Installation plan

Tumble dryer

PT 5135 C
PT 7135 C
en - GB
To avoid the risk of accidents or damage to the machine, it is essential to read
operating and installation instructions before installation and commissioning
This prevents both personal injury and damage to the machine.
10 145 320 / 01

Advertisement

Table of Contents
loading

Related Manuals for Miele PT 7135 C

Summary of Contents for Miele PT 7135 C

  • Page 1: Installation Plan

    Installation plan Tumble dryer PT 5135 C PT 7135 C en - GB To avoid the risk of accidents or damage to the machine, it is essential to read operating and installation instructions before installation and commissioning This prevents both personal injury and damage to the machine.
  • Page 2 Legend: Connection optional or required, Connection required depending on model Vented Cooling air Condensate drain hose Equipotential bonding Machine anchors Peak-load connection Electrical connection Box plinth Machine feet, adjustable Open plinth Payment system WTV Washer-dryer stacking kit Payment system connection Communication module Cooling air Air intake...

  • Page 3: Machine Dimensions

    PT 5135/7135 en - GB Machine dimensions 10 145 320 / 01...
  • Page 4 en - GB PT 5135/7135 Installation 10 145 320 / 01...

  • Page 5: Washer-Dryer Stack

    PT 5135/7135 en - GB Washer-dryer stack 10 145 320 / 01...
  • Page 6 en - GB PT 5135/7135 Installation 10 145 320 / 01...
  • Page 7 PT 5135/7135 en - GB Installation 10 145 320 / 01...

  • Page 8: Technical Data

    - GB PT 5135/7135 Technical data PT 5135 C PT 7135 C Drying system Condensation Condensation Drum volume Load capacity Door opening diameter E l e c t r i c a l c o n n e c t i o n ( E L )
  • Page 9 PT 5135/7135 en - GB Technical data PT 5135 C PT 7135 C Standard voltage (FIN only) 2N AC 400 V Frequency Total rated load 3.68 Fuse rating (B trip rating according to EN 60898) 2 x 10 Supply lead min. cross-section mm²...
  • Page 10 Rawl plugs (diameter x length) 8 x 40 8 x 40 Anchoring of Miele plinths   Miele plinth installation (fasteners included) Required anchor points Wood screws according to DIN 571 8 x 65 8 x 65 Rawl plugs (diameter x length)

  • Page 11: Options & Accessories

    PT 5135/7135 en - GB Options / Accessories: Features B o x p l i n t h ( U G ) Box plinth, H 300 mm (UG 5005) Galvanised plinth, stainless-steel sides Box plinth, H 470 mm (UG 5005-47) Galvanised plinth, octoblue stove-finished side panels Box plinth, H 750 mm (UG 5005-75) Galvanised plinth, octoblue stove-finished side panels...
  • Page 12 An appropriate message appears in the instructions in the wiring diagram. Conversion must be performed display. by an authorised agent or a Miele service technician. The heater The programme is resumed automatically when the peak-load system rating must also be properly set.
  • Page 13 Washer-dryer stack A Miele tumble dryer can be stacked on top of the washer-extractor. A "WTV" stacking kit (optional accessory) is required for this. Installation of the stacking kit must be performed by Miele Service or an authorised agent.
