SURROUND SOUND RECEIVER Dimension Control (Use track 1 and 3 from PLII Audio Test CD ver1.0) Step Step ≤-31dB -7.8dB ≤-31dB -20.4dB ≤-31dB ≤-31dB ≤-31dB -11.5dB ≤-31dB -14.0dB ≤-31dB ≤-31dB -19.5dB -11.5dB ≤-31dB ≤-31dB ≤-31dB ≤-31dB ≤-30dB ≤-31dB ≤-31dB AM TUNER SECTION Input level is expressed as the reading in open-circuit of 75-ohm source impedance signal generator Usable sensitivity (999/1000kHz)
SURROUND SOUND RECEIVER DISASSEMBLY INSTRUCTIONS 1. Remove machine screws M 4.0 x 6.0 ( 1 to 6 ) from the side panels. Remove tapping screw 3.0 x 8.5 ( 7 )from the back panel. Refer to Figure No.1. Figure No.1 2.
SURROUND SOUND RECEIVER FM/RDS SECTION - FM mono: 1kHz, 75kHz devi., 60dB/µV - FM stereo: 1kHz, 67.5kHz devi., 60dB/µV Pilot signal 19kHz 7.5kHz devi. OUTPUTS - Connect the non-inductive type resistor of 8 ohms to the all speaker terminals unless otherwise noted. Connection FM SG Stereo mod-...
Page 60
SURROUND SOUND RECEIVER Reference No. Part No. Description U404 3131-3730-0 IC BA7625 2X5CH U410 3131-7690-0 IC BA7623 VIDEO SOP8 ROH VOLUME BOARD PCB-AL020C-VOL VOLUME ASSEMBLY WAFER J207B 2102-031S-004 3 PIN ST. WAFER VOLUME M301 4750-6010-0 ROTART ENCODER NOTE: The components identified by mark are critical for risk of fire and electrical shock.
