigation device or measuring instrument. • Use information (such as direction, altitude and water depth) measured by the camera as a guideline only. Do not use this information for navigation of an airplane, car, and person or land survey applications.
  • Page 18 CAUTIONS Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Nikon Corporation may void the user’s authority to operate the equipment. Interface Cables Use the interface cables sold or provided by Nikon for your equipment. Using other interface cables may exceed the limits of Class B Part 15 of the FCC rules.
  • Page 19 Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash hands after handling. Nikon Inc., 1300 Walt Whitman Road, Melville, New York 11747-3064, U.S.A. Tel: 631-547-4200...
  • Page 20 EU or EFTA can be used anywhere within the EU and EFTA). Nikon does not accept liability for use in other countries. Users who are unsure as to the original country of sale should consult with their local Nikon service center or Nikon-authorized service representative.
  • Page 21 COOLPIX AW130, which is equipped with a DW092 (FCC ID:EW4DW092 / IC ID:4634A-3149EC) Wireless LAN Module, has been tested and found to comply with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules.
  • Page 22 Precautions when Using Radio Transmissions Always keep in mind that radio transmission or reception of data is subject to interception by third parties. Note that Nikon is not responsible for data or information leaks that may occur during data transfer.

  • Page 23: Preparing For Shooting

    Preparing for Shooting Insert the Battery and Memory Card Battery latch Memory card slot • Press the battery-chamber/memory card slot cover latch release (1) and rotate the battery-chamber/memory card slot cover latch (2) to open the cover (3). • With the battery’s positive and negative terminals oriented correctly, move the orange battery latch (4), and fully insert the battery (5).

  • Page 24: Removing The Battery Or Memory Card

    Opening/Closing the Battery-Chamber/Memory Card Slot Cover Do not open and close the battery-chamber/memory card slot cover in a sandy or dusty environment or with wet hands. If the cover is closed without removing foreign particles, water may seep inside the camera or the camera may become damaged.

  • Page 25: Charge The Battery

    Charge the Battery With the battery installed, connect the camera to an electrical outlet. Charge lamp Charging AC Adapter Electrical outlet USB cable (included) If a plug adapter* is included with your camera, securely connect it to the Charging AC Adapter. Once the two are connected, attempting to forcibly remove the plug adapter could damage the product.
  • Page 26 Notes About the USB Cable • Do not use a USB cable other than the UC-E21. Using a USB cable other than the UC-E21 could result in overheating, fire or electric shock. • Make sure that the plugs are properly oriented. Do not insert or remove the plugs at an angle when connecting or disconnecting them.

  • Page 27: The Camera

    Turn the Camera On and Set the Display Language, Date, and Time When the camera is turned on for the first time, the language-selection screen and the date and time setting screen for the camera clock are displayed. Press the power switch to turn on the camera.
  • Page 28 Set the date and time, and press Date and time the k button. • Use JK to select a field and then use HI to set the date and time. 2 0 1 5 0 0 0 0 • Select the minute field and press the k button to confirm the setting.

  • Page 29: Basic Shooting And Playback Operations

    Basic Shooting and Playback Operations Shooting with Scene Auto Selector Mode Hold the camera steady. • Keep fingers and other objects away from the lens, flash, AF assist-illuminator, microphone, and speaker. • When taking pictures in portrait (“tall”) orientation, turn the camera so that the flash is above the lens.
  • Page 30 Press the shutter-release button halfway. • When the subject is in focus, the focus area or focus indicator is displayed in green. • When you are using digital zoom, the camera focuses in the center of the frame and the focus area is not displayed.

  • Page 31: Play Back Images

    Play Back Images Press the c (playback) button to enter playback mode. • If you press and hold down the c button while the camera is turned off, the camera turns on in playback mode. Use the multi selector to select an Display the previous image image to display.

  • Page 32: Delete Images

    Delete Images Press the l (delete) button to delete the image currently displayed in the monitor. Use the multi selector HI to select the desired deletion Delete method and press the k button. Current image • To exit without deleting, press the d Erase selected images All images button.

  • Page 33: Changing The Shooting Mode

    Changing the Shooting Mode The shooting modes described below are available. • x Scene auto selector The camera automatically recognizes the shooting scene when you frame a picture, making it easier to take pictures using settings that suit the scene. •...

  • Page 34: Recording Movies

    Using the Flash, Self-timer, Etc. When the shooting screen is displayed, you can press the multi selector H (m) J (n) I (p) K (o) to set the functions described below. • m Flash mode You can select a flash mode to match the shooting conditions. •...
  • Page 35 Action Control The operations described below can be performed by shaking or tilting the camera. Displaying the Previous or Next Image in Full- frame Playback Mode In full-frame playback mode, shake the camera up/ down to display the next image, or forward/ backward to display the previous image (when Playback action control in the setup menu (A14) is set to On).

  • Page 36: Using Menus

    Using Menus You can set the menus listed below by pressing the d (menu) button. • A Shooting menu Available by pressing the d button when the shooting screen is displayed. Allows you to change image size and quality, continuous shooting settings, etc.
  • Page 37 Select a menu icon Set up and press the k Time zone and date Monitor settings button. Date stamp • The menu options Photo VR become selectable. AF assist Digital zoom Select a menu option and press the k Time zone and date Monitor settings button.

  • Page 38: Using Location Data Functions/Displaying Maps

    Using Location Data Functions/ Displaying Maps The camera starts to receive signals from positioning satellites when Record location data in Location data options in the z (location data options) menu (A14) is set to On. Reception status can be checked on the shooting screen.

  • Page 39: Using The Wi-Fi (Wireless Lan) Function

    Using the Wi-Fi (Wireless LAN) Function You can perform the following functions if you install the dedicated software “Wireless Mobile Utility” on your smart device that runs on Android OS or iOS, and connect it to the camera. Take Photos You can capture still images using the two methods described below.

  • Page 40: Technical Notes

    Technical Notes Caring for the Product Observe the precautions described below in addition to the warnings in “For Your Safety” (Avii–ix) and “<Important> Shockproof, Waterproof, Dustproof, Condensation” (Ax) when using or storing the device. The Camera Do Not Apply Strong Impact to the Camera The product may malfunction if subjected to strong shock or vibration.

  • Page 41: The Battery

    • If you notice any abnormalities such as excessive heat, smoke, or an unusual smell coming from the battery, immediately discontinue use and consult your retailer or Nikon-authorized service representative. • After removing the battery from the camera or optional battery charger, put the battery in a plastic bag, etc.

  • Page 42: Battery Life

    Carrying Spare Batteries Whenever possible, carry fully charged spare batteries when taking pictures on important occasions. Using the Battery When Cold On cold days, the capacity of batteries tends to decrease. If an exhausted battery is used at a low temperature, the camera may not turn on. Keep spare batteries in a warm place and exchange as necessary.

  • Page 43: Cleaning And Storage

    Cleaning and Storage Cleaning Do not use alcohol, thinner, or other volatile chemicals. Avoid touching glass parts with your fingers. Remove dust or lint with a blower (typically a small device with a rubber bulb attached to one end that is pumped to produce a stream of air out the other end). To remove fingerprints or other stains that cannot be removed with a Lens blower, wipe the lens with a soft cloth, using a spiral motion that...

  • Page 44: Troubleshooting

    Troubleshooting If the camera fails to function as expected, check the list of common problems below before consulting your retailer or Nikon-authorized service representative. Also, refer to the Reference Manual (PDF format) for further details on how to use this camera (Aii).
  • Page 45 It is protected by copyright, and is subject to the following terms and conditions which are agreed to by you, on the one hand, and Nikon Corporation (“Nikon”) and its licensors (including their licensors and suppliers) on the other hand.
  • Page 46 YOUR USE OF OR INABILITY TO USE THIS INFORMATION, ANY DEFECT IN THE INFORMATION, OR THE BREACH OF THESE TERMS OR CONDITIONS, WHETHER IN AN ACTION IN CONTRACT OR TORT OR BASED ON A WARRANTY, EVEN IF NIKON OR ITS LICENSORS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some States, Territories and Countries do not allow certain liability exclusions or damages limitations, so to that extent the above may not apply to you.
  • Page 47 Government End Users. If the Data supplied by HERE is being acquired by or on behalf of the United States government or any other entity seeking or applying rights similar to those customarily claimed by the United States government, the Data is a "commercial item"...
  • Page 48 Austria:  Bundesamt für Eich- und Vermessungswesen Belgium:  - Distribution & Copyright CIRB Croatia/Cyprus/Estonia/Latvia/Lithuania/Moldova/Poland/Slovenia/Ukraine:  EuroGeographics Denmark: Contains data that is made available by the Danish Geodata Agency (FOT) Retrieved by HERE 01/2014 Finland: Contains data from the National Land Survey of Finland Topographic Database 06/2012. (Terms of Use available at h ttp://www.maanmittauslaitos.fi/en/ NLS_open_data_licence_version1_20120501)
  • Page 49 Contains information copyrighted by  Kartverket, made available in accordance with (http:// creativecommons.org/licenses/by/3.0/no/). Contains data under the Norwegian licence for Open Government data (NLOD) distributed by Norwegian Public Roads Administration (NPRA) Portugal: Source: IgeoE – Portugal Spain: Información geográfica propiedad del CNIG Contains data that is made available by the Generalitat de Catalunya Government in accordance with the terms available at ttp://www.gencat.cat/web/eng/avis_legal.htm)

  • Page 50: Approved Memory Cards

    Approved Memory Cards The following Secure Digital (SD) memory cards have been tested and approved for use in this camera. • Memory cards with an SD Speed Class rating of 6 or faster are recommended for recording movies. When using a memory card with a lower Speed Class rating, movie recording may stop unexpectedly.
  • Page 51 • The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries. • All other trade names mentioned in this manual or the other documentation provided with your Nikon product are the trademarks or registered trademarks of their respective holders. AVC Patent Portfolio License...
  • Page 52 No reproduction in any form of this manual, in whole or in part (except for brief quotation in critical articles or reviews), may be made without written authorization from NIKON CORPORATION. YP5L07(11) 6MN55211-07...
