Mechanical PARTS LIST
AJ-SD255PE/D255MC
Note:
1. *Be sure to make your orders of replacement parts according to this list.
2. Unless otherwise specified, all resistors are in OHMS, K=1,000 OHMS,
all capacitors are in MICROFARADS (µF), P=µµF.
3. The P.C. Board untils marked with " " shown below the main assembled parts.
4. The parts marked with E on the exploded view show the electric parts.
5. IMPORTANT SAFETY NOTICE
Components identified with the mark
of these components, use only the same type.
6. The marking (RTL) indicates the retention time is limited for this item.
After the diacontinuation of this assembly in production, it will no longer be available.
Mechanical Chassis Assembly(1)................................................................................ MPL-2
Mechanical Chassis Assembly(2)................................................................................ MPL-4
Sub Chassis Assembly................................................................................................ MPL-6
Front Loading Assembly.............................................................................................. MPL-8
Casing Assembly......................................................................................................... MPL-10
Front Jack Assembly ................................................................................................... MPL-12
Chassis & Frame Assembly ........................................................................................ MPL-14
Packing Parts Assembly.............................................................................................. MPL-16
Eectrical Replacement Parts List
Panasonic Broadcast
have the special characteristics for safety. When replacing any
CONTENTS
................................................................................
MPL-16
Advertisement
Table of Contents
Related Manuals for Panasonic AJ-D255MC
Summary of Contents for Panasonic AJ-D255MC
-
Page 1: Table Of Contents
Mechanical PARTS LIST AJ-SD255PE/D255MC Note: 1. *Be sure to make your orders of replacement parts according to this list. 2. Unless otherwise specified, all resistors are in OHMS, K=1,000 OHMS, all capacitors are in MICROFARADS (µF), P=µµF. 3. The P.C. Board untils marked with " " shown below the main assembled parts. 4. -
Page 2: Mechanical Chassis Assembly(1)
MECHANICAL CHASSIS ASSEMBLY (1) MPL-2... - Page 3 MECHANICAL CHASSIS ASSEMBLY(1) Ref.No. Part No. Part Name & DescriptionPcs VEM0815 S REEL MOTOR A ASS'Y VEM0816 T REEL MOTOR A ASS'Y VMS5923 REEL OUTER RAIL VMS5924 REEL INNER RAIL VXL2589 S BASE DRIVE ARM ASS'Y VMB2944 CHARGE SPRING VXL2590 T BASE DRIVE ARM ASS'Y VXA5625 SLIDE ROD ASS'Y...
-
Page 4: Mechanical Chassis Assembly(2)
MECHANICAL CHASSIS ASSEMBLY (2) 14-1 14-3 14-2 16-1 24-1 PRT-4 13-1... - Page 5 MECHANICAL CHASSIS ASSEMBLY(2) Ref.No. Part No. Part Name & DescriptionPcs VXA5554 A/C HEAD BASE (1) ASS'Y VED0519 A/C HEAD VXA6067 A/C HEAD BASE (2) ASS'Y VMB2935 A/C HEAD HIGHT SPRING VEG1498 CYLINDER UNIT VXA5715C EMERGENCY SHAFT HOLDER ASS' 1 VEM0645C LOADING MOTOR (1) ASS'Y L9AABBEB0007 PINCH SOLENOID VXA8117C...
-
Page 6: Sub Chassis Assembly
SUB CHASSIS ASSEMBLY MPL-6... -
Page 7: Sub Chassis Assembly
SUB CHASSIS ASSEMBLY Ref.No. Part No. Part Name & DescriptionPcs VXL2656 MIC DRIVE ARM A ASS'Y VMB3018 MIC DRIVE SPRING VXL2657 MIC DRIVE ARM (B) ASS'Y VDB1429 MIC DRIVE ARM BOSS VXL2613 REEL DRIVE ARM ASS'Y VDG1192 REEL DRIVE CAM GEAR VDG1193 REEL DRIVE WORM WHEEL VEM0827C... -
Page 8: Cassette Compartment Assembly
CASSETTE COMPARTMENT ASSEMBLY MPL-8... - Page 9 CASSETTE COMPARTMENT ASSEMBLY Ref.No. Part No. Part Name & DescriptionPcs VXA7347 FRONT LOADING ASS'Y VMS5865 MAIN SHAFT VMA0T36 TOP PLATE VMA0M72 FRONT GUIDE 1 ASS'Y VMB3075 M GUIDE SPRING VML3191 M GUIDE RIGHT LEVER VML3192 M FRONT GUIDE VML3190 M GUIDE LEFT LEVER VML3397 CASSETTE PROTECT PLATE VMZ3233...
-
Page 10: Casing Assembly
CASING ASSEMBLY MPL-10... - Page 11 CASING ASSEMBLY Ref.No. Part No. Part Name & DescriptionPcs VYM0203 TOP PLATE ASS'Y VMT0967 DUST PROOF CUSHION (C) VMP8359 TOP PANEL ANGLE VMX2582 WASHER VMZ2325 TOP PANEL BARRIER VMX2930 SCREW GUIDE SPACER VMX3466 SPACER VHD0274 SCREW VMT1641 GASKET VMT1635 GASKET VYF3008 BOTTOM PLATE VMG1197...
-
Page 12: Front Jack Assembly
FRONT JACK ASSEMBLY 6-11 6-11 6-11 6-10 6-10 6-11 MPL-12... - Page 13 VYP9058 FRONT PANEL (1) ASS'Y VGU9679 KNOB HOLDER VGU9680 KNOB HOLDER B VGU9682 OPERATION BUTTON A VGU9683 OPERATION BUTTON B RGB0116-S PANASONIC BADGE VGB0637 DVC BADGE VGU8377 EJECT KNOB VYQ2807 CASSETTE GUIDE ASS'Y VMB3564 CASSETTE GUIDE SPRING 6-10 VMB3565 CAM SPRING...
- Page 14 SHASSIS & FRAME ASSEMBLY IMPORTANT SAFETY NOTICE: COMPONENTS IDENTIFIED WITH THE MARK FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE SAME TYPE. 22-1 22-3 22-6 15-1 MPL-14 HAVE THE SPECIAL CHARACTERISTICS 22-5 22-2 14-1 14-2 15-2 15-3 22-4...
- Page 15 SHASSIS & FRAME ASSEMBLY Ref.No. Part No. Part Name & DescriptionPcs VGF0762 DUST PROOF SHEET (B) VGU8051 POWER BUTTON VJF0004 WIRE SADDLE VJF0456 BINDER VJF0861 BUSH VJF1158 CLAMPER VMP8126 SIDE FRAME R VMP8128 BACK FRAME VMP8129 FRONT FRAME VMP8132 MECHA EXT FIX ANGLE VMP8133 PCB FIX ANGLE VSC5658...
-
Page 16: Packing Parts Assembly
PACKING PARTS ASSEMBLY IMPORTANT SAFETY NOTICE: COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE SAME TYPE. E Only E Only MC Only MPL-16... -
Page 17: Packing Parts Assembly
VXF0173 EMERGENCY EJECT ASS'Y Remarks Ref.No. Part No. Part Name & DescriptionPcs 1 FOR AJ-SD255P 1 FOR AJ-SD255E 1 FOR AJ-D255MC 1 FOR AJ-SD255P 1 FOR AJ-SD255E 1 FOR AJ-D255MC 1 FOR AJ-SD255P 1 FOR AJ-SD255E 1 FOR AJ-D255MC 1 FOR AJ-SD255E ONLY...
