1.2.4 Setting Home Position/Sensor Position/Preset
Button
The home position, sensor position and 8 preset buttons can be registered. Preset
buttons (1—4) are registered 1: Upper Left, 2: Upper Right, 3: Lower Left and 4:
Lower Right. These buttons can be changed (see page 20).
• Registered buttons are shown in blue.
• Unregistered buttons are shown in white.
When clicking each button, the image switches to the home/sensor/preset position.
When restarted, the camera takes a home position. If the Lens Position When
Triggered setting is set (see page 61), the camera takes a sensor position after the
pyroelectric infrared sensor detects temperature differences.
Registering Home Position/Sensor Position
1.
Click [Program].
• [Program] switches to [Cancel].
Click [Cancel] to quit without saving
changes.
2.
Pan and tilt the camera to a desired
position.
3.
Click the home position button or the
sensor position button.
4.
Click [Save].
• When finished, "Success!" is
displayed.
• Clicking [Back] takes you back to the
previous page without changing the
settings.
5.
Click [Back].
• The bar switches to the operation
bar.
Home
Position
Pan/Tilt
Program
Sensor
Position
