Lock your bike.
NOTE: For bikes with a slack head tube angle, long-travel suspension fork, and a large frame size/long wheelbase, the
FrontLoader's lock cable may not reach all the way around the down tube of the frame. For the vast majority of bikes, this
is NOT an issue. If your cable doesn't reach, then adjust the front wheel hoop to the 29" wheel. The 29" wheel setting is
also useful for bikes with higher volume tires 2.35 and up.

CHECK REAR WHEEL.

•
Tighten the strap if needed.
1033644B-5/18
INSTALL OPTIONAL LOCK CORES (sold separately).
If you have purchased locks, follow your lock core instructions to
install. To purchase lock cores (Yakima Part Number 8007202) (2-pack)
visit www.yakima.com or visit your local Yakima dealer.
Follow the
instructions that
came with your lock
cores to remove the
lock plug and install
your lock cores.
Follow the instructions that
came with your lock cores
to remove the lock plug and
install your lock cores.
Access the built-in lock
cable on either side of the
small hoop. Store cable
here when not in use.

BEFORE DRIVING AWAY

PERIODICALLY CHECK THAT KNOBS
•
ARE ADEqUATELY TIGHTENED.
NOTE: Front knob
must be in horizontal
position to lock.
Thread the cable
through your bike
frame, and insert silver
post into lock housing.
Turn the key
counter-clockwise
to lock.
HORIZONTAL
CHECK THAT FRONT
•
WHEEL IS SECURE.
Continued on next page...
