PORTACOOL CYCLONE
OWNER'S MANUAL
™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the cyclone 3000 and is the answer not in the manual?

Questions and answers

Related Manuals for Portacool cyclone 3000

Summary of Contents for Portacool cyclone 3000

  • Page 1 PORTACOOL CYCLONE OWNER’S MANUAL ™...

  • Page 2: Table Of Contents

    MAINTENANCE AND STORAGE ............page 11 FREQUENTLY ASKED QUESTIONS ..........page 22 STOP DO NOT RETU RN! For questions or comments, please call Portacool Customer Service at 936-598-5651. Visit www.sylvane.com or call (800) 934-9194 to purchase. Contact Port-A-Cool at 1-800-695-2942 for product support.

  • Page 3: Quick Setup Guide

    QUICK SET UP Remove box and palette Position product on level surface Plug into appropriate outlet Fill sump or attach water hose For setup, pads should appear wet before starting the fan. Check the water gauge to monitor water level in tank.The water flow valve on each unit is set at max flow.

  • Page 4: Product Overview

    CYCLONE 3000 OVERVIEW PAC2KCYC01, PAC2KCYC01A Control Panel Adjustable Adjustable Louvers Louvers Water Adjustment Valve Hose Connec- tion Drain Electrical Plug Plug Locking Casters...
  • Page 5 CYCLONE 3200 OVERVIEW PACCYC04, PACCYC04A Control Panel Adjustable Adjustable Louvers Louvers Hose Connection Water Adjustment Valve Drain Locking Plug Electrical Casters Plug...
  • Page 6 CYCLONE 2000 OVERVIEW PACCYC02, PACCYC02A Control Panel Adjustable Louvers Adjustable Louvers Water Electrical Adjustment Plug Valve Drain Plug Locking Hose Casters Connection...
  • Page 7 CYCLONE 2200 OVERVIEW PACCYC03, PACCYC03A Control Panel Adjustable Louvers Adjustable Louvers Water Adjustment Valve Electrical Plug Drain Plug Locking Hose Casters Connection...
  • Page 8 CYCLONE 1000 OVERVIEW PACCYC06 Control Panel Adjustable Louvers Manual Water Fill Recessed Drain Casters Plug Water Hose Electrical Connection Cord...

  • Page 9: Safety Information

    • Never wash the evaporative cooler cabinet with a garden hose; water may harm the motor and electrical system. • If the product is damaged or malfunctions, do not continue to operate it. Refer to the warranty, troubleshooting or FAQ section, call Portacool, LLC, Technical Support at...

  • Page 10: General Operation

    Specifications Each Portacool evaporative cooler has its own set of operational specifications, sizes, weights, voltage frequency, current requirements, etc. Please ask for the specifications for your model from your distributor, check the serial number plate, or visit www.portacool.com for the specifications for your product.
  • Page 11 It is important to ensure that the spray bar is properly adjusted when first starting the water flow in the Portacool evaporative cooler. Increasing the flow using the water flow valve (see Quick Setup on page 2) makes this adjustment.

  • Page 12: Maintenance And Storage

    MAINTENANCE & STORAGE MAINTENANCE 1) Keep the product clean to ensure peak operating performance. 2) The rugged, corrosion-resistant construction ensures low maintenance will be required. However, in dusty or dirty environments, optional filters are available from your distributor or at www.portacoolparts.com. Daily Maintenance The pump should be turned off approximately 15 minutes before the fan is turned off.

  • Page 13: Troubleshooting

    TROUBLESHOOTING The Portacool evaporative cooler consists of three systems — the fan system, the electrical system, and the water system. It is important to determine with which of the systems the problem is associated. Certain problems may be associated with more than one system. A careful check of all systems should be made to fully understand the extent of the problem.

  • Page 14: Troubleshooting

    The following troubleshooting guide is intended to address the most common symptoms which may occur. If you are unable to resolve the issue, please call Technical Support. Turn off all power to the cooler before attempting to troubleshoot any of the following symptoms. SYMPTOM POSSIBLE CAUSES REMEDY...

  • Page 15: Technical Support And Warranty

    If the Equipment and/or its original component parts develop a defect covered by this limited warranty within the applicable time periods described above, the same will be repaired or replaced at Portacool’s option. In the case of a breach of any implied or written warranty relating to the Equipment and/or its component parts, Portacool shall not be liable for any incidental or consequential damages, and the limits of liability against Portacool for any such breach shall not exceed the cost of replacement or repair of the Equipment.
  • Page 16 2. The defective part need to be returned to Portacool, LLC, labeled with the RMA number within 90 days of receipt of replacement parts. 3. The customer / distributor can call Tech Support to get an RMA number to send the defective part back to Portacool, LLC. Once the part is received by Portacool, a replacement part will be sent at no charge.

  • Page 17: Exploded Views

    CYCLONE 1000 PARTS PACCYC06 PACCYC06 Revised 02/24/15 ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION ACCDOOR-C1-714 WATER FILL DOOR PUMP-CYC-3 CYCLONE PUMP -OK4000 ACCFRM-C1-715 FILL DOOR FRAME S-003 5/16 - 18 x1/2” TRUSS HEAD SCREW (2EA) BLOWER-WHL-2CW CYCLONE 2000 BLOWER WHEEL - CW S-007 5/16 - 18 x 3/4 TRUSS HEAD SCREW (16EA) BLWEHSG-C1-7162...
  • Page 18 FLAP TOG-BOOT-01 RUBBER TOGGLE SWITCH BOOT (2) FLOAT-CYC-03 FLOAT VALVE FOR CYCLONE UNITS VALVE-01 PUMP TO SPRAY BAR CONTROL VALVE LOUVERS-CYC-16 CYCLONE 3000 LOUVER W/MESH TUBE-01 PUMP TO SPRAY BAR TUBING MOTOR-013-07 1/3 HP - 2SPD MOTOR TUBE-03 SIGHT TUBE...
  • Page 19 CYCLONE 2000 PARTS PACCYC02 Revised 02/04/2015 ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION PACCYC02A BLOWER-02 BLOWER HOUSING - CYCLONE2000 MOTOR-016-01 CYCLONE2000 - 2SPD MOTOR BLOWER-WHL-2CW CYCLONE2000 BLOWER WHEEL (PART 1) PAC-PLB-14 INLET HOSE ADAPTER BLOWER-WHL-3CCW CYCLONE2000 BLOWER WHEEL (PART 2) PAD6019/22 KUUL PAD SET FOR CYCLONE2000 BONNET-06...
  • Page 20 CYCLONE 2200 PARTS ITEM# PART # DESCRIPTION ITEM# PART # DESCRIPTION PACCYC03 Revised 02/25/15 BLOWER-02 BLOWER HOUSING - CYCLONE2000 MOTOR-016-01 CYCLONE2000 - 2SPD MOTOR PACCYC03A BLOWER-WHL-2CW CYCLONE2000 BLOWER WHEEL (PART 1) PAC-PLB-14 INLET HOSE ADAPTER for CYCLONE2000 BLOWER-WHL-3CCW CYCLONE2000 BLOWER WHEEL (PART 2) PAD6019/22 KUUL PAD SET FOR CYCLONE2200 BONNET-06...
  • Page 21 TOG-BOOT-01 RUBBER TOGGLE SWITCH BOOT (2) FLOAT-CYC-03 FLOAT VALVE FOR CYCLONE UNITS TUBE-01 PUMP TO SPRAY BAR TUBING LOUVERS-CYC-16 CYCLONE 3000 LOUVER W/MESH TUBE-03 SIGHT TUBE MOTOR-013-07B 1/3 HP - 2SPD MOTOR (BO) VALVE-01 PUMP TO SPRAY BAR CONTROL VALVE...

  • Page 22: Wiring Diagram

    WIRING DIAGRAM...

  • Page 23: Frequently Asked Questions

    UNPLEASANT ODOR! directly from Portacool Parts/Technical Support department. You may also visit www. A. The pads, located in the back of your Portacool product, have never been wet portacoolparts.com to order online. before. The resin in the pads will emit an odor the first time you wet them that lasts Q.
  • Page 24 1-936-598-5651 • 1-888-COOLAID SUPPORT@PORTACOOL.COM VISIT PORTACOOL.COM MANR0002 OR CALL 1-936-598-5651 FOR MORE INFORMATION Portacool, LLC • Manufacturer of Portacool™ portable evaporative coolers and KÜÜL® Pads evaporative media 709 Southview Circle • Center, Texas 75935 • 936-598-5651 • www.portacool.com • www.kuulpads.com...

This manual is also suitable for:

Cyclone 2000Cyclone 3200Cyclone 2200Cyclone 1000
